BOERPLAY BBI 504 Series Installation Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Politieauto
BBI.504.K

Advertisement

loading
Need help?

Need help?

Do you have a question about the BBI 504 Series and is the answer not in the manual?

Questions and answers

Related Manuals for BOERPLAY BBI 504 Series

Summary of Contents for BOERPLAY BBI 504 Series

  • Page 1 Politieauto BBI.504.K...

  • Page 2: Installation Instructions

    Si el tierra no ayuda a la estabilidad del equipo que se está colocando, vierta 50L de hormigón por poste. FR - Important ! Si le sol ne contribue pas à la stabilité de l’équipement à placer, versez 50L de béton par poteau. BBI 504 x © Copyright BOERplay 22-2-2021 Revision:...
  • Page 3 Hoofdafmetingen Hauptabmessungen Dimensiones principales Dimensions principales 1,29 m 1,18 m 0,11 m 0,00 m 0,93 m 0,30 m 0,28 m 0,00 m BBI 504 x © Copyright BOERplay 22-2-2021 Revision:...
  • Page 4 Zona libre de obstáculos Zone libre d’obstacle 5,23 m Impact area Opvangzone Ausprallbereich Zona de impacto Zone d‘impact Obstacle free zone Obstakelvrije zone Hindernissfreie raum Zona libre de obstáculos Zone libre d’obstacle BBI 504 x © Copyright BOERplay 22-2-2021 Revision:...
  • Page 5 Bodemplan Bodenplan Plan de superficie Plan de surface 4,29 m 2,59 m 2,51 m 2,44 m 1,77 m 1,69 m 0,00 m Ground level Maaiveld Bodennahe Nivel del suelo Niveau au sol BBI 504 x © Copyright BOERplay 22-2-2021 Revision:...

