InnoLux MR19 Service Manual

Hide thumbs

Advertisement

Quick Links

MR19
Service Manual
Copyright
Copyright 2009 Innolux Display Corp. Ltd
All Rights Reserved
This manual may not, in whole or in part, be copied, Photocopied, reproduced, translated, or converted to any
electronic or machine readable form without prior written permission of Innolux Display Corp. Ltd.
MR19 Wide Service Manual
Service Manual
LCD Monitor MR19
- 0 -

Advertisement

loading
Need help?

Need help?

Do you have a question about the MR19 and is the answer not in the manual?

Questions and answers

Related Manuals for InnoLux MR19

Summary of Contents for InnoLux MR19

  • Page 1 All Rights Reserved This manual may not, in whole or in part, be copied, Photocopied, reproduced, translated, or converted to any electronic or machine readable form without prior written permission of Innolux Display Corp. Ltd. MR19 Wide Service Manual - 0 -...

  • Page 2: Table Of Contents

    Table of Contents Important Safety Notice ..................02 01 Product Specification ..................03 02 Flat Panel Specification ..................29 03 Exploded Diagram ....................59 04 Troubleshooting....................61 05 Spare Parts List ....................69 06 Schematics and Layouts..................73 07 Assembly and Disassembly ................88...

  • Page 3: Important Safety Notice

    MR19 Service Manual Important Safety Notice 1. Safety precautions This monitor is manufactured and tested on a ground principle that a user’s safety comes first. However, improper usage or installation may cause damage to the monitor as well as to the user.

