SBE 55 ECO Water Sampler
Document No.
SBE55ECO
Release Date:
2024-02-08
Version:
A
User manual
425-643-9866
seabird.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SBE 55 ECO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sea-Bird Scientific SBE 55 ECO

  • Page 1 User manual SBE 55 ECO Water Sampler Document No. SBE55ECO Release Date: 2024-02-08 Version: 425-643-9866 seabird.com...
  • Page 3: Table Of Contents

    Table of Contents Section 1 Safety information ......................3 1.1 Hazard information........................3 1.2 Equipment labels.......................... 3 Section 2 Specifications ........................5 2.1 Mechanical and electrical ......................5 2.2 Cables and connectors ......................6 Section 3 System description ......................9 3.1 Autonomous operation.........................
  • Page 4 Table of Contents 9.1 Charge NiMH batteries....................... 35 9.2 Clean bulkhead connectors......................37 9.3 Remove and replace latches...................... 38 9.4 Storage............................39 9.5 Spare parts list........................... 39 Section 10 Reference ........................41 10.1 Command descriptions......................41 10.1.1 Status..........................41 10.1.2 Other commands......................42 10.1.3 ECO commands......................
  • Page 5: Section 1 Safety Information

    Section 1 Safety information Please read this entire manual before this equipment is unpacked, set up, or operated. Pay attention to all danger, warning, and caution statements. Failure to do so could result in serious injury to the operator or damage to the equipment. D A N G E R Indicates a potentially or imminently hazardous situation which, if not avoided, will result in death or serious injury.
  • Page 6 Safety information EFUP: Hazardous material exists over the threshold of GB/T 26572.2011. The number in the center of the symbol is the Environmentally Friendly Use Period as specified by SJ/T 11364-2014, China's marking for the Restriction of the Use of Hazardous Substances in Electrical and Electronic Products. This product should be recycled after its environmentally friendly use period.
  • Page 7: Section 2 Specifications

    Section 2 Specifications 2.1 Mechanical and electrical Rated depth Plastic: 600 m Optional titanium: 3500 m Materials Frame: 316 stainless steel Latch assembly: titanium, plastic, other corrosion-resistant components Number of bottles 3 or 6, four liter capacity Dimensions Diameter: 67.3 cm, height: 94.2 cm Weight in air 30 kg 19plus, 6 empty bottles: 60 kg...
  • Page 8: Cables And Connectors

    Specifications 2.2 Cables and connectors Table 1 Electronics Control Module Connectors Table 2 Connector 1 Contact Function MCBH2MP Ground (-) Power (+) Table 3 Connector 2 Contact Function MCBH6MP Ground TX from PC RX to PC Table 4 Connectors 3 and 4 Latch connector 1 Contact Function...
  • Page 9 Specifications Table 5 Connector 5 Contact Function MCBH6MP Ground TX from sensor RX to sensor + 15 V in Table 6 Data I/O cable Table 7 Data I/O extension cable Table 8 Test cable, SBE 33 to SBE 55 Table 9 SBE 55 sea cable extension...
  • Page 10 Specifications Table 10 SBE 55 to CTD cable Table 11 SBE 55 to latch cable...
  • Page 11: Section 3 System Description

    Band clamps are used to attach the bottles. The SBE 55 ECO Water Sampler is designed for continuous data collection in coastal and estuarine waters, and large lakes. The SBE 55 can be used with an SBE 19, 19plus, 19plus V2, 25, 25plus, or 49 CTD.
  • Page 12: Real-Time Operation

    System description 3.2 Real-time operation The Electronics Control Module (ECM) includes a winch cable connector for real-time use. To change from autonomous to real-time operation, connect the winch cable to the ECM and the SBE 33 Carousel Deck Unit to AC power and winch slip rings. The ECO is then powered and controlled by the SBE 33.
  • Page 13: Section 4 Assemble Carousel

    Section 4 Assemble carousel This section gives details to attach bottles, the Electronics Control Module (ECM), and other sensors to the SBE 55 frame, and how to set lanyards. 4.1 Attach bottles Do the steps below to attach the four-liter water bottles to the SBE 55 frame. The frame has top and bottom attach points for each bottle.
  • Page 14: Assemble Lanyards

    Assemble carousel ® 3. Make sure to put a layer of Teflon or electrical tape on the inside of the band clamps to isolate the clamps from the sensor housing. 4. Use two band clamps to attach the CTD to the blocks. For a three-bottle system, mount the ECM and CTD off-center to more equally distribute the weight.
  • Page 15 Assemble carousel 4. Pull the bottle top cap toward the latch. Thread the upper lanyard over the oblong- shaped frame, and attach the upper lanyard to the latch. 5. Push against the trigger until it there is a click, which sets the release mechanism. 6.
  • Page 16 Assemble carousel...
  • Page 17: Section 5 Get High Quality Data

