Summary of Contents for SPIKECAM S4JL
- Page 1 SPIKECAM Body Camera USER MANUAL Model: S4JL https://www.spikecam.com...
- Page 2 SPIKECAM Dear Customer, Thank you for choosing the SPIKECAM S4JL body camera. We hope you find it useful for your needs. Before using the camera, please take a few minutes to carefully read the manual. For your convenience, we have also prepared a quick video guide. Please...
- Page 3 SPIKECAM Diagram 13 14 1. Infrared LED 10. USB Charging port 2. Microphone 11. Battery LED 3. Camera Lens 12. WiFi LED 4. Power/Record Button 13. Charging LED 5. LED Ring 14. Power LED 6. Reset Button 15. Pogo Pin(Data Port) 7.
-
Page 4: Specification
SPIKECAM Specification RECORDING Multiple Recording Resolution Video Resolution 1296P/1080P/ 720P/480P/VGA Video Format .MOV Recording Angle Wide Angle 140 degrees Audio High Quality Built-in Microphone. Recording Indicator Front LED Ring and Top LED Indicator Water Mark User ID, Time and Date Stamp Embedded into Video. -
Page 5: Power On/Off
SPIKECAM Power On/Off Power on: 1. Press and hold the Power Button (No. 4) for 3 seconds to turn on the camera. The Power LED (No. 14) will light up green, accompanied by a power-on sound. Please note that the camera will take 2-3 seconds to initialize the settings during which time the button will not respond. - Page 6 SPIKECAM Taking a Photo 1. Whilst in Recording Standby Mode or during Video Recording Mode, simply press the Photo Button (No. 8) to capture a photo. 2. If the device is in Recording Standby Mode, the Power Indicator will flash red once. A shutter sound will accompany the photo capture process.
- Page 7 SPIKECAM WiFi Function To activate the WiFi function, press and hold the Photo Button for more than 3 seconds until the White LED(No.12) on the top lights up. This indicates that the camera has entered WiFi hotspot mode, and you can locate the camera's WiFi signal (starting with "...
-
Page 8: Charge The Camera
To access the software for configuring camera settings, copy the " Cam Manager.zip " file from the SPIKECAM USB Disk or download it from our official website to your desktop. Once the file is downloaded, unzip it and open the software. - Page 9 SPIKECAM Cam Manager Setting How to Login? 1. Connect Camera to PC via cradle. 2. Input your password, then click “Login” Default Password is 000000 (six zero). When the "Sync Time" checkbox is selected, the camera will synchronize with the Windows time.
- Page 10 SPIKECAM Cam Manager Setting Below are the options you can change Parameter Settings Reminder: The camera will vibrate at regular intervals during recording to remind the user that it is still recording. You can adjust the interval time to 10, 20, or 30 seconds.
- Page 11 SPIKECAM WiFi App 2.To connect to the camera, turn on the camera's WiFi Hotspot and use your mobile phone to connect to the camera's WiFi signal started with wifi-camera-xxxxxx (with the default password "12345678"). For more details, please refer to step WiFi Function.
- Page 12 SPIKECAM How to use viidure App? Playback files (1) Click the “Access Camera” button to enter camera preview mode. Camera will start video recording automatically. (2) Click the recorder icon to start or stop video recording. (3) Click the camera icon at the bottom to capture a photo.
- Page 13 SPIKECAM How to use viidure App? (5) In IOS, you have to go to downloaded files and click the save button to save the downloaded video to your phone's album. Therefore, you will be able to share it to other apps.
- Page 14 SPIKECAM Trouble Shooting 1. The camera won't turn on. Please charge the camera battery for at least 3 hours before attempting to turn on the camera again. 2. The camera is unresponsive. Please press the Reset Button (No.6) to power off the camera, and then restart it.
