- Page 1 You weld. We protect. FEX-PRO Operating Manual AVAILABLE IN THE UK EXCLUSIVELY FROM 822038 rev1...
-
Page 2: Warranty Registration
Important: To gain the maximum warranty period you must register your machine on installation. See terms and conditions. Photocopy and post or fax to: ABICOR BINZEL UK Ltd. Binzel House, Mill Lane, Winwick Quay, Warrington, Cheshire. WA2 8UA T: +44 (0)1925 653944 F: +44 (0)1925 654861 E: service@binzel-abicor.co.uk - 2 -... -
Page 3: Table Of Contents
CONTENTS Page Warranty Registration Consumables & Spares EC Declaration of Conformity Warnings Routine Maintenance Installing the Machine Control System Filtration & Changing Filters Interfacing Power Troubleshooting Terms & Conditions ATTENTION! CONSUMABLES & SPARES ATTENTION! Filters Should always be ordered in advance of requirement from Purex or your authorised local agent. Replacement filter part numbers are shown on the original packaging, please ensure you make a note here for future reference: Pre-filter Part Numbers... -
Page 4: Ec Declaration Of Conformity
Purex International Limited QWP House, Island Drive Capitol Park Thorne Doncaster DN8 5UE United Kingdom Apparatus WEL300/FEX-PRO Technical Construction File Purex Engineering File - Issue 3 Date 4th November 2016 Standards Applied EN 60335-1:2012+A1:2014 EN 60335-2-2:2010+A1:2013 FCC CFR 47: PART 15: B: 2015... -
Page 5: Warnings
WARNINGS The use of filters other than those supplied by Purex will invalidate any warranty, service contract and any LEV certification ! • Always isolate the system from the mains power supply before removing the machine cover. • Disposable gloves and a dust mask are supplied with replacement filters/pre-filters. These should be worn when removing filters and disposed of with the used filter in the bag which is also provided. -
Page 6: Installing The Machine
INSTALLING THE MACHINE ENSURE ALL FILTERS ARE FITTED CORRECTLY PRIOR TO USING THE MACHINE Positioning the machine The machine should be as near to the process as possible with space allowed for the following access: • Internal maintenance • Control panel •... -
Page 7: Control System
CONTROL SYSTEM Set up Ensure the fume extractor is connected to the correct electrical supply. Also ensure that the fume extractor is properly connected to the process. To switch the machine ON/OFF • Place black multi toggle switch into position 1 (4) •... -
Page 8: Filtration & Changing Filters
FILTRATION & CHANGING FILTERS ENSURE ALL FILTERS ARE FITTED CORRECTLY PRIOR TO USING THE MACHINE. ENSURE THE AIRFLOW ARROW ON THE FILTER POINTS THE CORRECT WAY. Filtration The machine employs a multi-stage filtration process. Contaminated air enters the machine from the process and is passed through a pre-filter which removes larger particles. -
Page 9: Interfacing
FILTRATION & CHANGING FILTERS Important note: Always clean the pre-filter (unless recently cleaned) and restart the machine. If the alert continues, change the pre-filter (unless recently changed). If alert continues change the main filter and restart the machine. Changing filters Always wear the appropriate PPE when coming into contact with used filters or cleaning the pre-filter. -
Page 10: Troubleshooting
TROUBLESHOOTING Red LED Flashing The pre-filter and/or main filters may be blocked. One or all of these filters may be blocked. Unless recently changed you should first clean then replace the pre-filter and re-start the machine. If the red LED (or audible alarm) does not switch off you should then replace the main filter. -
Page 11: Terms & Conditions
TERMS & CONDITIONS 1. Contract 6.5 Purex does not exclude or limit its liability in negligence for death or personal injury, or for fraud or wilful 1.1 All quotations given, orders accepted and contracts entered into by Purex International Limited (“Purex”) with default, or otherwise to the extent that any exclusion or limitation of its liability is void, prohibited or any person (“Purchaser”) for supply of goods (“Goods”), or for services (“Services”) are subject to these unenforceable by law. - Page 12 FEX-PRO FUME EXTRACTION SYSTEM Available in the UK EXCLUSIVELY from: ABICOR BINZEL UK LTD. BINZEL HOUSE, MILL LANE, WINWICK QUAY, WARRNGTON CHESHIRE, WA2 8UA T: +44 (0)1925 653944 E: sales@binzel-abicor.co.uk You weld. We protect.