    Section 5 Get high quality data 5.1 Water samples on upcast For typical applications, CTD data from a downcast is recommended because the CTD is pointed so that the intake can sample water before the rest of the package causes the water to mix and can have an effect on water temperature.
  • Page 18 Get high quality data...
  • Page 19: Section 6 Real-Time Operation

    Section 6 Real-time operation W A R N I N G Dangerous voltages over 75 volts are present inside the instrument even after external power is removed. Only qualified personnel may do the servicing. W A R N I N G If the user thinks that a sensor has water in the pressure housing: Disconnect the sensor from any power supply.
  • Page 20 Real-time operation • Set the "Bottle to Fire" switch to 00 then push Reset. • To fire bottles in random order, set the "Bottle to Fire" switch to the bottle to fire and push Fire. • To fire bottles in sequential order, set the "Bottle to Fire" switch to 99 and then fire the first bottle.
  • Page 21: Section 7 Autonomous Operation

    Section 7 Autonomous operation W A R N I N G Dangerous voltages over 75 volts are present inside the instrument even after external power is removed. Only qualified personnel may do the servicing. W A R N I N G If the user thinks that a sensor has water in the pressure housing: Disconnect the sensor from any power supply.
  • Page 22: Seaterm Software

    Autonomous operation 15. Select the Bottle Closure Pressure or Times tab and select the "Number of Bottles to Close" and select the "Closure order." 16. Push OK. 17. Exit SeatermAF. 18. Disconnect the I/O cable from the SBE 55 extender cable and attach a dummy plug and lock collar on the end of the extender cable.
  • Page 23: Configuration Options

    Autonomous operation Closure Show all auto fire parameters and auto fire status. Parameters Set Time Set date and time. Accuracy is ±25 milliseconds of time on connected PC. 19plus: MMDDYY= Note that this function does not work with SBE 19 or 25. Use the ST command HHMMSS= to set the date and time.
  • Page 24: Communication Setup Tab

    Autonomous operation area. These pressures determine when to close bottles. The configuration file must agree with the actual sensor configuration, or the ECO cannot process data correctly. • A new or manufacturer-calibrated CTD has a configuration file as known by the manufacturer.
  • Page 25: Close On Downcast

    Autonomous operation "Pressure change to enable upcast logic," so that samples are collected even if the ECO did not go as deep as specified. 7.3.3.2 Close on downcast If "Close on downcast" is selected and there is a check in the box for "Bottom bottle closure enabled,"...
  • Page 26: Upload And Header Options Tab

    Autonomous operation 3. Enter the "Bottle position." These values can be in any order. 4. Enter the "Closure pressure (db)" values. • If bottles are closed on upcast, the pressures must decrease from closure 1 to the last closure. • If bottles are closed on downcast, the pressures must increase from closure 1 to the last closure.
  • Page 27: Configure And Verify System Operation

    Autonomous operation • Verify that the date and time are correct. If not, enter DateTime=mmddyyyyhhmmss and push Enter. Select Status on the Toolbar menu to make sure the new date and time were transmitted to the ECO. • Verify that the SBE 55 is not armed. If it is, enter DA (disarm) and push Enter. The ECO must be disarmed before the bottle closure information from the Configuration Options is accepted.
  • Page 28: Deploy System

    Autonomous operation The software will prompt the user to save the system settings to the .psa file if they were changed. 7.5 Deploy system Deployment notes: • Make sure to transmit data from the ECO before each deployment, because the ECO overwrites any data in the memory.
  • Page 29: Transmit Data

    Autonomous operation 4. Make sure that the hardware and cables are attached correctly. 5. Deploy the system. 7.6 Transmit data Make sure that the data stored in the ECO is transmitted between deployments because any stored data will be overwritten. 1.
  • Page 30: Eco Data Formats

    Autonomous operation SeatermAF automatically adds the .afm file extension, sends the DD command to transmit data, and writes the response to that file. 7.6.2 ECO data formats Use Upload on the toolbar or from the menu to transmit data from the ECO. Data is written to a file with an .afm extension.
  • Page 31: Transmit Data From The Sbe 25Plus

    Autonomous operation the Configure menu and that the communication setting were entered correctly on the Communication Setup tab in the Configuration Options dialog box. 2. Push Upload on the toolbar to transmit data from the CTD. SeatermAF sends DS and DH commands, shows the responses, and writes this information to the transmitted file.
  • Page 32: Ctd Data Formats

    Autonomous operation SeatermAF transmits data in blocks and calculates a checksum at the end of each block. If a block fails the checksum verification, SeatermAF reduces the block size by half and tries to transmit the data again. 8. Push Upload. The status bar at the bottom of the window shows the transmit status.
  • Page 33: Section 8 Recover System And Process Data

    Section 8 Recover system and process data W A R N I N G If the user thinks that a sensor has water in the pressure housing: Disconnect the sensor from any power supply. Put on safety glasses and make sure that the sensor is pointed away from the body and other people.
  • Page 34 Recover system and process data Program setup file This is the directory in which all information from the File setup tab and the Data Setup tab is stored. • Push Open to select a different .psa file. • Push Save or Save As to save the current settings. •...
  • Page 35: Data Setup Tab

