Megmeet MV300 Series User Manual

Universal vector control variable speed drive

Table of Contents

Quick Links

MV300 Series Universal Vector Control Variable

Speed Drive

User Manual

Document Version:

Archive Date:

BOM Code:

Shenzhen Megmeet Drive Technology Co., Ltd. provides full technical support for our

customers. Customers can contact local Megmeet offices or customer services centers, or

directly contact Megmeet headquarters.

Shenzhen Megmeet Drive Technology Co., Ltd.

Address: 5th Floor, Block B, Unisplendor Information Harbor, Langshan Rd., Science &

Technology Park, Nanshan District, Shenzhen, 518057, China

Website: www.megmeet-drivetech.com

Tel: +86-755-86600500

Fax: +86-755-86600562

Service email: driveservice@megmeet.com

V1.0

2015/07/29

R33010207

Table of Contents

Need help?

Do you have a question about the MV300 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Megmeet MV300 Series

Page 1: Mv300 Series Universal Vector Control Variable Speed Drive
Archive Date: 2015/07/29 BOM Code: R33010207 Shenzhen Megmeet Drive Technology Co., Ltd. provides full technical support for our customers. Customers can contact local Megmeet offices or customer services centers, or directly contact Megmeet headquarters. Shenzhen Megmeet Drive Technology Co., Ltd.
Page 2 Foreword Thank you for using the MV300 series universal vector control variable speed drive of Shenzhen Megmeet Drive Technology Co., Ltd. As new generation of integrated vector control platform, MV300 adopts the advanced integrated drive solution, realizing the integration of asynchronous motor driving and the integration of torque control and speed control, all driving indexes reach industry-leading level.
Page 3 Safety Precaution Operation without following instructions can cause death or severe personal injury. Operation without following instructions can cause medium or slight personal injury or damage to product and other equipment. ·Please install the product on the incombustible materials (e.g., metal), otherwise, fire may be caused. ·Do not place any combustible material near the product, otherwise, fire may be caused.
Page 4 ·Take care not to drop any foreign objects, such as the screws, gaskets and metal bars, into the drive, otherwise, fire and property damage may be caused. ·Do not install and operate the drive if it is damaged or its components are not complete, otherwise, fire and human injury may be caused.
Page 5: Table Of Contents
Contents MV300 Series Universal Vector Control Variable Speed Drive ..........1 Chapter 1 Introduction of MV300 Series Drive ..............7 1.1 Product model ............................. 7 1.2 Product nameplate ..........................7 1.3 Product series............................8 1.4 Technical specifications of product ...................... 9 1.5 Drive structure ...........................
Page 6 6.11 Auxiliary function parameters (Group P11) ..................179 6.12 Advanced function parameters (Group P12) ................. 185 6.13 Multi-stage reference and simple PLC parameters (Group P13) ........... 188 6.14 Process PID parameters (Group P14) ................... 194 6.15 Communication parameters (Group P15) ..................201 6.16 Keyboard display setting parameters (Group P16) ................
Page 7: Chapter 1 Introduction Of Mv300 Series Drive
Chapter 1 Introduction of MV300 Series Drive 1.1 Product model The description of the drive model on the nameplate indicates the information of the product series, such as voltage class of power supply, power class, the software/hardware code of customized product, etc.
Page 8: Product Series
1.3 Product series Table 1-1 Name and model of MV300G Rated input Rated output Rated capacity Rated output power Enclosure current current Product model mode (kVA) (kW) MV300G-4T0.75 0.75 MV300G-4T1.5 MV300G-4T2.2 MV300G-4T3.7 10.5 MV300G-4T5.5 14.5 13.0 MV300G-4T7.5 11.0 20.5 17.0 MV300G-4T11 17.0 26.0...
Page 9: Technical Specifications Of Product
MV300P-4T11 17.0 26.0 25.0 MV300P-4T15 21.0 35.0 32.0 MV300P-4T18.5 24.0 38.5 37.0 18.5 MV300P-4T22 30.0 46.5 45.0 MV300P-4T30 40.0 62.0 60.0 MV300P-4T37 50.0 76.0 75.0 MV300P-4T45 60.0 92.0 90.0 MV300P-4T55 72.0 113.0 110.0 MV300P-4T75 100.0 157.0 152.0 MV300P-4T90 116.0 180.0 176.0 MV300P-4T110 138.0...
Page 10 Speed control precision ±0.2% (vector control without PG) Speed fluctuation ±0.3% (vector control without PG) Torque response <10ms (vector control without PG) The torque control precision is 7.5% when vector control without Torque control Startup torque 150% @ 0Hz (vector control without PG) Fast tracking, over-torque/under-torque detection, torque limit, multi-stage speed operation, multiple acceleration/deceleration time switching, auto-tuning, S curve acceleration/deceleration,...
Page 11: Drive Structure
Humidity 5%~95%RH, non-condensing Vibration less than 5.9m/s (0.6g) -40℃~+70℃ Storage temperature 1.5 Drive structure 1. Mid-enclosure 2. Main control board 3. Upper cover 4. Operation panel 5. Main circuit wiring terminal 6. Lower cover 7. Fan guard 8. Fan 9. Mounting holes for complete unit 10. Bottom enclosure 11. Dustproof plate 12.
Page 12 Fig. 1-3 Outline, mounting dimensions for products of R5~R8 3. Enclosure R9~R10 (G: 132kW-315kW; P: 160kW-315kW) Fig. 1-4 Outline, mounting dimensions for products of R9~R10 4. Enclosure R11 (G: 355kW-400kW; P: 355kW-400kW) Fig. 1-5 Outline, mounting dimensions for products of R11 Table 1-4 Outline, mounting dimensions and gross weight of MV300G Diameter of...
Page 13 MV300G-4T3.7 MV300G-4T5.5 MV300G-4T7.5 MV300G-4T11 314.5 MV300G-4T15 MV300G-4T18.5 MV300G-4T22 437.5 451.5 284.5 MV300G-4T30 MV300G-4T37 MV300G-4T45 MV300G-4T55 MV300G-4T75 MV300G-4T90 726.5 328.5 MV300G-4T110 MV300G-4T132 827.5 849.5 MV300G-4T160 MV300G-4T200 827.5 849.5 MV300G-4T220 MV300G-4T280 361.5 MV300G-4T315 MV300G-4T355 1624 －－－ MV300G-4T400 Table 1-5 Outline, mounting dimensions and gross weight of MV300P Diameter of Enclosure mounting...
Page 14 Note: For 75kWG drive or above, DC reactor is included in its standard configuration. The weight of DC reactor is not included in the gross weight of the Table 1-4 and Table 1-5. Outline and dimensions of DC reactor are shown below. For the drive of 355kWG/355kWP and above, DC reactor is included in its standard configuration.
Page 15: Outline And Mounting Dimensions Of Operation Panel
2 ． For the drive of 75kWG~110kWG/110kWP, the DC reactor is packed separately with a wooden box, so the gross weight includes the weight of the DC reactor and the wooden box. 3 ． DC reactor should be installed at the bottom of the cabinet if it is to be installed inside a cabinet. The clearance between reactor and the drive should be at least 35cm, and the reactor should be as far away from the air inlet port of the drive as possible.
Page 16: Options
Fig. 1-9 Mounting dimensions of operation panel box 1.9 Options 1.9.1 LCD operation panel (reserved) Fig. 1-10 LCD operation panel 1.9.2 Braking components The information of braking components is as shown in Table 1-7.
Page 17 Table 1-7 Braking components of MV300 Model Braking components 15kW and below Built-in braking unit. Built-in braking unit, need 18.5kW ~ 75kW customization. Separate braking unit, 90kW and above Appendix 2. 18.5kW and below Built-in braking unit. Built-in braking unit, need 22kW ~ 90kW customization.
Page 18: Chapter 2 Drive Installation
Chapter 2 Drive Installation 2.1 Removal and installation of drive components 1. Lower cover 2. Operation panel 3. Upper cover 4. Dustproof plate Fig. 2-1 Removal and installation of drive components (taking R4 as an example) 1. Removal and installation of lower cover Removal: Loosen the fixing bolts of the lower cover with the screwdriver, press the snap-fits on both sides in direction A, make snap-fits off with the mid-enclosure and then lift the lower cover in direction B.
Page 19: Installation Environment
Removal: It is recommended to push both snap-fits of the dustproof plate from the inside of the enclosure with tools, so that the snap-fits can be separated from the mid-enclosure. Now, the dustproof plate is removed. Note: Removing the dustproof plate from the outside of the enclosure directly may damage it or the mid-enclosure.
Page 20 Fig. 2-3 Installation spacing for models of 55kWG/75kWP and above When more than two drives are mounted in the up-down installation mode, the partition plate should be installed between them, so as to avoid the influence of the heat dissipation from the bottom drive on the top one, as shown in Fig.2-4.
Page 21: Chapter 3 Wiring Of Drive
Chapter 3 Wiring of Drive This chapter introduces the wiring and cable connection of drive, as well as the issues needing attention. • Do not open the cover until the power supply of the drive is completely disconnected for at least 10 minutes.
Page 22: Wiring And Configuration Of Main Circuit Terminals
Fig. 3-1 Simple wiring diagram for main circuit 3.1 Wiring and configuration of main circuit terminals 3.1.1 Types of main circuit input/output terminals There are six types of main circuit terminals, due to different drive models. The detailed descriptions are as follows: Terminal type 1 Applicable models: MV300G-4T0.75 ~ MV300G-4T15, MV300P-4T0.75 ~ MV300P-4T18.5...
Page 23 DC negative bus output terminals U/T1, V/T2, W/T3 Three-phase AC output terminals Terminal type 3 Applicable models: MV300G-4T37 ~ MV300G-4T45, MV300P-4T45 ~ MV300P-4T55 Terminal Function R/L1, S/L2, T/L3 Three-phase AC 380V input terminals Reserved for external DC reactor, connected with copper bus +DC, P/ B 1 upon delivery P/ B 1, B2...
Page 24 DC negative bus output terminals U/T1, V/T2, W/T3 Three-phase AC output terminals Terminal type 6 Applicable models: MV300G-4T355 ~ MV300G-4T400, MV300P-4T355 ~ MV300P-4T400 Terminal Function R/L1、S/L2、T/L3 Three-phase AC 380V input terminals P, +DC Reserved for external DC reactor, connected with copper bus upon delivery P, -DC Reserved for external braking unit...
Page 25 3.1.2 Connecting drive and options Fig. 3-2 Connection of drive and options 1. Isolation device (e.g., isolation switch) must be installed between the AC supply and the drive to ensure the personal safety during the equipment maintenance.
Page 26 2. In North America, the delay type fuse (the current rated value of which should be 225% of the maximum full load output current value) should be used before the drive to isolate the faults caused by other equipments. For the selection of the fuse, please refer to Table 3-1. Table 3-1 Recommended fuse capacity and cross section area of the copper-cored insulation wire Main circuit Incoming line...
Page 27 · When the drive is connected to a large-capacity transformer, the current in the input power circuit of the drive may damage the rectifying circuit. In general, when the power supply capacity of the drive is larger than 550kVA, or 10 times higher than the drive capacity, the drive needs to be configured with the DC reactor. 5.
Page 28 3.1.3 Wiring for basic operation 20mA 20mA Fig. 3-3 Basic wiring diagram 1...
