- Page 1 NEED HELP? AIYI Technologies SCAN OR CLICK HERE TO CONTACT US Air-Met Scientific www.airmet.com.au Nanjing AIYI Technologies Co., ltd. Control Panel Operator ’s Manual Operator’s Manual JUDD/JUDD-S AG200/Anr-N /Anr-S Version：2.6.19.01 Version: 1.1.1901...
- Page 2 Dear customer： Glad to have your trust and support on AIYI Technologies, we will provide you best product and service in return. As an ISO certified manufacturer. AIYI Technologies has been focus on safety and environment many years, we provide you gas & dust detector and systems. The design and manufacture of product is strictly follow the international standard and company regulations, and each product get a normative QC control to ensure the best quality for you.
- Page 3 Copyright Statement Copyright© 2017 Nanjing AIYI Technologies Co., ltd. All Rights Reserved. This document property Nanjing AIYI Technologies Co., ltd. neither reproduced nor disclosed to a third party without a written authorization. is the registered trademark of Nanjing AIYI Technologies Co., ltd. The others inside of the document belongs to other companies.
- Page 4 Attention: please read the manual carefully before connecting and operating your device. Contact Us Nanjing AIYI Technologies Co., Ltd. Address: Building 13, No. 1318 Qingshuiting East Road, Jiangning District, Nanjing 210000, Jiangsu, China Tel：0086-25-87756351 Fax：0086-25-87787362 Web：www.aiyitec.com Email：sales@autequ.com...
-
Page 5: Table Of Contents
CONTENT Chapter 1 Product Introduction 1.1 Brief Introduction………………………… …… ……………………………………01 1.2 Description……………………………………………………………………………02 1.3 Specifications…………………………………………………………………………04 Chapter 2 Installation 2.1 Packing list……………………………………………………………………………05 2.2 Cautions………………………………………… ………… …………………………05 2.3 Installation ……………………………………………………………………………05 2.4 Wiring…………………………………………………………………………………06 2.5 Power-on test …………………………………………………………………………07 Chapter 3 Operations and Maintenance 3.1 Menu …………………………………………………… ……... -
Page 6: Chapter 1 Product Introduction
AIYI Technologies Chapter 1 Product Introduction 1.1 Brief introduction JUDD/JUDD-S series control panel (hereinafter referred to as control panel) is a new generation product independently developed by Nanjing AIYI Technologies Co., Ltd., which is specially used for matching toxic gas detectors. -
Page 7: Description
AIYI Technologies Judd Judd-S Wall-mounted single- Cabinet type multi- channel panel is access channel panel, the to connect a single number of channels detector can be customized from 1 to 100. It is recommended to use a large number of Judd detectors. - Page 8 Scroll up menu, increase value, mute Scroll down menus, reduce values, DOWN view alarm records MENU Enter menu, setting confirmation Dimension Note: The JUDD series controllers are modular in design and can be freely configured according different requirements, operation modes are the same.
-
Page 9: Specifications
AIYI Technologies 1.3. Specifications Description Specifications JUDD JUDD-S Function ● Channels >16 ● Suitable detector Electrochemical, infrared, PID ● ● Electric Power supply 220VAC ● ● Power consumption Single modular≤1W ● ● Signal input 4-20mA ● ● Signal output 4-20mA ●... -
Page 10: Chapter 2 Installation
AIYI Technologies Chapter 2 Installation 2.1. Packing list 2.2. Cautions The controller is non-explosion-proof and is only used in safe area such as duty rooms and operating ▎ rooms. Do not use it in hazardous areas. Please select the corresponding wiring method according to the input signal. ▎... -
Page 11: Wiring
AIYI Technologies Multi-channel controller installation diagram 2.4. Wiring Be sure to turn off the power before wiring. ▎ Open the panel ▎ Unscrew the bottom locking port of the panel and introduce the cable into the controller. ▎ According to the terminal port identification, make sure the wiring between the detectors and panel in one ▎... -
Page 12: Power-On Test
AIYI Technologies Multi-channel terminal block Wiring 4-20mA 2.5 Power-on test Please confirm that the wires and terminals are safe before power-on. ▎ The wall-mounted multi-channel panel requires a key to open and switch the power to the "on" . ▎ It starts work and POWER light of the panel is always on when supplied by 220VAC power. -
Page 13: Chapter 3 Operations And Maintenance
AIYI Technologies Chapter 3 Operations and Maintenance 3.1. Menu In the normal monitoring state, the main interface displays information such as the concentration value, concentration bar, and measurement unit. 3.2. Mute When the control panel alarms, press the “UP” button to mute. 3.3. -
Page 14: Alarm Set
AIYI Technologies Record delete Press "MENU" to enter ▎ Short press "MENU" to adjust position ▎ Press "UP" or "DOWN" to adjust the value ▎ After setting, long press “MENU” to clear the ▎ historical data before setting date and return to the previous menu. -
Page 15: Language Set
AIYI Technologies 3.7. Language set Language set Press "MENU" to enter ▎ Press "UP" or "DOWN" to select ▎ Press “MENU” to confirm the language change and ▎ return to the main menu. 3.8. Save & exit Save & exit Press "MENU"... - Page 16 SCIENTIFIC INNOVATION SPECIALIZED DEDICATED Nanjing AIYI Technologies Co., Ltd. Address: Building 13, No. 1318 Qingshuiting East Road, Jiangning District, Nanjing 210000, Jiangsu, China Tel: 0086-25-87756351 Fax: 0086-25-87787362 Web: www.aiyitec.com Email: sales@autequ.com...
