Service Manual
Specifications
(Information in brackets [ ] refers to model 26´´)
Power Source:
Power Consumption
Stand-by Power Consumption: 0.9W
Aerial Impedance:
Receiving System:
Receiving Channels:
Operating Conditions:
220-240V AC, 50Hz
112W [64W]
75Ω unbalanced, Coaxial Type
PAL-I/H, B/G, D/K
SECAM B/G, D/K, L/L'
PAL-525/60 (AV only)
M.NTSC (AV only)
NTSC (AV only)
VHF E2-E12
VHF A-H (ITALY)
VHF R3-R5
UHF E21-E69
CATV S1-S10 (M1-M10)
CATV S21-S41 (Hyperband)
0°C ÷ 35°C
Temperature:
Humidity: 20% ÷ 80% RH (non condensing)
Colour LCD Television
GLP24 Chassis
VHF H1-H2 (ITALY)
VHF R1-R2
VHF R6-R12
CATV (S01-S05)
CATV S11-S20 (U1-U10)
ORDER No. PCZ0905093CE
TX-L32C10P
TX-L32C10PS
TX-L26C10P
TX-L26C10PS
© Panasonic Corporation 2009.
Unauthorized copying and
distribution is a violation of law.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TX-L32C10P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Panasonic TX-L32C10P

  • Page 1 VHF R6-R12 UHF E21-E69 CATV (S01-S05) CATV S1-S10 (M1-M10) CATV S11-S20 (U1-U10) CATV S21-S41 (Hyperband) 0°C ÷ 35°C Operating Conditions: Temperature: Humidity: 20% ÷ 80% RH (non condensing) © Panasonic Corporation 2009. Unauthorized copying and distribution is a violation of law.
  • Page 2 Intermediate Frequency: Video/Audio Video 38.9MHz, 33.9MHz Audio 33.4MHz (B/G), 33.16MHz (A2) 33.05MHz (NICAM B/G, D/K, L’) 32.4MHz (D/K), 32.66MHz (CZ STEREO) 40.4MHz (L’), 39.75MHz (L’ NICAM) Colour 34.47MHz (PAL) 34.5MHz, 34.65MHz (SECAM) 38.3MHz, 38.15MHz (SECAM L’) Terminals: AV1 IN Video (21 pin) 1V p-p 75Ω Audio (21 pin) 500mV rms 10kΩ...
  • Page 3: Table Of Contents

    CONTENTS SAFETY PRECAUTIONS ................4 GENERAL GUIDE LINES..............4 TOUCH – CURRENT CHECK.............. 4 PREVENTION OF ELECTROSTATIC DISCHARGE (ESD) TO ELECTROSTATICALLY SENSITIVE (ES) DEVICES ......5 ABOUT LEAD FREE SOLDER (PBF)............6 SUGGESTED PB FREE SOLDER............6 APPLICABLE SIGNALS................7 SERVICE HINTS ..................
  • Page 4: Safety Precautions

    Safety Precautions General Guide Lines When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed.
  • Page 5: Prevention Of Electrostatic Discharge (Esd)

    Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor "chip"...
  • Page 6: About Lead Free Solder (Pbf)

    About lead free solder (PbF) Note: Lead is listed as (Pb) in the periodic table of elements. In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder. The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu). That is Tin (Sn), Silver (Ag) and Copper (Cu) although other types are available.
  • Page 7: Applicable Signals

    Applicable Signals Component (Y, Pb, Pr), HDMI Signal name COMPONENT HDMI 525 (480) / 60i 525 (480) / 60p 625 (576) / 50i 625 (576) / 50p 750 (720) / 60p 750 (720) / 50p 1,125 (1,080) / 60i 1,125 (1,080) / 50i Note: •...
  • Page 8: Service Hints

    Service Hints How to remove the backcover Remove the 19 fixing screws. (see Fig.5) SCREWS SCREWS How to remove the Pedestal assembly Fig.5 Lay the main unit face down. (see Fig.6) Fig.6 Remove the 4 fixing screws and the pedestal assembly. (see Fig.7) SCREWS Fig.7...
  • Page 9: Chassis Board Layout

    Chassis Board Layout POWER UNIT A-BOARD V-BOARD Board Name Function A-Board Tuner,VCTP,HDMI, AV Terminal, Speaker out, Side AV Connector Power Unit Power Supply, Main Input V-Board Remote Receiver, Bats, R/G LED Location of Lead Wiring To find the Part Number of required wire in Replacement Parts List click on the wire name in red box. [ 26´´] A20-P3 [ 32´´]...
  • Page 10: Setting Inspection

