8 LAN 10Gig Fiber SFP+ 4G NGFW Firewall 1U Rackmount Server

NSHO-001

User Manual

www.pondesk.com

Table of Contents

Need help?

Do you have a question about the NSHO-001 and is the answer not in the manual?

Questions and answers

Summary of Contents for Winston NSHO-001

Page 2 8 LAN 10Gig Fiber SFP+ 4G NGFW Firewall 1U Rackmount Server NSHO-001 WWW.PONDESK.COM 8 LAN 10Gig Fiber SFP+ 4G NGFW Firewall 1U Rackmount Server © Copyright Winston Marriot Ltd. All Rights Reserved. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 3 Winston Marriot Ltd takes no liability and responsibility for any in error that may appear in this manual. Winston Marriot Ltd will not be responsible and liable for the errors that may contained in this manual and for incidental or consequential damages (including lost profits) in connection with the furnishing, performance or use of this material.
Page 7 Mikrotik, firewall and gateways like, pfSense, Sophos, Untangle, Linux, Unix and Windows etc. For details: https://www.pondesk.com/product/NSHO-001 © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 8: Specifications
Size: 430mm x 360mm x 46mm (L*W*H) 1 x RJ45-DB9 COM (CISCO standard) Package: 1 x Network Server 2 x USB 2.0, 1 x VGA 1 x Power Cord 2 x LED Signal indicator © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 9: Front & Back Side View
8 LAN 10Gig Fiber SFP+ 4G NGFW Firewall 1U Rackmount Server NSHO-001 FRONT & BACK SIDE VIEW WWW.PONDESK.COM PACKAGE 1 x Rackmount Server 1 x Power Cord © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 11: Interfaces
Support dual 2.5" SATA SSD/HDD or 3.5" SATA HDD storage drives. INTERFACES WWW.PONDESK.COM 8 x Gigabit LAN 1 x RJ45 COM 2 x USB2.0 4 x SFP Fiber Interfaces 1 x VGA 1 x C14 Power Socket DIMENSIONS © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 12: Opening The Case
There are two screws at the back side of the chassis for holding the case cover. Remove these screws and slightly press the case from the front side and slide the case cover towards the backside to remove it. WWW.PONDESK.COM © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 15 In the process of installation of the device must be careful for some part, if not properly installed, it will not work properly. Please wear anti-static gloves when handling the components, as the static electricity may damage the parts/components. WWW.PONDESK.COM © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 16: Interfaces
Remove the power adapter before doing any changes. please don’t touch any components or plug and socket pins. Wear anti-static gloves/wrist strap while touching any component. Always keep the removed parts in anti-static bag. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 17: Processor
Step 5: Close the load plate and push down the load lever. Step 6: Hook the load lever under the retention tab. Your processor is now correctly in place and ready for heatsink installation. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 18: Heatsink
Thermal grease is a kind of thermally conductive compound used as an interface between heat sinks and processor to eliminate air gaps or spaces from the interface to maximize heat transfer. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 19 After that tighten the screws. Be sure to tighten the screws in a crossing pattern, going over each screw several times to ensure that they are all tight and then connect the heat sink 4- wire fan cable connector to the motherboard 4-pin CPU fan header. WWW.PONDESK.COM © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 20: Memory
There is one mSATA socket onboard. Turn off the machine and remove the chassis cover. Locate mSATA socket and align the notches of the SSD with mSATA socket and insert it. After that screw it according to the below illustrations. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 21: 2.5" Sata Ssd/Hdd
2.5" SATA interface on the motherboard. Add storage drive with the drive bay and secure it with the screws. (Do not over-tighten the screws) after that connect the SATA data and SATA power cables. WWW.PONDESK.COM © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 22: Wi-Fi & 3G/4G
Turn on the system and press <DEL> to enter in BIOS setup. Press <F9> key and then press <Enter> to overload optimal default value and press <F10> to save and exit the setting. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 23: Jpw1
3.6.2 JPW1 Settings JPW1 Turn off the call self-starting function Turn on the call self-starting function 3.6.3 JP3, JP9 Settings JPW1 Default settings, power-down starts the BYPASS function Turn on BYPASS function © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 24: Sata (Sata3)
