Monosem MONOSHOX ridetech RIDEPRO-E5 Manual

Air control system
Hide thumbs

Advertisement

Quick Links

Download this manual
®
M ON OSH OX
A I R
CON T ROL SY ST EM M A N U A L
RI DEPRO-E5 V ERSI ON
V
2023

Advertisement

loading
Need help?

Need help?

Do you have a question about the MONOSHOX ridetech RIDEPRO-E5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Monosem MONOSHOX ridetech RIDEPRO-E5

  • Page 1 ® M ON OSH OX A I R CON T ROL SY ST EM M A N U A L RI DEPRO-E5 V ERSI ON 2023...
  • Page 2 RIDEPRO-E5 Basic Controls CONTROL PANEL BASED CONTROL: AIRBAG PRESSURE AIRBAG PRESSURE RIGHT WING LEFT WING AIRBAG PRESSURE INCREASE DECREASE SUPPLY TANK PRESSURE AIRBAG PRESSURE AIRBAG PRESSURE AIRBAG PRESSURE LEFT CENTER RIGHT CENTER PRE-SETS #1, #2, #3...
  • Page 3 RIDEPRO-E5 Basic Controls MOBILE APP BASED CONTROL: AIRBAG PRESSURE AIRBAG PRESSURE RIGHT WING LEFT WING AIRBAG PRESSURE AIRBAG PRESSURE SUPPLY TANK RIGHT CENTER LEFT CENTER PRESSURE AIRBAG PRESSURE INCREASE DECREASE AIRBAG PRESSURE PRE-SETS #1, #2, #3...
  • Page 4 DISPLAY OPERATION: INFLATE & DEFLATE BUTTONS: To inflate a section of air springs simply press and hold the corresponding UP arrow until desired pressure is reached. To deflate a section of air springs simply press and hold the corresponding DOWN arrow until pressure is reached. The corresponding section of air springs will inflate OR deflate until the button is released.
  • Page 5 MONOS HOX AIR AIRBAG PRESSURE ADDITIONAL (psi) DOWNFORCE (lbs) NOTE: This is additional downforce added by increasing the air pressure in the airbag. It is added to the average 250 pounds of unit weight and 45 pounds of downforce from the Monoshox absorber pre-charge.

  • Page 6: Plumbing Diagram

    Plumbing Diagram MONOSEM PLANTER APPLICATION Dual Compressor System Right Left Wing Wing Solenoid Right Valve Left Center Center Check Valve Check Valve Compressor Compressor Tank...

  • Page 7: Wiring Diagram

    Wiring Diagram MONOSEM PLANTER APPLICATION NOT USED SWITCHED +12VDC YELLOW 15 Amp Fuse +12VDC 30 Amp Fuse 30 Amp Fuse BLACK - TO BATTERY GROUND 20 Amp Fuse BLUE Storage Tank +12VDC GREY Secondary Compressor BLACK Air Pressure Sensors 20 Amp Fuse...
  • Page 8 Mobile App Connection You can pair your smart phone by pushing the button on the ECU. The Mobile App only works when the RidePRO e5 is powered up! You will need to download the Ridetech RidePro E5 app from your app store. Make sure all app permissions are turned on. Power up the E5 by turning the vehicle key on.
  • Page 9 Installation Guide & Operation Manual Thank you for choosing a Ridetech air suspension control system. We are committed to providing the best experience possible throughout the process of getting your car on air. Our commitment doesn’t end with your purchase, in fact, it has only begun. This guide should provide you with the information you need to properly install and set-up your suspension control system.
  • Page 10 Installing an AirPod Remove the negative battery cable before beginning installation. STOP MOUNT THE MAIN UNIT: 1- Mount the base at to the vehicle surface (do not bend the base) 2- Secure the base with self-tapping screws or bolts. 3 - If optional cover is used, secure the cover to the airpod base using the supplied screws. CONNECT AIR LINES: 1 - Airline cuts must be straight and clean - use a razor blade or tubing Required airline hookup.

