- Page 1 WHYNTER Eco Pure Air Purifier MODEL# : AFR-300 SB/W Instruction Manual Thank you for your purchase of this WHYNTER product. Please read this Instruction Manual carefully before using the product to ensure optimal performance. Keep this manual in a safe place for future reference.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safety Instructions………………………………..3 Purification Technology……………………...4 Technical Data………………………………………………...5 Parts and Features ……………………………...6 Control Panel & Remote Control……………….………….7-9 Installation ……………………………………………...10 Care and Maintenance………………………………...10-12 Troubleshooting………………………...13 Warranty …………..………………………...14... -
Page 3: Important Safety Instructions
5. Keep the appliance away from any heat source, direct sunlight or area with excessive moisture such as bathrooms and kitchens. 6. This air purifier is an electrical appliance. To avoid injury from electrical shock do not operate the appliance with wet hands, while standing on a wet surface or while standing near in water. -
Page 4: Purification Technology
Pre-filter, HEPA filter, Activated carbon filter, Photo-catalyst filter and UV light. The AFR-300 air purifier not only traps dust and dirt, it also destroys allergens such as dust mites, pollen and pet epithelia. It kills over 99% of viruses, over 98% of bacteria and over 94% of mold and fungus. -
Page 5: Technical Data
Voltage Purification efficiency Input power Noise level (at lowest setting) Fan Speed Air flow Net weight Product size(W×H×D) AFR-300 600 Sq. Ft. 120v / 60Hz >99.97% 76 Watts <35dB 4 adjustable speed 250 Square Meter per Hour Max. / 147 Cubic feet per minute Max. -
Page 6: Parts And Features
1. Control Panel 2. Front Cover 6. Filter Frame 7. HEPA Filter & Activated Carbon Filter 11. Handle 12. Air Outlet Vent PARTS OVERVIEW 3. Front Cover Clip 4. Air Intake Vents 8. Photo-catalyst 9. UV Lamp Filter 13. Fragrance 14. -
Page 7: Control Panel & Remote Control
2. FAN: Sets fan speed setting in the cycle of High –> Medium –> Low –> Silent. 3. SILENT: Sets the air purifier to run at a noise level below 35 dB to ensure sound sleep. By pressing this button, this machine will be switched into the “SILENT” fan mode. -
Page 8: Remote Control Operation
2. FAN: Sets fan speed setting in the cycle of High –> Medium –> Low –> Silent. 3. SILENT: Sets the air purifier to run at a noise level below 35 dB to ensure sound sleep. By pressing this button, this machine will be switched into the “SILENT”... - Page 9 The remote control is loaded with a CR2025 battery in advance. Before use, please pull off the battery insulating plastic. • Aim the emitter of the remote control to receiver in the front of the air purifier. The maximum signal transmission distance is approximately 15 feet. •...
-
Page 10: Installation
3. Keep a distance of at least 3 feet of space between the air purifier and any equipment which emits electric waves such as televisions, radios or wave clocks. - Page 11 Remove the front cover, the pre-filter and the old HEPA filter. • Install the new HEPA filter with the arrow in the front to the air purifier. • Press the HEPA “RESET” button on the remote control to reset the HEPA filter timer.
- Page 12 ► Replacing the UV Lamp The UV lamp should be replaced every 15,000 working hours. This is indicated by the blinking of the UV icon on the LCD display. Please contact Whynter’s service department for purchase information of a new UV lamp.
-
Page 13: Troubleshooting
Air inlets maybe obstructed Unit is not reset Unit needs to be restarted Solution Ensure that the air purifier is plugged in and the power outlet has power Install the front cover properly Turn off the Child lock Replace battery in the remote... -
Page 14: Warranty
Whynter’s service department), along with an explanation of the claim to Whynter LLC. Please package the air purifier carefully in its original packaging material to avoid damage in transit. Please retain the original box and packaging material.