  • Page 4: Product Specification

    01 Product Specification 1. General: MR19 series LCD monitor is designed with a screen 19” SXGA+ TFT LCD panel, LVDS interface, RGB analog and digital input(option). It featured with embedded universal AC power supply. This monitor can support maximum resolution up to 1280x1024@60Hz.
  • Page 5 MR19 Service Manual 2. Operation Specifications The unit should suffer no visible cosmetic damage and should operate with no degradation in display quality during exposure to the operating conditions and after exposure to the non-operating conditions, in any sequence. 2.1 Environmental conditions...
  • Page 6 MR19 Service Manual AC input frequency rating 100~240Vac 50~60Hz 100Vac 1.0A AC Input Current 240Vac 0.6A 115 V AC cold star,25°C <35A Inrush Current See Note1 230 V AC cold star,25°C <70A DC output full loading ≥75% Regulator Efficiency Before each test, the buck capacitor needs to be discharged.
  • Page 7 MR19 Service Manual H-sy V-sy Status Video Power Power On（with audio） active ≤34W Blue blanked < 1W Amber Power Saving blanked < 1W Amber blanked < 1W Amber Power Off < 1W 3.2 Backlight Power Supply Items Specification Panel LGD LM190E08 panel...
  • Page 8 MR19 Service Manual 3.3 Input / Output Signal Specifications Video signals 3.3.1 Note Items Condition Spec 15 pin D-Sub ● Monitor side should be Color: BLACK blue right angle. Length: 1800 20 mm Signal Cable DVI-D(option) NO DVI cable in carton...
  • Page 9 MR19 Service Manual 1280*1024@75Hz 79.976 75.025 135.000 WXGA WSXGA+ IBM MODES 720x400@70Hz 31.469 70.087 28.322 MAC MODES 66.667 30.24 640*480@66.7Hz SVGA 832*624@74.55Hz 49.722 74.55 57.283 1152*870@75Hz 68.681 75.062 Other MODES WXGA Note: 1. Non-interlace signals only (An interlace signal cannot be display) 2.
  • Page 10 MR19 Service Manual Pixel Pitch 0.294mm(H)x0.294mm(W) Display Colors: 16.7Million (6bit+Hi-FRC) Number of Pixel 1280x1024 pixels Pixel Arrangement RGB vertical stripe Brightness 250cd/m (Typ.) Contrast Ratio 800:1 (Typ.) Viewing Angle Hor:170°, Ver: 160°(Typ) Brightness Uniformity ≧75% Display Mode Normally White Response Time(Tr+Tf) 5ms (Typ.), 10ms (Max.)
  • Page 11 MR19 Service Manual Item Condition SPEC Brightness=100% ≧ 200 cd/m Brightness Contrast = 100% Brightness=100% the last 3~8 levels of 32 Grey Scale grey scales is combined Contrast = 100% 4.4 White balance The test standard conditions refer to Sec 3.3. (Brightness control is at 100 contrast control is at 50.)
  • Page 12 MR19 Service Manual 4.6 Audio Signal Items Specification ≧ 10K ohm Input impedance 200Hz –20kHz Frequency response range ≧ 40 dB Signal to noise ratio ≦1 W + 1 W(±20% tolerance), THD 10%. Output power Loading impedance 4 ohm Note: The low pass RC Filter (R=100Ω / C=0.047uF) for Class-D output power and THD+N measurement, and under 1KHz, 1Vrms and sine wave input.
  • Page 13 MR19 Service Manual 5.1.2 Hot Key Operation HOT KEY OPERATION FUNCTION DESCRIPTION AUTO MENU ＜ ＞ POWER Press [AUTO] at the same time, and then press FACTORY [POWER] for DC power on. OSD menu will be ● MODE shown with “F” on the left top. Select “F” for entering factory mode ●...
  • Page 14 MR19 Service Manual tructure OSD S The On-Screen Display (OSD) shall be an easy to use icon based menu through keypad OSD buttons or remote control unit. The unit shall leave the factory with all OSD controls set to their default values.
  • Page 15 MR19 Service Manual DVI(option): If our monitor is in Dual mode, the gray area below will be the function which could not be adjusted. First Second Third Fourth Control Value Default Auto Input Audio Volume Brightness Contrast Picture Gamma Gamma2.0 Gamma 2.2...
  • Page 16 MR19 Service Manual Theme Mode Brightness Contrast Movie Game Picture User(After Reset all) Remark: 1. Main OSD will Show 10 Second on the Screen，if there is No Operation on the OSD，And ±1 Second is accepted. 2.Gamma 2.0(2.0±0.2), Gamma 2.2(2.2±0.2), Gamma 2.4(2.4±0.2).
  • Page 17 MR19 Service Manual SOP of PCBA ISP Programming 6.1 Operational condition: Equipment: PC, ISP card, signal cable and power cable. ESD requirements: antistatic wrists, antistatic gloves(fingers), and connecting cable Name of ISP program: ISP_Tool_V4.4.2.4 Manufacture of FW IC：PMC/SST/MX 6.2 Operational steps: 1.
  • Page 18 MR19 Service Manual Secondly﹐download FW software: first select “READ”, and then load FW software in Rooter (Fig.2). Software Checksum value FW BIN file Thirdly, select “AUTO”, and keep its default value. Click “RUN” for beginning programming. There will be prompting if programming is OK.
  • Page 19 MR19 Service Manual ◆Note: if programming fails or success rate is not high, click “Config” and adjust its speed to lower in “I2C Speed Setting”and check Communication Setting. If connect port is print port, please check port type.
  • Page 20 MR19 Service Manual 3. Flow Chart...
  • Page 21 MR19 Service Manual 7. SOP of EDID 7.1 Request of hardware and software: 1. Software a.port95nt.exe b.Edid.exe c.MR19 model 2. Hardware a. PC（winXP or win2000）1PCS； b. Tool（EDID Card、VGA cable & DVI cable) 7.2 Operational steps: 1. First set up Port95nt.exe...
  • Page 22 MR19 Service Manual 2. Click next button continually then can finish setting.
  • Page 23 MR19 Service Manual EDID Tool Set up A : USB interface provide +5V DC power（No Power is ok ） B : Connect DDC Card and PC with collateral interface ； C :VGA、DVI use different cable to link DDC and PC...
  • Page 24 MR19 Service Manual EDID ISP Card: A：Collateral printing interface (connect with PC) B : VGA interface (one VGA connect with PC to provide signal for monitor the other one connect with PC VGA interface to write VGA EDID, Write EDID can without providing signal)
  • Page 25 MR19 Service Manual 3. Write EDID Process： 3.1 Choose File menu in main menu ，choose Auto Write button，click S/N blank . MR19...
  • Page 26 MR19 Service Manual 3.2 Cloose the Model in main menu, and the password is 1234. MR19...
  • Page 27 MR19 Service Manual 3.3 Choose the model, MR19_A(Update VGA) ,MR19_D(Update DVI) . MW19 MR19_D MR19_A...
  • Page 28 MR19 Service Manual 3.4 Input S/N in the Blank , eg:ETLA10C109805111D94023，the program can write directly. MR19...
  • Page 29 MR19 Service Manual 3.5 After the process is ok , the program can check that automatically MR19...
  • Page 30 MR19 Service Manual 3.6 If write successfully , you can see PASS in the right MR19 MR19...