  • Page 6: Assembly Manual

    Plastic Roestvrij staal Kunststof Blauw aluminium Zwart aluminium Hout Edelstahl Kunststoff Blaues Aluminium Schwarzes Aluminium Holz Acero inoxidable Plastico Aluminio azul Aluminio negro Madera Acier inoxydable Plastique Aluminium bleu Aluminium noir Bois BBI 504 x © Copyright BOERplay 22-2-2021 Revision:...
  • Page 7 Ø3 mm Ø5 mm Ø11 mm Ø12 mm Ø4.8 mm Only for metal posts Alleen voor metalen staanders Nur für Pfosten aus Metall Solo para postes de metal Seulement pour poteaux en métal BBI 504 x © Copyright BOERplay 22-2-2021 Revision:...
  • Page 8 1 / 3 Montagevolgorde Montagereihenfolge Orden de esemblado Ordre de montage assembly manual module MOD.BBI.311.006 2 / 3 assembly manual module MOD.BBI.305.x BBI 504 x © Copyright BOERplay 22-2-2021 Revision:...
  • Page 9 3 / 3 BOER PLAY xxx.xxx.xxx EN 1176 www.boerplay.com BBI 504 x © Copyright BOERplay 22-2-2021 Revision:...
  • Page 10 LOGBOEK (Onderstaand logboek kan gebruikt worden om te voldoen aan de eisen, gesteld in artikel 14 van het Warenwetbesluit Attractie- en Speeltoestellen) Type aanduiding Figura Play Artikelnummer BBI.504.K Naam toestel Politieauto Maximale valhoogte 0,3 m Bouwjaar 2023 Certificaat 065949 Keuringsinstantie TUV Nederland QA BV Ekkersrijt 4401 5692 DL Son...
  • Page 11 LOGBOEK Inspectie en onderhoud Datum Tijdstip Naam Naam Geconstateerde Te vervangen inspectie inspectie uitvoerder uitvoerder gebreken onderdelen onderhoud onderhoud inspectie onderhoud Ongevallen Genomen Datum Leeftijd Vermoedelijk oorzaak letsel Opgetreden persoonlijk letsel maatregel n.a.v. ongeval slachtoffer ongeval...
  • Page 12 Inspectie en onderhoud intervallen Maanden Nr. Inspectie Onderhoud tussen controle Speeltoestel controleren op stabiliteit, goede Ontbrekende onderdelen toevoegen, verbindingen en ontbrekende onderdelen. verbindingen vastdraaien. Ontbrekende Bouten, schroeven en moeren controleren op bevestigingsmiddelen aanbrengen en ontbreken, vastzitten, corrosie en slijtage gecorrodeerde onderdelen vervangen. Vervangen van versleten onderdelen en/of Ophangingen controleren op slijtage.
  • Page 13 6. Controleer het terrein regelmatig op zaken die er niet thuis horen, onveilig zijn of uitnodigen tot verkeerd gebruik, bijvoorbeeld giftige planten, glas enz. De controle frequentie is afhankelijk van de belasting. 7. Bedenk dat slecht onderhoud leidt tot onveiligheid en aantoonbare snellere verpaupering van de speelomgeving.
  • Page 15 Roestvrij staal Kunststof Blauw aluminium Zwart aluminium Hout Edelstahl Kunststoff Blaues Aluminium Schwarzes Aluminium Holz Acero inoxidable Plastico Aluminio azul Aluminio negro Madera Acier inoxydable Plastique Aluminium bleu Aluminium noir Bois MOD BBI 305 x © Copyright BOERplay 15-6-2022 Revision: A...
  • Page 16 BSR.030.010.002 BSR.026.010.120 BSR.010.010.010 BSR.030.010.002 KST.DOP.010.060 KST.DON.010.060 KST.DOP.010.060 S.BBI.042.x SME.BBI.040.372 Detail B (4x) BSR.014.005.052 BSR.002.005.050 OME.VRB.903.VZP OME.VRB.903.VZP 18 mm mm 50 mm mm ø5mm ø3mm x 30 BSR.014.005.052 BSR.002.005.050 OME.VRB.903.VZP OME.VRB.903.VZP MOD BBI 305 x © Copyright BOERplay 15-6-2022 Revision: A...
