www.heylo.de
Stand: 05/2020
Art.-Nr. 1 110 890
BEDIENUNGSANLEITUNG
USER MANUAL
DE
EN
PF 3500
Luftreiniger
Air Filter
DER EXPERTE FÜR PROFIS
LUFTREINIGER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PF 3500 and is the answer not in the manual?

Questions and answers

Related Manuals for Heylo PF 3500

Summary of Contents for Heylo PF 3500

  • Page 1 Stand: 05/2020 Art.-Nr. 1 110 890 DER EXPERTE FÜR PROFIS PF 3500 LUFTREINIGER BEDIENUNGSANLEITUNG USER MANUAL Luftreiniger Air Filter...

  • Page 2: Table Of Contents

    Type: PowerFilter PF 3500 (patented) HEYLO GmbH of Im Finigen 9, D-28832 Achim, Germany, declares that, if they are fitted, maintained and used in conformity with the operating instructions and the generally accepted engineering standards, the machines mentioned are in keeping with the fundamental safety and health requirements of the “Machine Ordinance” as well as with the regulations and standards mentioned hereinafter.

  • Page 3: General Aspects

    The manufacturer shall not be liable for any damage and/or consequential damage resulting. PF 3500 is a mobile air filtration unit. The air drawn from the environment and is passed through a two-stage filtration system. In the process the filter collect particles from the air, such as coarse and fine dusts, mould spores, pollen, pet hair and smoke.

  • Page 4: Safety Guidelines

    Keep away from children: Do not allow children to play with or in the vicinity of the unit. Electric connection: Air filter, such as PF 3500, have been designed for operation on 230 V / 50 Hz. The connection has to be fused with 16 A.

  • Page 5: Putting Into Operation / Operation

    (5) Putting into operation / operation 1. Attention: The device can only be switched on when the main filter is inserted and the fan is set up correctly. A safety switch ensures that the device is switched off while changing the filter 2.

  • Page 6: Application / Fields Of Operation

    (BG-Bau in Germany) requires a 15-fold air exchange. In order to ensure maximum performance of PF 3500 and to achieve a correct display of the filters used, the air filter has to be operated at maximum fan stage. If suction or exhaust hoses are used, all hose connections have to be fitted with hoses (exhaust air two hoses of 205 mm each, and on the suction side three hoses of 205 mm - accessories see chapter (11)).
  • Page 7 1. Adapter sheets for hose connections (diam. 200 mm) can be fitted to the three suction sides (A) of the unit. Thus, PF 3500 can be set up outside of the enclosed area as well in order to draw off by means of suction hoses and/or local removal in the black area.

  • Page 8: Filter / Change Of Filter

    (7) Filter / change of filter Filter system: The air filter PF 3500 uses a two-stage filter system which uses the latest HEPA filter technique. The first filter stage consists of three pre-filters and the main filter stage of one robust HEYLO drum filter in various filter classes.
  • Page 9 Change of filter indicator: When the signal is sounded, the pre-filter has to be replaced and the main filter has to be vacuumed (if the type of dust is not known, use safety vacuum cleaner of dust class H) wearing personal protection equipment. Please remember to have sufficient filter material available in order to prevent interruption of the work.
  • Page 10 After use After every use PF 3500 has to be cleaned thoroughly before taking it out of the refurbishment area. This is done by using a safety vacuum cleaner and by moist wiping. Compressed air is not permitted here.
  • Page 11 Types of filter Pre-filter: Z line pre-filter (coarse dust filter) class G4 in conformity with EN 779 ▪ Pre-filter for the main filter ▪ Filter for especially coarse dust of up to 3 µm ▪ Separation efficiency 85 to 98 per cent at 10 µm and 30 to 55 per cent at 1 µm ▪...

  • Page 12: Installation Guidelines

    PF 3500. Decommissioning and disposal of the unit HEYLO units have been designed for many years of operation. If it has to be disposed of, the competent legal regulations have to be observed in environmentally-gentle manner.

  • Page 13: Maintenance / Fault Finding

    Replace micro fuse (6.3 A) not functional. (cf. chapter on operation). (11) Optional accessories Description HEYLO Art. No. Pre-filter - coarse dust G4 (pack of 3) 1 110 926 Pre-filter - coarse dust G4 for pre-filter cassette 1 110 834...

  • Page 14: List Of Spare Parts

    (12) List of spare parts Item HEYLO Art. No. Description 1631701 Base box 1631703 Cover 1631704 Wheel receiver 1631796 Switch panel 1631707 Pressure monitor unit 1631708 Handle 1631709 Axle 1631730 Filter frame 1631731 Bottom grip 1631780 Radial fan with holder...

  • Page 15: Wiring Diagram

    Prof (13) Wiring diagram...
  • Page 16 Fax +49 (0) 42 02 – 97 55 97 E-Mail: info@heylo.de Mieten Sie HEYLO-Produkte Hire HEYLO products Für Ihre Baustelle, Produktion oder Event über das HEYLO-Miet-Netzwerk: For your construction site, production facility or event via the HEYLO rental network: www.heylo-mietservice.de HEYLO GmbH Im Finigen 9 28832 Achim info@heylo.de...