  • Page 31: Flat Panel Specification

    MR19 Service Manual 02. Flat Panel Specification...
  • Page 32 2. Absolute maximum ratings The following are maximum values which, if exceeded, may cause faulty operation or damage to the unit. Table 1. Absolute maximum ratings Values Parameter Symbol Units Notes Power Supply Input Voltage -0.3 +6.0 At 25℃ °C Operating Temperature °C Storage Temperature...
  • Page 33 3. Electrical specifications 3-1. Electrical characteristics It requires two power inputs. One is employed to power the LCD electronics and to drive the TFT array and liquid crystal. The second input power for the CCFL/Backlight, is typically generated by an inverter. The inverter is an external unit to the LCDs. Table 2.
  • Page 34 Table 3. Electrical characteristics Values Parameter Unit Notes LAMP : (640) (650) (780) Operating Voltage 1, 2 (8.0mA) (7.5mA) (3.0mA) Operating Current Established Starting Voltage 1, 3 at 25 °C 1,100 0 °C 1,400 Operating Frequency Discharge Stabilization Time 1, 5 Power Consumption 9.75 10.73...
  • Page 35 Note : 8. The output of the inverter must have symmetrical(negative and positive) voltage waveform and symmetrical current waveform (Unsymmetrical ratio is less than 10%). Please do not use the inverter which has unsymmetrical voltage and unsymmetrical current and spike wave. Requirements for a system inverter design, which is intended to have a better display performance, a better power efficiency and a more reliable lamp, are following.It shall help increase the lamp lifetime and reduce leakage current.
  • Page 36 3-2. Interface connections LCD connector(CN1) : IS100-L30O-C23 (UJU) , 187034-30091 (P-TWO) Mating connector : FI-X30H and FI-X30HL (JAE) or Equivalent Table 4. Module connector(CN1) pin configuration Pin No Symbol Description RXO0- Minus signal of 1st channel 0 (LVDS) RXO0+ Plus signal of 1st channel 0 (LVDS) RXO1- Minus signal of 1st channel 1 (LVDS) RXO1+...
  • Page 37 FIG. 4 Connector diagram IS100-L30O-C23(UJU) 1’st signal pairs 2’nd signal pairs Power(+5V) PWM_OUT Rear view of LCM Note: 1. NC: No Connection. 2. All GND(ground) pins should be connected together and to Vss which should also be connected to the LCD’s metal frame. 3.
  • Page 38 The backlight interface connector is a model 35001HS-02LD manufactured by YEONHO. The mating connector part number are 35001WR-02L(2pin) or equivalent. The pin configuration for the connector is shown in the table below. Table 5. Backlight connector pin configuration(CN2,CN3) Symbol Description Notes High Voltage for Lamp Low Voltage for Lamp...
  • Page 39 3-3. LVDS characteristics 3-3-1. DC Specification Description Symbol Unit Notes LVDS Differential Voltage LVDS Common mode Voltage LVDS Input Voltage Range 3-3-2. AC Specification LVDS Clock LVDS Data = 1/T SKEW 1) 85 MHz > Fclk ≥ 65 MHz : - 400 ~ +400 2) 65 MHz >...
  • Page 40 SKEW _ EO LVDS Odd Clock LVDS Even Clock LVDS Even Data < Clock skew margin between channel > Freq. center center Time < Spread Spectrum > 3-3-3. LVDS Data format Tclk Tclk* 4 /7 Tclk* 3 /7 RCLK + Tclk* 1 /7 RXinO0 +/ - RXinO1 +/ -...
  • Page 41 Table 6. Required signal assignment for Flat Link(NS:DS90CF383) transmitter Pin # Pin Name Require Signal Pin # Pin Name Require Signal Power Supply for TTL Input Ground pin for TTL TTL Input (R7) TTL Input (DE) TTL Input (R5) CLKIN TTL Level clock Input TTL Input (G0) PWR DWN...
  • Page 42 3-4. Signal timing specifications This is the signal timing required at the input of the User connector. All of the interface signal timing should be satisfied with the following specifications for it’s proper operation. Table 7. Timing table Symbol Min. Typ.
  • Page 43 3-5. Signal timing waveforms 1. D DE, DATA waveforms CLK , Dclk Valid Invalid Invalid Data DE(Data Enable) 2. Horizontal waveform DE(Data Enable) 3. Vertical waveform DE(Data Enable)
