lapesa GEISER INOX GX6 D90 Installation And Usage Instructions

lapesa GEISER INOX GX6 D90 Installation And Usage Instructions

Double-walled tanks in stainless steel domestic hot water calorifiers
Hide thumbs

Advertisement

Quick Links

Download this manual
Réservoir en acier inoxydable double paroi /
Réservoir en acier inoxydable double paroi /
de production et de stockage d'eau chaude sanitaire
de production et de stockage d'eau chaude sanitaire
Installation verticale
Installation verticale
Modèles /
Modèles /
:
:
Manuel d’installation et d’utilisation
Manuel d’installation et d’utilisation
pour l’installateur et l’utilisateur /
pour l’installateur et l’utilisateur /
GX6 D90....600
GX6 D90....600
GX6 DEC90....600
GX6 DEC90....600
GX6 S90....600
GX6 S90....600

Advertisement

loading
Need help?

Need help?

Do you have a question about the GEISER INOX GX6 D90 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for lapesa GEISER INOX GX6 D90

Summary of Contents for lapesa GEISER INOX GX6 D90

  • Page 1 Réservoir en acier inoxydable double paroi / Réservoir en acier inoxydable double paroi / de production et de stockage d'eau chaude sanitaire de production et de stockage d'eau chaude sanitaire Installation verticale Installation verticale GX6 D90..600 GX6 D90..600 Modèles / Modèles / GX6 DEC90..600 GX6 DEC90..600...
  • Page 3 Installer le réservoir dans un endroit protégé des gelées et des intempéries. En cas de remplacement des composants, ces éléments seront toujours des pièces de rechange originales LAPESA. Toute défaillance dans l’installation peut causer des dommages et entraîner des risques.
  • Page 5 Modèle double paroi / avec option de chauffage électrique / Inspection hole D.H.W. storage tank Heating body External lining Cover top and bottom Thermal insulation Control panel Hole for electric resistance / Air vent 1/8” female (supplied) / Probe for sensors Charactéristiques techniques/ Connexion/ Dimensions GX6 D90 GX6 D130 GX6 D190 GX6 D260 GX6 D400 GX6 D600 / Total capacity...
  • Page 6 Modèle double paroi / avec chauffage électrique / Inspection hole D.H.W. storage tank Heating body External lining Cover top and bottom Thermal insulation Control panel Cover hole for electric resistance Air vent 1/8” female (supplied) Electric resistance Probe for sensors Charactéristiques techniques/ Connexion/ Dimensions GX6 DEC90 GX6 DEC130 GX6 DEC190 GX6 DEC260 GX6 DEC400 GX6 DEC600 / Total capacity...
  • Page 7 Modèle double paroi / Inspection hole D.H.W. storage tank Heating body External lining Cover top and bottom Thermal insulation Inspection hole / Air vent 1/8” female (supplied) / Probe for sensors Charactéristiques techniques/ Connexion/ Dimensions GX6 S90 GX6 S130 GX6 S190 GX6 S260 GX6 S400 GX6 S600 / Total capacity / D.H.W.

  • Page 8: Installation Hydraulique

    Installation hydraulique Exemples d’schémas d'installation / Si un circuit de bouclage ECS n’est pas raccordé à la In the event that no recirculation circuit is installed on connexion ‘Z’ du réservoir, installer un purgeur ou the "Z" tank connection, a stainless steel plug or purger bouchon en acier inoxydable.
  • Page 9 Periodic cleaning of the DHW tank must be carried out, independently from any thermal treatments demanded for the Legionella bacterium elimination. To perform this cleaning, double-wall LAPESA tanks have a hole for inspection and top cleanliness by means of which, and after previous withdraw of their connection plate (inlet of cold water and DHW's outlet), there is access to cleaning the secondary tank (DHW).

  • Page 10: Règles Générales

    Installation hydraulique Règles Générales Exemple de groupe de sécurité sanitaire / Coldwater inlet Orifice control shutoff and one-way valve Heater connection Safety valve and manual emptying Emptying and discharge orifice One-way valve Isolating valve The safety system should be included directly in to the domestic water installation.
  • Page 11 150 mg/l. or more and in installations where recirculation pipes are made of copper All GEISER-INOX storage heaters can be equipped with the LAPESA Correx-up permanent cathode protection system which is totally automatic and maintenance free.
  • Page 12 Chauffage électrique Résistances électriques de chauffage Cold water inlet Hot water outlet Recirculation Primary inlet Primary return Control panel Electric heating resitance hole Cover Electric heating resistance The “D” models are supplied with a “K” type control panel and flanged housing to allow an electric heating element to be fitted.
  • Page 13 Lapesa Control panel, is FORBIDDEN, since mesure où son utilisation incorrecte pourrait produire un its incorrect use could cause an excess of heat at the heating réchauffement incontrolé...

  • Page 15: Conditions De Garantie

    Conditions de garantie 10 - 11 - 12 - 13 - 14 -...

  • Page 16: Terms Of Warranty

    Terms of warranty ONE: TWO: 10.- 11.- 12.- 13.- 14.- THREE: FOUR: FIVE: SIX: SEVEN: EIGHT: NINE: Lapesa Grupo Empresarial S.L., reserves the right to make technical changes in its products without notice...