    Setting Inspection Voltage Confirmation Confirm the following voltages: A board TP No. Voltage TP2765 5.6V +/- 0.25V SUB_ TNR_6V TP2770 5.6V +/- 0.25V TP2766 TV_SOS TP5481 INVERTER_SOS TP2761 P17V TP2777 17V +/- 1V SUB_F_12V TP2782 12V +/- 1V INV_ON TP2759 2.85V +/- 2%...
  • Page 11: Self-Check

    Self-check is used to automatically check the bus lines and hexadecimal code of the TV set. To enter Self-Check mode, keep pressing the down (-/v) button on the TV set and press the STATUS button on the remote control. To exit Self Check, switch off the TV set at the power button. TX-L32C10P/PS TX-L26C10P/PS Panasonic 2009LCD Panasonic 2009LCD SW V1.01...
  • Page 12: Service Mode

    Service MODE How to enter Service 1 • Set the Bass to maximum position, set the Treble to minimum position then keep pressing the INDEX button on the remote control and press the down button (-/v) on the TV set, this will place the TV set into the Service Mode 1. Key Command •...
  • Page 13: Adjustment Method

    Adjustment Method Sub-Contrast/White Balance Adjustment Instrument Name Connect to Remarks Remote controller Correlation can be also taken by LCD WB meter (Minolta CS-1000A equivalent) CA-210 or equivalent Comunication jig Computer for external control Procedure Remarks Let the panel standfor more than 3 hours at more than 20 °C.
  • Page 14: Wiring Diagram

    Wiring diagram...
  • Page 17 HP_SENSE PANEL_OFF MAIN_SENSE_MUTE ALL_OFF_DET MAIN_MUTE_IC 5V6_SW_ON HP_MUTE_IC HP_MUTE HP_MUTE 5V6_SW_ON ALL_OFF_DET MAIN_MUTE SDA3V3 HP_MUTE_IC SCL3V3 EAROM_VCC_OFF MAIN_MUTE MAIN_MUTE_IC AUDIO_MUTE MAIN_SENSE_MUTE 5V6_SW_ON AV2_FBL SWITCH_HOLD_ON AV2_QLINK AV2 _SLOW SDA3V3 SCL3V3 16 AV1 AV1_QLINK AV1_SLOW CEC_P1 SCL_P1 SDA_P1 +5V_HDMI_P1 HPDT_5V_P1 CEC_P0 SCL_P0 SDA_P0 +5V_HDMI_P0 HPDT_5V_P0 5V_SIG...
  • Page 18: Parts Location

    Parts Location NOTE: The numbers on the exploded view below refer to the exploded view section of the Replacement Parts List.
  • Page 19 NOTE: The numbers on the exploded view below refer to the exploded view section of the Replacement Parts List. Difference for 26´´...
  • Page 20: Replacement Parts List