    Recover system and process data 8.1.2 Data setup tab Put a check in "Process scans to end of file" box to process all data. If there is no check in this box, enter the "Scans to process." Enter the number of "Scans to skip over" to exclude the first scans of a file.
  • Page 36: Bottle Summary Module

    Recover system and process data 8.2 Bottle summary module In the Run menu of the Data Processing software, select "Bottle Summary." The File Setup tab is similar to the tab in "Data Conversion." The input files for the bottle summary are the .ros file and the .xmlcon or .con file.
  • Page 37: Section 9 Maintenance

    Section 9 Maintenance Flush the entire ECO with fresh water after each cast, and flush the inside and outside of all the bottles to prevent salt deposits on the tubing that closes the bottles. Some ECO systems have a zinc anode attached to prevent corrosion. Examine the anode at regular intervals and replace when it is worn.
  • Page 38 Maintenance 3. Remove any water on all of the O-ring surfaces with a lint-free cloth or tissue. 4. Keep the end flange and make sure to protect the O-ring from contamination or other damage. 5. Remove the battery pack from the housing: a.
  • Page 39: Clean Bulkhead Connectors

    Maintenance d. Make sure that the screws are fully tightened or the battery power will be intermittent. 13. Carefully put the end flange onto the housing and screw the end flange into place. use a wrench to make sure the cap is tightly installed. 14.
  • Page 40: Remove And Replace Latches

    Maintenance Use a finger to put a small quantity (approximately 1 cm in diameter) of silicone grease on the socket end of the connector and push as much of the lubricant as possible into each socket. Do not use too much lubricant, as that will prevent a good seal.
  • Page 41: Storage

    Maintenance b. Pull the trigger horizontally from the latch assembly. Put a mark on the trigger to make it easier to assemble again. 3. To install the trigger on the latch assembly, insert the trigger on the assembly. 4. Install the two socket-head screws to attach each trigger to the latch assembly. 5.
  • Page 42 Maintenance 233587 water bottle cap 233575 lanyard guide D-ring, attaches to band clamp and routes middle lanyard 30379 ECO sampler bottle clamp, 2 per bottle 50430 ECO attachment and lanyard kit for 801714 bottle, includes 233575 lanyard guide D-ring, attaches to band clamp and routes middle lanyard 30664 Nicopress oval sleeves for lanyard 311396 2 mm OD monofilament for lanyard 30772 brass snap hook for lanyard...
  • Page 43: Section 10 Reference

    Section 10 Reference 10.1 Command descriptions Verify that the PC communicates with the ECO, not the CTD. When connected to the ECO, SeatermAF shows an A> prompt. When connected to the CTD through the ECO, SeatermAF shows an S> prompt. If necessary, select Connect ECO on the toolbar in SeatermAF.
  • Page 44: Other Commands

    Reference 10.1.2 Other commands Table 12 Date and time DateTime=x x=realtime clock date and time, mmddyyyyhhmmss Arm before deployment to enable the ECO to take water samples. Disarm to disable water samples. The CTD can still collect data. Table 13 Autofire Enable auto fire to close bottles.
  • Page 45: Make Lanyards

    Reference Command to ECO Description Fire position x, where xis in ASCII Position # Command Position # Command #SNx #SN1 #SN4 #SN2 #SN5 #SN3 #SN6 Command to ECO Description Set ECO to CTD communication baud rate x Baud rate Command #SB0 #SBx 1200...
  • Page 46: Make Middle Lanyard

    Reference 4. Put one end of the monofilament through the Nicopress sleeve. Put the other end through the sleeve from the opposite direction. Align the marks of one side of the sleeve 5. Crimp the sleeve in two places. 6. Cut any extra length of monofilament at a 45 degree angle for a smooth end. 7.
  • Page 47 Reference 8. If the bottle has a handle, put the end of the middle lanyard through the handle to prevent the loss of either end cap if the rubber tubing between the end caps breaks. 9. Put the end of the middle lanyard through a Nicopress sleeve. 10.
  • Page 48: Make Upper Lanyard

    Reference 10.2.3 Make upper lanyard The length of the upper lanyard depends on the size and type of bottle used on the carousel. It may take several tries to make the correct length. 1. Cut a length of monofilament and make two marks 1 inch from each end. 2.
  • Page 49: Section 11 General Information

    Section 11 General information Revised editions of this user manual are on the manufacturer's website. 11.1 Service and support The manufacturer recommends that sensors be sent back to the manufacturer annually to be cleaned, calibrated, and for standard maintenance. Refer to the website for FAQs and technical notes, or contact the manufacturer for support at support@seabird.com.
  • Page 50 General information...
  • Page 52 Sea-Bird Electronics 13431 NE 20th Street Bellevue WA 98005 U.S.A. (425) 643-9866 © Sea-Bird Electronics, Inc., 2024. All rights reserved. *SBE55ECO*...
