RB1 RECUMBENT BIKE
OWNER'S MANUAL
Model No. RB1
Fitness Authority Industrial Co., LTD.
MA902
No. 15, Xiangxue Rd., Dali Dist.,
Taichung City 41275, Taiwan.
ATTAIN FITNESS
VERSION-2023.12

Advertisement

loading
Need help?

Need help?

Do you have a question about the RB1 and is the answer not in the manual?

Questions and answers

Summary of Contents for ATTAIN FITNESS RB1

  • Page 1 RB1 RECUMBENT BIKE OWNER’S MANUAL Model No. RB1 Fitness Authority Industrial Co., LTD. MA902 No. 15, Xiangxue Rd., Dali Dist., Taichung City 41275, Taiwan. ATTAIN FITNESS VERSION-2023.12...
  • Page 2 IT IS IMPERATIVE THAT YOU FILL IN THE FOLLOWING INFORMATION AND REFER TO IT SHOULD THE NEED FOR SERVICE ARISE. Product Name: RB1 RECUMBENT BIKE Serial # _ _ _ _ _ _ _ _ _ _ _ _ Serial No.:...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Product Safety…….…….……….…………….….….….….….……….….….…….………1 Parts Contents……….….….….….……….….….….….….……….…….….….…….……2 Assembly….……….….….……….….….….….……….……………….….….……………3 Adjustments………….………………….….……….….….……….….….….….….………6 Detailed Parts List.……………………….……….….….….….…………….……………..7 Exploded Drawing.…………….……….……….……….……….….…………….………..10 Computer Operation………………………….…………….…………….…………………12...
  • Page 4: Product Safety

    5. Do not attempt any maintenance or adjustments other than those described in this manual. Should any problems arise, discontinue use and consult an Authorized Service Representative. Please call your local dealer for assistance or ATTAIN FITNESS at +1 877-551-7484 and info@attainfitnessusa.com 6.
  • Page 5: Parts Contents

    RB1 PARTS CONTENTS Rear Stabilizer Front Stabilizer Main Bike Assembly Right Left Seat Pad Handlebar Handlebar Console Mast Console Bottle Water Computer Back Support Mast Holder Bottle Frame Console Cover Back Pad Left Right...
  • Page 6: Assembly

    ASSEMBLY Step 1 Front & Rear Stabilizer 1. Use a Styrofoam block from the packing material to raise the front of the Bike Assembly (1) then a�ach the Front Stabilizer (2) using two 3/8" x 2-1/4" Hex Head Bolts (79), as shown in Fig.
  • Page 7 ASSEMBLY Step 3 Handlebars Pulse Handlebar Wire (42) to the Pulse Coiled Wire (41) on the Seat Frame (5). Store excess Spring Washers (99), and two M8 x 15L Dome Head Allen Bolts (76) as shown in Fig. C1. Insert the Seat Adjustment Handle (11) into the bracket welded to the Seat Frame (5). As M8 x 8L Set Screws (91) and then �ghten the Set Screws (91) against the flat side.
  • Page 8 ASSEMBLY Step 5 Console Mast & Computer Console Be Careful not to pinch any of the wires while assembling IMPORTANT the Console Mast and Computer. NOTE! Slide the Console Mast Cover (30) onto the Console Mast (6). See Fig. E1 and E2. Hold the Console Mast (6) close to the Bike Assembly and connect both wires;...
  • Page 9: Adjustments

    ADJUSTMENTS The seat can adjust front-to-back to accommodate your leg length. Simply rotate the Seat Adjustment Handle (11) upward to loosen then rotate downward with force to lock the seat into place. The Pedal Straps can be adjusted to fit your shoes. The Back Support (18) can be adjusted for your comfort.
  • Page 10: Detailed Parts List

