USER'S
MANUAL
rev. 1.0 D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SR Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Audison SR Series

Summary of Contents for Audison SR Series

  • Page 1 USER’S MANUAL rev. 1.0 D...
  • Page 2 User’s Manual PACKAGING CONTENTS HEX KEY 2,5 mm HEX KEY 3 mm SR 1.500 SR 4.300 SCREWDRIVER SCREWDRIVER HEX KEY 2 mm HEX KEY 2 mm SCREWS Remote Remote 4,2 x 55 mm SCREWS IN / OUT cable IN / OUT cable 4,2 x 55 mm Fuse 30A Ferrules...

  • Page 3: Table Of Contents

    User’s Manual Index 1. PRECAUTIONS......................................08 2. INSTALLATION AND SIZES ................................. 42 3. CABLE SIZE CALCULATION TABLES. 1: POWER SUPPLY / 2: SPEAKERS ................42 4. POWER SUPPLY and REMOTE IN CONNECTION / FUSE REPLACEMENT ................43 5. SUBWOOFER REMOTE VOLUME CONTROL: VCR-S2 INSTALLATION .................. 44 6.

  • Page 4: Precautions

    14. Pre-plan the configuration of your new amplifier and the best wiring routes to ease installation. 15. In order to avoid incidental damage, keep the product in the original packaging until you are ready for the final installation. 16. Always wear protective eyewear when using tools, as splints or product residue may become airborne. TYPICAL INSTALLATION SEQUENCE If you have any questions please refer to the User’s Manual you can find available on www.audison.com or contact your AUDISON dealer or AUDISON authorized service for assistance. 1. Before installing the amplifier turn off the source and all other electronic devices in the audio system to prevent any damages. 2. Using a cable with adequate AWG (see chart: Power Supply Cable), run the power wire from the battery location to the amplifier mounting location. 3. Connect the power supply with the correct polarity. connect (+) terminal to the cable coming from the battery and (-) terminal to the car chassis.

  • Page 5: Installation And Sizes

    User’s Manual INSTALLATION AND SIZES 47,5 SR 1.500 10.39 9.21 5.31 1.87 47,5 SR 4.300 7.48 5.31 1.87 47,5 SR 4.500 10.39 9.21 5.31 1.87 47,5 SR 5.600 11.57 10.39 5.31 1.87 47.5 SR 6.600 12.36 11.18 5.31 1.87 CABLE SIZE CALCULATION TABLES: 1: Power supply cable / 2: Speakers cable.

  • Page 6: Power Supply And Remote In Connection / Fuse Replacement

    User’s Manual POWER SUPPLY and REMOTE IN CONNECTION / FUSE REPLACEMENT POWER SUPPLY 15 mm / 0.6 in. SR 1.500 SR 4.300 POSITIVE Ferrules SR 4.500 15 mm / 0.6 in. SR 5.600 SR 6.600 NEGATIVE REMOTE CABLE CONNECTION Rem OUT Rem IN FUSE REMOTE...

  • Page 7: Subwoofer Remote Volume Control: Vcr-S2 Installation

    User’s Manual SUBWOOFER REMOTE VOLUME CONTROL: VCR-S2 INSTALLATION SR 1.500 Rem. Vol. Control REMOTE VOLUME OPTIONAL CONTROL VCR-S2 SR 4.500 Rem. Vol. Control - B Ch - REMOTE VOLUME OPTIONAL CONTROL VCR-S2 SR 5.600 (Active only on B Ch) Rem. Vol. Control REMOTE VOLUME...

