- Page 2 21062 Bake Parkway Lake Forest, CA 92630 Thank you for purchasing this Element RC product. This assembly manual contains instructions and tips for building and maintaining your new Enduro chassis. Please take a moment to read through this manual to help familiarize Customer Service yourself with these steps.
- Page 3 33.657120, -117.701139 HARDWARE 1:1 SCALE VIEW HARDWARE USED WITH OPTIONAL REPLACEMENT PART NUMBERS FLAT HEAD SCREWS (FHCS) BUTTON HEAD SCREWS (BHCS) SHIMS AND WASHERS 2.5x10mm (41088) Servo Horn Spacer (42041) 2.5x10mm (31350) 3x5mm (31530) 2.5x14mm (41077) 3x7mmx1mm (42260) 3x6mm (31531) 3x8mm (25201) 3x7mmx2mm (42260) 3x8mm (31532)
- Page 4 33.657120, -117.701139 TABLE OF CONTENTS 7/17/2023 COVER DRIVESHAFTS BUILD (BAG 8) INTRODUCTION SHOCKS BUILD (BAG 9) 1:1 HARDWARE “FOLD OUT” BUMPERS BUILD (BAG 10) TABLE OF CONTENTS WHEELS/TIRES BUILD CHASSIS BUILD (BAG 1, 2) BODY BUILD (BAG 11) ELECTRONIC MOUNTS BUILD (BAG 3) WHEELBASE CHART GEARBOX BUILD (BAG 4) OPTIONAL GEARBOX BUILD...
- Page 5 YOUR BUILD BEGINS HERE. GATE 01 CHASSIS BUILD: BAG 1, 2 25211 42001 42005 89208 31532 3x10mm Bumper Mount Shock Mount 3x14mm 31531 3x8mm BHCS Front (Left, Front) FHCS BHCS 3x6mm BHCS 25211 3x10mm 31532 42006 BHCS 3x8mm Floor Board BHCS 31532 25211...
- Page 6 GATE 01 ELECTRONIC MOUNTS BUILD: BAG 3 NOTE: There is an optional 71050 “standard pack” sized battery Hook and 25203 tray included! Loop Straps 3x12mm FHCS 42003 Battery Box, Shorty Pack GATE 02 ELECTRONIC MOUNTS BUILD: BAG 3 Receiver 42007 6727 Receiver Servo Tape...
- Page 7 33.657120, -117.701139 GATE 01 GEARBOX BUILD: BAG 4 42028 Stealth X Gearbox Drive Gear, 53T 41077 2.5x14mm FHCS 42027 91563 Stealth X Gearbox 10x15x4mm 42027 Outdrive, Short 42027 Bearing Stealth X Gearbox Stealth X Gearbox Outdrive, Long Drive Gear Shim 31350 42028 2.5x10mm...
- Page 8 GATE 04 GEARBOX BUILD: BAG 4 1336 Pinion Gear 42023 Stealth X Gearbox Gear Cover 25225 3x3mm Set Screw NOTE: Make sure the gear mesh 31530 between the spur gear and pinion 89208 25201 3x5mm has a slight amount of movement 3x14mm 3x8mm BHCS...
- Page 9 33.657120, -117.701139 GATE 03 GATE 01 FRONT AXLE BUILD: BAG 5 REAR AXLE BUILD: BAG 6 42060 42065 25211 Axle Housing, Ring Gear, 3x10mm 91479 Differential Cover BHCS 7x14x3.5mm Bearing 42064 Steering Block Arm, BTA, Right 42064 Steering Block Arm, BTA, Left 42019 Wheel Hex...
- Page 10 GATE 02 LINKS BUILD: BAG 7 NOTE: Install servo link 42260 screw #2308 in outermost 42041 3x7mm hole in servo horn. Spacer Pivot Ball, 25187 42043 3x14mm Link, BHCS 83mm 42040 Rod End, Curved NOTE: Check the rod end angles before installation 102.20mm 25215 M3 Locknut,...
- Page 11 33.657120, -117.701139 GATE 05 LINKS BUILD: BAG 7 25187 NOTE: Build and install 3x14mm, 42041 two front lower links BHCS Pivot Ball, 4689 3x16mm, Set Screw 42043 Link, 42040 100mm Rod End, Curved NOTE: Check the rod end angles before installation 129.50mm GATE 06 LINKS BUILD: BAG 7...
- Page 12 GATE 01 DRIVE SHAFT BUILD: BAG 8 42020 42021 42020 42021 31532 Gearbox Side Drive Shaft, Drive Shaft, Female Pin, 3x8mm Male, CVA (33mm, 42mm) 2x11mm BHCS 42020 Axle Side 42020 42021 Pin Retainer, Drive Shaft 42021 Long Barrel Drive Shaft, 42020 42020 Female, CVA...
- Page 13 33.657120, -117.701139 GATE 01 SHOCK BUILD: BAG 9 SHOCK CAP 42081 42081 O-RING Shock O-Ring, Small, Piston Shock Cap 42082 SHOCK COLLAR O-RING Shock Body, 10x32mm 5407 6299 O-Ring, E-Clip 42040 Enduro 42081 Rod Ends Shock O-Ring 42083 Spacer Shock Shaft, Pro Tip: 3x30mm 42080...
- Page 14 GATE 04 SHOCK BUILD: BAG 9 42041 42041 Pivot Ball, Pivot Ball, Upper Shock Upper Shock 42260 42260 3x1mm 3x1mm Spacer Spacer 89203 89203 3x16mm 3x16mm BHCS BHCS 25187 25187 3x14mm 3x14mm BHCS 42041 BHCS 42041 Pivot Ball Pivot Ball GATE 01 BUMPER BUILD: BAG 10 31531...
- Page 15 33.657120, -117.701139 GATE 02 WHEEL/TIRE BUILD NOTE: Install 4 wheels/tires 42009 Body Mount, Short Pin Front Post Rear Post 25391 FT M4 Locknut, Blue 42022 42100 Screw Pin Method 701, 1.9” NOTE: Install Nut Cap, Bronze 4 body mounts GATE 01 BODY BUILD: BAG 11 42277 42277...
- Page 16 GATE 03 BODY BUILD: BAG 11 6332 Body Clips 25211 42278 3x10mm Knight Walker Roll BHCS Cage Washers GATE 04 BODY BUILD: BAG 11 42100 Method 701, 1.9” Nut Cap, Bronze 25391 FT M4 Locknut, Blue GATE 05 WHEELBASE CHART 73mm FRONT UPPER FRONT LOWER...
- Page 17 33.657120, -117.701139 GATE 01 STEALTH X: BUILD CONFIGURATION: MOTOR MOUNT FACING REAR (STOCK) OVERDRIVE: Overdrive is a scenario where the front and rear wheels do not rotate at the same speed. The Stealth X gearbox is designed to allow the front wheels to spin faster than the rear wheels. Overdrive is advantageouse when climbing up rock faces because the front tires will want to pull the vehicle up the rock.