    DETAILED PARTS LIST DESCRIPTION QTY. MAIN BIKE ASSEMBLY FRONT STABILIZER REAR STABILIZER SLIDING SEAT TRACK SEAT FRAME CONSOLE MAST LEFT HANDLEBAR RIGHT HANDLEBAR BACK SUPPORT FRAME SEAT TRACK BACKING PLATE BACK PAD ADJUSTMENT KNOB SEAT ADJUSTMENT HANDLE 12 L LEFT CRANK ARM 12 R RIGHT CRANK ARM WRENCH...
  • Page 11 DETAILED PARTS LIST QTY. 33 L LEFT SHROUD 33 R RIGHT SHROUD BRAKE MOTOR ASSEMBLY 34-1 8 PIN C O N SO L E MAST HARNESS 8 PIN CONSOLE MAST HARNESS POWER RECEPTACAL HARNESS SPEED SENSOR PICKUP CABLE 4 PIN CONSOLE MAST HARNESS PULSE CONNECTHARNESS BRAKE ANTI-ROTATION BRACKET PULSE COILED WIRE...
  • Page 12 DETAILED PARTS LIST DESCRIPTION QTY. 1/2" X 3-1/2" HEX HEAD BOLT 3/8" X 2-3/4" HEX HEAD BOLT M8 X 15L DOME HEAD ALLEN BOLT M8 X 20L HEX HEAD THREADED BOLT M8 X 20L DOME HEAD ALLEN BOLT 3/8" X 2-1/4" HEX HEAD BOLT M8 X 30L FLAT HEAD ALLEN BOLT M8 X 16L FLAT HEAD ALLEN BOLT M6 X 15L FLAT HEAD ALLEN BOLT...
  • Page 13: Exploded Drawing

    10 92 Exploded View 1 of 2 99 89...
  • Page 14 34-1 98 84 Exploded View 2 of 2...
  • Page 15: Computer Operation

    SM52027 SERIES INSTRUCTION MANUAL DISPLAY FUNCTIONS ITEM DESCRIPTION TIME Count up - No preset target, Time will count up from 00:00 to maximum 99:59 with each increment is 1 minute. Count down - If training with preset Time, Time will count down from preset to 00:00. Each preset increment or decrement is 1 minute between 00:00 to 99:00.
  • Page 16 KEY FUNCTION ITEM DESCRIPTION Increase resistance level Setting selection. Decrease resistance level Setting selection. Confirm setting or selection. Press and hold for 2 seconds, computer will reboot and start from user setting. Reverse to main menu during preset workout value or stop mode. Start or Stop workout.
  • Page 17 OPERATION PROCEDURE POWER ON Plug in power supply, computer will power on and display all segments on LCD for 2 seconds (Drawing 1). Drawing 1 Then enter into User data setting. Use UP or DOWN key to select U1~U4, then set SEX, AGE, HEIGHT (Drawing 2), WEIGHT and confirm by pressing MODE key.
  • Page 18 Built in Wireless Heart Rate Receiver Note: Chest strap transmitter does not come with this unit; contact ATTAIN FITNESS, or your dealer for purchase. This product is equipped with a built-in receiver for your heart rate monitoring. Any heart rate telemetry strap that transmits at 5Khz is compatible.
  • Page 19 Drawing 11 Drawing 12 Drawing 13 Drawing 14 Watt Mode (use UP/DOWN key to select and press MODE key to confirm, or press the fast key to get into.) 1. Use UP or DOWN key to select workout program, choose W and press MODE key to get into.
  • Page 20 RECOVERY (In heart rate status, press RECOVERY key to get into.) After exercising for a period, keep holding on hand grips or wearing chest strap and press RECOVERY key. All function display will stop except “TIME” starts counting down from 00:30 to 00:00 (Drawing 17). Screen will display your heart rate recovery status with the F1, F2 .to F6 (Drawing 18).
  • Page 21 Drawing 25 Advice symbol THIN PLUMP Noted: 1. After 4 minutes without pedaling or pulse input, console will enter into power saving mode. Press any key may wake the console up. 2. When computer act abnormal, please plug out the adaptor and plug in again. 1.
  • Page 22 *This warranty is in lieu of all warranties, expressed or implied, and/or all other obligations or liabilities on our part and we neither assume nor authorize any person to assume for us any other obligation or liability in connection with the sale of your ATTAIN FITNESS product.