  • Page 11: Control Panel Features

    Control Panel Features Display Left Front Right Front Lock Air Pressure Air Pressure Left Front Left Front Right Front Right Front In ate De ate De ate In ate Back Plate Display Preset #3 Brightness Mode Preset #2 Preset Position Icon Preset #1 Tank...
  • Page 12 App Control Panel Features System Control This system can be controlled 2 ways; Display & Mobile App (SYSTEM DOES NOT REQUIRE CELL SERVICE TO WORK). This section will cover all control options. MAIN CONTROL SCREEN The Main Control Screen displays information about the pneumatic suspension system including: •...
  • Page 13 System Control Options & Icons IF YOU ARE RUNNING A 2 COMPRESSOR SYSTEM, THE 2ND COMPRESSOR WILL NEED TO BE TURNED ON IN THE SETUP MENU! PAGE 10 WILL SHOW YOU WHERE TO TURN IT ON. YOU MAY GET ERROR #143 BEFORE YOU TURN COMPRESSOR #2 ON.

  • Page 14: Control Panel

    Control Panel - MENU BUTTON - CONTROL PANEL ONLY The Menu provides the ability to adjust system parameters to meet an individual’s tastes, as well as displaying useful information. One may exit the Menu at any time by pressing either the “Home” button or “Menu” button. Home Menu Button...
  • Page 15 Control Panel & Mobile App Guide Back Home - MOBILE APP ONLY Just like the main control panel, the Menu provides the ability to adjust system parameters to meet an individual’s tastes, as well as displaying useful information. One may exit the Menu at any time by pressing the “Home” button. Back Home - MOBILE APP ONLY...
  • Page 16 Control Panel & Mobile App Guide - CONTROL PANEL & MOBILE APP The Menu Set Points screen displays the saved Preset set points of each corner of the vehicle, as well as the current values for each corner. If the system is running in air pressure only mode, it will automatically display pressure (psi). If the system is running in air pressure and height sensor mode (with optional Ride Height Sensors), it will automatically display level sensor voltage.
  • Page 17 Control Panel & Mobile App Guide - CONTROL PANEL & MOBILE APP The Menu Diagnostics screen can be used to diagnose problems/issues, speci cally with the sensors during installation and/or the vehicle charging system. Each corner can be manually in ated and de ated via the buttons surrounding the read out screen.
  • Page 18 Control Panel & Mobile App Guide - CONTROL PANEL ONLY The Menu Display screen allows you to control the brightness settings of the day and night modes. It also allows you to change the orientation of the control panel. BRIGHTNESS ADJUSTMENT The Day and Night settings are adjustable independently of each other.
  • Page 19 Control Panel & Mobile App Guide The Menu Wireless screen allows you to pair your smart phone to the RidePro E5 ECU. You can pair your smart phone through the main display or by pushing the button on the ECU. The Mobile App only works when the RidePRO e5 is powered up! You will need to download the Ridetech RidePro E5 app from your app store.
  • Page 20 Control Panel & Mobile App Guide - ANDROID MOBILE APP ONLY Control System Renaming: The name of the system can be changed in the app. This can be useful if you have multiple vehicles with the RidePRO e5 system. THE SYSTEM HAS TO BE POWERED UP WITH THE APP PAIRED TO THE SYSTEM!! THE SYSTEM CAN NOT BE RENAMED USING THE MAIN CONTROL PANEL!! Step 2: A Box will pop up that has the current name of the Step 1: Open the Setup Menu and select the word RIDEPRO.
  • Page 21 Control Panel & Mobile App Guide - IPHONE MOBILE APP ONLY Control System Renaming: The name of the system can be changed in the app. This can be useful if you have multiple vehicles with the RidePRO e5 system. THE SYSTEM HAS TO BE POWERED UP WITH THE APP PAIRED TO THE SYSTEM!! THE SYSTEM CAN NOT BE RENAMED USING THE MAIN CONTROL PANEL!! Step 2: A Box will pop up that is blank along with the Step 1: Open the Setup Menu and select the word RIDEPRO.
  • Page 22 Control Panel & Mobile App Guide The Menu Error History screen displays any errors that have occurred, as well as the ignition cycle during which they occurred. You can see what power cycle the system is currently on by going to the info screen.
  • Page 23 Calibration DO NOT RERUN CALIBRATION ON A SYSTEM THAT HAS BEEN PREVIOUSLY CALIBRATED. IF YOU ARE HAVING A PROBLEM WITH THE SYSTEM, TRYING TO RECALIBRATE WILL MAKE IT DIFFICULT TO DIAGNOSE THE PROBLEM. Calibration: !ATTENTION!!!!! The vehicle MUST be running in order to calibrate this system! Only turning the key on will NOT work! Hooking it to a battery charger will NOT work! The vehicle must be running!

