Summary of Contents for FRIEND FL-8214D
- Page 1 Model No. FL-8214D Installation, Operation Clear Floor Two Post Lift， and Parts Manual Manual Release Lifting Capacity 9200LB Distributed by...
- Page 2 Installation, Operation and Parts Manual FL-8214D Read this entire manual carefully and completely before installation or operation of the lift. INDEX 1. Important safety instructions……………………………………………………………………..….…3~4 1.1 Important notices 1.2 Qualified personnel 1.3 Danger notices 1.4Training 1.5 Warning signs 2. Overview of the lift………………………………………………………………………………………..….5 2.1 General descriptions...
-
Page 3: Important Safety Instructions
1.1 Important notices FRIEND will offer one-year's quality warranty for the whole machine，during which any quality problem will be properly solved to the user's satisfaction. However, we will not take any responsibility for whatever bad consequence resulted from improper installation and operation, overload running or unqualified ground condition. -
Page 4: Warning Signs
Installation, Operation and Parts Manual FL-8214D a. Disconnect the power source; b. Empty the oil tank; c. Lubricate the moving parts with hydraulic oil. 1.4 Training Only these qualified people, who have been properly trained, can operate the lift. We are quite willing to provide professional training for the users when necessary. -
Page 5: General Descriptions
Installation, Operation and Parts Manual FL-8214D OVERVIER OF THE LIFT 2.1 General descriptions This two- post lift is composed of posts, carriages, lifting arms, cylinders and motor unit, etc. The lift is driven by an electro-hydraulic system. The gear pump delivers hydraulic oil to oil cylinders and pushes upwards its piston. -
Page 6: Technical Data
Installation, Operation and Parts Manual FL-8214D the safety teeth will automatically and firmly bite with the safety rod in the posts. Therefore, no slipping will happen in case the hydraulic system beaks down. Safety structure 2.2 Technical data Model Lifting capacity... -
Page 7: Installation Instructions
Unfold the package and check if any parts missed as per Annex 1. Do not hesitate to contact us in case any parts missed, but if you do not contact us and insist installing upon the lack of some parts, FRIEND as well as our dealers will not bear any responsibility for this and will charge for any parts subsequently demanded by the buyer. - Page 8 Installation, Operation and Parts Manual FL-8214D Step 4: Connect extending posts and cross beams. 1. Firstly have the extending post firmly secured on to the body posts. This is only necessary when your lift is ordered with extending posts. 2. Unfold the package and decide on which post the power unit will be mounted.
- Page 9 Installation, Operation and Parts Manual FL-8214D Step6: Install cross beam and hang on the top roof protection bumper. Step7: Connect steel cables. 1. Route and fix according to the following diagram of steel cable connection. 2. Raise carriages on both sides approximately 800mm above the ground. Carriages must be on the same height from the floor.
- Page 10 Installation, Operation and Parts Manual FL-8214D Step9. Connect oil hoses NOTE: make sure the connectors and hose are clean. Step10: Connect wires. Attention: Only licensed electricians are allowed to carry out electrical connection. Mount the control box on to the power side post.
- Page 11 Installation, Operation and Parts Manual FL-8214D POWER SIDE POST OTHER POST Step11: Install lifting arms. Connect the lifting arms and the carriage by shafts. Step12: Put oil inside. Oil tank volumn is 10L. Normal work should have 80% oil inside the tank.
- Page 12 4.1.3 The machine shall not lift or lower an automobile if its center of gravity is not positioned midway of the lifting arms. Otherwise, the FRIEND as well as our dealers will not bear any responsibility for any consequence resulted thereby.
-
Page 13: Troubleshooting
Installation, Operation and Parts Manual FL-8214D Connect the power supply as per requirements on the nameplate attached, and switch on. Press the”UP”button on the control box until pads of lifting arms touched the prop-position of vehicle. Keep on raising the vehicle to let it have a bit clearance from the ground and check again its stability. -
Page 14: Maintenance
Installation, Operation and Parts Manual FL-8214D The overflow valve is not adjusted to the right position. Adjust it. The hydraulic oil is too hot ( above 45°）. Change the oil. The seal of the cylinder is abraded. Replace the seal. - Page 15 Installation, Operation and Parts Manual FL-8214D ·Check the amount of oil left in the oil tank. Oil is enough if the carriage can be raised to highest position. Otherwise, oil is insufficient. ·Check whether expansion bolt s firmly screwed. 6.3 Monthly checking items ·Check whether expansion bolts are firmly screwed.
- Page 16 Installation, Operation and Parts Manual FL-8214D Name Drawing#/Spec. Property Spring washer Standard Standard Standard Circlip Standard Φ38 Expansion bolt Standard M18*180 Hex head full swivel screw Standard M14*25 Hex head full swivel screw Standard M14*30 Spring washer Standard Flat washer...
- Page 17 Installation, Operation and Parts Manual FL-8214D Annex2, Overall diagram...
- Page 18 Installation, Operation and Parts Manual FL-8214D Annex3, Floor plan...
- Page 19 Installation, Operation and Parts Manual FL-8214D Annex4, Wiring diagram Single phase...
- Page 20 Installation, Operation and Parts Manual FL-8214D Three phase Annex5, Hydraulic working system...
- Page 21 Installation, Operation and Parts Manual FL-8214D Drive cylinder Assistant cylinder Manual unloading valve Throttle valve Motor Coupling Gear pump Single-way valve Overflow valve 10. Anti-surge valve 11. Cushion valve Description Motor Hydraulic block Overflow valve Fitting Cushion valve Absorbing oil pipe...
- Page 22 Installation, Operation and Parts Manual FL-8214D Annex 6，Separate diagrams for the lift...
- Page 23 Installation, Operation and Parts Manual FL-8214D Annex6, Separated drawings for the lift Name Drawing#/Spec. Property Note Steel cable L=10870mm FL-8214-A6 Assembly Hex nut M16 GB/T610-2000 Standard Expansion bolt M18*180 Standard Name Drawing#/Spec. Property Note rubber oil hose L=9960（mm） Assembly rubber oil hose...
- Page 24 Installation, Operation and Parts Manual FL-8214D Name Drawing#/Spec. Property Note Cover plate FL-8224-A1-B5 Q235A GB/T95-1985 Flat washer M6 Standard GB/T818-2000 Cross socket cap head screw M6*10 Standard GB/T894.2-1986 Circlip 25 Standard SF-1 Bearing 2512 Standard Annex Down pulley FL-8224-A1-B2 Q235A...
- Page 25 Installation, Operation and Parts Manual FL-8214D Item Spec. Note Power switch LW26GS-20/04 Button AR22FOR-11W Power indicator AD16-22G AC/DC 24V Same look as item 7 Transformer JBK-40VA220V-24V Transformer Same look as item 7 JBK-40VA230V-24V Transformer Same look as item 7 JBK-40VA240V-24V...
- Page 26 Installation, Operation and Parts Manual FL-8214D Spare parts list – for the mechanical system Name Drawing#/Spec. Property Note Slider FL-8224-A3-B6 Nylon 1010 Rubber lifting pad FL-8224-A7-B3-C4 Rubber O-seal ring (Inside)23.6*3.55 Y- seal ring KD 63*48*10 Anti–dust ring DHS 40*48*5/6.5...
