Summary of Contents for AE GTQ-Anr-A
- Page 1 NEED HELP? SCAN OR CLICK HERE TO CONTACT US Air-Met Scientific www.airmet.com.au Nanjing AIYI Technologies Co., ltd. Fixed Gas Detector Operator’s Manual Operator’s Manual GTQ-Anr-A/ GTQ-Anr-D/ AG210/ AG211 AG200 Anr-N /Anr-S Version : 1.2.2001 Version: 1.1 1901...
- Page 2 Dear customer Glad to have your trust and support on AIYI Technologies, we will provide you best product and service in return. As an ISO certified manufacturer. AIYI Technologies has been focus on safety and environment many years, we provide you gas & dust detector and systems. The design and manufacture of product is strictly follow the international standard and company regulations, and each product get a normative QC control to ensure the best quality for you.
- Page 3 Copyright Statement Copyright© 2017 Nanjing AIYI Technologies Co., ltd. All Rights Reserved. This document property Nanjing AIYI Technologies Co., ltd. neither reproduced nor disclosed to a third party without a written authorization. is the registered trademark of Nanjing AIYI Technologies Co., ltd. The others inside of the document belongs to other companies.
- Page 4 Note: To avoid possible personal injury and equipment damage before and during the installation of the equipment, please read the relevant contents of this manual carefully. Contact Us Nanjing AIYI Technologies Co., Ltd. Address: Building 13, No. 1318 Qingshuiting East Road, Jiangning District, Nanjing 210000, Jiangsu, China Tel +86-25-87756351 Fax +86-25-87787362...
-
Page 5: Table Of Contents
CONTENT Chapter 1: Product Introduction 1.1 Brief introduction 1.2 Appearance structure 1.3 Specifications Chapter 2: Installation 2.1 Packing list 2.2 Installation cautions 2.3 Installation preparation 2.4 Location selection 2.5 Installation 2.6 Wiring 2.7 Power-on test Chapter 3: Operation and Maintenance 3.1 Power on 3.2 Main menu 3.3 Alarm setting... -
Page 6: Chapter 1: Product Introduction
1 1. Brief introduction AE’S GTQ-Anr-A GTQ-Anr-D AG210 AG211 gas detector are suitable for detecting the content of combustible and toxic gases such as combustible gas, oxygen, and toxic gases in explosion hazard areas. The product adopts the integrated design of sound and light alarm, which can effectively warn of various gas leakage hazards;... -
Page 7: Appearance Structure
AIYI Technologies GBZ 2.1-2007 "Occupational Exposure Limits for Hazardous Factors in the Workplace Part 1: Chemical Hazardous ▎ Factors" JJG365-2008 "Electrochemical Oxygen Analyzer" ▎ JJG 693-2011 "Combustible gas detection alarm" ▎ JJG 915-2008 "Carbon Monoxide Detection Alarm" ▎ JJG 695-2003 "Hydrogen Sulfide Gas Detector"... - Page 8 AIYI Technologies Screen and indicator Infrared Receive infrared remote signal Power Normal on, the green light is off Fault Normally off, yellow light is Normally off, and the red light Alarm1 is always on when the alarm-1 Normally off, the red light is Alarm2 always on when the alarm-2 1 Task...
- Page 9 AIYI Technologies Remote control Move up or number plus Move down or decrease the number Left Right Confirm or enter the menu MUTE mute BACK Exit Gas detector dimensions(mm) Dimensions of gas detector with GARY sound-light alarm (mm)
-
Page 10: Specifications
AIYI Technologies Description Specifications GTQ-Anr-A GTQ-Anr-D AG210 AG211 Gas detected Combustible gas Combustion catalytic Electrochemical, PID, Infrared Toxic gas Detection Measure range 0-100%LEL See Appendix T90≤30S See Appendix T90≤30/60/180S Accuracy 3%FS Repeatability 3%FS Electric 1.3 Specifications Power supply 18-28VDC(Standard24VDC) 2.5W... - Page 11 AIYI Technologies Specifications Description GTQ-Anr-A GTQ-Anr-D AG210 AG211 Structure ADC12Aluminum alloy + 304L stainless steel Body Material Conduit Port NPT1/2 Weight About 1.45kg Dimensions 157*133*79mm(H*W*D) Note: ● means it has this function,-means it does not have this function. *Refer to attached table 1 for detailed detection gas.
-
Page 12: Chapter 2: Installation
AIYI Technologies Chapter 2: Installation 2 1. Packing list Please check and count the goods before installation to confirm that the appearance of the packing box is complete. After unpacking, check the installation accessories and check whether they are complete. If there is any loss, please contact our company as soon as possible. Items not included in the packing list may be used during the installation process, please purchase by yourself. -
Page 13: Installation Preparation
Hazardous Locations of the People's Republic of China"; the wiring should be avoided in parallel with the power cable, and the interference affects the communication. The recommended cable is as follows: For long-distance transmission, replace the cable or install a repeater or other device according to the actual situation. Model AG210 AG211 GTQ-Anr-A GTQ-Anr-D Single output 4~20mA RS485 4~20mA... -
Page 14: Installation
AIYI Technologies the source of the leak and at the highest point in the plant where it is prone to build up. Installation height selection: ▎ When it is heavier than air: the height of the detector should be higher than the floor (floor surface) 0.3-0.6m; when it is lighter than air;... -
Page 15: Wiring
AIYI Technologies Unscrew the upper cover of the transmitter counterclockwise. ▎ Unscrew the fixing screws on both sides of the display module, buckle the upper and lower recessed parts of the panel with ▎ your fingers, and slowly pull out the circuit module upwards. Note that there is a cable link between the circuit module and the sensor, and do not use violence to operate. - Page 16 AIYI Technologies Terminals 24V power positive pole for detector 4~20mA signal output 24V power negative pole for detector RS485 signal (only for setting use) Low alarm relay contact output High alarm relay contact output Fault relay contact output Note: 4~20mA signal output and RS485 output can only choose one, pay attention to distinguish the actual Controller Detector Controller...
