- Page 1 EK-Loop D5 Pump Mounting Kit USER GUIDE...
- Page 2 The following instructions are subject to change without notice. Please visit our website at www. ekwb.com for updates. Before installation of this product, please read the important notice, disclosure, and warranty conditions that are printed on the back of the box.
-
Page 3: Table Of Contents
TABLE OF CONTENTS BOX CONTENTS COMPATIBILITY REPLACING THE PUMP CONNECTING THE PUMP SUPPORT AND SERVICE SOCIAL MEDIA - 3 -... -
Page 4: Box Contents
BOX CONTENTS D5 Pump mounting screws D5 Pump holder (1 pc) D5 Pump O-ring (1 pc) M4x20 DIN7984 (4 pcs) COMPATIBILITY The upgrade kit is compatible with the following products: - 3831109905630 EK-Mana G2 PC-O11D EVO DDC D-RGB Distribution Plate - 3831109851159 EK-Quantum Kinetic FLT 80 DDC PWM D-RGB - Plexi - 3831109819753 EK-Quantum Kinetic FLT 120 DDC PWM... -
Page 5: Replacing The Pump
Important! This kit does NOT contain a D5 pump. EK suggests DDC PUMP the EK-Loop D5 G3 PWM Motor, which is the most SCREWS modern version of the D5 pump with a SATA power connector. The pump can be purchased in EK Shop: https://www.ekwb.com/shop/ek-loop-d5-g3-pwm-motor... - Page 6 SCREW A leakage test is mandatory after fixing the screws. EK recommends using the EK-Loop Leak Tester for the test. More information on leak testing can be found here: https://www.ekwb.com/shop/ek-loop-leak-tester-flex For this step, you will need: PUMP D5 Pump mount-...
-
Page 7: Connecting The Pump
CONNECTING THE PUMP The EK-D5 PWM pump has two connectors. 1. SATA Connector: It must be connected directly to your PSU at all times as it is used to power the pump. 2. 4-pin PWM fan: It can be connected to your motherboard’s CPU_ Fan or designated water pump header. -
Page 8: Support And Service
SUPPORT AND SERVICE In case you need assistance, please contact: https://www.ekwb.com/customer-support/ EKWB d.o.o. Pod lipami 18 1218 Komenda Slovenia - EU SOCIAL MEDIA EKWaterBlocks @EKWaterBlocks ekwaterblocks EKWBofficial ekwaterblocks...
