Fitting the Bar & Chain (continued)
• Pay attention to the direction of rotation of the chain
(Fig. 6).
• Fit the chain cover and the relative nuts without
tightening them.
• Tension the chain by means of the tensioning screw
(L, Fig. 5).
• Hold the tip of the guide bar up and tighten the chain
cover nuts securely (Fig. 7). The chain should be taut
but turn freely by hand (Fig. 8). Wear gloves while
accomplishing this task.
• The chain is tensioned correctly when it can be
pulled upwards a few millimeters (Fig. 8).