-
Page 17: Power-On Test
AIYI Technologies Grounded Principle Time Principle Time Combustible Combustion 0.5h Electrochemical 0.5h catalytic Toxic gas Electrochemical Electrochemical Infrared 0.5h The above time is for reference only, please consult the manufacturer for details. 2 7. Power-on test The first power-on should be stable for not less than 20 minutes. After the power is turned on, the detector ▎... -
Page 18: Chapter 3 Operation And Maintenance
AIYI Technologies Chapter 3 Operation and Maintenance 3 1. Power on Self-check Version No. Countdown Main interface After power-on, the monitor light on the transmitter panel is always on, and the screen displays the self-check, version number, and countdown (warm-up) 45s before entering the main interface. 3 2. -
Page 19: Calibration Preparation
AIYI Technologies Alarm-1 Value setting Back Enter the alarm setting menu. At this time, the screen displays the current alarm value. Press the "Up" and ▎ "Down" keys to adjust the value, and press the "Left" and "Right" keys to adjust the number of digits. After setting, press "OK"... -
Page 20: Span Calibration
AIYI Technologies 3 5. Zero calibration In order to ensure accuracy, it is recommended to use pure nitrogen for zero calibration. ▎ Slowly open the gas cylinder valve, adjust the flow meter knob to 0.5L/min, ventilate and wait for a stable ▎... -
Page 21: Factory Setting
AIYI Technologies 3 8. Factory setting password Decimal point unit Range 4mA correction return 20mA correction Press the "OK" key to enter, enter the password (four "up" keys) and then enter the factory setting menu ▎ (automatically return to the main menu if an operation error occurs). The factory setting includes 6 options including decimal point, unit, range, 4mA correction, 20mA correction, and return. -
Page 22: Save And Back
AIYI Technologies 3 10.Save and Exit Save Main interface After all settings are completed, select save in the main menu and press "OK" to save and exit ▎ 3 11. Maintenance In order to ensure the performance of the transmitter, calibration should be carried out regularly. The calibration ▎... -
Page 23: Appendix 1 Gas Detector Selection Table
AIYI Technologies Chapter IV Attached Table 4 1. Appendix 1: Gas detector selection table Measure range principle AG210 AG211 GTQ-Anr-A GTQ-Anr-D Combustible EX Catalytic combustion 0 100%LEL Oxygen 0-30%VOL 0-25%VOL Electrochemical Carbon 0-1000μmol/mol Electrochemical Hydrogen 0-100μmol/mol Electrochemical Chlorine 0-10μmol/mol Electrochemical Sulfur 0-20μmol/mol... -
Page 24: Appendix 2 Voc Gas Selection Table
AIYI Technologies 4 2. Appendix 2: VOC gas selection table... - Page 25 AIYI Technologies Note: This table only lists some VOC gases, please consult the manufacturer for other unlisted gases.
-
Page 26: Appendix 3 Recommended Calibration Gas Table
AIYI Technologies 4 3. Appendix 3: Recommended Calibration gas table Measure Range Standard gas Concentration 100%LEL 60%LEL 30%VOL 20.9%VOL 5%VOL 3%VOL 1000μmol/mol 700μmol/mol 500μmol/mol 300μmol/mol 1000μmol/mol 700μmol/mol I-C4H8 20μmol/mol 15μmol/mol 1000μmol/mol 700μmol/mol 100μmol/mol 80μmol/mol 100μmol/mol 60μmol/mol 30μmol/mol 60μmol/mol 10μmol/mol 10μmol/mol 20μmol/mol 15μmol/mol 20μmol/mol... -
Page 27: Appendix 4 Trouble-Shooting
AIYI Technologies 4 4 Appendix 4: Trouble-shooting FAULTS REASONS SOLUTIONS Wrong wiring Re-wiring Wrong power supply Check power supply No output signal Circuit fault Return to factory The sensor cable is broken Return to factory Sensor failure Replace sensor modular Lower readings Need calibration Re-calibration... - Page 28 AIYI Technologies SCIENTIFIC INNOVATION SPECIALIZED DEDICATED Nanjing AIYI Technologies Co., Ltd. Address: Building 13, No. 1318 Qingshuiting East Road, Jiangning District, Nanjing 210000, Jiangsu, China Tel: 0086-25-87756351 Fax: 0086-25-87787362 Web: www.aiyitec.com Email: sales@autequ.com...