  • Page 8: Pre In / Speaker In / Pre Out

    User’s Manual PRE IN / SPEAKER IN / PRE OUT SR 1.500 POWER ON AMP OUT LED Blue FILTER OFF LED Red BOOST - 50 Hz FILTER ON + 12 LO-PASS @ 24 dB/Oct. CHECK PRE OUT HI-PASS @ 12 dB/Oct. LEVELS (INPUT SENSITIVITY) PHASE SUBSONIC AMP OUT...
  • Page 9 User’s Manual SR 4.300 / SR 4.500 POWER ON LED Blue A Ch / B Ch FILTER MODE AMP OUT AMP OUT AMP OUT LED Red FULL RANGE HI-PASS @ 12 dB/Oct. LO-PASS @ 12 dB/Oct. 20k Hz 3,2k 3,2k PASS MODE PASS MODE PASS MODE FULL HI LO...
  • Page 10 User’s Manual REAR MODE SR 5.600 FULL RANGE Mode 5 Ch 20k Hz LEVELS (INPUT SENSITIVITY) LO-PASS @ 24 dB/Oct. HI-PASS @ 12 dB/Oct. POWER ON LED Blue 0.2 V BOOST - 50 Hz (Min) (Max) BAND @ 12 dB/Oct. + 12 LED Red 500 500 5000 HI-PASS LO-PASS...
  • Page 11 User’s Manual SR 5.600 Mode 3 Ch BOOST - 50 Hz LEVELS (INPUT SENSITIVITY) POWER ON LO-PASS @ 24 dB/Oct. + 12 LED Blue 0.2 V (Min) (Max) LED Red 3 CH CHECK FRONT MODE LEVELS (INPUT SENSITIVITY) SUBSONIC FULL RANGE HI- PASS @ 12 dB/Oct. HI- PASS @ 12 dB/Oct.
  • Page 12 User’s Manual SR 6.600 C Ch FILTER MODE AMP OUT AMP OUT AMP OUT LEVELS (INPUT SENSITIVITY) POWER ON FULL RANGE HI-PASS @ 12 dB/Oct. LO-PASS @ 12 dB/Oct. LED Blue 40k Hz PASS MODE PASS MODE PASS MODE LED Red FULL HI LO FULL HI LO FULL HI LO...

  • Page 13: Auto Turn-On By Speaker In (Without Remote In)

    User’s Manual AUTO TURN ON BY SPEAKER IN (without REMOTE IN) SR 1.500 ART (AUTO TURN ON) enable SPEAKER IN Rem. Vol. Control REMOTE IN SPEAKER REMOTE OUT Available SOURCE Set-up Adjustment AVAILABLE CONTROLS CONTROLS...
  • Page 14 User’s Manual SR 4.300 / SR 4.500 ART (AUTO TURN ON) enable SPEAKER IN REMOTE IN REMOTE OUT SPEAKER IN Available IN A SOURCE Set-up Adjustment AVAILABLE CONTROLS CONTROLS...
  • Page 15 User’s Manual SR 5.600 ART (AUTO TURN ON) enable SPEAKER IN Rem. Vol. Control REMOTE IN SPEAKER IN FRONT REMOTE OUT Available SOURCE Set-up Adjustment AVAILABLE CONTROLS CONTROLS...
  • Page 16 User’s Manual SR 6.600 ART (AUTO TURN ON) enable SPEAKER IN REMOTE IN SPEAKER IN REMOTE OUT A Ch Available SOURCE Set-up Adjustment AVAILABLE CONTROLS CONTROLS...

  • Page 17: Installation Examples

    User’s Manual INSTALLATION EXAMPLES SR 1.500 1CH: FILTERED SUBWOOFER LEVEL LO PASS 16 mm / 0.62 in. SPEAKERS CABLE Rem. Vol. Control INPUT SPEAKER SUBWOOFER (min 1Ω) to OTHER AMPLIFIERS SOURCE USE PRE-IN OR SPEAKER IN: NOT BOTH Set-up Adjustment AVAILABLE CONTROLS CONTROLS...