    Replacement Parts List Important Safety Notice Components Identified by mark have special characteristics important for safety. * When replacing any of these components, use only manufacturers specified parts. In case of ordering these spare parts, please always add the complete Model-Type number to your order. RTL (Retention Time Limited) Note: The marking (RTL) indicates that the Retention Time is Limited for this item.
  • Page 21 Cct Ref Parts Number Description Cct Ref Parts Number Description D3877 MAZ81800ML DIODE Q3202 B1ADCE000023 TRANSISTOR D3878 MAZ80820ML DIODE Q3204 BC847B TRANSISTOR D3879 MAZ81300HL ZENER DIODE Q3205 BC847B TRANSISTOR D3880 MA2J11100L DIODE Q3803 B1DHDC000028 TRANSISTOR D3881 MA2J11100L DIODE Q3804 BC847B TRANSISTOR D3882 MA2J11100L...
  • Page 22 Cct Ref Parts Number Description Cct Ref Parts Number Description L1724 J0JHC0000078 COIL R267 D0GB104JA041 0.1W 100K Ω L1725 J0JHC0000078 COIL R268 D0GB104JA041 0.1W 100K Ω L2350A J0JHC0000078 COIL R273 ERJ3GEYJ223V S.M.CARB 0.1W 22K Ω L3051 J0JCC0000241 INDUCTOR R274 ERJ3GEY0R00 0.1W 0 Ω...
  • Page 23 Cct Ref Parts Number Description Cct Ref Parts Number Description R1505 ERJ3GEYJ123 0.1W 12K Ω R2352 ERJ3GEYJ681V 0.1W 680 Ω R1506 ERJ3GEYJ123 0.1W 12K Ω R2353 D0GB101JA041 0.1W 100 Ω R1507 ERJ8GEYJ750 0.25W 75 Ω R2354 D0GB101JA041 0.1W 100 Ω R1508 ERJ3GEY0R00 0.1W...
  • Page 24 Cct Ref Parts Number Description Cct Ref Parts Number Description R3700 ERJ6GEYJ393 S.M.CARB 0.1W 39K Ω R5005 ERJ3GEYJ472 0.1W 4K7 Ω R3701 ERJ6GEYJ393 S.M.CARB 0.1W 39K Ω R5006 ERJ3GEYJ472 0.1W 4K7 Ω R3702 ERJ6GEYJ184 S.M.CARB 0.1W 180K Ω R5008 ERJ3GEYJ220 0.1W 22 Ω...
  • Page 25 Cct Ref Parts Number Description Cct Ref Parts Number Description R5113 ERJ3GEYJ682 0.1W 6K8 Ω C1517 F1H1H102A970 S.M.CAP R5114 ERJ3GEYJ682 0.1W 6K8 Ω C1518 F1H1E104A129 S.M.CAP 100nF R5117 ERJ3GEYJ472 0.1W 4K7 Ω C1519 F1H1E104A129 S.M.CAP 100nF R5118 ERJ3GEYJ472 0.1W 4K7 Ω C1520 F1H1H102A970 S.M.CAP...
  • Page 26 Cct Ref Parts Number Description Cct Ref Parts Number Description C2355 F2A1C470A824 ELECT 47µF C5009 ECJ2FB0J106M S.M.CAP 6.3V 10µF C2356 F1H1A1050032 S.M.CAP 1000nF C5010 F1H1E104A129 S.M.CAP 100nF C2357 F1H1H102A219 CERAMIC C5011 F1H1E104A129 S.M.CAP 100nF C2358 F1H1H102A219 CERAMIC C5012 F1H1E104A129 S.M.CAP 100nF C2359 F1H1A1050032...
  • Page 27 100nF TBM0E1969 MODEL LABEL C5087 F1H1H150A971 S.M.CAP 15pF N0AC4GJ00009 P UNIT C5088 F1H1H150A971 S.M.CAP 15pF TBMA294 PANASONIC BADGE TERMINALS AND LINKS TBL0E0103 PEDESTAL ASSY TTP0E0095 SIDE AV BRACKET K1KA04B00273 4P CONNECTOR EAS12S19A SPEAKER UNIT K1KA30AA0250 30P CONNECTOR TKZ0EG5003 VESA METAL...
  • Page 28 LCD BOTTOM MTG L5EDD8Q00048 LCD PANEL TKZ0EA5010 MASK BRACKET BOTTOM TKZ0EA5004 MASK BRACKET SIDE TBM0E1971 MODEL LABEL N0AC4GJ00007 P UNIT TBMA293 PANASONIC BADGE TBL0E0103 PEDESTAL ASSY TTP0E0088 SIDE AV BRACKET EAS16S12A SPEAKER UNIT TXFKZ010PKA VESA METAL ASSY MISCELLANEOUS COMPONENTS TKP0E40703 IR/LED WINDOW...
  • Page 29: Schematic Diagrams

    Schematic Diagrams IMPORTANT SAFETY NOTICE Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacturers' specified parts. NOTE RESISTOR All resistors are carbon ¼W resistor, unless marked otherwise. Unit of resistance is OHM (Ω) (k=1,000, M=1,000,000) CAPACITORS All capacitors are ceramic 50V unless marked otherwise.
  • Page 36: Conductor Views

    Conductor Views A-BOARD TNP0EA014 - TOP IC’S Q1231 IC1120 Q1232 IC1220 Q1721 IC1500 Q3204 IC1501 Q3803 IC2350 Q3804 IC250 Q3805 IC3801 Q3813 IC3806 Q3820 IC3808 Q3821 IC3809 Q3822 IC3812 Q3823 IC3813 Q3824 IC3862 Q3825 IC5001 Q3826 IC5002 Q3827 IC5003 Q3828 Q3829 TRAN’S Q3831...
  • Page 37 A-BOARD TNP0EA014 – BOTTOM TRAN’S Q1130 Q123 Q254 Q272 Q276 Q277 Q3201 Q3202 Q3205 Q5001 Q5004 Q5005 Q5012...
  • Page 38 V-BOARD TNP8EV101 - TOP IC’S RM2500 1A SN2500 1A TRAN’S Q2500 Q2501 Q2504 DIODE’S D2500...