Page 29 Braking unit and resistor DCL DC reactor (External, optional part) (External, optional part) R/L1 3-phase S/L2 380V T/L3 50/60Hz MV300 P 24 Multi-function input 1 DC voltage/current meter Multi-function input 2 Voltage/current signal 20mA Multi-function input 3 Multi-function input 4 Frequency meter Multi-function input 5 (open collector output)
Page 30: Wiring And Configuration Of Control Circuit
4. “ ○ ” in the figure is main circuit terminal and “ ” in the figure is control circuit terminal. 5. For the usage of the control circuit terminal, please refer to section 3.2. 6. Fig. 3-3 is the wiring diagram for basic operation of model 75kWG/90kWP and below, and Fig. 3-4 is the wiring diagram for basic operation of model 90kWG/110kWP and above, special attention should be paid to these models: 355 kWP, 355 kWG, 400 kWP, 400 kWG, the main circuit terminal of external braking unit is P, 3.2 Wiring and configuration of control circuit...
Page 31 Type Terminal Name Function Specification Analog To receive the single-end analog voltage or Input voltage range: -10V~10V single-end current input with the analog input (input resistance: 20kΩ), input AI1 Analog voltage/current selected via the jumper and resolution: 1/4000 input the corresponding input type selected by the Input current range: 0mA~20mA Analog function code P10.00 (reference grounding:...
Page 32 Type Terminal Name Function Specification It can be set as the digital input terminal with Multi-functional Opto-isolated input, please refer to multiple functions.The factory default input terminal the introduction to the settings for X1 and X2 are FWD (forward multifunctional input/output running command terminal)
Page 33 Type Terminal Name Function Specification Power +24V power To provide +24V power for external load Maximum output current: 200mA supply supply Multi-functional Common end of Multi-functional input Common terminal of X1~X6, PLC input common terminal is interally isolated with P24 Common terminal (Short circuited with P24 upon delivery)
Page 34 Analog output terminal wiring The external analog meter of the analog output terminal AO1 can indicate various parameters. The analog output of the voltage/current is selected via the jumper, and the output range of the analog voltage/current is selected in the function code P10.22. The terminal wiring mode is as shown in Fig. 3-7. Unit place of P10.22: AO1 select Analog meter 0: 0~10V(or 0~20mA)
Page 35 2. Connection of the drive and the host device with RS232 interface: Host RS485/232 converter RS232(DB9) Function Terminal Signal Pin No. Shield cable MV300 +5V power Enclosure DATA TXD DATA RXD Power GND Function Terminal Terminal Function Signal - RS485- RS485 Signal - RS485+...
Page 36 1. Dry contact mode (X1~X6) 1) When using the internal +24V power supply of the drive, the wiring mode is as shown in Fig.3-11. Fig. 3-11 The wiring mode when using the internal +24V power supply of the drive 2) When using the external power supply (which shall meet the UL CLASS 2 standard, and 4A fuse shall be installed between the power supply and the interface), the wiring mode is as shown in Fig.3-12 (be sure to remove the short circuit plate between PLC and P24).
Page 37 2) When the internal +24V power supply is used and the external controller is the PNP common emitter output ( note : be sure to remove the short circuit plate between the user terminal PLC and P24 first, then connect it between PLC and COM terminals firmly), the wiring mode is as shown in Fig.
Page 38 Fig. 3-16 The drain connecting mode when using the external power supply Wiring for Multi-functional output terminals 1. When the Multi-functional output terminals Y1 and Y2 use the internal 24V power supply of the drive, the wiring mode is as shown in Fig.3-17. Warning: The inductive load (such as relay) shall be anti-parallel with the fly-wheel diode! Fig.
Page 39 Fig. 3-18 Wiring mode 2 of multi-functional output terminal 3. When the digital pulse frequency output DO (Y1 terminal used as DO) uses the internal 24V power supply of the drive, the wiring mode is as shown in Fig.3-19. Fig. 3-19 Connecting mode 1 of output terminal DO 4.
Page 40 Wiring for relay output terminals TA, TB and TC In the case of drive inductive load (e.g., electromagnetic relay, contactor), the surge absorption circuit shall be installed, such as the RC absorption circuit (whose leakage current shall be less than the holding current of the controlled contactor or relay), piezoresistor or fly-wheel diode (used in DC electromagnetic circuit, and correct polarity shall be ensured during the installation).
Page 41: Installation Method For Emc Requirements
3.2.3 Schematic diagram of control board Fig. 3-21 Schematic diagram of control board 3.3 Installation method for EMC requirements Because of the working principle of the drive, it is unavoidable to produce certain noise and cause EMC problems. To reduce the interference of the drive to the external world, the installation method will be detailed in this section for field installation reference, including the noise suppression, field wiring, grounding, leakage current, use of power filter etc.
Page 42 3.3.1 Noise supression The noise generated by the drive may affect the instrument and equipment nearby, and the influence is determined by various factors, including the noise immunity of the drive control system and the equipment, the wiring, the installation distance, the grounding method, etc. Noise type Noise Circuit conduction...
Page 43 Table 3-4 Table for noise suppression measures Noise transmission path Measure for reducing influence If the external devices form a closed loop through the drive wiring, the drive grounding cable will have leakage current, which will cause the relevant device to mis-operate. The ②...
Page 44 Motor cable >50cm >30cm Power supply cable >20cm Signal/Control cable Power supply or motor cable Signal/Control cable Fig. 3-24 System wiring requirement If the motor cable is too long or the cross section area of the motor cable is too large, it shall be derated. The larger the cross section area is, the larger the ground capacitance and ground leakage current will be.
Page 45 Enclosure Enclosure Fig. 3-26 Incorrect grounding method of shielding 3.3.3 Grounding Dedicated grounding pole (the best) Drive Other equipment Fig. 3-27 Grounding diagram 1 Shared grounding pole (acceptable) Drive Other equipment Fig. 3-28 Grounding diagram 2 Shared grounding cable (unacceptable) Drive Other equipment...
Page 46 Drive Other equipment Fig. 3-30 Grounding diagram 4 In addition, please pay attention to the following points: · To minimize the impedance of different grounding systems, the standard grounding cable of largest size shall be adopted. The flat cable is preferred, because the high-frequency resistance of the flat cable is smaller than the round cable of the same cross section area.
Page 47 Diode 24VDC Varistor Drive 220V RC-filter 220V Fig. 3-31 Installation requirement for relay, contactor and electromagnetic braking unit 3.3.5 Leakage current and countermeasures The leakage current will pass the line capacitor and motor capacitor at the input and output ends of the drive. Its magnitude depends on the distribution capacitor and carrier frequency.
Page 48 capacity (7.5kW and below), when the wires are very long (over 50m), the leakage current will increased relatively, which is easy to cause the mis-operation of the external thermal relay. Suppression measures: · Reduce the carrier frequency, but the motor noise will increase. ·...
Page 49 Note : Area I: the control power transformer, control system, sensor, etc. Area II: the interface for the signal and control cables, which shall have certain immunity Area III: incoming reactor, drive, braking unit, contactor, and other noise source Area IV: output noise filter and its wiring Area V: power supply (including the radio noise filter wiring) Area VI: motor and its cable ·...
Page 50 The grounding wire of the motor shall be grounded at the drive side. The motor and the drive shall be separately grounded. The motor cable and control cable should use shielded/armoured cable. The shielding metal mesh shall be connected to the both ends of the grounding cable through cable clamps to avoid the twisting of the ends of the metal mesh, because in this case, the shielding effect will be affected in the high-frequency conditions.
Page 51 emission. If the relevant cable is connected according to the requirement in this section, the cable radiation emission can be effectively suppressed. If the drive and other control devices are installed in the same metal enclosure, the above-mentioned partition principle shall be considered when designing the cabinet. The partition isolation, wiring, shielding and connecting of the cables shall also be considered.
Page 52: Chapter 4 Quick Operation Guide For Drive
Chapter 4 Quick Operation Guide for Drive 4.1 Drive operation panel 4.1.1 Introduction to drive operation panel Fig. 4-1 Schematic diagram of operation panel 4.1.1.1 LED description Table 4-1 LED description LED symbol Name Meaning Color On: Current parameter displayed represents the running frequency Frequency LED Green...
Page 53 the rotating speed On: In the stop status, it means the drive has forward running command Forward running LED In the running status, it means the drive is Green running forward Flash: The drive is switching from FWD to REV On: In the stop status, it means the drive has reverse running command Status...
Page 54 Table 4-4 Useage of the Multi-functional key Multi-functional key (M key) Function Function meaning No function The M key is disabled. The M key is used as JOG key. In the operation panel running command channel, press this key and hold, the drive will run in real time JOG mode.
Page 55 When the verification menu is selected, only the function codes whose parameter value is different from the leave-factory value will be displayed. You can press the ∨ or ∧ key to browse all the function codes whose parameter set value is different from the leave-factory value, and check which parameters have been changed.
Page 56 a. Stop parameter display status b. Run parameter display status c. Alarm display status d. Fault display status Fig. 4-2 The stop, run, alarm and fault display of the drive 4. Fault display status When the drive detects a fault signal, it will immediately enter the fault alarm display status (as shown in Fig.4-2d), and the fault code will be displayed in flashing mode.
Page 57 4.1.2 Indentification of LED display symbols The correspondence relation between the LED display symbols and the character/figure is as shown below: 4.1.3 Operation example In the below example, the stop display parameter is the set frequency and its leave-factory value is 50.00Hz. The black part in the figure indicates the current editing status.
Page 58 Assuming that the valid user password is “1368”, the drive is locked at this time, and no operation can be performed. You can unlock the drive by entering the user password through the following steps: 1. Press the MENU/ESC key in the drive locked status, and then the LED will enter the password verification status 00000.
