7400 / 7478 - Buggy vorne

7401 / 7479 - Buggy hinten

7471 - Truck

15.8MM

22.0MM

7414

7413

Front upper tie rod assembly

Steering gear tie rod assembly

23.30MM

19.8MM

7415

7415

Rear tie rod assembly

Steering tie rod assembly