  • Page 18: 1Ch: Filtered 2 X 2Ω Subwoofer

    User’s Manual SR 1.500 1CH: FILTERED 2 X 2Ω SUBWOOFER LEVEL LO PASS 16 mm / 0.62 in. SPEAKERS CABLE Rem. Vol. Control INPUT SPEAKER SUBWOOFER min 2Ω SUBWOOFER min 2Ω to OTHER AMPLIFIERS SOURCE USE PRE-IN OR SPEAKER IN: NOT BOTH Set-up Adjustment AVAILABLE CONTROLS CONTROLS...

  • Page 19: 4Ch: A Ch + B Ch

    User’s Manual 4CH: A Ch + B Ch SR 4.300 / SR 4.500 INPUTS: INPUT A A Ch LEVELS HI-PASS B Ch LEVELS HI-PASS 16 mm / 0.62 in. OUTPUTS SPEAKERS CABLE A Ch INPUT SPEAKER IN IN A A Ch B Ch OUTPUTS OUTPUTS...
  • Page 20 User’s Manual 4CH: A Ch + B Ch SR 4.300 / SR 4.500 Using also B Ch: A Ch LEVELS HI-PASS activate B Ch B Ch INPUT LEVELS HI-PASS 16 mm / 0.62 in. OUTPUTS SPEAKERS CABLE A Ch B Ch OUTPUTS OUTPUTS COAXIAL SPEAKERS...

  • Page 21: 4Ch: Woofer + Mid/Hi

    User’s Manual 4CH: WOOFER + MID/HI SR 4.300 / SR 4.500 MID/HI LEVELS HI-PASS WOOFER LEVELS LO-PASS 16 mm / 0.62 in. OUTPUTS SPEAKERS CABLE A Ch SPEAKER IN INPUT IN A MID / HI WOOFER to OTHER AMPLIFIERS SOURCE USE PRE-IN OR SPEAKER IN: NOT BOTH...

  • Page 22: 3Ch: Front + Sub

    User’s Manual 3CH: FRONT + SUB SR 4.300 / SR 4.500 INPUT: INPUT A Ch MID/HI LEVELS HI-PASS SUBWOOFER LEVELS LO-PASS 16 mm / 0.62 in. OUTPUTS SPEAKERS CABLE A Ch SPEAKER IN PASSIVE FILTERS INPUT IN A SUBWOOFER min 4Ω (L+R) to OTHER AMPLIFIERS USE PRE-IN...
  • Page 23 User’s Manual 3CH: FRONT + SUB SR 4.300 / SR 4.500 Using also B Ch INPUT to drive SUBWOOFER: MID/HI LEVELS HI-PASS activate B Ch SUBWOOFER INPUT LEVELS LO-PASS 16 mm / 0.62 in. OUTPUTS SPEAKERS CABLE PASSIVE FILTERS SUBWOOFER min 4Ω (L+R) A Ch B Ch INPUT INPUT USE PRE-IN OR SPEAKER IN:...

  • Page 24: 2Ch: Bridge Left + Right

    User’s Manual 2CH: BRIDGE LEFT + RIGHT SR 4.300 / SR 4.500 LEVELS HI-PASS Set to 0dB LEVELS HI-PASS 16 mm / 0.62 in. OUTPUTS SPEAKERS CABLE SPEAKER IN SPEAKER IN IN A IN B PASSIVE FILTERS A Ch B Ch INPUT INPUT SOURCE...

  • Page 25: 5Ch: Front + Rear + Sub

    User’s Manual 5CH: FRONT + REAR + SUB SR 5.600 REAR LEVELS HI-PASS NOTE REAR INPUT If using FRONT INPUT only, select: If using REAR INPUT 5 CH select: NOTE SUB INPUT If using FRONT INPUT only, select: If using SUB INPUT select: FRONT LEVELS HI-PASS...

  • Page 26: 5Ch: 2 Way Front + Sub

    User’s Manual 5CH: 2 WAY FRONT + SUB SR 5.600 WOOFER LEVELS HI-PASS LO-PASS BAND 5 CH TWEETER LO-PASS LEVEL LEVELS HI-PASS 16 mm / 0.62 in. OUTPUTS SPEAKERS CABLE Rem. Vol. Control FRONT SPEAKER IN FRONT INPUT TWEETER WOOFER SUBWOOFER min 2Ω (L+R) USE PRE-IN...

