Hydro SinkMaster 8821 User Manual

Safety Precautions
WARNING! Read and fully understand the user manual before operating this product.
Please use this equipment carefully and observe all warnings and cautions.
protective clothing and eyewear when dispensing chemicals or other materials or when working in the
WEAR
vicinity of all chemicals, filling or emptying equipment, or changing metering tips.
observe safety and handling instructions of the chemical manufacturer.
ALWAYS
direct discharge away from you or other persons or into approved containers.
dispense cleaners and chemicals in accordance with manufacturer's instructions. Exercise CAUTION when
maintaining your equipment.
reassemble equipment according to instruction procedures. Be sure all components are firmly screwed or
latched into position.
equipment clean to maintain proper operation.
KEEP
only to water tap outlets (25 psi Minimum, 85 psi Maximum and Maximum water temperature 120° F).
ATTACH
If the unit is used to fill a sink, or the discharge hose can be placed into a sink. The unit must be mounted
NOTE
so that the bottom of the cabinet is above the overflow rim of the sink.
Device shall be installed in a vertical orientation.
A plumbed, dedicated line is preferred for installation. When a dedicated line is not available, installation shall
ensure that no cross-connections between hot and cold water are created, and that atmospheric vaccum
breakers integrated into the building water supply are not negatively affected by being under pressure for
over 12 continuous hours.
introduction
Package Contents
1) Proportioning unit
2) Suction tubing: 1/4" x 14'
3) Foot valves and weights.
installation and operation
Installation
1. Hold unit up to wall and drill holes for the wall anchors with a 9/32" drill. Install mounting anchors, and then install screws
into top two anchors. Slide key holes at top of dispenser over screw heads. Install bottom two screws through holes in
cabinet. Tighten all screws. Do not mount more than 6 ft. (1.8 m) above bottom of concentrate container, nor below the
highest concentrate level (never mount your concentrate higher than the dispenser). Turn ball valves so they are in a horizontal
position (pointing left and right).
2. Select metering tips (see next section) and insert a tip into each hose barb on the eductor bodies.
3. Suction tubes should reach from hose barbs on eductors to bottoms of concentrate containers. Cut tube supplied to lengths
required. (There is enough tube for 7 feet of tube per eductor.) Slide a weight over one end of each suction tube and slide a
foot valve into the same ends of the tubes.
4. Slip open ends of suction tubes over the hose barbs/metering tips on the eductors (one at each side).
SinkMaster Propotioner
For Models 8821, 8831, 8841, 8851, 886
THANK YOU FOR YOUR INTEREST IN OUR PRODUCTS
4)
5) Metering tip kit(s)
6)
user manual
with E-Gap eductors
Discharge tubes
Mounting anchor kit
1
