  • Page 1 Huis Trujillo BBI.102.HBP...

  • Page 2: Installation Instructions

    Il est conseillé de ne pas orienter de FR - Important ! l’équipement avec toboggans vers le sud. Si le sol ne contribue pas à la stabilité de l’équipement à placer, versez 50L de béton par poteau. BBI 102 HxP © Copyright BOERplay 2-11-2021 Revision:...
  • Page 3 Hoofdafmetingen Hauptabmessungen Dimensiones principales Dimensions principales 1,79 m 1,19 m 0,39 m 0,00 m 2,50 m 1,81 m 0,95 m 0,00 m BBI 102 HxP © Copyright BOERplay 2-11-2021 Revision:...
  • Page 4 Zone libre d’obstacles 5,84 m 5,34 m 0,50 m Impact area Opvangzone Ausprallbereich Zona de impacto Zone d‘impact Obstacle free zone Obstakelvrije zone Hindernissfreie raum Zona libre de obstáculos Zone libre d’obstacles BBI 102 HxP © Copyright BOERplay 2-11-2021 Revision:...
  • Page 5 Nivel del suelo para postes de metal Nivel del suelo para postes de plástico o madera Niveau au sol pour poteaux en métal Niveau au sol pour poteaux en plastique ou en bois BBI 102 HxP © Copyright BOERplay 2-11-2021 Revision:...

  • Page 6: Assembly Manual

    - assembly manual - module Montagehandleiding - module Montageanleitung - Modul Manual de ensamblado - módulo Manuel de montage - module MOD.BBI.103.x MOD.BBI.100.x MOD.BBI.137 MOD.BBI.101.x MOD.BBI.001.x MOD.BBI.141.x MOD.BBI.001.x MOD.BBI.100.x MOD.BBI.101.x MOD.BBI.103.x MOD.BBI.137 MOD.BBI.141.x BBI 102 HxP © Copyright BOERplay 2-11-2021 Revision:...
  • Page 7 Ø3 mm Ø5 mm Ø11 mm Ø12 mm 4,8mm Only for metal posts Alleen voor metalen staanders Nur für Pfosten aus Metall Solo para postes de metal Seulement pour poteaux en métal BBI 102 HxP © Copyright BOERplay 2-11-2021 Revision:...
  • Page 8 1 / 7 Montagevolgorde Montagereihenfolge Orden de esemblado Ordre de montage assembly manual module MOD.BBI.001.x 2 / 7 assembly manual module MOD.BBI.103.x BBI 102 HxP © Copyright BOERplay 2-11-2021 Revision:...
  • Page 9 3 / 7 Montagevolgorde Montagereihenfolge Orden de esemblado Ordre de montage assembly manual module MOD.BBI.101.x 4 / 7 assembly manual module MOD.BBI.100.x BBI 102 HxP © Copyright BOERplay 2-11-2021 Revision:...
  • Page 10 5 / 7 Montagevolgorde Montagereihenfolge Orden de esemblado Ordre de montage assembly manual module MOD.BBI.141.x 6 / 7 assembly manual module MOD.BBI.137 BBI 102 HxP © Copyright BOERplay 2-11-2021 Revision:...
  • Page 11 7 / 7 BOER PLAY xxx.xxx.xxx EN 1176 www.boerplay.com BBI 102 HxP © Copyright BOERplay 2-11-2021 Revision:...
  • Page 12 LOGBOEK (Onderstaand logboek kan gebruikt worden om te voldoen aan de eisen, gesteld in artikel 14 van het Warenwetbesluit Attractie- en Speeltoestellen) Type aanduiding Figura Play Artikelnummer BBI.102.HBP Naam toestel Huis Trujillo Maximale valhoogte 1,0 m Bouwjaar 2023 Certificaat 063142...
  • Page 13 LOGBOEK Inspectie en onderhoud Datum Tijdstip Naam Naam Geconstateerde Te vervangen inspectie inspectie uitvoerder uitvoerder gebreken onderdelen onderhoud onderhoud inspectie onderhoud Ongevallen Genomen Datum Leeftijd Vermoedelijk oorzaak letsel Opgetreden persoonlijk letsel maatregel n.a.v. ongeval slachtoffer ongeval...
  • Page 14 Inspectie en onderhoud intervallen Maanden Nr. Inspectie Onderhoud tussen controle Speeltoestel controleren op stabiliteit, goede Ontbrekende onderdelen toevoegen, verbindingen en ontbrekende onderdelen. verbindingen vastdraaien. Ontbrekende Bouten, schroeven en moeren controleren op bevestigingsmiddelen aanbrengen en ontbreken, vastzitten, corrosie en slijtage gecorrodeerde onderdelen vervangen. Vervangen van versleten onderdelen en/of Ophangingen controleren op slijtage.
