heute wohnen HOUSTON DC Assembly Instructions

Assembly Instructions
CAUTIONS : Please read instructions thoroughly before unpacking assembly parts. Sharp, exposed staple tips can cause
injury; therefore, for your protection, please remove any exposed staples used in packing.
1. We recommend that you should assemble this product with the assistance of another person; this will make assembly easier,
and will help to eliminate damage the product or injury to persons during assembly.
2. Be sure to check all packing materials carefully for small parts that may have come loose inside the carton during shipment.
3. Please do not over tighten screws or bolts.
4. Please put all parts on a non-abrasive floor before assembly, and follow the assembly steps to assemble your newly purchased
product correctly and efficiently.
PARTS LIST
NO DESCRIPTION
1
2
3
4
5
6
7
TOP VIEW
Outside
Front
Inside
Inside
Front
Outside
QTY
BACK 1
SEAT FRAME -
1
LEFT
SEAT FRAME -
1
RIGHT
FRONT LEG
1
WITH RAIL
CUSHION
1
SEAT
SIDE SUPPORT
1
RAIL - LEFT
SIDE SUPPORT
1
RAIL - RIGHT
ASSEMBLY PARTS DETAILS NOTES
6
Back
7
Back
MADE IN MALAYSIA
MODEL : HOUSTON_DC
HARDWARE LIST
NO DESCRIPTION
A ALLEN KEY M4
B JCBC BOLT M6 x 50MM
WOOD DOWEL (M8 x 30MM)
C
CSK C/B SCREW (M4 x 32MM)
D
Screwdriver (not provide)
SIDE VIEW
Front
QTY
1
6
6
7
ASSEMBLY TOOLS REQUIRED
Upper
Back
Lower
6 7
PAGE 1 OF 3