  • Page 27: 3Ch: Front + Sub

    User’s Manual 3CH: FRONT + SUB SR 5.600 INPUTS: FRONT FRONT LEVELS HI-PASS LO-PASS LEVEL 16 mm / 0.62 in. OUTPUTS SPEAKERS CABLE Rem. Vol. Control FRONT SPEAKER IN FRONT FRONT INPUT PASSIVE FILTERS SUBWOOFER min 2Ω (L+R) SOURCE USE PRE-IN OR SPEAKER IN: NOT BOTH Set-up Adjustment...

  • Page 28: 6Ch: 3 Way Front

    User’s Manual 6CH: 3 WAY FRONT SR 6.600 INPUTS: A WOOFER LEVELS LO-PASS BAND TWEETER MIDRANGE LEVELS HI-PASS LEVELS LO-PASS HI-PASS 16 mm / 0.62 in. OUTPUTS SPEAKERS CABLE SPEAKER IN A Ch IN A INPUT TWEETER MIDRANGE WOOFER min 1Ω SOURCE USE PRE-IN OR SPEAKER IN:...

  • Page 29: 5Ch: Front + Rear + Sub

    User’s Manual 5CH: FRONT + REAR + SUB SR 6.600 INPUTS: A - B - C NOTE INPUT B SUB WOOFER If using INPUT A only, LEVELS LO-PASS select: If using INPUT B select: NOTE INPUT C If using INPUT A only, select: If using INPUT C select:...

  • Page 30: 3Ch: Front + Sub

    User’s Manual 3CH: FRONT + SUB SR 6.600 INPUTS: A - B - C SUB WOOFER LEVELS LO-PASS FRONT R FRONT L LEVELS HI-PASS LEVELS HI-PASS 16 mm / 0.62 in. OUTPUTS SPEAKERS CABLE FRONT PASSIVE FILTERS SUBWOOFER A Ch (L) min 2Ω (L+R) INPUT B Ch (R)

  • Page 31: Block Diagrams

    User’s Manual BLOCK DIAGRAMS SR 1.500...
  • Page 32 User’s Manual SR 4.300...
  • Page 33 User’s Manual SR 4.500...
  • Page 34 User’s Manual SR 5.600...
  • Page 35 User’s Manual SR 6.600...

  • Page 36: Technical Specifications

    User’s Manual TECHNICAL SPECIFICATIONS SR 1.500 SR 4.300 POWER SUPPLY POWER SUPPLY Nominal power supply voltage / fuse 11 ÷ 15 VDC / 1 x 30 A Nominal power supply voltage / fuse 11 ÷ 15 VDC / 2 x 35 A Pulse Operating voltage 6.5 ÷...
  • Page 37 User’s Manual SR 4.500 SR 5.600 POWER SUPPLY POWER SUPPLY Nominal power supply voltage / fuse 11 ÷ 15 VDC / 2 x 25A Nominal power supply voltage / fuse 11 ÷ 15 VDC / 2 x 25A Pulse Operating voltage 6.5 ÷...
  • Page 38 User’s Manual SR 6.600 POWER SUPPLY INPUTS / OUTPUTS / FILTERS Nominal power supply voltage / fuse 11 ÷ 15 VDC / 2 x 30A Inputs Pre-In / Speaker-In Pulse Operating voltage 6.5 ÷ 17 VDC Full A Ch Filters: Idling current 2.2 A Hi-pass: 50 ÷...
  • Page 39 PART OF ELETTROMEDIA 62018 Potenza Picena (MC) Italy T +39 0733 870 870 - F +39 0733 870 880 www.elettromedia.it...

This manual is also suitable for:

Sr 1.500Sr 4.300Sr 4.500Sr 5.600Sr 6.600