Page 59 MENU ENTER DATA P00.04 0000 50.00 P00.00 0000 ENTER MENU DATA 0500 50.00 P00.05 50.00 Fig. 4-4 Operation example for locking the operation panel keys Key unlocking When all the keys on the operation panel are locked, they can be unlocked through the following operation: Press and hold the M key, and then press the ∨...
Page 60 4.1.3.4 Restore to leave-factory values For example, set P00.05=2, the parameters will restore to the leave-factory values. The leave-factory value setting will make the drive parameters restore to the leave-factory values. 1. In the stop parameter display status, press MENU/ESC key to enter the first level menu P00.00; 2.
Page 61: Drive Running Mode
MENU P02.00 50.00 P00.00 P00.00 P02.00 ENTER MENU ENTER DATA DATA 50.00 P02.05 25.00 P00.06 25.00 Fig. 4-7 Operation example for setting the set frequency 4.1.3.6 Switching status display parameters The drive parameters displayed on the operation panel when the drive is stopped can be set through function code P16.02, such as the frequency, bus voltage, etc.
Page 62 The command channel can be selected through function code P02.02, the PANEL/REMOTE key on the operation panel, and the multi-functional input terminals (functions No. 38, 39 and 40 are selected through P09.00~P09.05). Note Before switching the channels, be sure to conduct the switching trial operation first, otherwise, equipment damage or human injury may be caused.
Page 63 ∧ ∨ Fig. 4-9 Running mode selection under speed control mode The five running modes provide five basic frequency sources. Except that the auxiliary frequency superimposition, frequency adjustment can be performed for common running frequency, “jog running”, “PLC running”, “multi-stage running" or “process closed loop running" can be served as an independent running channel, among which, “PLC running”...
Page 64: Initial Power-Up
are in OFF status or fail to meet the above conditions, the multi-speed will run at the main reference frequency digital set value (P02.05). Note For the specific frequency reference channels of each running mode under the speed control mode, please refer to Chapter 6 Parameter Description.
Page 65 Start Carry out wiring as required Confirm the correctness of wiring Confirm the correctness of input voltage Power on Display 8.8.8.8.8? Is the contactor closing sound heard? Displays set frequency? Power-on failed Power-on Disconnect the MCB at successful the power supply input Analyse the cause Fig.
Page 66: Chapter 5 Parameter List
Chapter 5 Parameter List Explanation to the terms in the function code parameter table Table field Explanation Function code Representing the number of the function code, e.g. P00.00 number Function code Name of the function code, explaining it name Leave-factory The value of the function code after restoring the leave-factory settings value Set range...
Page 67 LCD display 0: Chinese Language P00.02 language × √ ○ Selection 1: English selection 0: All the data can be changed; 1: Only the main set frequency Parameter Parameter (digital setting P02.05) and this P00.03 protection protection √ √ ○ function code can be changed setting setting...
Page 68 0: Disabled 1: Uploading parameter 2: Downloading parameters Parameter Parameter P00.06 × √ × 3: Downloading parameters copy copy (except the motor parameters) Note: The drive parameters will not be uploaded/downloaded Group F01: Status display parameters 0: Disabled 1: Digital reference 1: Keyboard ∧∨...
Page 69 0~+100.0％ 0.1％ 0.0％ P01.09 Flux current Flux current × √ Output Output P01.10 -300.0~+300.0％ 0.1％ 0.0％ × √ torque torque 0.0%~200.0% (rated power of the 0.1％ 0.0％ P01.11 Motor power Motor power × √ motor) Estimated Estimated P01.12 frequency of frequency of -650.00~650.00Hz 0.01...
Page 70 AI2 input AI2 input P01.21 -10.00~10.00V 0.01V 0.00 × √ voltage voltage P01.22 Reserved 0.0~100.0％ 0.1％ 0.0％ P01.23 AO1 output AO1 output × √ (percentage relative to the full range) P01.24 Reserved -100.0~100.0％ Process Process 0.1％ 0.0％ P01.25 closed loop closed loop ×...
Page 71 1: reserved 2: V/F control without PG 3: reserved 0: Motor 1 Motor Motor P02.01 × √ × selection selection 1: Motor 2 0: Keyboard control Running Command 1: Terminal control command P02.02 channel √ √ ○ channel 2: communication control selection selection 3: Bus control...
Page 72 are only applicable for P02.04=0, 1, 2 hundreds and thousands place are only applicable for P02.07=1, 2, 3 0: No auxiliary reference 1: Digital reference 1: Keyboard ∧∨ reference 2: Digital reference 2: terminal Auxiliary Auxiliary UP/DN reference reference frequency 3: Serial port communication P02.07 frequency...
Page 73 frequency frequency Proportion adjustment Proportion 0.1％ 100.0％ P02.12 coefficient of adjustment 0.0%~200.0% × √ ○ coefficient frequency (Unit 0.75~22:6S adopts Acceleration Acceleration that of P02.13 0.0~3600.0 30~45:20S √ √ ○ time 1 time 1 P11.01) Others:30S (Unit 0.75~22:6S adopts Deceleratio Deceleration that of P02.14...
Page 74 of motor 1 Leakage Leakage Depending P03.07 inductance inductance of 0.0~2000.0 √ √ × on model of motor 1 motor 1 Rotator Rotator Depending P03.08 resistance resistance 0.000~65.000 0.001 √ √ × on model of motor 1 of motor 1 Mutual Mutual Depending...
Page 75 inductance inductance of on model of motor 2 motor 2 Rotator Rotator Depending P03.20 resistance resistance or 0.000~65.000 0.001 √ √ × on model of motor 2 of motor 2 Mutual Mutual Depending P03.21 inductance inductance of 0.0~2000.0 √ √ ×...
Page 76 gain gain （ASR2-P） Speed loop Speed loop high-speed P05.05 high-speed 0.000~10.000S 0.001s 0.600s √ √ ○ integral time integral time (ASR2-I) ASR2 ASR2 output P05.06 0~8 (corresponds to 0~2^8/10ms) × √ ○ output filter filter 0.0％~100.0% 20.0％ P05.07 switching switching ×...
Page 77 P05.17 Reserved P15.19 Action selection Action 0: Decelerate to stop upon selection P05.20 detection of upon × √ × 1: Coast to stop, display Er.dEv large speed detection 2: Continue to run deviation of DEV (DEV) Detection Detection 0％~50.0％ 0.1％ 20.0％...
Page 78 n time time Speed/Torq Speed/torque 0.1％ P06.05 ue switching switching 0％~+300.0％ initial torque 100.0% × √ × point point Speed/ Speed/ torque torque P06.06 0~1000ms × √ × switching switching delay delay 0: FWD speed limit value FWD speed FWD speed P06.07 ×...
Page 79 2: Continue to run after the over-torque during running; 3: Turn off the output after the over-torque is detected only when the speed is consistent; 4: Turn off the output after the over-torque is detected during running; 0.0％~300.0% Over-torque Over-torque SVC: Rated torque of equivalent P06.21 detection...
Page 80 voltage 3 voltage 3 Motor 1 V/F Motor 1 V/F P07.03 P07.05 ~P07.01 0.01Hz 0.00Hz × √ × frequency 2 frequency 2 Motor 1 V/F Motor 1 V/F P07.04 P07.06~P07.02 0.1% 0.0% × √ × voltage 2 voltage 2 Motor 1 V/F Motor 1 V/F P07.05 0.00~P07.03...
Page 81 0: Disabled 1: Always enabled P07.19 AVR function × √ × function 2: Disabled only in deceleration situation Drooping Drooping P07.20 control 0~30.00Hz 0.01 0.00 × √ ○ control value value Group P08: Start and stop control parameters 0: Start from the startup frequency 1: Start form the startup frequency Startup after braking...
Page 82 Stop (dwell) Stop frequency frequency P08.11 0.00~10.00s 0.01s 0.00s × √ ○ retention retention time time Initial Initial frequency frequency for 0.01Hz 0.00Hz × √ ○ P08.12 0.00~60.00Hz for stop DC stop braking braking Waiting time Waiting time P08.13 for stop DC for stop 0.00~10.00s 0.01s...
Page 83 0: No function 1: Forward running (FWD) 2: Reverse running (REV) 3: External jog forward running control input 4: External jog reverse running control input 5: Three-wire operation control 6: Multi-stage reference terminal 1 7: Multi-stage reference terminal 2 8: Multi-stage reference terminal 3 9: Multi-stage reference terminal 4 10: Acceleration/deceleration time terminal 1...
Page 84 31: PID integral retention 32: PID integral clearing 33: Switching PID adjustment features 34: Main reference frequency source selection 1 35: Main reference frequency source selection 2 36: Main reference frequency source selection 3 37: Switching main reference frequency to AI 38: Command source selection 1 39: Command source selection 2 40: Switching command to...
Page 85 input (valid only for X6) 75: PID feedback frequency pulse input (valid only for X6) 76~95: Reserved Only the following function No. will be shown in the quick menu: 0, 1~4, 6~11, 14, 15, 22~27, 29, 33~35, 37~44. P09.06 Reserved P09.07 0: Two-wire control mode 1 1: Two-wire control mode 2...
Page 86 setting disconnection Unit place of LED: BIT0~BIT3: X1~X4 Tens place of LED: BIT0~BIT1: X5~X6 Binary setting: 0: Disabled 1: Enabled Virtual input Virtual input P09.16 terminal terminal Unit place of LED: × √ ○ setting setting BIT0~BIT3: X1~X4 Tens place of LED: BIT0~BIT1: X5~X6 Output Output...
Page 87 enabled when exceeding P09.33 21: Reserved 22: Analog torque offset enabled 23: Over-torque output 24: Under-torque output 25~33: Reserved 34: Drive FWD/REV indication terminal 35: Motor 1 and 2 indication terminal 36: Communication card ON/OFF signal 37~42: Reserved 43: PID feedback loss 44: PID feedback exceeding limit Only the following function No.
Page 88 6: Output torque current (0~3*I 7: Motor rotating speed (0~Maximum output frequency) 8: Output voltage (0~1.5 * V 9: AI1（-10~10V/4~20mA） 10: AI2（-10~10V/4~20mA） 11: Reserved 12: Output power (0~2*P 13: Electric torque limit value (0~3T 14: Braking torque limit value (0~3Tem) 15: Torque offset (0~3T 16: Torque reference (0~3T 17: Percentage of host device...
Page 89 1: Current input Unit place of LED: AI1 function selection 0: No function 1: Main reference frequency setting 2: Auxiliary reference frequency setting 3: Torque offset 4: Speed limit value 1 5: Speed limit value 2 6: Torque limit value 1 Analog AI 7: Torque limit value 2 AI function...
Page 90 reference of Magnetic flux: 0.0~100.0%Φe line 1 Minimum Minimum P10.08 reference of 0.0%~P10.06 0.1% 0.0% √ √ ○ reference 1 line 1 Actual value corresponds Actual value to the corresponds P10.09 The same as P10.07 0.1% 0.0% √ √ ○ minimum to minimum reference of...
Page 91 the curve 1 curve 1 reference reference Actual value corresponds Actual value to the P10.19 of inflection The same as P10.15 0.1% 0.0% × √ ○ inflection point 1 point 1 of the curve 1 Minimum Minimum P10.20 reference of 0.0%~P10.18 0.1% 0.0%...
Page 92 17: Torque offset (+10V/+300%) 18: Torque command (+10V/+300%) 19: Flux command (+10V/+100%) 20: Reserved (position deviation (+10V/2048 command pulse) 21: Output torque (-300.0~+300.0%) 22: Output torque current (-300.0~+300.0%) 23: Torque offset (bipolar) (-300~+300%) 24: Motor rotating speed (bipolar, output frequency during V/F – slip compensation) 25: Reserved (output the motor temperature measured with...
Page 93 that of P11.01) (Unit adopts Deceleration Decelerati that of P11.03 0.0~3600.0 × √ ○ time 2 on time 2 P11.01) (Unit adopts Acceleration Accelerati that of P11.04 0.0~3600.0 × √ ○ time 3 on time 3 P11.01) (Unit adopts Deceleration Decelerati that of P11.05...
