USER MANUAL
Washing machine
WM75.B
EN
Carefully read the instructions for use before using the washing machine.
W20864R
W20964R

Advertisement

Table of Contents
loading

Related Manuals for Asko W20864R

Summary of Contents for Asko W20864R

  • Page 1 USER MANUAL W20864R W20964R Washing machine WM75.B Carefully read the instructions for use before using the washing machine.

  • Page 2: Table Of Contents

    Dear Customer, We thank you for purchasing this quality ASKO product. We hope it meets all your expectations. Scandinavian design combines pure lines, everyday functionality, and high quality. These are the key characteristics of all our products, and the reason why they are highly appreciated across the globe.

  • Page 3: Safety Precautions

    Keep the instruction manual handy, near the washing machine. • Instructions for use are available on our website at www.asko.com. • Your washing machine is intended solely for household use.
  • Page 4 • Bleaches that contain chlorine can be replaced with oxygen-based bleaches. Otherwise, a neutralization cycle should be performed by running the Cotton program at the highest temperature. For best results, use hydrogen peroxide or oxygen-based detergents. • Do not use colourants (dyes) or bleaching substances (substances for discolouration or removal of colourants) as they contain sulphuric compounds that could cause corrosion.
  • Page 5 hazards of inappropriate use. Make sure children do not play with the appliance. Make sure the children do not clean the washing machine or perform any maintenance tasks without supervision. DANGER OF HOT SURFACE • At higher washing temperatures, the door glass will heat up. Be careful to avoid burns.

  • Page 6: Washing Machine Description

    WASHING MACHINE DESCRIPTION Main switch (ON/OFF) Program selector knob Display unit Program settings buttons Button (start/pause) Detergent compartment QR and AUID code (on the inside of the washing machine door) Rating plate with information about the washing machine (on the inside of the washing machine door) Washing machine door 10.

  • Page 7: Before Using The Appliance For The First Time

    BEFORE USING THE APPLIANCE FOR THE FIRST TIME PACKAGING Remove all packaging. Please sort the materials in compliance with local recommendations (see chapter ”DISPOSAL”). TRANSPORT PROTECTION Before using the appliance, remove the three transport bolts and plastic plugs which protect the appliance during transport.
  • Page 8 CLEANING Disconnect the washing machine from the power mains and open the door. Clean the washing machine drum with a damp cloth and a mild detergent. Connect the washing machine to the power mains and run the dedicated drum cleaning program. See chapter "WASHING PROCESS;...
  • Page 9 In models with ADS the amount of detergent dispensed also depends on the water hardness setting. Before using the AD system for the fi rst time, run one of the programs (without any laundry), after fi lling the A or B tank with liquid detergent (see chapter ”SPECIAL FEATURES”). Before the product is dispatched from the factory, every appliance is tested.

  • Page 10: Installation And Connection

    If the appliance is installed on a plinth or a similar structure, then the appliance must be fi xed to it, to avoid the risk of falling. ASKO original accessories are available for this purpose, complete with fi xing instructions. Clearances around the washing machine min.
  • Page 11 Stacking an ASKO dryer on top of an ASKO concept or closet installation washing machine To stack an ASKO dryer on top of a washing ASKO's front panel controls make it possible to machine, use the extra vacuum feet and the tipping install the washers and dryers in a cabinet or closet.
  • Page 12 ADJUSTING THE FEET MOVING THE WASHING MACHINE AND TRANSPORT AFTER INSTALLATION Place the washing machine so that it is stable. 1. Level the washing machine in longitudinal and If you are moving the washing machine without traverse direction by rotating the adjustable feet packaging, open the washing machine door and pull (using a No.
  • Page 13 CONNECTING TO WATER SUPPLY CONNECTING TO HOT/COLD WATER SUPPLY The machine has to be connected to water (Only available in some models) supply by an adequately trained person. If your appliance has connections for both hot and cold water, then connect one hose to the cold Use the water supply hose to connect the appliance.
  • Page 14 INSTALLING THE DRAIN HOSE CONNECTING TO THE POWER MAINS After installation, the washing machine should stand still for two hours before it is connected to the power mains. Connect the appliance to an earthed power outlet. After installation, the wall outlet should be freely accessible.
  • Page 15 ASKO LAUNDRY CARE - HIDDEN HELPERS* Laundry care ironing board The ironing board is a clever solution. It is always handy when you need to iron your clothes, and it can be easily, safely and invisibly stored away when not in use.
  • Page 16 Laundry care plinth Thanks to the stainless steel plinth, your appliance will be raised by 30 cm, which makes loading and unloading of laundry easier. *AVAILABILITY DEPENDING ON MARKET DENOMINATION ART. No. IRONING BOARD HI1153 White 576552 IRONING BOARD HI1153 Stainless steel 732756 IRONING BOARD HI1153 Titanium 576553...

