Summary of Contents for develogic Sono.Vault C8
-
Page 1: Installation & User Manual
Installation Installation & User & User Manual Manual Installation Installation & User & User Manual Manual Sono.Vault Acoustic Recorder Acoustic Recorder Acoustic Recorder Acoustic Recorder REV C8 Sono.Vault_C8_UserManual.doc 1/33 develogic GmbH... -
Page 2: Table Of Contents
5.4 Example on How to Schedule an Interval Measurement ............... 22 Sensor Section ..............................23 6.1. Compass ..............................23 VII. User Interface ..........................24 How to Read and Write System Parameters ....................25 1.1 Clock Commands ............................. 25 Sono.Vault_C8_UserManual.doc 2/33 develogic GmbH... - Page 3 1.2 File System Commands ........................... 26 1.3 System Commands ..........................27 1.4 Sampling Commands ..........................28 1.5 Sensor Commands ........................... 29 1.6 Sampling and Recording Parameters ..................... 30 Technical Data..............................31 Extended or Recovery Firmware Upgrade ...................... 32 Sono.Vault_C8_UserManual.doc 3/33 develogic GmbH...
-
Page 4: Revision History
Commands added: system.FRAMcfg; storage.ExtStart 06/2014 S. Rautenberg Examples added (Scheduling), Details, Corrections; 09/2014 F. Berning Sensor Section and Analogue Event added, 01/2015 R. Weber DirFiles Description, Corrections M. Motz F. Danckwerts Adjustment of amplifier steps 02/2015 R. Weber F.Danckwerts Sono.Vault_C8_UserManual.doc 4/33 develogic GmbH... -
Page 5: System Overview
3.584 TB (7 x 512GB SDXC cards). With up to 4 additional storage modules, the memory can be extended up to 17.920 TB. Optional: A precision clock module hosting a GPS synchronizable Symmetricom CSAC clock. Sono.Vault_C8_UserManual.doc 5/33 develogic GmbH... -
Page 6: Mooring Frame
The Sono.Vault system can be mounted in vertical orientation using our corrosion resistant stainless steel mooring frame with sacrificial zinc anodes. The mooring frame can be fully disassembled for servicing and transport. Fig. 2 – Sono.Vault in 2x extended DW.TH housing installed in mooring frame Sono.Vault_C8_UserManual.doc 6/33 develogic GmbH... -
Page 7: Internal Interfaces
3.1 RS232 Serial Interface – P1 Tyco Micro MNL 2x3 pole receptacle Lock notch 5 NC 3 RX-IN 1 TX-OUT 6 GND 4 RTS-IN 2 CTS-OUT Tab. 3 – Sono.Vault electronic internal RS232 serial connector P1 (top view socket) Sono.Vault_C8_UserManual.doc 7/33 develogic GmbH... -
Page 8: Rs232 Serial Interface - P2
Tyco Micro MNL 2x3 pole receptacle Lock notch 5 TX + 3 CMT TX 1 RX + 6 TX - 4 CMT RX 2 RX - Tab. 6 – Sono.Vault electronic ethernet connector (top view socket) Sono.Vault_C8_UserManual.doc 8/33 develogic GmbH... -
Page 9: External Interfaces
The biasing can be performed internally at the analogue frontend. Please contact develogic for details. The biasing of the inverting input (- IN) can also be performed at the connection cable side. This is done by connecting a capacitor with a value equal to the capacitance of the hydrophone between IN and COM. -
Page 10: Rs232 Serial And Usb Interface
(host to Sono.Vault) RS232 in (host to Sono.Vault) RS232 out (Sono.Vault to host) USB D+ USB D D D D - - - - Signal Tab. 9 – Sono.Vault electronic external RS232 serial and USB connector Sono.Vault_C8_UserManual.doc 10/33 develogic GmbH... -
Page 11: Hydrophone And Recorder Electronics
Hydrophone and Recorder Electronics Hydrophone The standard system is equipped with a Reson TC4037-3 hydrophone. The maximum operation depth of the hydrophone is 1500m. Survival depth of the hydrophone is rated to 3500m. Fig. 4 – Hydrophone assembly Sono.Vault_C8_UserManual.doc 11/33 develogic GmbH... -
Page 12: Analogue Frontend And Interface Module
It is possible to sample the hydrophone signal with up to 220 kSPS at 16 bit nominal resolution or with up to 96 kSPS at 24 bit nominal resolution. The module hosts a precision oscillator with a standard precision of less than 0.5 ppm drift / year. It is software calibratable. Sono.Vault_C8_UserManual.doc 12/33 develogic GmbH... -
Page 13: Recording Modules
Acoustic signal data is written in individual WAV files with – due to file system restrictions – sizes of up to 4 GB per file. Sampling frequency, start time and amplification are written into the WAV-file header. Optional data, Sono.Vault_C8_UserManual.doc 13/33 develogic GmbH... - Page 14 Finally, the currently active recording module is sent to sleep and the next module is activated. Fig. 7 – Sono.Vault storage modules – rear view Sono.Vault_C8_UserManual.doc 14/33 develogic GmbH...
