AMT-FAPVS-21

Thank you for choosing our product. Please read the instructions carefully

before operation. Follow these instructions to ensure that the product is

functioning properly. The images shown in this manual are for illustrative

purposes only.

P a g e

| 1

User Manual

AMT-FAPVS-21

Date: October 2022

Doc Version: 1 .2

English

For further details, please visit our Company's website

www.armatura.us.

User Manual

Table of Contents

Need help?

Do you have a question about the AMT-FAPVS-21 and is the answer not in the manual?

Questions and answers

Summary of Contents for ARMATURA AMT-FAPVS-21

Page 1 Follow these instructions to ensure that the product is functioning properly. The images shown in this manual are for illustrative purposes only. For further details, please visit our Company’s website www.armatura.us. P a g e Copyright© 2022 ARMATURA LLC. All rights reserved.
Page 2 ARMATURA supplied product vests in and is the property of ARMATURA. The contents hereof should not be used or shared by the receiver with any third party without express written permission of ARMATURA.
Page 3 ARMATURA in no event shall be liable to the user or any third party for any incidental, consequential, indirect, special, or exemplary damages, including, without limitation, loss of business, loss of profits,...
Page 4 User Manual About the Company ARMATURA is a leading global developer and supplier of biometric solutions which incorporate the latest advancements in biometric hardware design, algorithm research & software development. ARMATURA holds numerous patents in the field of biometric recognition technologies. Its products are primarily used in business applications which require highly secure, accurate and fast user identification.
Page 5 The general information which helps in performing the operations faster. The information which is significant. Care taken to avoid danger or mistakes. The statement or event that warns of something or that serves as a cautionary example. P a g e Copyright© 2022 ARMATURA LLC. All rights reserved.
Page 6: Table Of Contents
........................... 24 ISSIPATION ESIGN INSTALLATION GUIDE ........................ 25 ..........................25 NSTALLATION ODES ......................26 NSTALLATION EIGHT AND NGLE 9.2.1 Horizontal Installation Mode ......................27 9.2.2 Slant Installation Mode ........................27 P a g e Copyright© 2022 ARMATURA LLC. All rights reserved.
Page 7: Product Introduction
User Manual Product Introduction Overview AMT-FAPVS-21 is a dual-camera multimodal standalone module for face and palm recognition empowered by high-performance processors. The multimodal standalone module includes functions such as image collection, biometric template extraction, matching, transmission, and data management. The module has compact, light-weight size and is highly adaptable to various ambient lighting and supports touchless multi-biometric recognition.
Page 8: Features
Dual 1/2.8" HDR CMOS, 2MP resolution Image Sensor (supports visible and near-infrared light) Communication Interface USB 2.0 Communications Protocol Composite UVC device + HID protocol Camera Type M8, 2MP P a g e Copyright© 2022 ARMATURA LLC. All rights reserved.
Page 9: Electrical Features
Visible-light Lens Near-infrared Lens 720 x 1280@25fps 720 x 1280@25fps Resolution @Frame rate 480 x 640@25fps 480 x 640@25fps Default Output MJPEG NV12 Format Signal-to-Noise 50 dB 50 dB Ratio P a g e Copyright© 2022 ARMATURA LLC. All rights reserved.
Page 10: Model Specifications
Supported Algorithm Type Facial Recognition Palm Recognition 50cm - 160cm 15cm - 40cm Effective Image Range (Algorithm Recognition Range) (1.5 feet – 5 feet) (6 inch – 15 inch) P a g e | 10 Copyright© 2022 ARMATURA LLC. All rights reserved.
Page 11: Algorithm Specifications
Algorithm Specifications Facial Recognition Algorithm Based on years of in-depth technological development in the biometrics industry, ARMATURA's facial recognition algorithm is able to handle multi-dimensional face attribute analysis and high-accuracy face identification from different age groups. It can detect up to 180 face landmark points within milliseconds, including the landmarks of eyes, lip edges, nose tips, contours and etc.
Page 12: Fake Face Detection
Visible-light lens detection (maximum range: 2 m or 6.5 feet ) Detection Speed 30 ms Min. Image Size 128 x 128 pixels Posture Adaptability Yaw ≤ 30°, Pitch ≤ 30°, Roll ≤ 45° P a g e | 12 Copyright© 2022 ARMATURA LLC. All rights reserved.
Page 13: Mask Detection
The algorithm is also capable of analyzing and understanding facial attributes such as age, gender, and facial expression. It can display all the above mentioned attributes when it detects a face, on the P a g e | 13 Copyright© 2022 ARMATURA LLC. All rights reserved.
Page 14: Facial Recognition
