- Page 2 Since 1978, Goldmund has been dedicated to developing audio equipment of the highest quality and accuracy to immerse you in the most realistic audio experience possible. At Goldmund, we are committed to being at the forefront of the creation, development, and manufacture of the industry's most advanced technologies, including audio systems and music distribution.
- Page 3 User Manual – MELOS STAND – ACCESSORIES - 3 -...
- Page 4 M6x30 hex socket screws (stand base screws) M6x10 countersunk head screws (central speaker bottom screw) M5x10 pan head screw (top nesting cube and stand tube fixations) Top Nesting Cube Bottom Nesting Cube Stand Adjustable Feet User Manual – MELOS STAND – ACCESSORIES - 4 -...
- Page 5 Central Stand Tube Bottom Stand Base User Manual – MELOS STAND – ACCESSORIES - 5 -...
- Page 6 Preparing the Melos Speaker Lay your Melos speaker on its side on a table or another stable surface. Use a soft fabric or another protective material underneath to prevent any scratches or damage to the speaker's enclosure. This precautionary step ensures the preservation of the speaker’s aesthetic and structural integrity during the assembly process.
- Page 7 The screw holes on the nesting cube should face the rear of the speaker. Secure the nest to the speaker's base panel using the provided M6x65 screws. User Manual – MELOS STAND – ACCESSORIES - 7 -...
- Page 8 Adjusting the Feet The stand has four adjustable feet, with two position options: narrower and wider. Choose the desired feet position and secure the feet to the base. User Manual – MELOS STAND – ACCESSORIES - 8 -...
- Page 9 Orient this end of the tube towards the rear of the Melos speaker. Fix the speaker to the tube by screwing two M5x10 screws into the holes in the nesting cube. User Manual – MELOS STAND – ACCESSORIES - 9 -...
- Page 10 Positioning the Speakers Your Melos speakers are now ready for floor-standing placement. Refer to the Melos Owner’s Manual for optimal stereo positioning recommendations. Transporting the Assembled Unit Carefully hold both the Melos speaker and the stand during transportation. For easier movement, you may rotate the unit on the ground.
- Page 11 35 W x 145 H x 35 D (cm) • 13.8 W x 57.1 H x 13.8 D (inch) WEIGHT (per unit, without speaker) • 9.5 kg WEIGHT (per unit, with speaker) • 33.5 kg User Manual – MELOS STAND – ACCESSORIES - 11 -...
