ILLEGEAR FLOW V2 User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Please read all instructions before using this liquid cooling module
and always keep this module on hand.
1
Please ensure that you have received all items as
listed below before using it.
1. Liquid Cooling
2. Water tube with magnetic connector on each end ×1
3. DC to DC power cord ×1
4. Fast draining tool ×1
5. HEX KEY ×1 (Remove the side case to use)
6. O-Ring ×6
CAUTION: This product is intended to be supplied by Power
Adapter, output rated 19.5Vdc, 16.9A or 20Vdc, 14A.
CAUTION: We conduct outgoing quality control (oqc) with
distilled water for each Liquid Cooling Module ensuring a
closed loop circuit where no leakage may occur.
CAUTION : Any changes or modifications not expressly
approved by the party responsible for compliance may void
the user's authority to operate this device.
CAUTION: Using unauthorized extension cables/tubes will
invalidate your warranty.
This unit can be operated at an ambient temperature of
max. 35°C (95°F). Do not subject it to temperatures below
5°C (41°F) or above 35°C (95°F).
ILLEGEAR FLOW V2 User Guide
Module
×1

Advertisement

loading
Need help?

Need help?

Do you have a question about the FLOW V2 and is the answer not in the manual?

Questions and answers

Summary of Contents for ILLEGEAR FLOW V2

  • Page 1 ILLEGEAR FLOW V2 User Guide Please read all instructions before using this liquid cooling module and always keep this module on hand. Please ensure that you have received all items as listed below before using it. 1. Liquid Cooling ×1 Module 2.
  • Page 2 ILLEGEAR FLOW Assemble 1. Read the User Manual before operating ILLEGEAR FLOW. 2. Check if the connectors are firmly attached to the Water Tubes. 3. Gently attach the black connectors on the Water Tubes to the Make sure it is attached firmly and avoid liquid cooling module.
  • Page 3 3. Connect the power adapter to the main unit's DC port (Note: Do not plug in to the main power yet). 4. Connect ILLEGEAR FLOW's DC cable to the laptop's DC port (Note: Do not plug in to the main power yet).
  • Page 4 Note : the water tubes is parallel when connected to Make sure the laptop. Please make sure the connectors are connected correctly and sturdy. Note: Please pay attention to the following points if you are using the water tubes No pressing Please remove connectors with your No folding hands.