  • Page 44 3-6. Color input data reference The brightness of each primary color (red,green and blue) is based on the 8bit gray scale data input for the color ; the higher the binary input, the brighter the color. The table below provides a reference for color versus data input. Table 8.
  • Page 45 3-7. Power sequence Power Supply For LCD T1 T2 Valid data Interface Signal (Tx) Lamp on Power for LAMP Table 9. Power sequence Values Parameter Units 0.01 0.01 Notes : 1. Please avoid floating state of interface signal at invalid period. 2.
  • Page 46 3-8. V Power dip condition FIG. 6 Power dip condition GND(ground) 1) Dip condition 3.5V ≤V ＜ 4.5V , t ≤20ms ＜ 3.5V 2) V -dip conditions should also follow the Power On/Off conditions for supply voltage.
  • Page 47 4. Optical specification Optical characteristics are determined after the unit has been ‘ON’ for 30 minutes in a dark environment at 25°C. The values specified are at an approximate distance 50cm from the LCD surface at a viewing angle of Φ and θ equal to 0 °. FIG.
  • Page 48 Notes : 1. Contrast ratio(CR) is defined mathematically as :It is measured at center point(1) Surface luminance with all white pixels Contrast ratio = --------------------------------------------------------- Surface luminance with all black pixels 2. Surface luminance is the luminance value at center 1 point(1) across the LCD surface 50cm from the surface with all pixels displaying white.
  • Page 49 Notes : 4. Response time is the time required for the display to transition from black to white (Decay Time, Tr ) and from white to black (Rise Time, Tr The sampling rate is 2,500 sample/sec. For additional information see FIG. 9. The response time is defined as the following figure and shall be measured by switching the input signal for each gray to gray.
  • Page 50 Notes : 6. Luminance Uniformity - angular – dependence (LR& TB) TCO ‘03 Luminance uniformity – angular dependence, is the capacity of the VDU to present the same Luminance level independently of the viewing direction. The angular-dependent luminance uniformity is calculated as the ratio of maximum luminance to minimum luminance in the specified measurement areas.
  • Page 51 Notes : 8. Color grayscale linearity , Δu’v’ is defined as − − Where indices A and B are the two gray levels found to have the largest color differences between them. i.e. get the largest Δu’ and Δv’ of each 6pairs of u’ and v’ and calculate Δu’v’ . -Test pattern : 100% full white pattern with a test pattern as shown FIG.12 Squares of 40mm by 40mm in size, filled with 255, 225, 195, 165, 135 and 105 grayscale steps should be arranged in the center of the screen.
  • Page 52 5. Mechanical characteristics The contents provide general mechanical characteristics. In addition the figures in the next page are detailed mechanical drawing of the LCD. Table 12. Mechanical characteristics Horizontal 396.0 mm Outline dimension Vertical 324.0 mm Depth 15.5 mm Horizontal 380.3 mm Bezel area Vertical...
  • Page 53 <FRONT VIEW>...
  • Page 54 <REAR VIEW>...
  • Page 55 6. Reliability Table 13. Environment test conditions Test Item Condition High temperature storage test Ta= 60°C 240hrs Low temperature storage test Ta= -20°C 240hrs High temperature operation test Ta= 50°C 50%RH 240hrs Low temperature operation test 0°C 240hrs (NDS conditions) Wave form : random Vibration level : 1.47G RMS Bandwidth : 5-200Hz...
  • Page 56 7. International standards 7-1. Safety a) UL 60950-1:2003, First Edition, Underwriters Laboratories, Inc., Standard for Safety of Information Technology Equipment. b) CAN/CSA C22.2, No. 60950-1-03 1st Ed. April 1, 2003, Canadian Standards Association, Standard for Safety of Information Technology Equipment. c) EN 60950-1:2001, First Edition, European Committee for Electro-technical Standardization(CENELEC) European Standard for Safety of Information Technology Equipment.