  • Page 17: Tips Before Washing

    TIPS BEFORE WASHING LAUNDRY SYMBOLS This chapter includes several tips on how to prepare the laundry for washing. Observe the laundry symbols. Textile maintenance symbols: LAUNDRY SORTING Washing Sort the laundry according to: • how soiled it is, Normal Delicate •...
  • Page 18 DYED COTTON ECONOMY AND EFFICIENCY Laundry made of dyed cotton which is to be washed You can save a lot of energy by not using the at 60 °C should be fi rst washed at a temperature of programs operating at higher temperatures. 60 °C to remove the excess dye.

  • Page 19: Washing Process, Step By Step (1 - 8)

    WASHING PROCESS, STEP BY STEP (1 – 8) STEP 1: SORT THE LAUNDRY See chapter "TIPS BEFORE WASHING" Use a washing net for underwire bras. Empty the pockets. Coins, nails etc. could damage the machine and the fabric. STEP 2: TURN ON THE MAIN SWITCH.
  • Page 20 STEP 4: ADD THE DETERGENT AND THE CONDITIONER. Recommended amount of detergent is usually specifi ed on the detergent packaging. When washing a smaller amount of laundry, the amount of detergent used can be decreased. Observe manufacturers' recommendations regarding the type of detergent suitable for certain temperatures, load size, and water hardness.
  • Page 21 STEP 5: CHOOSE THE PROGRAM. Choose the program by rotating the Program selector knob in either direction. The Program selector knob can be used when arrows appear on the display. Choose the program depending on the type of laundry and how heavily soiled it is (see chapter "TIPS BEFORE WASHING").
  • Page 22 Program Description QUICK Quick program for lightly soiled laundry. The program operates at certain temperatures; therefore, observe the instructions indicated on the clothing. A lower temperature setting will result in shorter duration of the wash. Spinning speed can be set to your preference. HEAVY Program for heavily soiled laundry.
  • Page 23 Program Description SYSTEM SETTINGS Use the program selector knob to choose System Settings and confirm with ENTER (button "2"). Use the Program selector knob to scroll through the settings. The following options are available: – Child Lock, – ADS (Auto Dose System), –...
  • Page 24 STEP 6: CHOOSING THE PROGRAM SETTINGS Using the program settings, the washing programs can be further adjusted to your wishes. Some program settings may not be available for your selected program. Selected program settings will remain stored after the end of the washing cycle and may be changed subsequently (except for Start delay and Anti-crease, which are not stored after the wash is complete).
  • Page 25 3. Spin speed By consecutively pressing the button 3, you can set the spin speed, choosing from the following available values: d (no drain) /... / max. (rpm) (max rpm = depends on the model) Default setting is 1400 rpm; it depends on the selected program (spin rate can be changed – reduced or increased (only in some models)).
  • Page 26 5. Start delay Press the button 5 to choose the delayed start when you wish the washing program to start after a certain period of time (30´ to 24 hours after you press the Start button). The estimated time remaining until the end of the washing program will be indicated above the button 5. Press the button 5 for the arrows to appear.
  • Page 27 STEP 7: START THE WASH Close the washing machine door and press the Start/Pause button. Start (short press of the button – start/resume) Pause (short press of the button – pause) Stop (press and hold for 3 seconds – stop or cancel) Info 2:20 Starting...
  • Page 28 Pausing, stopping or changing the program To pause the program, shortly press the Stop program Paused Add clothes Start/Pause button. To resume a program, press the Start/ Pause button again. To stop the washing program, press and hold for 3 seconds button Start/Pause. Use the button 1 to choose "Stop program".
  • Page 29 STEP 8: END OF PROGRAM After the end of the washing program, Start Cycle completed succsessfully the display will indicate that the program has been successfully completed ("Cycle completed successfully"). If you have selected the Anti-Crease Anti Stop anti creasing Cycle completed succsessfully creasing extra function, gentle tumbling will...
  • Page 30 Changing a favourite program If you wish to store a program after the end of the washing cycle, but there is no more room for another favourite program (only 4 favourite program slots are available), then one of the existing stored favourite programs can be substituted with a new one.