  • Page 5 Inject water into the ILLEGEAR FLOW 1. Open the lid on ILLEGEAR FLOW. Distilled water is recommended. 2. After filling distilled water, long press the power button located on the Liquid Cooling for 4-5 seconds. The power button will module glow in purple indicating entering “Water Injection Mode”.
  • Page 6 Operate your ILLEGEAR FLOW 1. Plug in the laptop power cord to the power socket. on the laptop and make sure the Bluetooth is turned on as well. Power 3. Press the power button on the Liquid Cooling module and the LED indicator will start glowing.
  • Page 7 Draining liquidl In order to properly release/drain the water from ILLEGEAR FLOW, please follow the below steps: 1. Shutdown the Laptop and Power off the module. 2. Open the lid and remove it from the top. 3. First disconnect the "water tube" from the module.
  • Page 8 Left side view Product Overview Right side view Front side view Back side view Power Button / LED Indicator* DC Port (IN) DC Port (OUT) Top side view Drain Pipes Vents Water tank meter Top Lid *(Colors for BT/Pump injection water/ lightbar) 1.
  • Page 9 2.When using in sub-zero temperature, please drain ILLEGEAR FLOW the water completely after every usage, to prevent the pipes from frost crack. 3.Using distilled water is recommended. 4.Coolants are not recommended as majority coolants that are sold/found in the...
  • Page 10 Note. 1.Due to different water quality, mineral water has higher chance if water scaling. 2.Pleas do not connect to power before (Only turn on injecting liquid the power/ connect to power if it is filled with water). 3.IF there is abnormal noise coming from the pump, this could be the result of air bubbles still trapped inside the tubes, Trouble shooting steps are as above.
  • Page 11 水冷散热器 简易用户手册 使用 散热器前请仔细阅读本使用说明和安全须知， 水冷 请妥善保管本使用说明。 为了保护您的权益，在您使用前，请确认以下配件的完备性： 1. 水冷机×1 2. 磁性连接器水管×1 3. 水冷机电源输出线×1 4. 泄水阀×1 5. 內6角扳手×1 (拆除侧面机壳使用) 6. O-Ring×6 注意：本产品由电源适配器供电 output rated 19.5Vdc, 16.9A 或 20Vdc, 14A. 注意：产品出厂前进行100％的试水检验，确保回路滴水不漏。如收到 水冷机里面有残留的水，属于正常现象。 注意：未经设备受让人明确许可的任何更改或修改都 可能使用户丧失操作设备的权限。 注意：使用未经授权使用的电缆扩展将使保修保护失效。 该设备可以在最高环境温度下运行。 35°C（95°F）。 请勿使其温度低于5°C（41°F）或高于35°C（95°F）。...
  • Page 12 准备你的水冷机： 1. 通读用户手册。 2. 检查水管两头是否连接牢固。 3. 两根水管黑色接口通过磁鐵吸附原理方式与水冷机出水孔连接，尽量保持 连接好以后两条水管不出现扭曲。 4. 将连接好的水冷设备放置于水平桌面。...
  • Page 13 水冷机连接电脑： 1. 将电脑放置于桌面，依照机型,部分机种需打开电脑水冷接口止水软塞。 2. 水管金属接口以磁动吸附方式连接至电脑，听到轻微的“咔哒”声表明已正确连接 （注：水管保持自然弯曲状态，切勿绷直)。 3. 将电源适配器插入水冷机DC接口（注：切勿先通电)。 4. 水冷机电源输出线连接至水冷机DC接口与电脑DC接口（注：切勿先通电)。 DC INPUT: 280 Watts (20V/14A) 330 Watts (19.5V/16.9A) 连接笔记型电脑DC接口 以”平行”推入方式接上(详解)