Page 94 of S curve segment Switching Switching frequency frequency of P11.14 acceleration/ acceleratio 0.00~3000.00Hz 0.01Hz 0.00 × √ ○ deceleration time 1 and 2 decelerati Switching hysteresis Switching loop hysteresis loop frequency frequency of P11.15 0.00~655.35Hz 0.01Hz 1.00 × √ ○ acceleration/ acceleratio deceleration...
Page 95 ng running g running 1: Enabled Carrier wav Carrier wave 0.7~15.0KHz (minimum vector: P12.02 √ √ ○ e frequency frequency Unit place: enable the over-modulation 0: Disabled 1: Enabled Tens place: Automatic adjustment selection for carrier wave frequency 0: No automatic adjustment 1: Automatic adjustment PWM mode PWM mode...
Page 96 magnetic adjustment adjustment coefficient 1 coefficient 1 Low intensity intensity magnetic magnetic P12.12 0~10000 1000 × √ ○ adjustment adjustment coefficient 2 coefficient 2 intensity Low intensity 0: Disable P12.13 magnetic magnetic × √ ○ 1: Enable control control mode mode 0: Operate automatically 1: Fun operates continually during...
Page 97 Multi-stage Multi-stage P13.10 reference 0.1% 40.0% × √ ○ reference 10 Multi-stage Multi-stage P13.11 0.1% 60.0% × √ ○ reference 11 reference 11 Multi-stage Multi-stage P13.12 reference 0.1% 80.0% × √ ○ reference 12 Multi-stage Multi-stage P13.13 reference 0.1% 90.0% ×...
Page 98 3: Reserved 4: AI analog reference 5: Terminal PULSE reference 6: Process closed loop PID 7: Reserved Tens place of LED: 0: FWD 1: REV 2: Determined by the running command Hundreds place of LED: 0: Acceleration/deceleration time 1: Acceleration/deceleration time 2: Acceleration/deceleration time 3: Acceleration/deceleration time Stage 1...
Page 99 Stage 8 Stage 8 P13.31 The same as stage setting 1 × √ × setting setting Stage 8 Stage 8 P13.32 0.0~6500.0 20.0 × √ ○ running time running time Stage 9 Stage 9 P13.33 The same as stage setting 1 ×...
Page 100 4:AI1+AI2 5:AI1-AI2 6:MIN（AI1，AI2） 7:MAX（AI1，AI2） PID digital PID digital P14.02 -100.0%~100.0% × √ ○ reference reference command command P14.03 acceleration acceleration/ 0~3600.0s 0.1s 0.0s × √ ○ /deceleratio deceleration n time time 0: Positive interaction adjustment adjustment P14.04 × √ × feature feature 1: Reverse interaction...
Page 101 PID upper PID upper limit P14.16 limit digital P14.17~100.0% 0.1% 100.0% × √ ○ setting digital setting PID lower PID lower limit P14.17 limit digital 0.0%~ P14.16 0.1% 0.0% × √ ○ digital setting setting Output Output P14.18 0.000~10.000s 0.001s 0.010s ×...
Page 102 detection value value feedback feedback lost P14.27 lost 0.0s~25.0s 0.1s 1.0s × √ ○ detection detection time time feedback feedback exceeding exceeding P14.28 0.0~100.0% 0.1% 100.0% × √ ○ limit limit detection detection value value feedback feedback exceeding exceeding P14.29 0.0s~25.0s 0.1s 1.0s...
Page 103 Response Response P15.04 delay of the delay of the 0~1000ms × √ × drive drive Reserved Reserved P15.05 function 1 function 1 for 0~65535 × √ ○ for user user Reserved Reserved P15.06 function 2 function 2 for 0~65535 × √...
Page 104 en stop BIT0: Preset frequency (Hz) BIT1: Running speed (r/min) BIT2: Preset speed (r/min) BIT3: DC bus voltage (V) Tens place of LED: BIT0: Running line speed (m/s) BIT1: Preset line speed (m/s) BIT2: Close loop feedback (%) BIT3: Close loop reference (%) Hundreds place of LED: BIT0: AI1 (V) BIT1: AI2 (V)
Page 105 speed/motor rated frequency × P16.04 Non-VF: Running rotating speed = measured/ estimated rotating speed × P16.04 Preset rotating speed = Preset frequency × motor rated rotating speed/motor rated frequency × P16.04 0.1％~999.9% Close loop Closed loop Note: The close loop P16.05 display display...
Page 106 1: Enable option reset Profibus-DP Profibus-DP P40.23 PPO type PPO type 1~5: PPO1~PPO5 × √ ○ selection selection Profibus-DP: Display the current communication baud rate 0: 9.6 kbps; 1: 19.2 kbps; Communica Communicati 2: 45.45 kbps; 3: 93.75 kbps; tion baud on baud rate P40.24 ×...
Page 107 upon 24V/±10V short circuit 0: Activate protection and coast to stop 1: Alarm and keep running Unit place of LED: Action upon phase loss 0: Activate protection upon input and output phase loss 1: No protection upon input phase loss 2: No protection upon output phase loss 3: No protection upon input and...
Page 108 inverter and stop in the stop mode Tens place of LED: Action upon under-voltage fault indication 0 : No action 1 : Action (under-voltage is regarded as a kind of fault) Hundreds place of LED: Action upon auto-reset interval fault indication 0 : No action 1 : Action...
Page 109 ature ture protection protection point point 0: Disabled (when the braking Over-voltag Over-voltage resistor is installed) P97.07 e stall × √ × stall selection selection 1: Enabled Over-voltag Over-voltage P97.08 e point at 120.0％~150.0％Udce 0.1% 140.0％ × √ × point at stall stall 0: Disabled at constant speed Auto current...
Page 110 7: Reserved 8: Input side phase loss (Er.IrF) 9: Output side phase loss (Er.odF) 10: Power module protection (Er.drv) 11: Inverter bridge over-temperature (Er.oH1) 12: Rectifier bridge over-temperature (Er.oH2) 13: Drive overload (Er.oL1) 14: Motor overload (Er.oL2) 15: External fault（Er.EFT） 16: EEPROM read-write error (Er.EEP) 17: Abnormal serial port...
Page 111 sampling disconnection protection (Er.THr) 44: Short circuit of ±10V analog output power (Er.10v) 45: Abnormal internal over-current reference (Er.rEF) 46~50: Reserved Note: 1. Er.drv fault can not be reset until 10s later; 2. For continuous over-current less than 3 times (including 3 times), it can not be reset until 6s later;...
Page 112 DC bus DC bus P97.24 voltage at voltage at the 0~999V × √ the 2nd fault 2nd fault Actual Actual P97.25 current at current at the 0.0~999.9A 0.1A 0.0A × √ the 2nd fault 2nd fault Running Running P97.26 frequency at frequency at 0.00Hz~3000.00Hz 0.01Hz...
Page 113 Software Software Manufactu P98.01 0.00~99.99 0.01 × √ version No. version No. rer setting User-custo User-customi Manufactu P98.02 mized zed version 0~9999 × √ rer setting version No. Output power (0~999.9KVA) Rated Rated Manufactu P98.03 0.1kVA × √ capacity capacity rer setting (set by the model automatically) 0~999V...
Page 114: Chapter 6 Parameter Description
Chapter 6 Parameter Description The parameter format is as follows: Menu No. Menu name Value range (default value) 6.1 System management parameters (Group P00) P00.00 Menu mode selection 0~2 (0) 0: Quick menu mode Only the parameters related to the quick running of the drive will be displayed. To start the drive quickly, change the parameters under this menu mode.
Page 115 0: Chinese 1: English This function is only enabled for configuring the operation panel of the LCD. P00.03 Parameter protection setting 0~2 (0) The setting of this function code determines the protection class of the drive parameters. The settings are as follows: 0: All the data can be changed 1: Only the main set frequency digital setting (P02.05) and this function code can be changed...
Page 116 Table 6-1 Working mode of operation panel Unit place Function Description Invalid in non-panel The STOP key is valid only in the panel control mode control mode Stop in the stop mode Valid in the command channel of panel, terminal and serial port . under the non-panel When this key is pressed, the drive will stop in the stop mode set by control mode...
Page 117 When it is set as 7, the M key is used to coast to stop the drive. Under any command channel, once this key is pressed, the drive will coast to stop. Thousands place: Locking function of the operation panel It is used to set the locking range of keys on the operation panel.
Page 118: Status Display Parameters (Group P01)
When it is set as 3 and confirmed, the drive will download all the function code setting values of Group P00~P98 from the operation panel to the internal control panel to store. (Except the status display parameters of Group P01, motor parameters of Group P03 and parameters of P98.) Note 1 ．...
Page 119 Monitoring the output voltage of the drive. P01.07 Output current 0.0~3Ie (0.0) Monitoring the output current of the drive. P01.08 -300.0~300.0%(0.0%) Torque current Monitoring the percentage of the drive torque current relative to the motor rated current. P01.09 Flux current 0~100.0%(0.0%) Monitoring the percentage of the flux current relative to the motor rated current.
Page 120 BIT0: RUN/STOP When the drive is in stop state, the value for the BIT0 place is 0, otherwise, it is 1. BIT1: REV/FWD When the drive runs forward, the value for the BIT1 place is 0, otherwise, it is 1. The corresponding bit will be set to 1 when the condition is met for other bits.
Page 121: Basic Parameters (Group P02)
P01.23 is used to display the percentage of the analog output relative to the full range. For example, the function of AO1 is set as “output frequency”. If the maximum frequency is 100Hz and actual running frequency is 50Hz, P01.23 will displays 50%. P01.24 Reserved P01.25...
Page 122 Fig. 6-5 Diagram for combining the set frequency P02.00 Motor and control mode selection 0000~303H (0000) Fig. 6-6 Motor control mode diagram Motor control mode: 0: Vector control without PG (open loop vector) It refers to the running mode of vector control without a speed sensor, which is applicable to the cases of high-performance generality and speed-adjustable driving.
Page 123 class higher that that of the drive. Otherwise, the control performance will decrease or the drive system can not run normally. 4. When “V/F control without PG” is selected, the special function codes under V/F control (parameters of Group P07) shall be set properly. P02.01 Motor selection 0~1 (0)
Page 124 When this setting mode is selected, the following parameters shall be set beforehand: 1) Define the function of two external control terminals as 14 and 15 respectively among parameters P09.00~P09.05. 2) With the function code P09.09, set the value change rate when setting the frequency with the UP/DOWN terminal.
Page 125 6: Process closed loop PID The frequency setting is determined by the calculation result of the process closed loop PID. 7: Multi-speed running In this mode, when the drive is powered on, it will use the value of the function code P02.05 as the current set frequency directly.
Page 126 0: The set frequency will be saved upon power down When the drive is powered down or under voltage, P02.05 will be refreshed automatically with the current actual frequency. 1: The set frequency will not be saved upon power down When the drive is powered down or under voltage, P02.05 will remain the same frequency.
Page 127 The auxiliary frequency is determined by the terminal pulse frequency and can be input by X6, please refer to the definition in the function codes of Group P09 for details. 6: Process closed loop output The process closed loop output is used as the auxiliary reference. 7:Field bus reference Set the reference via the Field bus.
Page 128 When the positive and negative polarity of the auxiliary set frequency is opposite to that of the main set frequency, the set frequency is the latter. 4: MIN (main set frequency, auxiliary set frequency) Select the minimum absolute value between the main set frequency and the auxiliary set frequency as the set frequency.