  • Page 31: System Settings

    SYSTEM SETTINGS In the Main menu, use the Program selector knob to select System Settings. Confi rm the selection by pressing the button 2. Then, use the Program selector knob to scroll the list of the following settings that you can adjust: •...
  • Page 32 ADS (AUTO DOSE SYSTEM) Press the ON/OFF button to switch on/off the ADS display in the Main menu. For ADS settings, see chapter "SPECIAL FEATURES". On = display the ADS menu in the Main Menu Off = do not display the ADS menu in the Main Menu Use the button 6 to return to System Settings.
  • Page 33 How to use the test strip: 1. Turn on the water tap and let the water run for a minute or so. 2. Fill a glass with cold water. 3. Remove the test strip from its packaging. 4. Dip the test strip in the water for about one second. 5.
  • Page 34 DISPLAY UNIT Set the contrast and logo display. Display Contrast Logotype Back Use the buttons 1 to 5 to set the contrast. Use the button 1 to toggle logo display or off If you choose on , the logo will be displayed on the display unit when the washing machine is turned on.

  • Page 35: Special Features

    SPECIAL FEATURES DOSE MODES 1. Display in the Main menu (see »SYSTEM SETTINGS«) 2. Choosing the DOSE MODES in the Main menu: Select program (Use the Program selector knob) and press the button 6. Choose between: • Options • ADS: Choosing tank A •...
  • Page 36 A, B. Choose the compartment from which the detergent is to be added depending on the type of laundry. You can choose between automatic detergent dosing from compartment A or from compartment B. Confi rm the setting with . Before choosing compartment A or B, you must fi ll the compartment with liquid detergent.
  • Page 37 Auto Dose Clean tank Black Back 1 dose 10 ML White Sensitive Other When you change the detergent in the tank B, select another type of laundry. The question whether you are sure you wish to change the detergent will appear on the display unit. We recommend changing the detergent when the detergent tray is empty.
  • Page 38 Please do not fi ll detergent (liquid detergent) while program is running! Start adding the liquid detergent to the selected compartment. The level for the selected compartment, indicated on the display unit, will increase. When the compartment is full, stop adding the detergent. (maximum amount of detergent that can be added to selected compartment is 1.5 l).

  • Page 39: Cleaning And Maintenance

    CLEANING AND MAINTENANCE CLEANING THE FILTER The washing machine has a fi lter that will retain smaller objects such as coins, buttons, hair etc. Before cleaning, drain the water from the washing machine using the Drain program, and disconnect the washing machine from the power mains. Open the pump fi...
  • Page 40 CLEANING THE DETERGENT COMPARTMENT AND DOOR RUBBER GASKET Press the tab to completely remove the detergent compartment from its housing. Rinse and thoroughly clean the tray. You may also remove the cap from the plug in the conditioner compartment (A). Clean any residue from the cap and tube.
  • Page 41 CLEANING THE AUTO DOSE SYSTEM (ADS) Cleaning the detergent compartment: Remove the detergent compartment from the detergent compartment housing by pulling it out and pressing the release tab (1). Open the cover for detergent compartment A and B (2). Rinse the detergent compartment by directing a stream of running water through it.
  • Page 42 CLEANING THE APPLIANCE EXTERIOR Clean the appliance exterior and the display unit using a soft damp cotton cloth and water. Do not use solvents or abrasive cleaners that could damage the appliance (please observe the recommendations and warnings provided by the manufacturers of the cleaning agents). Do not clean the washing machine with a jet of water! Always disconnect the washing machine from the power mains before cleaning.
  • Page 43 CLEANING THE RINSING HOLES (UNDER THE AGITATOR IN THE DRUM) If you believe that objects like nails or paper clips fell into the washing machine drum, check the area underneath the agitator. Such objects may rust (corrode) and cause stains on your clothes. Nails and other sharp objects can also cause holes in the fabric.

  • Page 44: Errors - What To Do

    ERRORS – WHAT TO DO? Disturbances from the environment (e.g. the power grid) may result in various error reports (see Troubleshooting table). In such case: • Switch off the appliance, wait for 1 minute, switch the appliance back on, and repeat the washing program. •...
  • Page 45 Problem/error Cause What to do? There are traces • The laundry was very greasy. • Wash the laundry again. When your laundry is of grease (or this heavily soiled, add more washing powder or grease rolls) on the use a liquid detergent in combination with a more clothes.
  • Page 46 Manual opening of washing machine door Washing machine door may be opened manually if the appliance is not connected to the power mains and if the water has been pumped out of the machine. A Choose the Spinning or Drain program to pump the water from the machine. If this does not work, water has to be drained from the washing machine drum manually.
  • Page 47 FAILURE DISPLAY In case of a failure while a program is in progress, the relevant Error X is indicated on the display unit. Press the INFO button to display the Error 3 Info Exit error description. Switch off the appliance and turn it back Errors indicated on the display unit may include the following: Error Error indication on the display...
  • Page 48 Error Error indication on the display What to do? unit E13.1 UNBALANCE EMPTY DRUM Call a service technician. E13.2 INERTIA ERROR Call a service technician. DOOR UNLOCK ERROR Door is closed, but it cannot be unlocked. Turn off the washing Error while unlocking the door.