-
Page 15: Configuration File
Basic configuration usually is delivered according to customer specification. If the system configuration needs to be altered after delivery, it is recommended to contact develogic for support. Changes of the configuration without detailed knowledge of all related aspects of system operation may render remote systems temporarily or permanently inaccessible. - Page 16 <Handshake>None</Handshake> <Parity>None</Parity> <Transceiver>232</Transceiver> <Mode>Command</Mode> <Sleep>Yes</Sleep> </Com_0> </Ports> <Clock> <UTCOffset>0</UTCOffset> <TCVCXO>16384000</TCVCXO> <BaseCalib>45875</BaseCalib> <Crystal>19200000</Crystal> </Clock> <Scheduler> <Event_0> <Time>2014-01-01 08:00:00.000</Time> <Interval>86400000</Interval> <Repeat>365</Repeat> <Fixed>Yes</Fixed> <ADC24Freq>24000</ADC24Freq> <ADC16Freq>0</ADC16Freq> <FileDuration>300</FileDuration> <WAVID>TestFile</WAVID> <Gain>4</Gain> <Type>StartSampling</Type> </Event_0> <Event_1> <Time>2014-01-01 08:30:00.000</Time> <Interval>86400000</Interval> <Repeat>365</Repeat> <Fixed>Yes</Fixed> <Type>StopSampling</Type> </Event_1> <Event_2> Sono.Vault_C8_UserManual.doc 16/33 develogic GmbH...
- Page 17 User Manual Rev. C8 Sono.Vault <Interval>10000</Interval> <Repeat>0xffff</Repeat> <Type>Analog</Type> <Eth>on</Eth> </Event_2> </Scheduler> <Sensors> <Compass> <CalibValue1>-203</CalibValue1> <CalibValue2>8</CalibValue2> </Compass> </Sensors> </Device> Tab. 10 – Sample configuration file – software revision 4.0 Sono.Vault_C8_UserManual.doc 17/33 develogic GmbH...
-
Page 18: System Section
<Mode> Mode of port operation Command: Local command port Instrument: Instrument connected to this port Routing: Data routing port Logging: normal logging operation Disabled: port disabled <Sleep> Enable or disable automatic sleep mode Yes: enabled No: disabled Sono.Vault_C8_UserManual.doc 18/33 develogic GmbH... -
Page 19: Clock Section
Input amplifier gain index (0-7) – see calibration sheet. The amplification for the different gain indexes are (for exact values, see calibration sheet delivered with Sono.Vault): 0: 6 dB, 1: 12 dB, 2: 18 dB, 3: 24 dB, 4: 27 dB, 5: 33 dB, 6: 39 dB, 7: 45 dB Sono.Vault_C8_UserManual.doc 19/33 develogic GmbH... - Page 20 (recording directories naming is based on a one hour grid). <FileDuration> Recording duration for one single file in seconds. <WAVID> Text with up to 40 characters to be written into WAV-file header. Sono.Vault_C8_UserManual.doc 20/33 develogic GmbH...