  • Page 57: Exploded Diagram

    MR19 Service Manual 03. Exploded Diagram 3.1 Screw List Fixed Item Part No. Description Remark T(kg*cm) 509146306200R SCREW,P,CROSS, 4 3.75±0.25 chassis&PCBA W/WAS,M3*6,Zn-Cc 509116612102R SCREW,B,CROSS, 11±1 Hinge &support*3 M4*12,BLK-Zn,ROH S(NYLOK)# 509000000700R BOLT,#4-40x11.8,Ni 4.0±0.25 D-SUB CON *2&DVI ROHS 3.2 Exploded Diagram...

  • Page 59: Troubleshooting

    MR19 Service Manual 04. TROUBLE SHOOTING 1. Common Acknowledge If you change the interface board, make sure that the U103, U105, U106, U108and U201 these five components also changed to the new I/F board because there are program and data insides. If not, please re-write EDID or upload firmware into MCU via VGA or DVI Cable.
  • Page 60 MR19 Service Manual 2. Backlight can’t be turned on No raster? LED Blue? Backlight can’t be turned on. Is there 14Vdc Check power voltage on pin9 supply of IC501? Is there high-level Is Ok R510? voltage on pin8 of Check I/F...
  • Page 61 MR19 Service Manual 3. No Power & Power LED Off No power Check IC802, Check circuit Check primary C804, T801 if short rectifier voltage Check F801, P801, D801 Check pin6 of Check D803,C807 IC802 voltage about 16V Check Check pin5 of IC802...
  • Page 62 MR19 Service Manual 4. Black Screen and backlight turn on Black Screen Check power supply: Power Fail Pin1, 2 of0 CN101 Check FB105 Check pin53, 74,104, and126 And U102 Of U105 Check pin40, 54, 58,59,60, Check FB102, 65,66,71,87,107,112,114,8,14 And U101...
  • Page 63 MR19 Service Manual 5. White Screen White Screen LVDS Cable Workmanship Reinsert Change LVDS LVDS Cable NG Cable Check VLCD Check LVDS Panel Fail Is 5V? Signals Check Panel - Enable Check the HW Reset Check C164 Of U105 (pin73) is High?
  • Page 64 MR19 Service Manual 6. Bad Screen Bad Screen LVDS Cable Workmanship Reinsert Change LVDS LVDS Cable NG Cable Check Crystal: Pin127, Check: X101, C157, Pin128 Of U105 C158,R147,R148 Check the communication Check :SDO,CSZ, of the U108 and U105 SCK,SDO,Reset Check the Pins of...

