Extraction unit for CAM systems
User's Manual
- The illustrations in this manual are intended for illustration only and may differ from the
actual appearance.
- The appearance, color, and specifications of the product are subject to change without
prior notice for quality improvement
- After reading, keep it in a place that is always visible to the person using it.
- This manual contains the quality warranty.
Advertisement
Table of Contents
Summary of Contents for Komax Silence CAM200-R
- Page 1 Extraction unit for CAM systems User’s Manual - The illustrations in this manual are intended for illustration only and may differ from the actual appearance. - The appearance, color, and specifications of the product are subject to change without prior notice for quality improvement - After reading, keep it in a place that is always visible to the person using it.
-
Page 2: Table Of Contents
Contents Contents ····················································································· specifications ············································································ Product description ··································································· Product Standard Components ··············································· Optional Components ······························································· Procuct assembly ······································································ Filter Replacement ··································································· OInformation for operators ···················································· Set up ··························································································· MODE information ····································································· Cleaning & Maintenance ·························································· Technical Data ··········································································· CAM interface ············································································... -
Page 3: Specifications
02 Specifications Silence Mobile Extractor SPECIFICATIONS · Description : Extraction unit for CAM systems · Materials : ABS, PP, PETG · Motor operating temperature : 0~40℃ · Storage temperature : -20~80℃ · Storage humidity : RH 20~80% · Product standard components : Main unit, Filters, Suction hose 2.5meter, Power plug, CAM interface cable ·... -
Page 4: Product Description
03 Product description Front appearance Handle Filter cover Touchpad Body Back appearance LED Lamp socket Circuit breaker Power plug socket Foot switch / Interface cable socket Micromotor controller socket... - Page 5 ④ DOWN : A number is displayed on ⑧ for the step adjustment of the suction down step. ※ In the case of Silence CAM100-R and Silence CAM200-R models. suction is performed in one step, and ③Up ④DOWN button does not work.
-
Page 6: Product Standard Components
04 Product Standard Components Silence CAM-100 Filters 1st Filter Filter Brecket 5th Filter Pocket filter(300mm) Air filter ※ The 1st filter replacement notification informs you when to replace by measuring the pressure in the suction part by the pneumatic sensor. Also, the replacement cycle of the filter may vary depending on the usage. - Page 7 04 Product Standard Components Silence CAM-200 Filters 1st Filter Filter Brecket 2nd Filter 5th Filter Poket filter(450mm) ULPA filter Air filter [99.9995%] ※ The 1st filter replacement notification informs you when to replace by measuring the pressure in the suction part by the pneumatic sensor. Also, the replacement cycle of the filter may vary depending on the usage.
-
Page 8: Optional Components
05 Optional Components Optional Components Filter Suction/Exhaust hose Bushing for suction hose Anti-static hose 2.5M Pocket filter(300mm) with 2 bushings 1 set of 2 pcs Caster Anti-static hose 6M without 2 bushings Pocket filter(450mm) 1 set of 4 pcs Anti-static hose 9M without 2 bushings Touchpad Filter Bracket... -
Page 9: Procuct Assembly
05 Optional Components Optional Components Foot switch CAM interface cable Interface cable (Suction on/off) for CAM machine 06 Product assembly Suction hose installation 1. Fasten the bushing to the suction 2. Insert the bushing into the body hose as shown. as shown. - Page 10 ④ Attach the exhaust hose to the ⑤ Attach the remaining exhaust attached outdoor exhaust plate. hose in the same way as ③. ※ Use of KOMAX Co., Ltd. exhaust hose does not cause excessive damage to the product.
-
Page 11: Filter Replacement
07 Filter replacement 1st filter replacement ① Disconnect the suction hose ② Loosen the locking device from the machine by lifting it up. ② ① ③ Open the product lid by turning ※pocket filter※ it counter clockwise. 1. Remove the pocket filter inserted in the ④- groove on the bottom of the lid by turning it clockwise. -
Page 12: Oinformation For Operators
The manufacturer is not responsible for any damage caused by improper use. Only parts and accessories provided or approved by KOMAX may be used for this product. Use of third-party parts or accessories may adversely affect the safety of the device, increase the risk of serious... - Page 13 08 Information for operators 2.3 Ambient conditions for safe operation The device may only be operated: • Indoors • Up to an altitude of 2,000 m above sea level. • At an ambient temperature of between 5 - 40 ºC [41 - 104 ºF] *). •...
