Feel Design

User Guide

MEDIAGATE NX HD

Table of Contents

Need help?

Do you have a question about the MEDIAGATE NX HD and is the answer not in the manual?

Questions and answers

Summary of Contents for MEMUP MEDIAGATE NX HD

Page 1 Feel Design User Guide User Guide User Guide MEDIAGATE NX HD MEDIAGATE NX HD...
Page 2: Table Of Contents
USER MANUAL SAFETY AND OTHER INSTRUCTIONS REMOTE CONTROL NETWORK DATA SHARING WITH WINDOWS XP AUDIO / VIDEO CONNECTION MENU INTERFACE VIDEO MENU MUSIC MENU PHOTO MENU VIRTUAL DVD SETUP MENU FIRMWARE UPGRADE SPECIFICATIONS TROUBLESHOOTING...
Page 3: Safety And Other Instructions
Mediagate NX HD Series is a Media Adapter, can play HD media files (movies, audios and photos) through TV with USB device (USB key or external hard disk). When connected to PC, can also play shared files via network. SAFETY AND OTHER INSTRUCTIONS Please use NX HD carefully and read following instructions.
Page 4: Remote Control
REMOTE CONTROL Turn on or Turn off Power Enter into Setup menu, or finish set up. Setup Choose the language you want Lang Adjusts the brightness, contrast, and color. Picture Change the value of each property by using the left and right arrow button. Change different TV output mode with this Button TV out Play or pause...
Page 5: Network Data Sharing With Windows Xp
NETWORK DATA SHARING WITH WINDOWS XP (HOME EDITION) Network-based Data Sharing with PC Connect direct to your PC or through a router as picture below: After LAN cable is connected, according to your system environment, set up windows network as follows.
Page 6 Data sharing Setup for Windows XP 1. Select folder you want to share and select “Sharing and security” with right mouse button. 2. Check “Sharing this folder on the network” and type “Share Name”. Ex: My Movie WARNING! “Share Name” should be less than 12 characters without accent or space. 3.
Page 7 WARNING! • Permission setting is only required for Windows XP Pro users. If you are an XP home user, go directly to step “6”. • If you cannot see “Administrative Tools”, click on “Switch to Classic view” on left corner. 5.
Page 8 7. Among displayed items, double-click “Internet Protocol (TCP/IP)”. After checking “Specify an IP address” enter your IP address and subnet mask. Ex: IP address: 192.168.1.3 Subnet Mask: 255.255.255.0. WARNING! If your PC already has “Obtain IP address automatically” checked and IP automatically assigned from an Internet router or DHCP server, you may not need this setup.
Page 9: Audio / Video Connection
AUDIO / VIDEO CONNECTION Connection with Ordinary (Composite) TV output Connect NX HD and your TV using the yellow video cable. Select appropriate video input mode on your TV until you get the initial NX HD screen Connection with HDMI output Connect the NX HD and your TV with HDMI cable, confirm your TV is on HDMI mode, then set the NX HD to HDMI mode by pressing “TV out”...
Page 10 Connection with 2CH audio output When you have a multi channel decoder/amplifier with coaxial input, you can enjoy 5.1CH high quality sound through coaxial cable. The illustration on the top shows how to connect with coaxial cable Connection with Coaxial output When you have a multi channel decoder/amplifier with coaxial input, you can enjoy 5.1CH high quality sound through coaxial cable.
Page 11: Menu Interface
MENU INTERFACE After a few seconds, the system will show guide menu. Network PC NX HD will search and display all the shared folder(s) in yours local network. See [Network-based Data Sharing] for more detail about data sharing setting USB Disk NX HD will search and display USB devices that are connected via a USB HOST port.
Page 12: Video Menu
VIDEO MENU Browse and play music, photo and movie files stored in external USB device, Network or Playlist. PLAYER can play the following files: AVI, MPG, MPEG, DAT, VOB, TP, TRP, WMV, ISO, etc Remote Function Description Multiple Audio Selects a specific audio source when multiple audio AUDIO Selection sources exist in a movie file...
Page 13: Music Menu
MUSIC MENU During music files playback, you can search folder and files. Buttons and Function for music playback Remote Function Description Support two types: stopped points and bookmarked Continuous Play BOOKMARK points(up to 9 in order) Volume Adjust Adjusts volume Sound mute Cuts off the sound MUTE...
Page 14: Photo Menu
PHOTO MENU NX HD also provides a slideshow function. The display duration or each picture can be set in SETUP menu by seconds. When 0 second is given, the system keeps displaying a specific picture until the “SKIP” or “STOP” button is pressed. Buttons and Function for photo playback Remote Function...
Page 15: Setup Menu
SETUP MENU The figure below is NX HD’s SETUP screen For each menu item, options are described below. A/V(Audio / Video Setting) TV Standard Choose PAL or NTSC TV output system. PALOutput Choose proper TV output among following options HDMI C/S Video There would be a window for changing confirmation, choose ‘Yes’...
Page 16 Language Choose proper Language with this option between English, Italian, Spanish, Russian, French, Deutsch, Czech, and Portuguese. Subtitle Size Select a subtitle size among small-subtitle, Big-subtitle, and No-subtitle. Subtitle Color You can set different subtitle color when use this function by choosing from ‘W/K, Y/K, C/K, W/B, Y/B, C/B’, picture as following.
Page 17 - you have shared folder(s) (without security, bracket and spacing) - you have shared file(s) - the router is on - files could be read by the Mediagate NX HD - the network cable is correctly plugged On Mediagate NX HD:...
Page 18: Firmware Upgrade
SETUP screen. 1. The latest firmware can be downloaded from www.memup.com 2. After connecting NX HD to your PC, copy the firmware to a desired USB key or external HDD.
Page 19: Specifications
SPECIFICATIONS CONTENT FORMAT SUPPORTED: Video codecs: MPEG-1, MPEG-2, MPEG-4, WMV9 (MP@HL), MPEG-2 HD TS, MPEG-4 ASP L5 (Without GMC), DVD-VIDEO, H.264(BP@L3, MP@4.0, HP@L4.0), VC-1(MP@HL, AP@L3) Video formats: AVI, .MKV, .WMV, .MPG, .DAT, .VOB, .IFO, .ISO, .MP4, .TP, .TRP, .TS, .M3T, .MOV Photos: JPEG / JPG / BMP / PNG - Maximum pictures recognizable: 9999 files Audio:...
Page 20: Troubleshooting
Please refer to Network settings part and follow step by step It could depend on your Operating system, for other OS, please check our FAQ in www.memup.com Make sure your personal firewall is deactivated or correctly set to function with NX HD...