Facial expression recognition > 88% 3.1.5 Facial Recognition The algorithm can detect a face and recognise the identity of the person within fractions of second and with high accuracy rate. P a g e | 14 Copyright© 2022 ARMATURA LLC. All rights reserved.
Page 15: Facial Registration Image Quality Requirements
• The whole face should be in the camera frame and the aspect ratio of the face must not be distorted. • Face contours should be clear and the light must be even. • The facial expression should be natural without obvious exaggeration. P a g e | 15 Copyright© 2022 ARMATURA LLC. All rights reserved.
Page 16: Palm Recognition Algorithm
In this appoach, the robustness and pass rate are considerably improved. The algorithm applies to various palm postures as shown in Figure 3.3: Figure 3.3 Definitions of palm postures P a g e | 16 Copyright© 2022 ARMATURA LLC. All rights reserved.
Page 17: Palm Recognition Specifications
• The whole palm (including the wrist) should be in the camera frame and the aspect ratio of the palm must not be distorted. • The palm angle tolerance for pitch, roll, yaw, and bend should be ±5 degrees. P a g e | 17 Copyright© 2022 ARMATURA LLC. All rights reserved.
Page 18: Application Scenarios
Figure 3.4 Example of a palm registration image Application Scenarios The AMT-FAPVS-21 dual-camera modules are optimized in structure based on the design and usage of built-in modules, facilitating quick integration into the host device. Due to the profoundly integrated design, the dual-camera module can be connected to a platform device using a single USB cable.
Page 19 The high- performance heterogeneous processor of the dual-camera modules helps free up the computing resources of your platform. Template Comparison and Management ⚫ P a g e | 19 Copyright© 2022 ARMATURA LLC. All rights reserved.
Page 20 As such, it is particularly suitable for the integration of the face/palm recognition function in low-performance embedded platforms. Figure 4.3 shows some functions of a front-end comparison system. P a g e | 20 Copyright© 2022 ARMATURA LLC. All rights reserved.
Page 21: Structural Dimensions
It shortens the development cycle and improves product competitiveness. Structural Dimensions Figure 5.1 Structural dimensions of a dual-camera module P a g e | 21 Copyright© 2022 ARMATURA LLC. All rights reserved.
Page 22: Port Definition
User Manual PIN Definition PIN Position and Definition The AMT-FAPVS-21 dual-camera modules use a 1.25 mm 5-pin wafer connector with lock. Figure 6.1 shows its position and pin definition below. Figure 6.1 Port definition of dual-camera modules PIN Socket Dimensions The AMT-FAPVS-21 dual-camera modules use a 1.25 mm 5-pin wafer connector with lock.
Page 23: Cable Requirements
Figure 7.1 Specifications of a double-plug cable (Unit: mm) Hardware Design and Integration Guide Optical Design AMT-FAPVS-21 are built-in dual-camera modules. The optical design is included when the modules are integrated into devices. To avoid mistakes in optical design and improve development efficiency, use the following specifications: For the transparent material used in front of a module, such as glass and acrylic, the transmittance should be greater than 85% with a wavelength coverage of 400 nm to 900 nm.
Page 24: Heat Dissipation Design
When a module is integrated into a device, the heat dissipation performance is improved by using a thermal conduction design. Similarly, the AMT-FAPVS-21 dual-camera modules are equipped with structural metal components capable of heat dissipation. A thermally conductive silicone pad is added to the back of the structural component.
Page 25: Installation Guide
Figure 8.4 Thermal conduction design Installation Guide Installation Modes Considering the built-in design of the AMT-FAPVS-21 dual-camera modules, it is recommended to use either rear-locking or front-locking mode to install and mount a module. Figure 9.1 shows a rear- locking mode.
Page 26: Installation Height And Angle
User Manual Installation Height and Angle When you install an AMT-FAPVS-21 dual-camera module, you need to consider the influence of the installation angle and height on the field of view for image collection. If the mixed face/palm recognition algorithm is used, you need to consider the field of view that faces can adapt to, the range requirements of palm recognition, and the convenience and speed of man-machine interaction.
Page 27: Horizontal Installation Mode
1.45 m. If a person can be recognized at a distance of 0.5 m to 0.8 m, the module can adapt to individuals with height is between 1.45 m and 2.18 m, as shown in Figure 9.4. Figure 9.4 Slant installation P a g e | 27 Copyright© 2022 ARMATURA LLC. All rights reserved.
Page 28 AMT-FAPVS-21 User Manual 190 Bluegrass Valley Pkwy, Alpharetta, GA 30005 E-mail: info@armatura.us www.armatura.us P a g e | 28 Copyright© 2022 ARMATURA LLC. All rights reserved. Copyright © 2022 ARMATURA LLC. All Rights Reserved.
