Summary of Contents for Webasto Turbo DX 2.0
- Page 1 Turbo DX 2.0 Plug-In Charger User Guide...
-
Page 2: Table Of Contents
Contents Section 1 – Introduction ..........................3 SYMBOL USAGE ..........................3 ABOUT YOUR TURBO DX 2.0 PLUG-IN CHARGER ................ 3 CHARGER COMPONENTS ........................6 SPECIFICATIONS ..........................7 Section 2 – Using Your Charger ......................... 8 KNOW YOUR INDICATOR LIGHTS ..................... 8 CHARGING YOUR VEHICLE ....................... -
Page 3: Section 1 - Introduction
ABOUT YOUR TURBO DX 2.0 PLUG-IN CHARGER The Turbo DX 2.0 Plug-In Charger is an easy-to-use, wall- or post-mountable power supply for your electric vehicle. The charger supplies and manages AC power to your electric vehicle and is compatible with a variety of battery electric vehicles and plug-in hybrids. - Page 4 DO NOT ATTEMPT TO REPAIR THE CABLE YOURSELF. Contact your local Webasto dealer for assistance. WARNING When using your Turbo DX 2.0 Plug-In Charger, basic precautions should always be followed, including the following: • See the warnings on the charger control box. Read the warnings before operating the product for the first time.
- Page 5 Use only accessories and replacement parts from Webasto with an approved NEMA 14-50 outlet. The plug must be in good condition and meet up-to-date NEC code.
-
Page 6: Charger Components
CHARGER COMPONENTS CONTROL BOX GRID PLUG COUPLER Release Button SAE Charger Coupler NEMA 14-50R Outlet (North America) Your Turbo DX 2.0 Plug-In Charger comes standard with a NEMA 14-50 plug. Doc ID 5913386 Webasto Charging Systems, Inc. Page 6 of 18... -
Page 7: Specifications
User Guide Turbo DX™ 2.0 Plug-In Charger SPECIFICATIONS Turbo DX 2.0 Plug-In Charger SAE (North America) Voltage: 120-240 VAC Maximum current: 32 amps max continuous Frequency: 50-60 Hz Power draw at idle: < 2 watts During charging: < 4 watts Cable length: Approximately 25 ft (7.6 m) -
Page 8: Section 2 - Using Your Charger
1. When first plugged into a wall socket, the AMBER, BLUE and RED indicators blink once. 2. Then the BLUE Indicator turns ON, followed by a blink of the RED indicator. 3. Lastly, the BLUE indicator turns OFF, then ON again. Doc ID 5913386 Webasto Charging Systems, Inc. Page 8 of 18... -
Page 9: Charging Your Vehicle
6. When charging ends, the BLUE STATUS Indicator illuminates solid blue. 7. To disconnect the coupler from the vehicle charge port, press the release button on the coupler, then pull the coupler away from the vehicle. Webasto Charging Systems, Inc. Doc ID 5913386 Page 9 of 18... -
Page 10: A Note On Auto-Restart
(GFI/GFCI). The charger will attempt to restart 15 minutes after this happens. After a fourth attempt to restart, the charger shuts down and the RED TROUBLE Indicator stays ON. If the fault persists, do not continue to try to charge your vehicle. Contact Webasto Customer Support (see page 3). - Page 11 Check and adjust your charging time preferences in The charger is not sync. charging the vehicle. If the vehicle is still not charging, contact Webasto Customer Support. Wait for the charger to return to standby. If the charger cycles for more than 2-3 minutes, The charger is auto- unplug the vehicle coupler.
- Page 12 Should the error persist after the ambient temperature is reduced and the control box is no longer in direct sunlight, contact Webasto Customer Support. There is an internal Non-recoverable If the error persists, contact Webasto Customer fault in the charger that fault Support. cannot be recovered.
-
Page 13: Appendix
NOTE: The images contained on pages 13-14 are for illustration purposes only. Your actual product may differ in appearance. The Turbo DX 2.0 comes with mounting screws in the box, and the wall-mounting bracket comes pre-installed and secured to the back of the control box (below left). - Page 14 #10 screw into the wall. 10.75 in (273 mm) 4. Carefully hang the control box bracket onto the screw heads and gently lower the control box to secure it. Doc ID 5913386 Webasto Charging Systems, Inc. Page 14 of 18...
- Page 15 Turbo DX™ 2.0 Plug-In Charger 5. Plug the grid cord into the power outlet – the control box will automatically turn ON. The Turbo DX 2.0 is now ready for charging an electric vehicle. Webasto Charging Systems, Inc. Doc ID 5913386...
-
Page 16: High Voltage Warning
Visually inspect the cable, charge coupler and charger module for WARNING damage before each use. Do not operate if any visual damage is apparent any- where, then contact Webasto Customer Support (page 3). ALWAYS position the charger cable and coupler to prevent those components WARNING from being driven over, stepped on, tripped over, damaged or stressed. -
Page 17: State Of California Proposition 65 Warnings
FCC compliance and the product will not be serviceable. SAFETY FEATURES The Turbo DX 2.0 Plug-In Charger is designed with your safety as the highest priority and includes the following safety features to protect against the risk of electric shock: •... - Page 18 Turbo DX™ 2.0 Plug-In Charger User Guide Webasto Charging Systems, Inc. 1333 S. Mayflower Ave., Suite 100 Monrovia, CA 91016 Corporate headquarters: Friedrichshafener Str. 9 82205 Gilching Germany Doc ID 5913386 Webasto Charging Systems, Inc. Page 18 of 18...
