CONTENTS PRODUCT OVERVIEW------------------------------------------------------------- 01-02 SAFETY WARNING------------------------------------------------------------------ USAGE Installation position of the car seat in vehicle---------------------------------------- Adjusting the headrest-------------------------------------------------------------------- Checking the shoulder strap height--------------------------------------------------- Using the buckle--------------------------------------------------------------------------- Adjusting the length of the harness---------------------------------------------------- Reclining the seat-------------------------------------------------------------------------- Removing the harness-------------------------------------------------------------------- Removing the chest pads----------------------------------------------------------------- Remove the crotch pad and buckle----------------------------------------------------- 3.10 Adjusting the height of the harness-----------------------------------------------------...
PRODUCT OVERVIEW Headrest Belt guide hook Belt clamp 5-point harness Chest pad Insert Buckle Crotch pad Harness adjustment button Recline adjuster Harness adjuster strap Harness connector Belt guide Headrest adjuster...
Page 4
“UNIVERSAL BELTED” NOTICE This is a Universal Belted Enhanced Child Restraint System. It is approved according to UN Regulation No.129, for use primarily in "Universal seating positions" as indicated by vehicle manufacturers in the vehicle user's manual. If in doubt, consult either the Enhanced Child Restraint System manufacturer or the retailer. “...
SAFETY WARNING This product can be used rearward-facing with the 5-point safety system for children with a height of 40-105cm, using adult three-point belt to fix the child restraint system. This product can also be used forward-facing for children with a height of 100-135cm, using the adult three-point belt to fix the child restraint system.
USAGE 3.1 Installation position of the child seat in vehicle Diagonal belt Not suitable Suitable Lap belt Only suitable if the approved vehicles are fitted with a 3 point safety-belt, approved to UN/ECE Regulation No.16 or other equivalent standards. Not to be used in seating positions where an active frontal airbag is installed.
3.2 Adjusting the headrest As shown in the picture, you can adjust the headrest up and down by pulling on the headrest adjuster adjust the headrest to a position suitable for the child's head. 3.3 Checking the shoulder strap height too low too high slightly higher...
3.4 Using the buckle Assemble the left and the right pieces of the buckle together. Insert the two pieces into the slot of the buckle. When the buckle is correctly engaged you will hear a “click”. Always double check the buckle is locked by pulling the harness. * If you want to release the harness, press the red button down on the buckle.
To tighten the harness pull the harness adjuster strap away from the car seat. You may need to guide the harness into place using your other hand. * The harness should be adjusted as tightly as possible without causing discomfort to your child. A loose harness can be dangerous.
3.7 Removing the harness Loosen the harness turn the child seat so you can connectors. (As shown in figure ①②③). see the back. Slide the harness off the harness You can then remove the buckle tongues from the harness and then hide the harness under the covers converting your car seat to a high backed booster.
3.9 Remove the crotch pad and buckle Adjust the child seat to the most reclined position and turn it so you can see the bottom. Turn the buckle locking clip on their narrowest position and feed it through the slot under the bottom of the child seat.
INSTALLATION 4.1 Installed rearward facing (Height:40-105CM) * Do not use forward facing before the child’s age exceeds 15 months. Method: Pull the recline adjuster under the seat, adjust to the most reclined position. Put the child seat rearward facing on the car seat and make sure that the front of the child seat is firmly pressed against the vehicle seat backrest.
Page 13
Shoulder belt Lap belt As shown in the figure, firstly pull the vehicle belt to give yourself as much slack as possible, feed the vehicle shoulder belt into the car seat belt guide hook and belt clamp on the same side, and then continue to pass the vehicle belt through to the other side of the seat (when doing so ensure the vehicle belt goes behind the...
Page 14
Put your child into child seat. * Check the height of the harness is in the correct position and fasten the buckle * Check that the harness has not been twisted. * Check that the cover is not impeding the movement or fit of the harness in anyway.
4.2 Installed forward-facing (Height:100-135CM) * Do not use the device in seating positions where an active frontal airbag installed. Put the child seat forward facing on the vehicle seat and make sure that the back of the child seat is firmly pressed against the vehicle seat backrest.
MAINTENANCE AND CLEANING 5.1 Daily maintenance In daily use, periodically check the child seat. The child seat should be replaced after an accident. Please keep this child seat in a dry and ventilated place to avoid damp and mold. If the child seat becomes dirty, clean the harness and the plastic pieces by wiping them with a damp sponge and let it dry naturally.