  • Page 17 S.BBI.043.x Detail C (2x) BSR.014.005.052 BSR.002.005.050 OME.VRB.903.VZP OME.VRB.903.VZP KST.LAM.100.100 KST.LAM.100.100 18 mm mm 50 mm mm ø5mm ø3mm x 30 BSR.014.005.052 BSR.002.005.050 OME.VRB.903.VZP OME.VRB.903.VZP MOD BBI 305 x © Copyright BOERplay 15-6-2022 Revision: A...
  • Page 18 S.BBI.042.x S.BBI.042.x Detail D (8x) BSR.026.010.120 KST.DON.010.060 BSR.030.010.002 BSR.010.010.010 BSR.010.010.010 KST.DOP.010.060 BSR.026.010.120 BSR.030.010.002 KST.DON.010.060 KST.DOP.010.060 MOD BBI 305 x © Copyright BOERplay 15-6-2022 Revision: A...
  • Page 19 S.BBI.043.x Detail E (4x) KST.DOP.010.060 BSR.010.010.010 BSR.030.010.002 BSR.010.010.010 KST.DON.010.060 BSR.026.010.150 BSR.026.010.150 BSR.030.010.002 KST.DON.010.060 KST.DOP.010.060 MOD BBI 305 x © Copyright BOERplay 15-6-2022 Revision: A...
  • Page 20 - module Montagehandleiding - module Montageanleitung - Modul Manual de ensamblado - módulo Manuel de montage - module MOD BBI 311 006 © Copyright BOERplay 11-8-2022 Revision: A...
  • Page 21 Detail B (1x) BSR.031.005.000 OPE.BBI.390.072 BSR.010.010.010 KST.DOP.010.030 BSR.023.010.055 BSR.023.010.070 BSR.010.010.010 BSR.030.010.002 BSR.031.005.000 BSR.030.010.002 KET.005.002.025 KST.DON.010.030 KST.BUS.012.020 KST.DON.010.030 KET.005.002.025 OPE.BBI.451.032 KST.DON.010.060 KST.DOP.010.030 BSR.030.010.002 KST.DOP.010.060 OPE.BBI.363.090 BSR.023.010.055 OPE.BBI.390.072 OPE.BBI.451.032 55 mm mm OPE.BBI.485.072 SMD.BBI.076 MOD BBI 311 006 © Copyright BOERplay 11-8-2022 Revision: A...
  • Page 22 / 23 OPE.BBI.459.090 C (6x) OPE.BBI.480.052 Detail C (14x) 35 mm BSR.053.005.035 BSR.053.005.035 OPE.BBI.459.090 OPE.BBI.480.052 MOD BBI 311 006 © Copyright BOERplay 11-8-2022 Revision: A...
  • Page 23 / 23 OPE.BBI.470.006 Detail D (3x) Detail E (6x) 70 mm ✔ BSR.002.005.070 BSR.010.008.008 OME.BBI.021 BSR.002.005.070 BSR.052.008.060 BSR.010.008.008 BSR.052.008.060 OME.BBI.021 OPE.BBI.470.006 MOD BBI 311 006 © Copyright BOERplay 11-8-2022 Revision: A...
  • Page 24 / 23 OPE.BBI.540.006 OPE.BBI.458.072 Detail F (2x) BSR.030.010.002 KST.DOP.010.060 BSR.023.010.060 BSR.010.010.010 BSR.030.010.002 KST.DON.010.060 Detail G (1x) BSR.010.010.010 BSR.023.010.060 BSR.030.010.002 KST.DON.010.060 KST.DOP.010.060 OME.BBI.158 OME.BBI.158 OPE.BBI.458.072 OPE.BBI.540.006 MOD BBI 311 006 © Copyright BOERplay 11-8-2022 Revision: A...
  • Page 25 / 23 OPE.BBI.539.072 C (5x) OPE.BBI.459.090 OPE.BBI.459.090 C (3x) OPE.BBI.544.052 OPE.BBI.478.090 C (6x) C (6x) OPE.BBI.478.090 OPE.BBI.539.072 C (5x) Detail C (25x) 35 mm BSR.053.005.035 OPE.BBI.459.090 BSR.053.005.035 OPE.BBI.478.090 OPE.BBI.539.072 OPE.BBI.544.052 MOD BBI 311 006 © Copyright BOERplay 11-8-2022 Revision: A...
