Large View Auto-Darkening

Welding Helmet with Light & Fan

Owner's Manual

WARNING:

Read and understand all instructions, warnings, and cautions before using this

product. Failure to follow the instructions, warnings, and cautions may result in serious personal

injury and/or property damage.

Item #113872

SAVE THESE INSTRUCTIONS

Table of Contents

Need help?

Do you have a question about the 113872 and is the answer not in the manual?

Questions and answers

Summary of Contents for Klutch 113872

Page 1 Welding Helmet with Light & Fan Owner’s Manual WARNING: Read and understand all instructions, warnings, and cautions before using this product. Failure to follow the instructions, warnings, and cautions may result in serious personal injury and/or property damage. Item #113872 SAVE THESE INSTRUCTIONS...
Page 2 Thank you very much for choosing a KLUTCH product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: Purchase Date: Save the receipt, warranty, and this manual. This product is designed for certain applications only. The distributor cannot be responsible for issues arising from modification or use of this product in an application for which it was not designed.
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Packaging Contents ..........................4 Technical Specifications ........................4 Important Safety Information ......................5 Specific operate warning ........................7 Before Use ............................. 8 Operating Instructions .......................... 8 After Use ............................. 12 Maintenance............................12 Troubleshooting ..........................12 Parts Diagram .............................
Page 4: Intended Use
Intended Use The KLUTCH Large view Auto-Darkening Welding Helmet designed with LED light and fan to provide comfortable user experience and protect the eyes and face from sparks, splatter, and harmful radiation under normal welding conditions. The Large view Auto-Darkening Filter automatically changes from a clear state to a dark state when an arc is struck, and it returns to the clear state when welding stops.
Page 5: Important Safety Information
Shade Guide Chart Sensitivity Setting Guide Recommended Sensitivity Settings Stick Electrode Mid-Range Short Circuiting (MIG) Low/Mid-Range Pulsed & Spray (MIG) Mid-Range Gas Tungsten Arc (TIG) Mid/High-Range Plasma Arc Cutting/Welding Low/Mid-Range Grind Position – Far Right (Clockwise) Grind Mode Important Safety Information ⚠WARNING ...
Page 6 ⚠WARNING WORK AREA SAFETY  Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit. Cluttered, wet, or dark work areas can result in injury. Using the product in confined work areas may put you dangerously close to cutting tools and rotating parts. ...
Page 7: Specific Operate Warning
⚠CAUTION WELDING HELMET USE AND CARE  Do not force the welding helmet. Products are safer and do a better job when used in the manner for which they are designed. Plan your work and use the correct product for the job. ...
Page 8: Before Use
Before Each Use ⚠WARNING  Before welding or cutting, ensure the darkness range of this helmet offers enough eye protection for your use.  Inspect lens before each use. Pitted or scratched lens plates reduce vision clarity, severely reduce impact protection and should be replaced immediately to prevent injury. ...
Page 9 Before Welding The Auto-Darkening Welding Helmet comes ready for use. Prior to first use, remove the protective film from both sides of the lens (if not already done), adjust the position of the headband, select the correct shade number for the welding application, and test the helmet for proper operation as described below.
Page 10 Time Delay Setting At the moment the welding operation is started, the filter screen automatically changes from clear to dark. The operator can set the delay time by turning the Delay Control Knob (Fig. B - 3). Important: Test the helmet auto-darkening filter lens before welding. While wearing the helmet, briefly strike an arc, keeping your face and eyes turned slightly away, and to one side.
Page 11 Battery Change When the low battery indicator lights on, the battery only 2 - 3 days life remain. Please replace with CR2450 lithium battery immediately before using (1 required). Battery Indicator Test Button Battery Cartridge Fig. D Light and Fan Operating Fan switch: when you push the button once, the fan will work at a low air volume.
Page 12: After Use
After Each Use After a welding job is complete, turn the dial to Grind Mode on the helmet and store the helmet in a dry and dark environment. Maintenance 1. Maintain the tool with care. A tool in good condition is efficient, easier to control and will have fewer problems.
Page 13: Parts Diagram
Parts Diagram Page 13 of 16...
Page 14: Replacement Parts
Part Number Part Description Quantity Helmet Outer Protection Lens Cover Angle Adjust Knob Grind / Shade Adjust Knob Inner Protection Lens Cover Test Button Sensitivity Adjustment Knob Mode Control Switch Battery Cap Delay Control Knob LED Light Headgear Adjust Bolt Segmental Position Plate Angle Adjustment Plate Block Washer...
Page 15: Limited Warranty
Limited Warranty Northern Tool and Equipment Company, Inc. ("We'' or '"Us'') warrants to the original purchaser only ("You'' or “Your”) that the IRONTON product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of 24 months limited parts / No labor from date of purchase.
Page 16 Distributed by Northern Tool and Equipment Company, Inc. Burnsville, Minnesota 55306 NorthernTool.com Made in China Page 16 of 16...