  • Page 49: Service

    SERVICE BEFORE CALLING A SERVICE TECHNICIAN 1, 2, 3 When you contact a service centre, please state the model (1), type (2), and serial number (3) of your washing machine. Model, type, and serial number are indicated on the rating (type) plate located on the washing machine door casing.

  • Page 50: Technical Information

    TECHNICAL INFORMATION PRODUCT INFORMATION SHEET ACCORDING TO EU-REGULATION NO. 2019/2014 (depending of model) Supplier’s name or trade mark: Supplier’s adress ( Model identifier: General product parameters: Parameter Value Parameter Value Height 85,0 Rated capacity ( ) (kg) Dimensions in cm Width 59,5 Depth...
  • Page 51 PRODUCT INFORMATION SHEET ACCORDING TO EU-REGULATION NO. 2019/2014 (depending of model) Supplier’s name or trade mark: Supplier’s adress ( Model identifier: General product parameters: Parameter Value Parameter Value Height 85,0 Rated capacity ( ) (kg) Dimensions in cm Width 59,5 Depth 58,5 51,8...
  • Page 52 PERFORMANCE DATA Program Maximum load Temp. °C Eco 40-60 8 / 4* / 2** kg; 9 / 4,5* / 2,5** kg (depending on model) Universal wash 8 / 4* kg ; 9 / 4,5* kg (depending on model) Mix/Synthetics 3,5 kg PRODUCT INFORMATION SHEET According to EU-Regulation No.

  • Page 53: Program Table

    PROGRAM TABLE Program Universal wash I/N 1600 1,60 2:26 Cotton X 40/20 1600 1,30 2:59/1:33 Eco 40-60 1600 44 0,84 3:20 Mix/Synthetics N/S 1200 0,60 1:54 Wool/Hand wash 0,28 0:52 Dark wash 1200 0,53 1:15 Time program 1000 Auto program 1600 Quick program 1600...
  • Page 54 W20964.R Program Universal wash I/N 1600 2,10 2:26 Cotton X 40/20 1600 1,80 2:59/1:33 Eco 40-60 1600 44 1,00 3:30 Mix/Synthetics N/S 1200 0,60 1:54 Wool/Hand wash 0,28 0:52 Dark wash 1200 0,53 1:15 Time program 1000 Auto program 1600 Quick program 1600 0,50...
  • Page 55 Adjustment of the displayed washing time Advanced technology allows the appliance to sense the amount of laundry and add the required amount of water during the washing process. Depending on the washing load, washing time can be longer or shorter and the time displayed will be adjusted accordingly.
  • Page 56 TABLE: WASHING MODE/TEMPERATURE Washing mode Program Universal wash 20°C-90°C 40°C-90°C -90°C -90°C Cotton 20°C-90°C 40°C-90°C -90°C -90°C Eco 40-60 Mix/Synthetics 20°C-60°C 40°C-60°C -60°C -60°C Wool/Hand wash ,30°C-40°C ,30°C-40°C Dark wash 40°C ,30°C-40°C ,30°C-40°C Time program -60°C/ -90°C Auto program -90°C Quick program ,40°,60°,90°C Heavy...
  • Page 57 TABLE OPTIONS Options Program Universal wash 1600 Cotton 1600 Eco 40-60 1600 Mix/Synthetics 1200 Wool/Hand wash Dark wash 1200 Time program 1000/1600 Auto program 1600 Quick program 1200/1600 Heavy 1600 Easy care 1200 Quick Pro 1200/1600 Hygiene 1600 Allergy program cotton 1600 Allergy program synthetics 1200...
  • Page 58 DISPOSAL Disposal / recycling of packaging Our product packaging is made of environmentally friendly materials that can be recycled, disposed of, or destroyed without any hazard to the environment. To this end, packaging materials are labelled appropriately. The symbol on the product or its packaging indicates that the product should not be treated as normal household waste.
  • Page 59 QUICK GUIDE SORT THE LAUNDRY. Close the zippers fasteners. Empty the pockets and turn them inside out. Check the laundry care symbols. Sort the laundry based on how heavily soiled it is, by colour, and by material. SWITCH ON THE MAIN ON/OFF SWITCH (ON/OFF) OPEN THE WASHING MACHINE DOOR AND INSERT THE LAUNDRY.
  • Page 60 Gorenje, Partizanska 12, 3320 Velenje, Slovenija www.asko.com WM75.B ADS SKO en (01-24)