  • Page 15 6. Controleer het terrein regelmatig op zaken die er niet thuis horen, onveilig zijn of uitnodigen tot verkeerd gebruik, bijvoorbeeld giftige planten, glas enz. De controle frequentie is afhankelijk van de belasting. 7. Bedenk dat slecht onderhoud leidt tot onveiligheid en aantoonbare snellere verpaupering van de speelomgeving.
  • Page 17 - module Montagehandleiding - module Montageanleitung - Modul Manual de ensamblado - módulo Manuel de montage - module MOD BBI 001 B © Copyright BOERplay 18-8-2023 Revision: C...
  • Page 18 A (18x) SME.BBI.053.372 Detail B (4x) Detail A (18x) 40 mm 35 mm BSR.026.008.040 KST.DON.010.060 BSR.026.008.035 BSR.030.008.016 BSR.030.008.016 BSR.011.008.015 BSR.010.008.008 KST.DOP.010.060 BSR.010.008.008 BSR.011.008.015 BSR.026.008.035 BSR.026.008.040 BSR.030.008.016 KST.BBI.011.LPE KST.DON.010.060 KST.DOP.010.060 SME.BBI.053.372 MOD BBI 001 B © Copyright BOERplay 18-8-2023 Revision: C...
  • Page 19 Postes de metal Postes de plástico o madera Poteaux en métal Poteaux en plastique ou en bois KST.LAM.100.100 18 mm 50 mm ø5mm ø3mm x 30 BSR.014.005.052 BSR.002.005.050 KST.LAM.100.100 BSR.014.005.052 BSR.002.005.050 MOD BBI 001 B © Copyright BOERplay 18-8-2023 Revision: C...
  • Page 20 Poteaux en plastique ou en bois 70 mm KST.LAM.013.006 BSR.002.005.070 Glue NL Lijm DE Kleber ES Pegamento 50 mm FR Colle ø5mm ø3mm x 30 BSR.002.005.050 BSR.014.005.052 18 mm BSR.002.005.050 KST.LAM.013.006 BSR.014.005.052 MOD BBI 001 B © Copyright BOERplay 18-8-2023 Revision: C...
  • Page 21 OME.KAP.100.204 SMD.BBI.500 S.BBI.004.B S.BBI.001.B S.BBI.001.B S.BBI.001.B Detail C (8x) 120 mm BSR.026.010.120 KST.DON.010.060 BSR.030.010.002 BSR.010.010.010 KST.DOP.010.060 BSR.010.010.010 BSR.026.010.120 BSR.030.010.002 KST.DON.010.060 KST.DOP.010.060 ! Max 12 Nm ! SMD.BBI.500 MOD BBI 001 B © Copyright BOERplay 18-8-2023 Revision: C...
  • Page 22 Metalen staanders Kunststof of houten staanders Pfosten aus Metall Pfosten aus Kunststoff oder Holz Postes de metal Postes de plástico o madera Poteaux en métal Poteaux en plastique ou en bois MOD BBI 100 © Copyright BOERplay 5-2-2020 Revision: A...
  • Page 23 1 / 6 OPE.BBI.005.006 BSR.026.010.120 KST.BBP.050.001 RNT.BUS.M10.040 OPE.BBI.006.022 OPE.BBI.001.062 Detail A (8x) BSR.053.005.035 35 mm 30 mm BSR.026.010.120 BSR.053.005.035 KST.BBP.050.001 OPE.BBI.001.062 OPE.BBI.005.006 OPE.BBI.006.022 RNT.BUS.M10.040 MOD BBI 100 © Copyright BOERplay 5-2-2020 Revision: A...
  • Page 24 Detail C (1x) BSR.023.010.080 KST.DOP.010.030 BSR.010.010.010 BSR.010.010.010 BSR.023.010.080 BSR.030.010.002 BSR.030.010.002 KST.DON.010.030 BSR.031.005.000 OPE.BBI.221.010 BSR.030.010.002 BSR.053.005.030 OPE.BBI.032.010 KET.005.002.029 BSR.031.005.000 KST.DON.010.030 KST.DOP.010.030 KET.005.002.029 KST.ROR.006.000 OPE.BBI.030.010 OPE.BBI.030.022 OPE.BBI.030.032 OPE.BBI.032.010 OPE.BBI.033.072 OPE.BBI.033.072 OPE.BBI.038.090 BSR.031.005.000 OPE.BBI.221.010 MOD BBI 100 © Copyright BOERplay 5-2-2020 Revision: A...
