lynx System Developers VeriLight Quick Start Manual

Verify that your VeriLight system contains the components pictured below.
If not, or if you need additional help, please call: USA 978 556 9780 or email
Item Description
VeriLight
(optional)
10' (3 meter)
100' (30 meter)
Ethernet Cable
Items Not Included
•
Windows PC running one of the following software:
o
FinishLynx with Network ComPort (NCP) plug-in, or
o
FieldLynx with Scoreboard plug-in, or
o
FieldLynx Lite
•
(Recommended) PoE+ Gigabit Hub/Switch

Introduction

The following guide will walk you through the VeriLight setup, configuration, and operations to be used as a foul
indicator light with VeriLynx or FieldLynx, or as a Ready to Start light with FinishLynx.
•
FinishLynx version 12.21 or later is required.
•
VeriLight default IP = 192.168.0.99 (port 10000)
•
VeriLight default password = Lynx

Hardware Setup

a. Place the VeriLight on the ground in a location where it will be seen by officials, athletes and/or spectators.
b. Plug the Power-over-Ethernet power supply into the power source or UPS battery backup.
c. Connect an Ethernet cable from the PC to the Hub/Switch or the
d. Connect a long Ethernet cable to the
open panel) and either the Hub/Switch or the
VeriLight gets Power-over-Ethernet (POE). The power supply is not required if used with a PoE+
NOTE:
switch.
www.facebook.com/finishlynx
VeriLight
Quick Start Guide
support@finishlynx.com.
ID
VLight
C10BT-10
C10BT-100
port on the back of the VeriLight (requires Philips screwdriver to
RJ45
port on the VeriLight power supply.
Out
L S
YNX YSTEM
Item Description
(optional)
Power Injector
for Power-
over-Ethernet
(optional)
Power-over-
Ethernet
Power Supply
Connector
port of the VeriLight power supply.
In
D , I
EVELOPERS NC
ID
IDL-PoE
Included with
IDL-PoE
www.finishlynx.com
.