Page 129 0: Disabled Do not adjust the set frequency that is combined by the main and auxiliary set frequency, that is, 1: Adjust according to the maximum output frequency P02.15 Set frequency × − 2: Adjust according to the current frequency Set frequency ×...
Page 130: Motor Parameters (Group P03)
Fig. 6-9 Diagram for the definition of limit frequency parameters Note 1. The maximum output frequency, upper limit frequency and lower limit frequency shall be set carefully according to the parameters on the nameplate of the controlled motor and the demands of the operation conditions.
Page 131 after the normal setting of rotation. You can choose not to change P03.05 manually, or choose to change it manually in the following two situations: 1) when all the settings are completed; 2) when there is no setting. Note The power class of the motor shall be configured according to that of the drive. Generally, it can only be two classes lower or one class higher that that of the drive.
Page 132 Fig. 6-11 Overload protection coefficient setting of motor The adjustment value can be set according to your need. In the same conditions, if you want to realize quick protection upon the motor overload, set a small value for P03.11; otherwise, a bigger value shall be set.
Page 133 P03.20 Rotator resistance of motor 2 00.000~65.000 (depending on model) P03.21 Mutual inductance of motor 2 0000.0~2000.0 (depending on model) P03.22 No-load current (I ) of motor 2 0.1~999.9 A(depending on model) The meanings of the above motor parameters are shown in Fig.6-12. Fig.
Page 134 The adjustment value can be set according to your need. In the same conditions, if you want to realize quick protection upon the motor overload, set a small value for P03.23; otherwise, a bigger value shall be set. Note If the rated current of the load motor is not consistent with that of the drive, the motor overload protection can be realized by setting the function code parameter of P03.23.
Page 135: Speed Control Parameters (Group P05)
4) When P03.24 is set as 2, disconnect the motor shaft from the loads and check its safety status carefully. It is prohibited to carry out rotation setting when the motor is connected to loads. 5) Set P03.24 as 1 or 2, press the ENTER/DATA key and the RUN key, and then the auto-tuning will be started.
Page 136 of motor 1 at high speed and low speed. P05.00 and P05.01 are parameters when the running frequency is less than the ASR switching frequency 1 (P05.03); P05.04 and P05.05 are parameters when the running frequency is higher than the ASR switching frequency 2 (P05.07).
Page 137 1. Component of speed regulator (ASR) As shown in Fig.6-15, K is the proportional gain P and T is the integral time I. Fig. 6-15 Simple diagram of the speed regulator When the integral time is set to be 0 (P05.01=0, P05.05=0), there is no integral action and the speed loop is a simple proportion regulator.
Page 138 Fig. 6-17 Step response with good dynamic performance Note If the PI parameter is not selected properly, the over-voltage fault may occur after the system is started to reach the high speed quickly (if no external braking resistor or brake unit is connected). This is caused by the energy feedback produced in the system regenerative braking while decelerating after the overshoot.
Page 139 0: The torque limit value is set by the digit P05.15 and P05.16 are the positive torque limit value and negative torque limit value respectively. 1: The torque limit value is the AI reference value The maximum value of AI input voltage/current (10V/20mA) can correspond to 300 ％ of rated torque command.
Page 140: Torque Control Parameters (Group P06)
When P05.13 or P05.14 is selected to be 0, P05.15 and P05.16 are used to limit the maximum output torque of the drive. The limit value is the percentage of the rated output torque of the motor. When large negative torque is required, please adopt additionally the dynamic braking method. Leave-factory values: 180.0% for P-type, 150.0% for G-type.
Page 141 Tens Hundreds Unit Torque command selection: 0: Torque referenc 1: Torque current reference Selecting positive direction of torque: 0: FWD driving direction is positive 1: REV driving direction is positive Selection for switching from speed control to torque control 0: Switching directly 1: Switching once over the torque switching point of P06.05 Fig.
Page 142 When using this function, the user needs to define the function of the AI terminal as the torque command reference. Taking AI1 as an example, set the unit place of the function code P10.01 as 8. Please refer to the descriptions in Group P10 for the detailed settings. 2: The torque command is set by the terminal PULSE The maximum value of the terminal PULSE input frequency corresponds with 300 ％...
Page 143 3. When the stop command is entered, if the current mode is the torque control mode, it will switch to the speed control mode automatically and then stop. FWD speed limit channel P06.07 0~1 (0) FWD speed limit value P06.08 0.0~100.0%0 (100.0%) REV speed limit channel P06.09...
Page 144 Friction torque P06.16 0~50.0% (0.0%) Set P06.13 as 1 to start the inertia identification automatically. The identification of the torque is set by P06.14. The identified values of inertia and friction torque will be saved into function code P06.15 and P06.16 respectively.
Page 145: Vf Control Parameters (Group P07)
Under-torque detection time P06.25 0.0~10.0s (0.0s) Under-torque judging: If the torque is continually less than the torque detection value (P06.24) within the detection time (P06.25), it is considered as the signal of under-torque detected. Action selection for under-torque detected: 0: Under-torque detection is disabled Do not detect under-torque.
Page 146 Fig. 6-20 V/F curve Fig. 6-21 Multi-stage V/F curve P07.00=0: Customized curve, applicable to sectional constant torque load situation, refer to Fig.6-21. In Fig.6-21: F1<F2<F3<Fb (Fb represents the basic running frequency, generally, it is the rated frequency of the motor) V1≤V2≤V3≤100% (V1, V2 and V3 represent the percentage of the maximum output voltage) Table 6-4 V/F curve types Set value...
Page 147 Output voltage V max Output freq. : Manual torque boost Vmax: Max output voltage : Cut-off freq. for torque boost : Basic operating freq. Fig. 6-22 Torque increase (the increase amount is the shaded part) Note 1. Improper setting of this parameter may cause motor over-temperature or over-current protection. 2.
Page 148: Start And Stop Control Parameters (Group P08)
AVR means automatic voltage regulation. Under the V/F control mode, when fast stop is need and there is no braking resistor, selecting “Disabled only in deceleration situation” can remarkably reduce the possibility of over-voltage fault. If there is braking resistor or the fast deceleration is not needed, please select “Always enabled”. Drooping control value P07.20 0~30.00 Hz(0.00Hz)
Page 149 Startup DC braking time P08.05 0.00~30.00s (0.00s) P08.04 sets the volume of the startup DC braking current, which is indicated in a percentage of the rated current of the drive. G-type: setting range is 0.0~100.0%; P- type: setting range is 0.0~50.0% P08.05 sets the action time for the startup DC braking.
Page 150 Note The stop speed delay time is invalid for the V/F control mode and the stop speed detection mode is valid only when it is the speed detection value (P08.09=1). Initial frequency for stop DC braking P08.12 0.00~60.00Hz (0.00Hz) Waiting time for stop DC braking P08.13 0.00~10.00s (0.00s) Stop DC braking current...
Page 151 Table 6-5 Startup conditions for re-start upon power fault Three-wire Two-wire Two-wire Status Operating panel Serial port Setting terminal 1, 2 terminal 1 terminal 2 before power Availa Availa P08.16 None None None None None fault Stop Stop Indicates the actions of the drive upon power-up under different combination conditions. 0: Enter the standby state;...
Page 152: Digital Input/Output Parameters (Group P09)
The use ratio of dynamic braking P08.21 and the braking startup voltage P08.22 are only applied to the drive with built-in braking unit. Action voltage of braking unit can be selected by adjusting P08.22. The system can be stopped rapidly by the dynamic braking with the appropriate action voltage.
Page 153 Item Function Item Function REV disabled Drive running disabled External stop command Auxiliary set frequency reset Speed control and torque control switching Pre-magnetizing command terminal terminal Torque direction switching terminal for torque control Torque offset selection terminal Pulse input terminal of the torque limit 1 AI torque offset retention (valid only for X6) Pulse input terminal of the torque limit 2 (valid only for...
Page 154 Frequency setting Multi-stage frequency 6 Multi-stage frequency 7 Multi-stage frequency 8 Multi-stage frequency 9 Multi-stage frequency 10 Multi-stage frequency 11 Multi-stage frequency 12 Multi-stage frequency 13 Multi-stage frequency 14 Multi-stage frequency 15 When P13.00=1, the multi-stage reference means multi-stage closed loop reference. The multi-stage closed loop reference selection in Table 6-8 can be realized by selecting the ON/OFF combination of the multi-stage closed loop terminals 1~4.
Page 155 Multi-stag Multi-stag Multi-stag Multi-stag e closed e closed e closed e closed Multi-stage closed loop loop loop loop loop reference selection terminal 4 terminal 3 terminal 2 terminal 1 Multi-stage closed loop reference 11 Multi-stage closed loop reference 12 Multi-stage closed loop reference 13 Multi-stage closed loop reference 14...
Page 156 14: Frequency increase command (UP) 15: Frequency decrease command (DN) The remote control of the frequency increase or decrease is realized through control terminals rather than operation panel. It is enabled when P02.04=1 (common operation) or P02.07=2 (as auxiliary frequency). The acceleration/ deceleration rate is set by P09.09.
Page 157 28: Clearing the PLC stop memory If the drive stops under the PLC running mode, when this function terminal is enabled, the PLC running stage, running time, and running frequency information stored in the PLC upon the drive stop will be cleared.
Page 158 Simple PLC Process closed loop PID Multi-speed 37: Switching main reference frequency to AI The main set frequency channel will be switched to AI reference when this function terminal is enabled. The choosing of AI shall be set in the AI function of Group P10.01. The frequency reference channel will be restored when this function terminal is disabled.
Page 159 It is only valid for the digital auxiliary frequency (P02.07=1, 2,3). When this function terminal is enabled, the auxiliary frequency reference will be cleared, and the set frequency is completely determined by the main reference. 46: Pre-magnetizing command terminal (Reserved) 47: Speed control and torque control switching terminal This function shall be used together with the speed/torque control function code of Group P06.00.
Page 160 57~59: Reserved 60: Emergency stop When this terminal function is enabled, the drive will stop as soon as possible. It will automatically determine the deceleration time according to the load torque to stop as soon as possible. 61~73: Reserved 74: PID reference pulse input It is only valid for the input terminal X6.