  • Page 25 3 / 6 OPE.BBI.007.006 OPE.BBI.002.006 Detail D (6x) Detail E (9x) BSR.011.008.015 BSR.030.008.016 BSR.052.008.035 ✔ BSR.010.008.008 OME.BBI.021 BSR.052.008.060 BSR.010.008.008 BSR.011.008.015 BSR.030.008.016 BSR.052.008.035 BSR.052.008.060 OME.BBI.021 OPE.BBI.002.006 OPE.BBI.007.006 MOD BBI 100 © Copyright BOERplay 5-2-2020 Revision: A...
  • Page 26 4 / 6 OPE.BBI.008.032 OPE.BBI.009.032 OME.BBI.031 OME.BBI.031 Detail D (6x) ✔ BSR.010.008.008 OME.BBI.021 BSR.052.008.060 Detail F (2x) BSR.010.008.008 BSR.010.010.010 BSR.026.010.040 BSR.030.010.002 BSR.026.010.040 BSR.052.008.060 KST.DON.010.020 KST.DON.010.020 KST.DOP.010.020 BSR.030.010.002 OME.BBI.021 OME.BBI.031 BSR.010.010.010 OPE.BBI.008.032 KST.DOP.010.020 OPE.BBI.009.032 MOD BBI 100 © Copyright BOERplay 5-2-2020 Revision: A...
  • Page 27 5 / 6 OME.BBI.017.905 Detail G (6x) BSR.026.010.040 KST.DON.010.030 BSR.010.010.010 BSR.026.010.040 BSR.030.010.002 BSR.030.010.002 BSR.010.010.010 KST.DON.010.030 KST.DOP.010.030 KST.DOP.010.030 OME.BBI.017.905 MOD BBI 100 © Copyright BOERplay 5-2-2020 Revision: A...
  • Page 28 BSR.026.010.040 BSR.030.010.002 KST.DON.010.020 BSR.026.010.040 KST.DOP.010.020 SME.BBI.002 KST.DON.010.020 MOD.BBI.100.A BSR.030.010.002 BSR.014.005.052 MOD.BBI.100.G BSR.010.010.010 KST.DOP.010.020 BSR.002.005.050 KST.ROR.006.000 Detail H (2x) MOD.BBI.100.A MOD.BBI.100.G 18 mm 50 mm BSR.014.005.052 BSR.002.005.050 KST.ROR.006.000 ø5mm ø3mm x 30 MOD BBI 100 © Copyright BOERplay 5-2-2020 Revision: A...
  • Page 29 Plastic or wooden posts Metalen staanders Kunststof of houten staanders Pfosten aus Metall Pfosten aus Kunststoff oder Holz Postes de metal Postes de plástico o madera Poteaux en métal Poteaux en plastique ou en bois MOD BBI 101 © Copyright BOERplay 21-2-2020 Revision:...
  • Page 30 1 / 3 OPE.BBI.004.061 Detail A (1x) OPE.BBI.030.xxx KST.ROR.006.000 KST.ROR.006.000 BSR.053.005.030 BSR.053.005.030 OPE.BBI.038.090 OPE.BBI.004.061 OPE.BBI.038.090 OPE.BBI.030.032 KST.ROR.006.000 BSR.053.005.030 MOD BBI 101 © Copyright BOERplay 21-2-2020 Revision:...
  • Page 31 2 / 3 Detail B (3x) BSR.011.008.015 BSR.030.008.016 BSR.030.008.016 BSR.052.008.035 BSR.011.008.015 BSR.030.008.016 BSR.052.008.035 MOD BBI 101 © Copyright BOERplay 21-2-2020 Revision:...
  • Page 32 3 / 3 MOD.BBI.101.A BSR.014.005.053 MOD.BBI.101.G BSR.002.005.070 KST.ROR.006.000 Detail C (4x) MOD.BBI.101.A MOD.BBI.101.G 30 mm 70 mm BSR.014.005.053 BSR.002.005.070 KST.ROR.006.000 ø5mm ø3mm x 30 MOD BBI 101 © Copyright BOERplay 21-2-2020 Revision:...
  • Page 33 Metalen staanders Kunststof of houten staanders Pfosten aus Metall Pfosten aus Kunststoff oder Holz Postes de metal Postes de plástico o madera Poteaux en métal Poteaux en plastique ou en bois MOD BBI 103 © Copyright BOERplay 27-2-2020 Revision: A...
  • Page 34 1 / 2 OPE.BBI.046.062 OPE.BBI.012.062 Detail A (3x) KST.DOP.010.020 BSR.010.008.008 BSR.035.008.002 KST.DON.010.020 BSR.010.008.008 BSR.035.008.002 BSR.052.008.060 BSR.052.008.060 KST.DON.010.020 KST.DOP.010.020 OPE.BBI.012.062 OPE.BBI.046.062 MOD BBI 103 © Copyright BOERplay 27-2-2020 Revision: A...
