HamiltonBuhl HASHV4226-E Instruction Sheet

Instruction Sheet
HamiltonBuhl Adjustable AV Cart
with Front Pull-Out Shelf
Model #: HASHV4226-E
Warranty begins the date item ships from our warehouse.
All products, except metal cart, have a one year warranty
from original date of shipment, unless otherwise noted.
Metal carts have a limited lifetime warranty on all housing
components; however, carts have a one year warranty on
any electrical/mechanical components.
Parts list
Qty. Description
1 Top table section with decal
1 Two shelf bottom section
1 Electrical bracket
1 Power cord
1 Rubber mat
1.
Insert top table section onto bottom section.
3.
Insert two bolts, washer and nuts (see screw table B) into each
leg of table. Washer and nut should be on the inside of leg.
Tighten all bolts and nuts.
Qty. Description
3 Screws and hex nuts (A)
9 Set Phillips head bolt, washer and hex nut (B)
2 Casters with brakes
2 Casters without brakes
Note: This unit is easier to assemble with two people.
(Continued on next page)
Screw table
Some screws may already be
screwed into related parts.
2.
Align corresponding holes of unit to obtain desired height of
table as needed.
4.
Lay unit on floor . Insert casters with brakes into opposite
corner holes in the bottom of the unit. Insert other casters into
remaining holes of unit.
HASHV4226-E
Tools required:
Adjustable wrench/pliers
Rubber mallet
Screw driver
! PROP 65 WARNING: This product
contains the chemical known to the
State of California to cause cancer
and birth defects or other reproductive
harm.
