Moons' MDX+40 Quick Setup Manual

MDX+
MDX+40/MDX+60/MDX+80 Quick Setup Guide

Requirements

To begin, make sure you have the following equipment:
● A 24-60 VDC power supply
● A PC running Windows Vista/Windows 7 / Windows 8 / Windows 10 (32-bit or 64-bit) system
A small flat-blade screwdriver for motor power cable connection
●
● One USB mini-B communication cable,Cable type: 2620-150
● One I/O cable
● For RS485, CANopen bus applications, a communication cable is required
For the application of EtherCAT, a CAT5e network cable is required
●

Step 1 Installing the software

a) Download the Luna software.
b) Install the Luna on your PC.
c) Connector the drive to PC with USB mini-B cable.

Step 2 Connecting the Power Supply

a) Connect the drive to the DC power supply
Power
Main
AUX
Note：
1) Please avoid connecting the power "+" and "-" in reverse, as it will damage the motor.
2) Please power on the motor after all the wirings on the motor are completed.
b) Ensure a proper earth ground connection to the drive's chassis.
Symbol Description
V+ Main Power +
V- Main Power -
AUX+ Auxiliary power +
AUX- Auxiliary power -
Function
Supplying power to the motor power and control
sections
Auxiliary power is required for the following two
applications:
a) When the main power is cut off, the DSP part of
the drive needs to work normally
b) Use a motor with a brake, supplying power to
the brake.
Input specs
24~60VDC
24VDC±10%
06 / 19 / 2023
