- Page 1 EQUINE DENTALSCOPE INSTRUCTION MANUAL HORSE DENTAL EQUIPMENT ZI de Bellevue 14, Rue Blaise Pascal 35 220 CHÂTEAUBOURG France horse@horse-dental-equipment.com +33 (0)2 99 00 71 29 www.horse-dental-equipment.com...
-
Page 3: Chapter 1: Safety Instructions
CHAPTER 1: SAFETY INSTRUCTIONS WARNING. Read safety warnings and instructions. Failure to follow safety warnings and instructions of use may result to electric shock, fire, and/or serious injury for the user. HDE declines all responsibility in the event of damage resulting from improper use or non-compliance with these safety ins- tructions. -
Page 4: Video Transmission
Video transmission Radio Frequency signal 5,86 GHz, integrated Wireless Technology transmitter inside the handle (RF receiver required) Wire technology AV connection, cable supplied, length 1,5 mm Battery and Charger Battery Lithium-Ion Polymer, Rechargeable single cell Battery Protection 3,7 Volts 600 mAh Charger In 100-230 V AC 50/60 Hz 0,4 A Charger Out... - Page 5 Product description - Basic set 1- Dentalscope 4 - Storage and transportation case - rigid 2- Charger plastic with protective foam 3- Video Cable, length 1.5 meter Easy to use: Plug and play system Setup sequence: - Connect cable with dedicated plug at the rear of the DentalScope - Connect the other side of the cable (AV plug) on a screen equipped with AV- Video plug - Press the green button on the DentalScope,...
- Page 6 Option 2: Monitoring an external monitor 10’’ DVR Viewing Monitor recording on SD-CARD (video + picture) 5 - 10’’ Monitor 6 - Monitor charger 7 - Storage and transporta- tion case - rigid plastic with protective foam...
-
Page 7: Chapter 3: Delivery Conditions - First Use
CHAPTER 3: DELIVERY CONDITIONS - FIRST USE 3.1 Battery The battery is delivered with almost 30% of charge. Fully charge the battery before the first use by inserting the charger cable into the rear side of the scope, and plug the charger into the electrical socket. -
Page 8: Chapter 4: Standard Use
CHAPTER 4: STANDARD USE 4.1 With the AV-cable √ Connect both sides of the AV-cable: - Small-pin side connected to the rear of the DentalScope, - Large-pin side connected to the screen. √ Press the green button on the DentalScope, And start working! 4.2 With the USB converter √... -
Page 9: Chapter 5: Maintenance, Cleaning And Storage
CHAPTER 5: MAINTENANCE, CLEANING AND STORAGE 5.1 Routine maintenance The equipment does not require any routine maintenance. 5.2 Cleaning At the end of each working day, clean the DentalScope with clean water. Do not use any concentrated detergent, thinner, acetone, acid or basic. Wipe clean and dry with a microfiber cloth, before storing in the transport box. - Page 10 ANNEX: MONITOR SETUP The monitor is equipped with several modes. Only 2 modes are useful for the DentalScope: • RF Mode: dedicated for direct visualization • DVR Mode: dedicated for visualization + screenshot + video capture. To choose the mode: √...
- Page 11 HEADQUARTERS Horse Dental Equipment Châteaubourg (35) FRANCE horse@horse-dental-equipment.com Ph: +33 (0)2 99 00 71 29 www.horse-dental-equipment.com...