- Page 14 08 Information for operators 2.5.2 Specific Information ► When connecting to a CAM system, please observe the CAM device instructions for use and comply with their safety precautions. ► Please observe the national regulations and permitted exposure to dust in a working environment. Please ask the “National Institute for Occupational Safety and Health”...
-
Page 15: Set Up
09 Set up Unboxing ⇒Remove the device and all the accessories from the delivery package. ⇒Check the delivery for completeness (refer to the “Standard componets” section). Set up The extraction unit is a free standing appliance which must not be operated in a lying position. Position the extraction device so that: •... - Page 16 09 Set up Connection to a CAM interface If the suction is frequently switched on or off via the CAM power supply, it may cause electronic damage to the CAM system as well as to the SILENCE CAM DUST COLLECTOR. For remote control of the SILENCE CAM it is essential to use the provided CAM interface, together with the “CAM interface cable type”...
-
Page 17: Mode Information
Foot pedal / Interface cable socket How to set MODE 1) Connect the KOMAX’s foot switch which has a 6pin circular terminal to the common port of Foot pedal / Interlocking cable socket. 2) Turns on the power of Silence CAM. - Page 18 10 MODE information •MICRO MOTOR (MODE3): -The dust collector is operated through a signal from the micromotor controlled device. Micromotor Controller socket How to set MODE 1) Connect the external electronic device to the Silence CAM. 2) Turns on the power of Silence CAM. 3) When an external electronic device and a dust collector are connected, the dust collector stores and sets the current value of the external device.
-
Page 19: Cleaning & Maintenance
11 Cleaning & Maintenance Filter cleaning In order to ensure maximum suction performance, it informs you when to change the filter for the filter unit. The following cleaning procedure is carried out. • When the dust collection performance is insufficient (when the suction speed drops below the specified level). •... -
Page 20: Technical Data
11 Cleaning & Maintenance Disposal Information 5.1 Disposing of Consumables Full dust bags and filters must be disposed of under compliance with locally applicable regulations. Depending on the material trapped by the filters, protective gear may need to be worn during disposal. 5.2 Disposing of the Unit The unit must be disposed of by an authorized recycling operation. -
Page 21: Cam Interface
13 CAM interface CAM interface This dust collector is a two-way interface capable of communicating with CAM devices. Through the input/output unit, commands can be received from the dust collector or status information can be sent to the CAM device. CAM Unit SILENCE SUCTION 1 Input... -
Page 22: Pin Assignment Interface Cable
14 PIN assignment interface cable Suction on command Suction off command OUT1 Suction on OUT2 OUT1 Suction off PIN assignment interface cable Interface cable Type A Silence CAM CAM device Rear Lumberg SV40 CAM interface cable view (with screw closure) Pin 1 Pin 1 (+) Pin 2... - Page 23 14 PIN assignment interface cable Interface cable Type E Silence CAM CAM device CAM interface cable 9pin D-Sub Pin 3 Pin 9 Pin 4 Pin 8 Interface cable Type F Silence CAM CAM device CAM interface cable Pin 1 DC12 or 24V Pin 2 Used when CAM system only has voltage for dust collector control.
-
Page 24: Error List
15 Error List Error List Errors Causes Corrective Action Since the temperature of the power line is • When the contact is shorted due overheated, press the circuit breaker switch to the external circuit breaker after cooling the device sufficiently. If you operation press this switch when the device is not cool If the power does... -
Page 25: Disclaimer & Warranty
► The product is altered in any way other than those alterations described in the operating instructions. ► The product is not repaired by an authorized facility or if non-original KOMAX parts are implemented. ► The product continues to be used despite obvious safety faults or damage. - Page 26 Extraction unit for CAM systems User’s Manual Tel : 032-582-4237(for Korean), +82-70-7772-6152(for English) Address: 20, Baekbeom-ro 810beon-gil, Seo-gu, Incheon, Republic of Korea(22839) Web : www.ko-maxkorea.com E-mail : komax2031@gmail.com (Overseas Sales Team) komaxko@naver.com (Domestic Sales Team) Fax : +82-32-572-4237...