Page 161 Fig. 6-28 Three-wire running mode 1 Where: SB1: Stop key SB2: FWD key SB3: REV key Xi is the multifunctional input terminal of X1~X6. Its corresponding terminal function shall be defined as function No. 5 “three-wire running control”. 3: Three-wire running mode 2 Running direction selection...
Page 162 Note When terminal X6 is used as the common digital input terminal, this filtering time (P09.10) is enabled; when terminal X6 is used as the high-speed pulse input terminal, the filtering time is P09.14. P09.11 Maximum input pulse frequency of X6 0.1~100.0kHz (10.0 kHz) When the digital input terminal X6 is used as the high-speed pulse input terminal, the maximum input pulse frequency can be determined by this function code.
Page 163 The pulse input has a central point. The frequency at the central point is half of the maximum pulse input frequency P09.11. When the input pulse frequency is lower than the central point frequency, the corresponding values are positive. 2: Central point mode 2 The pulse input has a central point.
Page 164 When 0 is selected for the BIT, it indicates the positive logic. When 1 is selected, it indicates the negative logic. For example: If you want to set X1~X4 as positive logic and set X5~X6 as negative logic, make the following setting: Set the logic state of X4~X1 as 0000, the corresponding hexadecimal value as 0, and then the LED will display 0 at the unit place.
Page 165 Item Function Item Function Under-torque output 25~33 Reserved Drive FWD/REV indication Motor 1 and 2 indication Bus card ON/OFF signal 37~42 Reserved PID feedback loss PID feedback exceeding limit 0: Drive in running state signal (RUN) When the drive is running, the relevant indication signal is output.. 1: Frequency arrival signal (FAR) Refer to the function description of P09.24.
Page 166 When the current stage of simple PLC running is completed, the relevant indication signal will be output (single pulse signal, width: 500ms). 12: PLC cycle completion indication When the simple PLC completes an operation cycle, the relevant indication signal will be output (single pulse signal, width: 500ms).
Page 167 When the feedback signal is less than the detection value set by P14.26 and its time exceeds the time set by P14.27, then PID feedback is considered as “loss”. 44: PID feedback exceeding limit When the feedback signal is greater than the detection value set by P14.28 and its time exceeds the time set by P14.29, then PID feedback is considered as “exceeding limit”.
Page 168 P09.27 FDT 2 level upper limit P09.28~P09.26 (25.00) P09.28 FDT 2 level lower limit 0.00~P02.17 (24.00Hz) P09.25~P09.26 are the complementary definitions of the No.3 function in P09.21, and P09.27~P09.28 are the complementary definitions of the No.4 function in P09.21. They have the same use method. The following will take P09.25~P09.26 for example.
Page 169 Item Function Indication range Host device expansion 0~65535 function 1 Reserved None Percentage of bus card 0~65535 P09.30 Maximum output pulse frequency 0.1~50.0kHz (10.0 kHz) This function code defines the maximum output frequency when the terminal Y1 is used as the DO high-speed pulse output terminal.
Page 170: Analog Input/Output Terminal Parameters (Group P10)
The pulse output has a central point. The frequency at the central point is half of the maximum pulse output frequency P09.30. When the output pulse frequency is higher than the central point frequency, the corresponding values are positive. Fig. 6-39 Central point mode 2 P09.32 Pulse output filtering time 0.00~10.00s (0.05s)
Page 171 The Fig. 6-41 shows the correspondence when the inflection point is set on the curve determined by the maximum and minimum reference point. If the inflection point is set on other positions, it has other flexible correspondence, please refer to the example below for details. Fig.
Page 172 AI function selections are as follows: 0: No function 1: Main set frequency reference (bipolar) When this function is selected, it shall be used together with the P02.04 function code setting. When used as the voltage input, and analog input polarity will affect the drive running direction: When the analog input is positive, the drive will be in forward operation, otherwise, it will be in reverse running.
Page 173 6: Torque limit value 1 When this function is selected, it shall be used together with the P05.13 function code setting. The analog input meaning is the same as torque offset. 7: Torque limit value 2 When this function is selected, it shall be used together with the P05.14 function code setting. The analog input meaning is the same as torque offset.
Page 174 The drive output voltage V Note The output voltage offset function is enabled only under the V/F mode. D: Output voltage When this function is enabled under V/F mode, the drive output voltage V and the output frequency are mutually independent. The drive output voltage is not restricted by the V/F feature curve of Group P07, but is determined by the analog input signal, as shown in Fig.6-45.
Page 175 Fig. 6-46 Analog and pulse curve selection P10.05 is used for selecting the analog and pulse curve. P10.06 Maximum reference of line 1 P10.08~100.0% (100.0%) P10.07 Actual value corresponding to the maximum reference of line 1 0.0~300.0% (100.0%) P10.08 Minimum reference of line 1 0.0%~P10.06 (0.0%) P10.09 Actual value corresponding to the minimum reference of line 1...
Page 176 2 ） Input signal 1kHz~20kHz; 3 ） The 1kHz, 8kHz, 12kHz and 20kHz input signal shall correspond to the set frequency of 50Hz, 10Hz, 40Hz and 5Hz respectively. Based on the above requirements, the parameter settings are as below: P02.04=4, adopting the terminal PULSE reference as the main frequency reference channel. 1 ）...
Page 177 20mA 20mA Fig. 6-48 Analog output type selection This function code is used for selecting the analog output range of AO1. For the voltage or current output, it shall be determined by the jumper on the terminal board. For details, please refer to the description of the terminal board.
Page 178 Item Function Indication range Reserved Output torque (bipolar) -300 ~ 300% of the rated torque of the motor Output torque current (bipolar) -300 ~ 300% of the rated torque of the motor Torque offset (bipolar) -300 ~ 300% of the rated torque of the motor Negative maximum output frequency ~ Motor rotating speed (bipolar) maximum output frequency...
Page 179: Auxiliary Function Parameters (Group P11)
Value after adjustment ( V ) P10.25 = 50% P10.25 = 0% Value before adjustment( V ) Fig. 6-50 Relation curve between analog output and zero offset Note The output gain and zero offset correction function codes will real time affect the analog output during the change.
Page 180 Frequency Time Fig. 6-51 Linear acceleration/deceleration 1: S curve acceleration/deceleration The output frequency is decreased or increased according to the S curve, as shown in Fig. 6-52. Fig. 6-52 S curve acceleration/deceleration The speed setting value is in the S curve status at the beginning of the acceleration and when it reaches the desired speed, and at the beginning of the deceleration and when it reaches the desired speed.
Page 181 (P02.15) to 0Hz, as t shown in Fig. 6-51. MV300 series drive has four acceleration/deceleration time settings in total. The acceleration/deceleration time (1~4) of the drive in the operation can be selected by different combinations of control terminals.
Page 182 2. In the acceleration section, the fast acceleration in start segment and end segment can be adjusted at your disposal. 3. In the deceleration section, the fast deceleration in start segment and end segment can be adjusted at your disposal. The schematic diagram of adjusting the S curve is as shown in Fig.
Page 183 Fig. 6-55 Schematic diagram for switching between acceleration/deceleration time 1 and 2 As shown in Fig. 6-55, for accelerating the motor 1, operate at the acceleration time 1, as the A curve × shown in Fig. 6-55 and the acceleration time .
Page 184 As shown in Fig. 6-56, t1 is the jog acceleration and deceleration time (P11.16) of actual running. t2 is the jog time and t3 is the jog interval time (P11.17). f is the jog running frequency (P11.18). The jog acceleration and deceleration time t of actual running is determined by the following equation: ×...
Page 185: Advanced Function Parameters (Group P12)
6.12 Advanced function parameters (Group P12) P12.00 Reserved P12.01 Energy-saving running 0~1 (0) 0: Disabled 1: Enabled In the no-load or light load process of the motor, detect the load current and properly adjust output voltage to achieve energy-saving effect. Note This function is especially suitable for the fan and pump load.
Page 186 Fig. 6-58 PWM mode optimization selection Unit place: Enable the over-modulation This function determines whether to enable the over-modulation function controlled by V/F. The over-modulation function is always enabled in the vector control mode. 0: Disabled Disable the over-modulation function controlled by V/F. 1: Enabled Enable the over-modulation function controlled by V/F.
Page 187 The current loop proportional gain and current loop integral time are automatically calculated in identifying the motor parameter. The PI values are saved to P12.05 and P12.06 respectively after identifying the parameter. P12.05 Current loop proportional gain ACR-P 1~5000 (1000) P12.06 Current loopintegral time ACR-I 0.5~100.0ms (8.0)
Page 188: Multi-Stage Reference And Simple Plc Parameters (Group P13)
The fan keeps running after the drive is powered up. 2: Fun operates based on command When the drive will operate normally upon receiving the running command, the fan will also operate. When the drive stops running, so does the fan. P12.15~P12.27 Reserved 6.13 Multi-stage reference and simple PLC parameters (Group P13)
Page 189 P13.16 Simple PLC running mode selection 0~1122H (0000) Simple PLC function is a multi-speed generator, the drive can automatically change its running frequency and direction according to its running time, to meet the requirements of the process. This function was previously completed by PLC (programmable logic controller), but now it can be realized by the drive itself, as shown in Fig.
Page 190 Unit place: PLC running mode selection 0: Stop after single cycle As shown in Fig. 6-61, the drive will be stop automatically after completing one cycle, and it can start up only after giving another running command. Fig. 6-61 Stop mode of PLC after single cycle 1: Hold the end value after single cycle As shown in Fig.
Page 191 Fig. 6-63 PLC continuous cycle mode Tens place: The restart mode selection for interrupted PLC running 0: Restart from the first section If it is stopped (caused by stopping command, fault or power down) during operation, it will operate from the first section after restarting.
Page 192 Fig. 6-65 PLC start mode 2 Hundreds place: Storage selection of PLC status parameter upon power down 0: No storage The PLC running status will not be saved upon power down, and it will restart from the first section after power on.
