COLOR TELEVISION
USER'S GUIDE
IMPORTANT NOTE TO THE CUSTOMER
In the spaces below, enter the model and serial number of your television (locat-
ed at the rear of the television cabinet). Staple your sales receipt or invoice to
the inside cover of this guide. Keep this user's guide in a convenient place for
future reference. Keep the carton and original packaging for future use.
Serial Number
Illustration of AV-27F802 and RM-C301G
For models:
AV-36F802
AV-36F702
AV-32F802
AV-32F702
AV-27F802
AV-27F702
Model Number
LCT0821-001D-A
0901-TN-FAA-JIM