3.6.5 Serial Ports (COM1, COM2) Two serial ports COM1 and COM2. COM1 is the standard RJ45 Console Port and COM2 is 2*5pin connector. WWW.PONDESK.COM Pins Signals Pins Signals 3.6.6 Display Interface (JVGA1) © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 25: Power Interface (Atxpwr1, Atx_12V1)
DDC_SDA DDC_SCL 3.6.7 Power Interface (ATXPWR1, ATX_12V1) There are two power input interfaces, 1 x 24pin ATX power connector 1 x 4pin ATX power connector WWW.PONDESK.COM ATX_12V1 Pins Signals Pins Signals © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 26: Keyboard & Mouse Interface (Kbms1)
3.6.9 USB Interface (USB1, USB2_USB4, USB3) There are two standard USB interfaces (USB1) 2 x 5pin USB2.0 socket (pitch: 2.54mm) (USB2 & USB4) 1 x 2*10pin USB 3.0 socket (pitch: 2.0mm) (USB3) © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 27 8 LAN 10Gig Fiber SFP+ 4G NGFW Firewall 1U Rackmount Server NSHO-001 USB2 & USB4 Interfaces: Pins Signals Pins Signals USB3 Interfaces: Pins Signals Pins Signals SRX1- SRX1+ STX1- STX1+ STX2+ STX2- SRX2+ SRX2- WWW.PONDESK.COM © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 28: Network & Fan Interface
LILED (Green) Connectivity ACTLED (Yellow) Status Enable Data Transfer Enable Disable Data Transfer Disable One 2*16pin network interface connector JLANLED1 is designed to connect an LED module for LAN ports. WWW.PONDESK.COM © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 29: Front Panel Connectors (Fpanel1, Fpw1)
HDD LED (1st and 3rd pin); when the hard disk is being read and written, the LED will blink to indicate. Power indicator (second and 4th pin); when the system is powered up, power light is on; when the system is powered off, then power led off. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 30: General Purpose I/O (Gpio1)
1,2,3,4,5,6,7,8 pin leads to simple GPIO, code 9 for GCD, code 10 VCC, odd numbers (1,3,5,7) for signal input pin and even numbers (2,4,6,8) pin for signal output. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 31: Mini-Pcie Interface (Mini-Pcie1, Msata1)
Determined by the BIOS settings 3.6.13 Mini-PCIe Interface (MINI-PCIE1, MSATA1) High speed mini PCIe slot for WiFi/3G/4G modules and mSATA slot for SSD solid state drive (data transmission speed up to 6Gbps). WWW.PONDESK.COM © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 33: Technical Specification
Output voltage: 3.3V, 5V, 12V1, -12V, +5VSB Output path: 5 Output efficiency: >70% Operating temperature: 0 ~ 50° C Relative Humidity 5 to 95 percent, non-condensing Dimension: 150 (L) x 82 (W) x 40 (H) mm © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 34: Input Specification
50mV +3.3V 0.1A +/- 5% 50mV -12V 0.3A +/- 5% 120mV 4.4 Capacitive Load Output Capacitive Load +12V 10000 uf 10000 uf +3.3V 10000 uf -12V 330 uf +5VSb 1000 uf © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 36: Details
8 LAN 10Gig Fiber SFP+ 4G NGFW Firewall 1U Rackmount Server NSHO-001 Server board has PCIe 8x interface for fiber ports. Optional fiber port modules, 4x Intel® 82580DB SFP 1Gig Interfaces 4x Intel® XL710-BM210 SFP+ 10Gig Interfaces WWW.PONDESK.COM © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 38: Functions & Interface
<F10> Save & Exit. SETTINGS Main Menu General information Advanced Main Configurations Chipset Chipset Configurations Boot Boot Configurations & Settings Security Passwords Settings Save & Exit Default, Discard & Save Settings © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 39 The main menu contains the BIOS information, OS selection, system date & time setup and user access level selection. Use arrow keys to select the items and press <Enter> to accept or enter Sub-menu. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 40: Advanced Menu
Advanced menu specifies the detailed system functions. The following options are available. ACPI Settings IT8728F Super IO Configuration Hardware Health Configuration IT8760SEC Super IO Configuration System Power Management Serial Port Console Redirection CPU Configuration SATA Configuration USB Configuration © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 41 ACPI (advanced configuration and power interface) settings gives the BIOS and operating system control over various devices power and modes of operation. The available settings are, Enable ACPI Auto Configuration Enable Hibernation ACPI Sleep State Lock Legacy Resources © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 42 GPIO 4 Controller: The output mode of GPIO 4 (low or high) GPIO 6 Controller: The output mode of GPIO 6 (low or high) GPIO 8 Controller: The output mode of GPIO 8 (low or high) © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 43 PC HEALTH STATUS WWW.PONDESK.COM Hardware monitor section include the settings and PC health status for hardware monitoring to monitor the parameters for critical voltages, CPU temperature & speed, temperatures and fan speeds. