Lumena OLY800B-W User Manual

PLEASE READ THESE INSTRUCTIONS CAREFULLY PRIOR TO INSTALLATION / MAINTENANCE

SPECIFICATIONS

Wattage: 3.5W
Lamp: In-built Epistar LED Chips 10 *18 mil (120˚ Beam Angle)
Colour Temperature: 3000K (Warm White) / 6000K (Daylight White)
Lumen Output: Approx. 420 lm
LED Life Expectancy: up to 50,000 hours
Sensor: Light / Charge Sensor
IP Rating: IP65
Battery Type: Lithium - LiFePO4 6.4v/5000mAh (replaceable)
Battery Charge Time: 6-8 hrs full sunshine (approx.)
Max Illumination Time at Full Charge: Up to 23hrs
Solar Panel: 9v / 5.5W Monocrystalline Solar Panel – Grade A
Materials: 6063 Die Cast Aluminium & Polycarbonate
Weight: 3.3KG (approx.)
Mounting: Internal Surface Mount
Lighting Function:1hr 100% + 2hrs 80% + 2hrs 50% + 9hrs 30%
Working Temperature: -25˚C ~ 55˚C
Included: Bollard, Rubber Bung, Anchor Bolts
UK REGISTERED DESIGN: 6089624
•
If a fitting is found to be damaged, cease use immediately.
•
The unit may get warm whilst on for a period of time.
•
Always take care when installing your solar light.
•
Fitting must be mounted to a solid surface or using relevant anchor bolts / J-Bolts
•
This Solar Light will not charge correctly if the panel is behind glass or artificial light is used.
•
Ensure the waterproof bung is in place at all times, other than when turning the unit on.
•
Due to temperature difference in and outside the fitting, condensation may be present internally but will not affect use.
CLEANING & MAINTENANCE:
Occasional cleaning and care is recommended for this product. Wipe with a soft, slightly damp cloth to remove any surface dirt.
To maintain efficiency, specifically clean the solar panel and polycarbonate lens on a regular basis. Also, keep the solar panel free
of debris and snow to prevent reduced battery life or malfunction. Do not use abrasive cleaners or a lot of water as this could
damage the fitting. Please refer to our website for more information on the best way to clean different materials.

RETURNS:

rd
If purchased from a 3 party, please contact your supplier. If purchased direct, contact us by phone or email:
Lumena Lights Ltd, Centre 33 Long March, Daventry, NN11 4NR
Our full returns policy is available on our website.
Waste Electrical Products should not be disposed of with household waste. Please check with your local authority or contact us
for more information. Please recycle packaging whenever possible.
THANK YOU FOR YOUR PURCHASE
Full product range & more information: www.lumenalights.com
OLYMPIA Professional Solar Post Light
800mm

WARNINGS

Tel: +44 1327 871161
Producer Registration Numbers: WEE/KC3440XY / BPRN0843
USER MANUAL
External Base
260mm
90mm
✔✔✔✔✔
5 YEAR
GUARANTEE
see website for
more details
185mm
Email: sales@lumenalights.com