  • Page 65: Spare Parts List

    MR19 Service Manual 05. Spare parts List 8191U1A1G120R ACER PART OEM PART NO PART NAME DESCRIPTION ET.C210C.003 PCBA,P/I POWER/INVERTER 55.C210J.001 793291400A00H BOARD,W/SPK,LE19U BOARD W/SPK 1-A12 PCBA,I/F MAIN BOARD 19.C210J.001 793291300A00H BOARD(EMEA,W/SPK) BOARD W/SPK ,LE19U1-A12 PCBA,KEYPAD 55.C210J.002 793281500000H KEYPAD BOARD BOARD,LE22T9...
  • Page 66 MR19 Service Manual CABLE AUDIO 1P 6FT CABLE AUDIO 1P 50.L63VF.003 453030300120R BLACK/GREEN CP03B06P0 CABLE DVI-D CABLE,DVI-D 18+1P 50.LA10J.003 453030300370R 18+1P MALE 6FT MALE 6FT BLACK , BLACK ROHS ROHS HRN ASSY 8P 50.C210J.001 430300803320H KEYPAD CABLE(1) UL3302#28 150mm HRN ASSY 2X4P TO 50.C210J.002...
  • Page 67 MR19 Service Manual BACK COVER COVER,BACK,W/D,W/ 60.C210J.002 501020238104R (W/SPK,W/DVI) SW,LGD,LE19U1 60.C210J.003 502020309901R STAND (BLACK) STAND,MR19,LE19U1 60.C210J.004 501240218600R BASE BASE,MR19,LE19U1 CHASSIS ASSY,CHASSIS,W/D, 60.C210J.005 701000019200R (W/SPK,W/DVI) W/SW,LE19U1 LCP 19" LCP 19" LM190E08- LK.19008.029 631102092690RA LM190E08- TLJ2(A)(LPL)ROHS TLJ2(A)(LPL)ROHS...