  • Page 24: Troubleshooting Guide

    Troubleshooting Guide RidePRO e5 will not turn on. Diagnosis : No LED light on top of ECU Solution : Check RED wire for constant 12 volts, YELLOW wire for 12 volts with key ON, and the 2 fuses in ground wires from ECU.
  • Page 25 Troubleshooting Guide Control panel switches do not activate the correct air spring. Diagnosis : Ex: LF switch actuates the RF air spring. Solution : Swap airline at the valve block. Presets work, but does not achieve target. Diagnosis A: Air tank is too small. Air spring pressure equalizes with tank pressure before achieving preset pressure/height. Solution A: Reprogram #1 preset for the highest psi that allows the suspension to bottom out.
  • Page 26 Troubleshooting Bluetooth Is the LED lit up on top of the ECU? If not, the system is not powering up. Check power and ground. Also, check the 2 ground fuses in the compressor harness. Are you trying to connect the app using the Bluetooth menu? The phone has to be connected to the ECU through the App.

  • Page 27: Tips And Tricks

    Tips & Tricks DO NOT RERUN CALIBRATION ON A SYSTEM THAT HAS BEEN PREVIOUSLY CALIBRATED. IF YOU ARE HAVING A PROBLEM WITH THE SYSTEM, TRYING TO RECALIBRATE WILL MAKE IT DIFFICULT TO DIAGNOSE THE PROBLEM. When in ating and de ating the vehicle manually, push both buttons for one end of the vehicle at the same time. Explanation: When you do one corner at a time, it is harder to get the vehicle level at the height you are trying to achieve.
  • Page 28 Control System Error Codes PRESSURE SENSOR RELATED ERRORS ERROR CODES AND TEXT POSSIBLE ISSUE SOLUTIONS ERROR 11: LF PRESSURE LOW VOLTAGE Sensor is disconnected or sensor has failed. Is the sensor harness plugged into the ECU? ERROR 21: RF PRESSURE LOW VOLTAGE ERROR 31: LR PRESSURE LOW VOLTAGE ERROR 41: RR PRESSURE LOW VOLTAGE Is the sensor harness plugged into the sensor?
  • Page 29 Control System Error Codes COMPRESSOR & SYSTEM RELATED ERRORS ERROR CODE & TEXT POSSIBLE ISSUE SOLUTIONS Is the valve compressor plugged into the ECU? Check wiring and fuse. ERROR 141: COMPRESSOR #1 NOT CONNECTED Compressor overheated and thermaled out. Is the harness plugged into the compressor? The compressor has a thermal switch that will ERROR 151: COMPRESSOR #2 NOT CONNECTED Is the compressor connected directly to the...
  • Page 30 Plumbing Diagram MONOSEM PLANTER APPLICATION Dual Compressor System Right Left Wing Wing Solenoid Right Valve Left Center Center Check Valve Check Valve Compressor Compressor Tank...
  • Page 31 Wiring Diagram MONOSEM PLANTER APPLICATION NOT USED SWITCHED +12VDC YELLOW 15 Amp Fuse +12VDC 30 Amp Fuse 30 Amp Fuse BLACK - TO BATTERY GROUND 20 Amp Fuse BLUE Storage Tank +12VDC GREY Secondary Compressor BLACK Air Pressure Sensors 20 Amp Fuse...