  • Page 26 C (4x) OPE.BBI.465.090 OPE.BBI.479.052 OPE.BBI.479.052 H (4x) H (4x) Detail C (22x) 35 mm BSR.053.005.035 Detail G (2x) Detail H (8x) BSR.053.005.035 KST.ROR.006.000 OME.BBI.158 OPE.BBI.465.090 KST.ROR.006.000 OPE.BBI.473.032 BSR.053.005.035 OPE.BBI.479.052 OME.BBI.158 MOD BBI 311 006 © Copyright BOERplay 11-8-2022 Revision: A...
  • Page 27 Detail C (5x) 35 mm BSR.053.005.035 Detail I (2x) Detail D (5x) KST.DOP.010.060 BSR.010.010.010 BSR.030.010.002 KST.DON.010.060 ✔ BSR.010.008.008 BSR.010.010.010 BSR.010.008.008 BSR.030.010.002 BSR.052.008.060 BSR.024.010.115 BSR.053.005.035 OME.BBI.021 KST.DON.010.060 BSR.052.008.060 KST.DOP.010.060 OME.BBI.021 OPE.BBI.385.022 BSR.024.010.115 MOD BBI 311 006 © Copyright BOERplay 11-8-2022 Revision: A...
  • Page 28 KST.DOP.010.060 BSR.010.010.010 BSR.030.010.002 KST.DON.010.060 KST.BUS.012.020 BSR.030.010.002 BSR.024.010.060 Detail K (1x) OPE.BBI.331.032 KST.DOP.010.060 BSR.010.010.010 BSR.030.010.002 OPE.BBI.476.072 KST.DON.010.060 KST.BUS.012.020 BSR.030.010.002 BSR.010.010.010 BSR.023.010.060 BSR.024.010.060 BSR.023.010.060 BSR.030.010.002 BSR.030.010.002 KST.BUS.012.020 KST.DON.010.060 KST.DOP.010.060 OPE.BBI.331.032 OPE.BBI.476.072 OPE.BBI.548.006 MOD BBI 311 006 © Copyright BOERplay 11-8-2022 Revision: A...
  • Page 29 35 mm BSR.053.005.035 Detail M (1x) OPE.BBI.471.072 BSR.023.010.080 BSR.030.010.002 OPE.BBI.475.090 OPE.BBI.477.006 BSR.010.010.010 BSR.030.010.002 BSR.031.005.000 KST.DON.010.060 BSR.030.010.002 BSR.053.005.035 KST.DON.010.060 KST.DOP.010.060 OPE.BBI.459.090 OPE.BBI.471.072 BSR.030.010.002 OPE.BBI.475.090 OPE.BBI.478.090 OPE.BBI.378.090 BSR.010.010.010 KET.005.002.011 KST.DOP.010.060 OPE.BBI.477.006 BSR.023.010.080 MOD BBI 311 006 © Copyright BOERplay 11-8-2022 Revision: A...
  • Page 30 / 23 Detail I (2x) Detail D (5x) KST.DOP.010.060 BSR.010.010.010 BSR.030.010.002 KST.DON.010.060 ✔ BSR.010.008.008 BSR.010.008.008 BSR.010.010.010 BSR.024.010.115 BSR.030.010.002 OME.BBI.021 BSR.052.008.060 BSR.052.008.060 KST.DON.010.060 KST.DOP.010.060 OME.BBI.021 BSR.024.010.115 MOD BBI 311 006 © Copyright BOERplay 11-8-2022 Revision: A...
  • Page 31 BSR.030.010.002 BSR.030.010.002 BSR.070.012.120 BSR.023.010.060 KST.BBI.035 BSR.070.012.120 KST.BOL.036.030 KST.BBI.035 KST.BOL.036.050 KST.BOL.036.xxx KST.DON.010.030 xxx: 030 Red KST.DON.010.050 Rood / Rot / Rojo / Rouge KST.DOP.010.030 KST.DOP.010.050 OPE.BBI.542.006 OPE.BBI.543.032 OPE.BBI.545.032 BSR.005.004.019 OPE.BBI.556.052 OPE.BBI.557.052 MOD BBI 311 006 © Copyright BOERplay 11-8-2022 Revision: A...
  • Page 32 / 23 OPE.BBI.547.072 Detail C (9x) 35 mm BSR.053.005.035 BSR.053.005.035 OPE.BBI.547.072 MOD BBI 311 006 © Copyright BOERplay 11-8-2022 Revision: A...
  • Page 33 / 23 Detail D (2x) ✔ Detail H (7x) BSR.010.008.008 OME.BBI.021 BSR.010.008.008 KST.ROR.006.000 BSR.052.008.060 BSR.052.008.060 BSR.053.005.035 BSR.053.005.035 KST.ROR.006.000 OME.BBI.021 MOD BBI 311 006 © Copyright BOERplay 11-8-2022 Revision: A...