Page 193 P13.23 Stage 4 setting 0~327H (000) P13.24 Stage 4 running time 0.0~6500.0 (20.0) P13.25 Stage 5 setting 0~327H (000) P13.26 Stage 5 running time 0.0~6500.0 (20.0) P13.27 Stage 6 setting 0~327H (000) P13.28 Stage 6 running time 0.0~6500.0 (20.0) P13.29 Stage 7 setting 0~327H (000) P13.30...
Page 194: Process Pid Parameters (Group P14)
Hundreds Tens Unit Frequency setting: 0: Select the multi-stage frequency 1: Keyboard reference ∧ ∨ 2: Terminal UP/DOWN reference 3: Reserved 4: AI reference 5: Reserved 6: PID 7: Reserved Running direction setting: 0:FWD 1: REV 2:Determined by running command Acceleration/deceleration time setting 0: Acceleration/deceleration time1 1: Acceleration/deceleration time2...
Page 195 Proportional control (P) The control quantity in proportion to the deviation cannot only rely on P control to eliminate steady-state error. Integral control (I) The control quantity in proportion to the deviation integral value can eliminate steady-state error, but it cannot control sharp change.
Page 196 Fig. 6-67 PID control block diagram...
Page 197 P14.00 Reference channel selection 0~5 (0) 0: P14.02 digital reference 1: AI1 analog reference 2: AI2 analog reference 3: Reserved 4: Terminal PULSE reference 5: Serial port communication reference P14.01 Feedback channel selection 0~7 (0) 0: AI1 analog feedback 1: AI2 analog feedback 2: Reserved 3: Terminal PULSE feedback 4: AI1 + AI2...
Page 198 Kd is used for improving the response performance of the system, but too large configuration may easily cause oscillation. P14.08 Integral separation threshold 0.0~100.0%(30.0%) The integral calculation will be stopped when the deviation of the reference and feedback is greater than the setting.
Page 199 Fig. 6-68 Schematic diagram of deviation limit P14.14 PID upper limit channel 0~2(0) 0: PID upper limit given by P14.16 digital 1: PID upper limit given by AI1 analog 2: PID upper limit given by AI2 analog P14.15 PID lower limit channel 0~2(0) 0: PID lower limit given by P14.17 digital 1: PID lower limit given by AI1 analog...
Page 200 Adjust the gain coefficient of the ultimate output, ultimate PID output = PID output x PID output gain. It has an obvious effect when it is used for adjusting the compensation dosage. P14.22 REV selection of PID output 0~1 (1) 0: When PID output is negative, force PID output to be set as 0.
Page 201: Communication Parameters (Group P15)
P14.27 PID feedback lost detection time 0.0~25.0s (1.0s) When the feedback signal is less than the detection value set by P14.26 and its time exceeds the time set by P14.27, then PID feedback is considered as “loss”. P14.28 PID feedback exceeding limit detection value 0.0~100.0%(100.0%) P14.29 PID feedback exceeding limit detection time...
Page 202: Keyboard Display Setting Parameters (Group P16)
P15.02 Local address 0~247 (5) This function code is used for marking the address of drive. Note : 0 is the broadcast address. If it is set as the broadcast address, it can only receive and execute the broadcast command from the host device, and will not respond to the host device. P15.03 Communication timeout detection time 0.0~1000.0s (0.0s)
Page 203 Fig. 6-72 Setting of LED display parameter selection 2 when running For the displayed terminal status, the terminal status adopts the defined value of the LED digital diode through the multi-functional input terminal X1~X6 status (bit0~bit5 corresponding to X1~X6) and output terminal Y1, Y2, RO1 (bit12~bit14 corresponding to Y1, Y2, RO1) to indicate the status of each function terminal.
Page 204: Fieldbus Option Parameters (Group P40)
In the stop parameter display state, the parameters for display can be switched in turn by pressing the shift key 》 . P16.03 Line speed coefficient 0.1~999.9% (1.0%) This function code is used for correcting the line speed proportion display error, and it has no influence on the actual rotating speed.
Page 205: Protection And Fault Parameters (Group P97)
P40.01 Option hardware version 0.00~99.99 (1.00) P40.02 Option software version 0.00~99.99 (1.00) P40.01 and P40.02 are used for representing the hardware version and software version of the option respectively. P40.03~P40.21 Reserved P40.22 Option reset selection 0~1 (0) Option reset action selection 0: Do not reset or reset successfully 1: Enable option reset P40.23...
Page 206 Thousands Hundreds Tens Uint Action upon communication fault : 0 : Activate protection and coast to stop 1 : Alarm and keep running 2 : Alarm and stop in the stop mode (only in serial port control mode) 3 : Alarm and stop in the stop mode (in all control modes) Action upon contactor abnormality : 0 : Activate protection and coast to stop...
Page 207 Fig. 6-76 Fault protection and alarm property setting 3 In certain abnormal situations, the drive can shield faults and stop actions and keep operating by setting P97.00, P97.01 and P97.02. The operation panel at that moment will display an alarm AL.XXX (XXX represents the alarm code. For details, please refer to Chapter 7 Troubleshooting).
Page 208 Thousands Hundreds Tens Unit Action upon motor overload protection: 0 : No action 1 : Action (with low-speed compensation) 2 : Action (without low-speed compensation) Overload pre-alarm detection selection : 0 : Always detect 1 : Detect only at constant speed Overload pre-alarm action selection : 0 : Alarm and keep running 1 : Activate protection and coast to stop...
Page 209 This function code defines the current threshold for the overload pre-alarm action. The setting value is the percentage relative to the rated current (refer to the thousands place of P97.03). P97.05 Overload pre-alarm detection time 0.0~60.0s (5.0s) This function code defines the output overload pre-alarm signal after the time that the drive output current is greater than the overload detection level (P97.04) exceeds the setting time.
Page 210 P97.07 = 1 means the over-voltage stall action is enabled. During the deceleration operation of the drive, due to the load inertia, the actual dropping rate of the motor rotating speed may be lower than the dropping rate of the output frequency. At this time the motor will feed back the power supply to the drive, causing the DC bus voltage of the drive to increase.
Page 211 The auto current limiting function is always enabled in the acceleration/deceleration state, and whether it will be enabled in constant speed operation depends on the auto current limiting action selection (P97.09). P97.09=0 indicates that the auto current limiting is disabled in the case of constant speed operation. P97.09 = 1 indicates that the auto current limiting is enabled in the case of constant speed operation.
Page 212: Drive Parameters (Group P98)
P97.20 Operation frequency at the 3rd fault 0.00~3000.00Hz(0.00Hz) P97.21 Drive operation status at the 3rd fault 0~FFFFH(0000) P97.22 Inveter module temperature at the 3rd fault 0.0~150.0 ℃ (0.0 ℃ ) P97.23 Rectifier module temperature at the 3rd fault 0.0~150.0 ℃ (0.0 ℃ ) P97.18 ~ P97.23 are the third (last) fault records.
Page 213 P98.03 Rated capacity 0~999.9kVA P98.04 Rated voltage 0~999V P98.05 Rated current 0~999.9A The above are read-only parameters. Record the basic information of the drive. The values for P98.03~P98.05 are set by the manufacturer. P98.06 Drive series selection This function code is used for setting the voltage level of the drive. 0: 220V 1: 380V 2: 400V...
Page 214: Chapter 7 Troubleshooting
Chapter 7 Troubleshooting 7.1 Displaying exception and solutions All possible fault types for MV300 are summarized as shown in table 7-1. The number of the fault code is 36. Before consulting the service department, the user can perform self-check according to the hints of the table and record the fault symptoms in detail.
Page 215 Fault code Fault type Possible fault cause Solutions When the vector control functions, the See the ASR parameter setting of Group P05 ASR parameter setting is improper. Constant The acceleration/deceleration time is too Lengthen the acceleration/deceleration time speed short. appropriately Er.oU3 over-voltage of Abnormal input voltage...
Page 216 Fault code Fault type Possible fault cause Solutions over-temperatu The fan is damaged. Replace the fan The motor parameters are incorrect. Perform the parameter auto-tuning of the motor The load is too large. Adopt the drive with higher power Reduce the DC braking current and lengthen the The DC braking amount is too large.
Page 217 Fault code Fault type Possible fault cause Solutions The grid voltage is too low. Check the grid voltage Replace the contactor of the main circuit, seek for The contactor is damaged. service support Abnormal Er.rLy The power-up buffer resistance is Replace the buffer resistance, seek for service contactor damaged.
Page 218 Fault code Fault type Possible fault cause Solutions The nameplate parameters of the motor Set the parameters properly according to the motor are incorrect. nameplate When reverse running is prohibited, reverse rotating auto-tuning is Cancel the reverse running prohibition Poor performed.
Page 219 Fault code Fault type Possible fault cause Solutions The motor operates at low frequency Add a large fan for the motor to dissipate heat and large load for a long time. Abnormal control circuit Seek for service support Abnormal AI Er.AIF The input analog is out of the range and analog input...
Page 220 Alarm Alarm type Possible alarm causes Solutions code Reduce the DC braking current and lengthen the The DC braking amount is too large. braking time When instantaneous stop happens, Set the start mode P08.00 as the speed tracking restart the rotating motor restart function The acceleration time is too short.
Page 221: Operation Exception And Solutions
Alarm Alarm type Possible alarm causes Solutions code The parameters for feedback loss are Modify the P14.26 setting set improperly. Closed loop AL.FbL Feedback wire-break Rewiring feedback loss The reference of closed loop feedback See the P14.01 setting and increase the feedback value is too low.
Page 222 Symptoms Conditions Possible causes Solutions The keys of the operation panel are Replace the operation panel or seek for service damaged. support Can not be modified in The function code can not be Modify it in the stop status running status modified in running status.
Page 223 Symptoms Conditions Possible causes Solutions There is something wrong with the Check the skip frequency setting skip frequency setting. The closed loop output is negative when the reverse running Check the P14.22 and the P08.18 setting is prohibited. Enable the “disabling forward run” Check the terminal function setting terminal during forward run process Enable the “disabling reverse...
Page 224 Symptoms Conditions Possible causes Solutions When the Since the thyristor or the contactor drive is The thyristor or the is not closed, when the drive started, the contactor disconnects runs with large load, the DC bus Run the drive after the thyristor or the contactor report -LU- and the drive load is voltage of the main circuit will drop;...
Page 225: Chapter 8 Maintenance