  • Page 14 详解: 水管接头需完全平行，请确实稳固插入笔记型电脑 或是水冷机的插孔内。 注意: 使用水管有以下注意事项。 勿压管 勿折管 如欲移除水管请手持接头平行退出 勿拉扯水管...
  • Page 15 水冷机注水 : 1. 旋转打开注水孔塞，向水冷机注水，建議使用蒸馏水。 2. 注水完毕后启动注水模式，长按水冷机电源键4~5秒，电源灯呈现紫灯闪烁, 开 始进入注水模式，结束后灯光熄灭。 3. 注水过程中时刻关注水位，第一次注水需加到最高水位线（MAX）以上（正常使用 情况下，快塞接头不会漏水，注水时无需担心)。 4. 防止倾倒，第一次注满水后，盖上注水口软塞，确认各接口处无漏水。 注意： 1. 水位检视窗上有標示最高以及最低水位的位置。 2. 不推荐使用冷却液，冷却液有使机器劣化的风险。 对齐指示线,打开水冷盖 对齐指示线,关闭水冷盖 注入蒸馏水...
  • Page 16 使用水冷机 : 1. 电脑接通电源。 2. 电脑开机，确认蓝牙已打开。 3. 按下水冷机电源按钮，水冷机的LED灯会亮起。 4. 打开电竞控制中心软件，选择”Liquid Cooling System Control”模块。 5. 选择”Device”后点击“Connect”按钮后水冷机与电脑蓝牙连接并正常工作 (风扇及水循环工作)。(蓝牙就绪：恒亮 (蓝灯)) 6. 水冷机运行5分钟左右后，检查各接口处是否出现漏水现象，如果有，需停止水循 环，重新接好各接口。 7. 水冷机正常运行后水位会有所下降，请二次注水。(补充:注意事项请参照4-3) 停止使用水冷机 : 1. 停止使用水冷机前，在电竞控制中心【性能】-【Liquid Cooling System Control】 下找到“Disconnect”按钮,并点击，使蓝牙连接断开。 2. 待风扇转动停止后，关闭水冷机电源。 拆卸水管： 当水冷机使用结束，欲拆卸水管，请遵守以下操作步骤: 1. 先将水冷机的电源关掉。 2. 将连接笔电端的水冷头，”平行”退出笔电。(勿拉扯水管) 注意：为减少因热引起的伤害或设备过热的可能性。 ， ，...
  • Page 17 换水或携带时： 1.将水冷机或笔记型电脑关机 2.取下水冷机顶盖 3.将水管从水冷机端拔下 4.将泄水阀 面插上水冷机端排出水冷机水槽内的水分。 5.待水冷机水槽内的水分排完，将泄水阀从水冷机出入水口拔下 6.将泄水阀 面插上水管一端，另一端插入笔记型电脑后端進行排水。 (当排出的水量开始减少时，轻轻提起设备并轻微摇晃以确保完全排干。) 注意： 1.为防止水冷机及水管产生水垢，请定期换水。 2.拔插水管前后都需检查是否有水漏出，并及时清理。...
  • Page 18 左侧视图/右侧视图 产品概览： 前视图/后侧视图 电源按钮+LED 指示燈 DC 插孔(输入) DC 插孔(输出) 上视图 水冷接口 散热孔 水位检视窗 入水孔盖 *（蓝牙/泵注水/灯条的颜色） 1. 注水：闪烁（紫色） 2. 蓝牙搜索：闪烁 (蓝灯) 3. 蓝牙就绪：恒亮 (蓝灯) 4. 液冷系统错误：闪烁（水流异常_橙色）...
  • Page 19 简易故障排除 1. 若出现漏水现象，请立即将设备断电，并确认水冷机各接口是否安装到位，各接 口需拧紧以确保管路密封。 2. 设备组装完毕并开机后，使用设备前请确认笔记本电脑与水冷机的蓝牙是否正 常连接，若蓝牙无法连接/水冷机未正常工作。 2.1 确认电源是否连接。 2.2 请确认电竞控制中心是否安装。 2.3 确认电脑蓝牙是否打开。 2.4 上若都确认无问题，可尝试将笔记本及水冷机重新启动，以重新匹配。 3. 当水泵异常时, 水冷机电源键会橘灯闪烁自动关泵，使用者检查确认无异常后，需手动 按下电源开关，重新开机连线。 4. 若水冷机有异音时, 原因可能为水路中空气残留，排解方式。 4.1 将外部水管与笔记本脱离, 使用双头排水塞插入快塞接头泄水2秒。 4.2 压水冷机左侧出水管，按压 放松 连续几次。 4.3往左方或后方倾斜机器, 倾斜后维持3秒在摆正。 需注意水箱注水口需上盖, 避免水漏出。 设备保养： 1.水冷机水槽内液体需定期更换，更换方式详见操作步骤四及步骤七跟八。 2.零下气温使用环境时，建议在使用水冷机后，将液体排放干净，以防管路冻裂。 3.推荐使用蒸馏水，因矿物质水易造成水垢，依照建议使用。 4.市售冷却液有使机器劣化的风险, 请不要任意使用。 警告： 1.因不同水质特性不同，建议使用蒸馏水进行加注。...

  • Page 20: Regulations Information

    Regulations Infor mation ¤ CE compliance This device is classed as a information technicalequipment (ITE) in class B and is intended for use in living room and office. The CE-mark approves the conformity by the EU-guidelines: - EMC Directive 2014/30/EU, - Low Voltage Directive 2014/35/EU, - RF Directive 2014/53/EU FCC Infor mation...
  • Page 21 RF Exposure War ning This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
