- Page 1 Installation and Operation Manual BS EN 13229:2001 + A2:2004 MODEL: Tested as intermittent appliance Coniston Inset burning wood logs & solid fuel www.mi-flues.com Version_1_01_2023_Coniston...
- Page 2 At Mi-Fires, we believe the best way to enjoy the maximum benefit from your new stove is that it should be installed by a fully trained competent stove installer that can identify the optimal way to install and commission your new appliance.
-
Page 3: Table Of Contents
MI-Fires Stoves Warranty ........ -
Page 4: Compliance
COMPLIANCE 1.1 TECHNICAL DATA This appliance designed for intermittent operation only Maximum log length 270mm x 100mm width Item No. MI-Fire Coniston Inset Weight 70KGS Dimensions (WxDxH mm) Four Sided 552 x 431 (Max Footprint excl Handle) x 683 Three Sided 552 x 431 (Max Footprint excl Handle) x 613... -
Page 5: Installation Of The Stove
2. INSTALLATION OF THE STOVE 2.1 PRE-INSTALLATION It is a legal requirement under England and Wales building regulations that the installation of the stove is carried out under local authority building control approval or installed by a competent person registered with a government approved scheme. -
Page 6: Preparation Of The Fire For Installation
2.3 PREPARATION OF THE FIRE FOR Do not fill the area surrounding the appliance INSTALLATION with insulating material, the void around the appliance must be ventilated to prevent the Remove internal components as follows and put build-up of excess heat. to one side There must be a minimum ventilating area at a) Remove ash pan... -
Page 7: Flue Requirements
2.4 FLUE REQUIREMENTS 2.5 VENTILATION / FRESH AIR SUPPLY Please ensure that all local rules and regulations In order for the multifuel stove to function are complied with, including CE marking of the at optimum efficiency, air is needed for the flue pipe. -
Page 8: Commissioning
The first few times the stove is used, there may requirements. be some smoke and unpleasant odours from All MI-Fires stoves are factory fitted with the the multi fuel stove, which is fairly normal. This Smoke control modification in place. -
Page 9: How Should I Use My Wood Burning Stove
3. Keep the door approx. 1 cm ajar. When there are distinct visible flames from the kindling, and the fire has taken hold, then close the door. Warning: The control and handles will get warm when the wood burning stove is in use. Please use the glove or tool provided when you operate the wood burning stove. -
Page 10: Lighting A Fire Using Smokeless Fuel
■ When the fire is fully established add more Always make sure that flames are visible above the wood after re-fuelling for cleanest burning. smokeless fuel and close the door. Burning without flames above the fuel will create ■ After another five to ten minutes close the unnecessary smoke. -
Page 11: Cleaning And Maintenance
The top baffle must also be cleaned once a year at All spare parts and consumable items are available least to remove any build-up of ash or residue from directly from MI-Fires or can be purchased from the chimney. your local stove specialist. -
Page 12: Installer Details And Handover Checklist
The following parts are considered as consumable and is not subjected to misuse or neglect, including items and as such are not covered by any warranty: the use of non-recommended fuels. ■ Glass * The Warranty registration form is found at the ■... -
Page 13: Annual Service / Sweeping Record
5.3 ANNUAL SERVICE / SWEEPING RECORD CERTIFICATE DATE ENGINEER/SWEEP NAME RETAINED... -
Page 14: Warranty Registration
5.4 WARRANTY REGISTRATION To validate and start your warranty please fill out this form and return it to: MI-Flues Ltd, MI-Fires Warranty Registration, Taymin Business Park, Mitcham Road, Blackpool, Lancashire, FY4 4QN Your Details Name Address Postcode Contact Number Email... - Page 15 Mi-Flues Limited, Taymin Business Park, Mitcham Road, Blackpool, Lancashire, FY4 4QN, United Kingdom Mi-Fires is part of the Mi-Flues Ltd group of companies. Tel: +44 (1253) 600060 Minimum distance from flammable Fireplace according to EN Fuel: Wood (Beech) materials: 13229: Roomheaters fired Efficiency: 83.7%...
- Page 16 MI-Flues Ltd Taymin Business Park Mitcham Road Blackpool, Lancashire FY4 4QN sales@mi-flues.com www.mi-flues.com...