  • Page 68: Schematics And Layouts

    MR19 Service Manual 06. Schematics and Layouts 6.1 Lay Out I/F Board Lay Out...
  • Page 69 MR19 Service Manual...
  • Page 70 MR19 Service Manual P/I Board Lay Out...
  • Page 71 MR19 Service Manual...
  • Page 72 MR19 Service Manual Keypad Board Lay out 6.2 Switching Mode Power Supply circui...
  • Page 73 TO Daughter BD +5V-Audio CN703 LOUT- ROUT- LOUT- ROUT- EP701 LOUT+ ROUT+ C721 LOUT+ ROUT+ P701 470u/16V PC AUDIO IN R719 EO_R Audio_MUTE SHUT EO_R EO_L EP702 R717 Volume EO_L Hp/Sp AGND Hp/Sp R718 100/NC Q701 +5V-Audio PMBT3904/NC 2*8P 2.54mm 90° CN705 CN704 EO_R...
  • Page 74 250V 0R75 2W 2A/250V 1000p/50V C821 2200P Y1/NC 250V C801 C802 NC 2200P/250V Y2 2200P Y2 InnoLux GTW MR19 CN801 Document Number : SIZE : APPRO BY : TITLE : CHECK BY : ON/OFF POWER SCH BRIGHTNESS Volume P801 Audio_MUTE AC IN-1 2009.02.27...
  • Page 75 C501 470u/25V R511 R509 R512 D501 SN4148 R513 R510 R514 D502 SN4148 InnoLux GTW MR19 Document Number : SIZE : APPRO BY : TITLE : CHECK BY : Inverter SCH 2009.02.27 DATE : DRAWN BY : Rev : Nothin SHEET...
  • Page 76 PMBT3904 R107 R106 Q102 100K 100K PANEL_ENABLE Q104 PMBT3904 C112 R108 1u/16V InnoLux MSTAR_TSUMU58EHJ Document Number : SIZE : APPRO BY : TITLE : CHECK BY : POWER (DC TO DC) DATE : 2009-01-05 DRAWN BY : Rev : SHEET...
  • Page 77 120Ω R133 HSYNC R134 VSYNC WP_EDID 3,4 DDC_SCL_VGA 4 DDC_SDA_VGA 4 C131 C132 33p/50V/NC 33p/50V/NC InnoLux MSTAR_TSUMU58EHJ Document Number : SIZE : APPRO BY : TITLE : CHECK BY : VGA-INPUT 2009-01-05 DATE : DRAWN BY : Rev : SHEET...
  • Page 78 BAV99 HPD_CTRL 4 PMBT3904 HDCP Function VCC_ESD C204 C206 C208 C210 0.1/16V 0.1/16V 0.1/16V 0.1/16V InnoLux MSTAR_TSUM58EHJ Document Number : SIZE : APPRO BY : TITLE : CHECK BY : DVI-INPUT DATE : 2009-01-05 DRAWN BY : Rev : SHEET...
  • Page 79 R137 C140 0.1/16V CON--HR-200PHD2X15ST U106 FOR SINGLE LVDS INPUT WP_OSD SCL_OSD R142 SDA_OSD R143 AT24C16AN InnoLux MSTAR_TSUMU58EHJ Document Number : SIZE : APPRO BY : Custom TITLE : CHECK BY : SCALER DATE : 2009-01-05 DRAWN BY : Rev :...
  • Page 80 SW901 LED B/A TACT-2.5 TACT-2.5 TACT-2.5 TACT-2.5 TACT-2.5 POWER RIGHT LEFT MENU AUTO InnoLux Gateway MW22&MR19 Document Number : SIZE : APPRO BY : KEYPAD TITLE : CHECK BY : Keypad DATE : 2009-02-16 DRAWN BY : Rev : SHEET...

  • Page 81: Assembly And Disassembly

    MR19 Service Manual 07. Assembly and Disassembly The tool of Assembly and disassembly: 1) Electrostatic gloves 2) Electric screwdriver: the length of screwdriver top is 6±0.5cm and 15±0.5cm ; the diameter of screwdriver top is Φ5*H5mm Sequence Item Photo Procedures Description (1).Take panel out of box and place it...
  • Page 82 MR19 Service Manual Assembly and Disassembly (continue) 1.Put the bezel on the form,withing it's Assembl key board is on the right hands. e front 2.Put the panel with two hands and put 714030032700 ASSY,FRONT,BEZ bezel into the bezel carefully , without...
  • Page 83 MR19 Service Manual Assembly and Disassembly (continue) the cable should 1.insert the connector of power board be turned back 90 into the port of I/F board Connect and not touch 2. place I/F board , with it's port on the...
  • Page 84 MR19 Service Manual Assembly and Disassembly (continue) position hooks chassis Connext insert the FFC cable into the correct cable port of panel with panel link the port Insert the Insert the lamp cable on the correct lamp location of chassis, like the attached...
  • Page 85 MR19 Service Manual Assembly and Disassembly (continue) Assembl 1.insert the speaker cable into the PIN SPEAKER 2.5W 4Ω 618100200630 e the location of chassis like the attached 220mm R/B/G speaker picture W/CASE 1.HRN ASSY 8P 1.43030080332 Connect 1.connect keypad cable in bezel with...
  • Page 86 MR19 Service Manual Assembly and Disassembly (continue) Assembl e Hinge Assemble the Hinge with back cover 502020309901 STAND,MR19,LE19 with as the picture Back Cover DVI&VGA &Audio&P ower cable Packing Put monitor into carton like the attached picture...