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 44 [Power off] leaves the system off until pressing the power button. [Last State] reboots the system automatically if it was active before power loss. [Follow AC Power] will start up anytime power is available. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 45 CPU configuration and information including, model, frequency, level of cache size, L2 cache size etc. Active Processor Cores: To turn off/ON CPU core to improve the frequency of overclocking, can provide set 1/2/3/4 core. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 46 SATA controller, ports as well as to select the modes. HotPlug allows you to add and remove SATA drive to a computer system while the computer is running and have the operating system automatically recognize the change. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 47 USB drive. Disable option will keep USB devices available only for EFI applications. The options are [Enabled] and [Disabled]. USB Mass Storage Driver Support: This feature enables to support the USB mass storage devices. The options are [Enabled] and [Disabled]. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 48: Chipset
The Chipset section provide the settings of North Bridge for internal graphics parameters, memory information, IGD configuration, IGD -LCD control, LCD control and power management settings; and South Bridge for USB configuration and PCI Express configuration etc. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 49: Boot
Boot Option Priorities: provides the boot priority configuration to specify which one is boot device and the order of device priority which the systems boots during startup. Option # 1 is the highest priority boot device. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 50: Security
User Password: This password will need to be entered during each system startup or boot, and will also have Administrator rights in the setup. Secure Boot menu and HDD security configuration. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 51: Save & Exit
Boot Override: This feature allows the temporary booting from a connected device without having to reassert your quick boot order for future boots. The bootable devices will be displayed below of this option. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 53: Terms And Conditions
RMA process. 12. Please keep the original package for shipping back in case of return. Please note: Winston Marriot Ltd reserves the right to change the terms and conditions without prior notice. Please check back regularly for updates...
Page 54: Product Registration
RMA by just providing your product serial number and purchase information. https://www.pondesk.com/support/productregistration WWW.PONDESK.COM Contact If you would like to contact to our customer support team directly, please contact them at, support@pondesk.com Monday – Friday 9:00AM - 5:00PM (GMT+1) © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 56 Dynamic random-access memory is a common type of general-purpose computer memory that stores each bit of data in a separate capacitor. DIMM Dual in-line memory modules. A small circuit board with memory chipset. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 57 PS/2 A keyboard & mouse connective 6-pin mini-DIN connector interface. FIREWALL WWW.PONDESK.COM Firewall is monitoring and controlling system of network security. It controls the incoming and outgoing network traffic. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 59 4. Reconnect the storage drive 5. Restore BIOS settings to default. 1. Use third-party software to check the hard disk for bad sectors. Running slow? 2. Low Disk Space. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 60 Can't detect USB? 3. Make sure the USB controller in the BIOS Setup is on. You can also reset the BIOS settings. 4. Virus infected USB also cause the issue. WWW.PONDESK.COM © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
Page 62 Rapid Deployment Pack Wide Area Network Error checking & correcting RBSU ROM-Based Setup Utility Wireless Access Point File Transfer Protocol WLAN HTTP Routing Information Wireless Local Area Hypertext Transfer Protocol Protocol Network © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