-
Page 21: Scheduler Section
Input amplifier gain index (0-7) – see calibration sheet. The amplification for the different gain indexes are (for exact values, see calibration sheet delivered with Sono.Vault): 0: 6 dB, 1: 12 dB, 2: 18 dB, 3: 24 dB, 4: 27 dB, 5: 33 dB, 6: 39 dB, 7: 45 dB Sono.Vault_C8_UserManual.doc 21/33 develogic GmbH... -
Page 22: Stopsampling Event
// repeat 1008 times: 1008*10min = 1 week // <Fixed>Yes</Fixed> // synchronize this event with all other events // <ADC24LPMode>48000</ADC24LPMode> // use 48 kHz sampling in 24-bit LowPower Mode // <ADC16Freq>0</ADC16Freq> // not use 16-bit sampling // Sono.Vault_C8_UserManual.doc 22/33 develogic GmbH... -
Page 23: Sensor Section
P - Pitch Angle (-180° to +180°) R – Roll Angle (-180° to +180°) H – Heading (0° to +360°) C – Compression (bar) 6.1. Compass <CalibValue1> , <CalibValue2> Calibration value for precision temperature measurement (do not change!) Sono.Vault_C8_UserManual.doc 23/33 develogic GmbH... -
Page 24: User Interface
(as e.g. after !{error.XXXXX error description} if an error occurred. In addition, there are information messages that display more information about the nature of an error or generic help information: !{info descriptive text – possibly over several lines} Sono.Vault_C8_UserManual.doc 24/33 develogic GmbH... -
Page 25: How To Read And Write System Parameters
Possible Responses: !{get Clock.Time 2010-10-01 12:00:00.050} System time response Retrieve system time. ?{set Clock.Time YYYY-MM-DD_hh:mm:ss.msec} Parameters: YYYY-MM-DD_hh:mm:ss:msec: Time stamp with given format Possible Responses: !{set Clock.Time 2010-10-01 12:00:00.050} Time change OK response. !{error.00002 Invalid parameter} The parameter category or id was invalid. Sono.Vault_C8_UserManual.doc 25/33 develogic GmbH... -
Page 26: File System Commands
Possible Responses: !{file.download Offset DataSize} followed by data. !{error.00003 File access} Problem with file/path name or SD-card access Download data from a file on the selected SD-card. ?{file.list \Path} Parameters: \Path\Filename: Path to directory to lists content Possible Responses: !{file.list Sono.Vault_C8_UserManual.doc 26/33 develogic GmbH... -
Page 27: System Commands
Possible Responses: ?{system.FRAMcfg 1234} The size of the FRAM configuration is 1234 bytes <?xml version="1.0" encoding="utf-8"?> <Device> … </Device> CRC: 7507 - ok}<CR><LF>: valid CRC Return size, transmit the configuration which is currently stored in the FRAM and perform a CRC check. Sono.Vault_C8_UserManual.doc 27/33 develogic GmbH... -
Page 28: Sampling Commands
WS:5031936: Number of bytes already written into this single recording file. FS will be reset and the recording file be changed when then number of written bytes (ws) reaches the file size of single recording file (FS) Sono.Vault_C8_UserManual.doc 28/33 develogic GmbH... -
Page 29: Sensor Commands
Up to 5 modules can be listed. Slot information only appears if a card is inserted into the corresponding slot. 1.5 Sensor Commands ?{Sensor.compass.temp} Parameters: None Possible Responses: Temperature in degree Celsius. ?{get Sensor.Compass.Temp}<CR><LF> !{get Sensor.Compass.Temp 023.21}<CR><LF> Sono.Vault_C8_UserManual.doc 29/33 develogic GmbH... -
Page 30: Sampling And Recording Parameters
Range: Value in seconds - depending on the sampling rate and bit resolution, this value must be set so that the resulting file size (sampling duration * rate * bytes / sample) does not exceed 4 GB. Sono.Vault_C8_UserManual.doc 30/33 develogic GmbH... -
Page 31: Technical Data
6 dB, 12 dB, 18 dB, 24 dB, 27 dB, 33 dB, 39 dB, 45 dB Input Attenuator: Typically -21 dB Differential input offset voltage range: 20mV Maximum ADC input voltage range -2.5V to +2.5 V Wav file output scaling: -1 to 1 Sono.Vault_C8_UserManual.doc 31/33 develogic GmbH... -
Page 32: Extended Or Recovery Firmware Upgrade
After finishing, the same green “Pass” status should appear. If instead a red “Fail” status is presented, verify all the connections, make sure that the system is connected to power and select “AUTO PROG” another time. 7. Reset the module by selecting the “Reset” button. Sono.Vault_C8_UserManual.doc 32/33 develogic GmbH... - Page 33 User Manual Rev. C8 Sono.Vault 8. Disconnect the JTAG-cable. Fig. 8 – Necessary settings for the flash programmer tool. Sono.Vault_C8_UserManual.doc 33/33 develogic GmbH...