  • Page 34 OPE.BBI.464.072 OPE.BBI.474.006 Detail P (2x) Detail C (6x) 35 mm mm BSR.053.005.035 Detail D (5x) ✔ BSR.010.008.008 BSR.052.008.060 BSR.053.005.035 BSR.010.008.008 OME.BBI.021 OME.BBI.174.304 OME.BBI.183.304 OME.BBI.021 OPE.BBI.462.072 BSR.052.008.060 OPE.BBI.464.072 OPE.BBI.474.006 OPE.BBI.481.006 OPE.BBI.482.006 MOD BBI 311 006 © Copyright BOERplay 11-8-2022 Revision: A...
  • Page 35 Detail R (1x) OPE.BBI.383.090 BSR.010.010.010 KST.DOP.010.060 BSR.021.010.100 BSR.021.010.100 BSR.023.010.040 BSR.030.010.002 KST.BUS.012.020 KST.BUS.012.020 KST.DON.010.010 BSR.030.010.002 KST.DON.010.060 KST.DON.010.060 KST.DON.010.030 BSR.030.010.002 KST.DON.010.050 KST.DON.010.060 OPE.BBI.446.090 KST.DOP.010.010 KST.DOP.010.030 BSR.010.010.010 KST.DOP.010.050 KST.DOP.010.060 KST.DOP.010.060 OPE.BBI.383.090 OPE.BBI.446.090 QRC.BBI.004 MOD BBI 311 006 © Copyright BOERplay 11-8-2022 Revision: A...
  • Page 36 BSR.030.010.002 Detail D (4x) OPE.BBI.386.090 BSR.010.008.008 BSR.010.010.010 BSR.021.010.100 KST.BUS.012.020 BSR.023.010.060 BSR.030.010.002 ✔ BSR.052.008.060 KST.DON.010.060 BSR.070.010.050 KST.BUS.012.020 BSR.030.010.002 BSR.010.008.008 KST.DON.010.030 KST.DON.010.060 KST.DOP.010.030 OME.BBI.021 BSR.010.010.010 KST.DOP.010.060 BSR.052.008.060 OME.BBI.021 KST.DOP.010.060 OPE.BBI.372.072 OPE.BBI.386.090 OPE.BBI.414.032 MOD BBI 311 006 © Copyright BOERplay 11-8-2022 Revision: A...
  • Page 37 / 23 OPE.BBI.483.090 OPE.BBI.484.072 ORE.BBI.026 Detail E (10x) 70 mm BSR.002.005.070 BSR.002.005.070 OPE.BBI.483.090 OPE.BBI.484.072 ORE.BBI.026 MOD BBI 311 006 © Copyright BOERplay 11-8-2022 Revision: A...
  • Page 38 / 23 OPE.BBI.460.006 OPE.BBI.459.090 OPE.BBI.478.090 C (6x) Detail C (6x) 35 mm BSR.053.005.035 BSR.053.005.035 OPE.BBI.459.090 OPE.BBI.460.006 OPE.BBI.478.090 MOD BBI 311 006 © Copyright BOERplay 11-8-2022 Revision: A...
  • Page 39 / 23 D (3x) Detail D (10x) Detail E (4x) 70 mm ✔ BSR.010.008.008 BSR.002.005.070 OME.BBI.021 BSR.052.008.060 BSR.002.005.070 BSR.010.008.008 BSR.052.008.060 OME.BBI.021 MOD BBI 311 006 © Copyright BOERplay 11-8-2022 Revision: A...
  • Page 40 Rood / Rot / Rojo / Rouge KST.BBI.035 KST.BOL.036.xxx xxx: 050 Blue Blauw / Blau / Azul / Bleu BSR.070.012.120 BSR.005.004.019 Detail C (8x) 35 mm BSR.005.004.019 BSR.053.005.035 BSR.070.012.120 KST.BBI.035 BSR.053.005.035 KST.BOL.036.030 KST.BOL.036.050 OPE.BBI.463.006 OPE.BBI.467.090 OPE.BBI.468.090 MOD BBI 311 006 © Copyright BOERplay 11-8-2022 Revision: A...
  • Page 41 / 23 OPE.BBI.541.052 Detail D (13x) Detail G (1x) ✔ BSR.010.008.008 OME.BBI.021 BSR.010.008.008 BSR.052.008.060 BSR.052.008.060 OME.BBI.021 OME.BBI.158 OME.BBI.158 OPE.BBI.541.052 MOD BBI 311 006 © Copyright BOERplay 11-8-2022 Revision: A...
  • Page 42 / 23 OPE.BBI.546.052 Detail D (5x) ✔ BSR.010.008.008 OME.BBI.021 BSR.052.008.060 BSR.010.008.008 BSR.052.008.060 OME.BBI.021 OPE.BBI.546.052 MOD BBI 311 006 © Copyright BOERplay 11-8-2022 Revision: A...
  • Page 43 / 23 OPE.BBI.458.072 Detail G (1x) OME.BBI.158 OME.BBI.158 OPE.BBI.458.072 MOD BBI 311 006 © Copyright BOERplay 11-8-2022 Revision: A...
