Summary of Contents for Lyngsoe Systems Rx/Ex XR30
- Page 1 Lyngsoe Systems RFID Rd/Ex XR30 RFID Rx/Ex XR30 User Guide Revision - – August 07, 2009 950213-.doc Page 1 of 5...
- Page 2 Lyngsoe Systems RFID Rd/Ex XR30 1. General RFID Rd/Ex XR30 is basically an RFID Exciter EX30 which incorporates also a Reader RD23. It can operate as an RFID Exciter and Reader to excite RFID Tags and to receive their UHF messages.
- Page 3 Lyngsoe Systems RFID Rd/Ex XR30 receptacle body – terminals 1 for (+24V), terminal 3 for (GND) voltage and terminal 2 (middle) for the ground. Remove the cover. Plug in the power connector into any of the corresponding headers on the RDS230. The POWER LED (green) goes ON.
- Page 4 Lyngsoe Systems RFID Rd/Ex XR30 Cover RS485 Cable Power Cable Fig 2-3 Cover installation for XR30 RS485 Connections For the RS485 connection use a standard Cat5 Ethernet cable and RJ45 plug. Crimp the connector using the recommended tool and the following color scheme: pin 1 - Wh/Or; pin 2 –...
- Page 5 Lyngsoe Systems RFID Rd/Ex XR30 serial communication program like Procomm, through a serial communication link type RS485. There are several specific commands to configure or to query the XR30 parameters values. XR30 has a unique address called NetId. The NetId is an integer in the range 0 to 127 and is a good practice to clearly mark it on the front label in the designated area.