  • Page 35 OPE.BBI.013.062 B (2x) B (2x) B (2x) B (2x) OPE.BBI.013.062 MOD.BBI.103.A BSR.014.005.053 MOD.BBI.103.G BSR.002.005.070 KST.ROR.006.000 Detail B (8x) MOD.BBI.103.A MOD.BBI.103.G 30 mm 70 mm BSR.014.005.053 BSR.002.005.070 KST.ROR.006.000 ø5mm ø3mm x 30 MOD BBI 103 © Copyright BOERplay 27-2-2020 Revision: A...
  • Page 36 Metalen staanders Kunststof of houten staanders Pfosten aus Metall Pfosten aus Kunststoff oder Holz Postes de metal Postes de plástico o madera Poteaux en métal Poteaux en plastique ou en bois MOD BBI 141 © Copyright BOERplay 28-2-2020 Revision: A...
  • Page 37 1 / 6 11mm Remove floor fixings (2x) NL Verwijder vloer bouten (2x) DE Bodenbefestigungen entfernen (2x) ES Retire las fijaciones del piso (2x) FR Retirer les fixations au sol (2x) MOD BBI 141 © Copyright BOERplay 28-2-2020 Revision: A...
  • Page 38 2 / 6 SME.BBI.003.916 Detail A (2x) BSV.030.010.002 BSV.023.010.050 BSV.023.010.050 BSV.030.010.002 SME.BBI.003.916 MOD BBI 141 © Copyright BOERplay 28-2-2020 Revision: A...
  • Page 39 3 / 6 MOD.BBI.141.A BSR.014.005.052 MOD.BBI.141.G BSR.002.005.050 KST.ROR.006.000 Detail B (2x) MOD.BBI.141.A MOD.BBI.141.G 18 mm 50 mm BSR.014.005.052 BSR.002.005.050 KST.ROR.006.000 ø5mm ø3mm x 30 MOD BBI 141 © Copyright BOERplay 28-2-2020 Revision: A...
  • Page 40 4 / 6 OPE.BBI.102.062 Detail C (1x) OPE.BBI.030.xxx KST.ROR.006.000 KST.ROR.006.000 BSR.053.005.030 BSR.053.005.030 OPE.BBI.038.090 30 mm BSR.053.005.030 KST.ROR.006.000 OPE.BBI.030.022 OPE.BBI.038.090 OPE.BBI.102.062 MOD BBI 141 © Copyright BOERplay 28-2-2020 Revision: A...
  • Page 41 D (2x) SME.MNP.143.916 D (2x) D (2x) SME.MNP.143.916 D (2x) E (2x) ORE.BBI.030.066 Detail D (12x) BSR.011.008.015 BSR.030.008.016 BSR.052.008.035 Detail E (4x) BSR.002.005.050 BSR.002.005.050 BSR.011.008.015 50 mm BSR.030.008.016 BSR.052.008.035 OPE.BBI.102.062 ORE.BBI.030.066 SME.MNP.143.916 MOD BBI 141 © Copyright BOERplay 28-2-2020 Revision: A...
  • Page 42 BSR.011.008.015 BSR.030.008.016 BSR.052.008.035 F (2x) F (2x) BSR.011.008.015 BSR.030.008.016 BSR.052.008.035 MOD.BBI.141.A BSR.014.005.053 MOD.BBI.141.G BSR.002.005.070 KST.ROR.006.000 Detail F (4x) MOD.BBI.141.A MOD.BBI.141.G 30 mm 70 mm BSR.014.005.053 BSR.002.005.070 KST.ROR.006.000 ø5mm ø3mm x 30 MOD BBI 141 © Copyright BOERplay 28-2-2020 Revision: A...
  • Page 43 Modul manual de instalación del módulo instructions d'installation du module MOD BBI 137 © Copyright BOERplay 30-4-2019 Revision: A...
  • Page 44 1 / 3 POL.BPK.004.203 12 mm 12 mm POL.BPK.004.203 MOD BBI 137 © Copyright BOERplay 30-4-2019 Revision: A...
  • Page 45 2 / 3 Detail A (4x) BSR.023.010.040 KST.ROR.010.000 BSR.017.010.005 BSR.017.010.005 BSR.023.010.040 KST.ROR.010.000 POL.BPK.004.203 MOD BBI 137 © Copyright BOERplay 30-4-2019 Revision: A...
  • Page 46 3 / 3 Detail B (4x) BSR.030.010.002 BSR.011.010.020 BSR.011.010.020 BSR.030.010.002 MOD BBI 137 © Copyright BOERplay 30-4-2019 Revision: A...