Chapter 8 Maintenance The influence of the ambient temperature, humidity, dust and vibration as well as the aging devices in the drive may cause the drive faults. Thus, it is necessary to carry out daily and periodical maintenance. 8.1 Daily maintenance Note Before inspection and maintenance, please confirm the following items first.
Page 226: Periodical Maintenance
2. Within the rated range and three-phase 2. Output voltage 2. Voltmeter equilibrium 3. Internal 3. The difference with the ambient 3. Thermometer temperature temperature is less than 35℃ 8.2 Periodical maintenance The users may carry out periodical maintenance of the drive once every 3 or 6 months according to the operating environment.
Page 227: Storage Of Drive
Table 8-2 Component life Part name Service Life 30,000~40,000 hours Electrolytic capacitor 40,000~50,000 hours Relay About 100,000 times Users can determine the replacement time according to the running time. 1. Cooling fan Possible damage causes: wear of the bearing, aging of the vanes. Judgment standard: whether there is crack on the blade and whether there is any abnormal vibration or noise.
Page 228: Appendix 1 Modbus Communication Protocol
Appendix 1 Modbus Communication Protocol 1. Networking mode The drive has two networking modes: single host/multiple slaves mode and single host/single slave mode. 2. Interface mode RS485 interface: asynchronous and half-duplex. Default: 1-8-N-2, 9600bps, RTU. Refer to Group P15 function code for the parameter setting. 3.
Page 229 Modbus adopts the ”Big Endian” encoding mode, which sends the high bytes first and then sends the low bytes. 1. RTU mode In RTU mode, the larger value between the function code setting value and the Modbus internal convention value shall be selected as the idle time between frames. The minimum idle time value between frames under the Modbus internal convention is as follows: the idle time that the frame head and frame trail pass the bus shall not be less than that of 3.5 bytes to define the frame.
Page 230: Protocol Functions
In the above table, the check code is the LRC checksum, which is equivalent to the complement of “05+06+02+01+0x0F+0xA0”. Response frame: Data Frame Slave Command Check Frame trail head address code code Register address Written content Character ASCII With the function codes, the drive can set different response delays to meet the specific application demands of various host stations.
Page 231 High byte of the address High byte of the address Drive parameter group Drive parameter group mapped mapped Group P00 0x00 Group P13 0x0D Group P01 0x01 Group P14 0x0E Group P02 0x02 Group P15 0x0F Group P03 0x03 Group P16 0x10 Group P05 0x05...
Page 232 If the operation fails, it will return to the abnormal response frame. The abnormal response frame includes the error code and exception code. In which, the error code = (command code + 0x80), and the exception code indicates the error cause. Abnormal response frame format: Application-layer protocol data unit Data length (number of bytes)
Page 233 If the operation is successful, the response frame is as follows: Application-layer protocol data unit Data length (number of bytes) Value or range Command code 0x06 Register address 0x0000~0xFFFF Register content 0x0000~0xFFFF If the operation is failed, it will return to the abnormal response frame and its format is as shown above. 3.
Page 234 Sub-command Data (request) Data (response) Function code slave with fault. Setting the slave not to respond to invalid or wrong 0x0000 0x0000 commands. 0x0030 Setting the slave to respond to invalid and wrong 0x0001 0x0001 commands. 4. Change multiple function code parameters and control parameters of the drive, and the parameter values will not be saved after power off.
Page 235 The application-layer protocol data units are as follows. Request format: Application-layer protocol data unit Data length (number of bytes) Value or range Command code 0x42 Sub-command code 0x0000~0x0008 Data Depends on the drive type If the operation is successful, the response frame is as follows: Application-layer protocol data unit Data length (number of bytes) Value or range...
Page 236 Sub-command Data (request) Data (response) Function code low byte is “00” Read the current status parameter Current status parameter index (please refer to the definition of 0x0006 0x6500 index the status parameter group for its meaning) Read the next status parameter Next status parameter 0x0007 0x6500...
Page 237: Control Parameters And Status Parameters Of Drive
Features Value Meaning No unit The unit is Hz The unit is A The unit is V BIT8~BIT6 Display unit The unit is r/min The unit is line speed (m/s) The unit is percentage (%) Others Reserved BIT9 Reserved Restore to Restore BIT10 leave-factory...
Page 238 Register Save upon Parameter name Remarks address power off 0x6400 Control word 1 Refer to its bit definition list Main reference frequency; the main reference channel uses serial communication, and whether 0x6401 Main reference it can be saved is dependent on the setting of P02.06 0x6402 Running frequency reference...
Page 239 Register Save upon Parameter name Remarks address power off Expansion virtual digital output BIT0~BIT1:ExRO1、ExRO2，when P26.09/ 0x6411 terminal (reserved) P26.11=17, the corresponding terminal is enabled 0x6412 Control word 2 Refer to its bit definition list Note 1. When reading the control parameter, the value returned is the value written in the previous communication; 2.
Page 240 Value Function Remarks The “jog reversely” is disabled The fault reset is valid The select bit for the validity of the BIT9 fault reset of the host device The fault reset is disabled BIT15~BIT10 Reserved Note 1. The control command (control words 1 and 2) of the host device is valid only when the value of “running command channel selection”...
Page 241 Note The overall word 2 is valid only when its BIT0 is valid. 2. Status parameters Register Parameter name Remarks address 0x6500 Status word 1 of drive 0x6501 Actual running value of current main reference Current running frequency 0x6502 Slave model 0x6503 Drive series number 0x6504...
Page 242 Register Parameter name Remarks address 0x651C Setting acceleration time 1 0x651D Setting deceleration time 1 Command reference channel (the same as function code 0x651E P02.02) 0x651F Status word 2 of drive Frequency reference channel (the same as function code 0x6520 P02.04) 0x6521 Accumulating length (reserved)
Page 243 Value Function Remarks Drive runs reversely BIT2 Drive runs forward Enable serial port reference BIT3 Disable serial port reference Meet the main setting BIT4 Does not meet the main setting If the value is 1, it means there is a fault. fault BIT5 Please refer to BIT15~BIT8 of status word 1...
Page 244: Expand Access Mode
The standard protocol only supports the register of 16 bits, and the above description is also based on the register of 16 bits. The parameters of MV300 series drive include both 16 bits (single character) and 32 bits (double characters). So, the data of both lengths shall be considered when reading/writing the parameters.
Page 245 Start register address Access mode Remarks BIT15 BIT14~BIT0 Actual address of the start parameter 16-bit Actual address of the start parameter 32-bit When accessing to the parameters in the 32-bit mode, as the unit of the register of the request frame is 16 bits and each parameter of 32 bits needs two registers of 16 bits, the “number of registers”...
Page 246 Value Bytes Description 16-bit mode 32-bit mode 15~16 Value P01.04 17~18 19~20 Check code If the operation is failed, it will return to the abnormal response frame and its format is as shown above. There are two types of drive parameters: one type of parameters adopts the decimal system and the other type is the variables adopting the hexadecimal system.
Page 247 The values returned in the reading operation are as shown in the following table: Register Access mode Value returned Description address 16-bit 0x1194 The actual value is returned. P01.01 The 16 high bits are filled with 0 and the actual value 32-bit 0x00001194 is returned.
Page 248 for the length expansion are as follows: expanding according to the highest bit of the 16-bit parameter value to be written, if the highest bit is 1, the 16 high bits will be filled with 0xFFFF, otherwise, they will be filled with 0x0000.
Page 249: Cautions
17~18 19~20 Value P02.03 21~22 23~24 Check code If the operation is successful, the response frame is as follows: Value Bytes Description 16-bit mode 32-bit mode 0x05 0x05 Slave address 0x10/0x43 0x10/0x43 Command code Start address (in the 32-bit mode, the highest byte of the 0x0200 0x8200 start address is 1)
Page 250 the storage address of the first fault, this parameter and its following parameters cannot be changed normally, but the parameters before it can be written normally and the error message will be returned. 2. For some special function codes, 0x06 and 0x41 have the same function, and 0x10 and 0x43 have the same function.
Page 251: Crc Verification
4) The operation of the host device and that of the operation panel on the user password are independent, even if the operation panel has decrypted already, the host device still need to decrypt to access to the function code parameters, and vice versa. 5) When the host device gets the authority to access to parameters, it will read the user password and return to “0000”...
Page 252 0x000A,0xC1CA,0x81CB,0x400B,0x01C9,0xC009,0x8008,0x41C8,0x01D8,0xC018,0x8019,0x41D9, 0x001B,0xC1DB,0x81DA,0x401A,0x001E,0xC1DE,0x81DF,0x401F,0x01DD,0xC01D,0x801C,0x41DC, 0x0014,0xC1D4,0x81D5,0x4015,0x01D7,0xC017,0x8016,0x41D6,0x01D2,0xC012,0x8013,0x41D3, 0x0011,0xC1D1,0x81D0,0x4010,0x01F0,0xC030,0x8031,0x41F1,0x0033,0xC1F3,0x81F2,0x4032, 0x0036,0xC1F6,0x81F7,0x4037,0x01F5,0xC035,0x8034,0x41F4,0x003C,0xC1FC,0x81FD,0x403D, 0x01FF,0xC03F,0x803E,0x41FE,0x01FA,0xC03A,0x803B,0x41FB,0x0039,0xC1F9,0x81F8,0x4038, 0x0028,0xC1E8,0x81E9,0x4029,0x01EB,0xC02B,0x802A,0x41EA,0x01EE,0xC02E,0x802F,0x41EF, 0x002D,0xC1ED,0x81EC,0x402C,0x01E4,0xC024,0x8025,0x41E5,0x0027,0xC1E7,0x81E6,0x4026, 0x0022,0xC1E2,0x81E3,0x4023,0x01E1,0xC021,0x8020,0x41E0,0x01A0,0xC060,0x8061,0x41A1, 0x0063,0xC1A3,0x81A2,0x4062,0x0066,0xC1A6,0x81A7,0x4067,0x01A5,0xC065,0x8064,0x41A4, 0x006C,0xC1AC,0x81AD,0x406D,0x01AF,0xC06F,0x806E,0x41AE,0x01AA,0xC06A,0x806B,0x41AB, 0x0069,0xC1A9,0x81A8,0x4068,0x0078,0xC1B8,0x81B9,0x4079,0x01BB,0xC07B,0x807A,0x41BA, 0x01BE,0xC07E,0x807F,0x41BF,0x007D,0xC1BD,0x81BC,0x407C,0x01B4,0xC074,0x8075,0x41B5, 0x0077,0xC1B7,0x81B6,0x4076,0x0072,0xC1B2,0x81B3,0x4073,0x01B1,0xC071,0x8070,0x41B0, 0x0050,0xC190,0x8191,0x4051,0x0193,0xC053,0x8052,0x4192,0x0196,0xC056,0x8057,0x4197, 0x0055,0xC195,0x8194,0x4054,0x019C,0xC05C,0x805D,0x419D,0x005F,0xC19F,0x819E,0x405E, 0x005A,0xC19A,0x819B,0x405B,0x0199,0xC059,0x8058,0x4198,0x0188,0xC048,0x8049,0x4189, 0x004B,0xC18B,0x818A,0x404A,0x004E,0xC18E,0x818F,0x404F,0x018D,0xC04D,0x804C,0x418C, 0x0044,0xC184,0x8185,0x4045,0x0187,0xC047,0x8046,0x4186,0x0182,0xC042,0x8043,0x4183, 0x0041,0xC181,0x8180,0x4040} If the CRC checksum of each byte to be sent is computed on line, it will take a longer time, but it can save the program space occupied by the table.
Page 253: Application Example
else crc_result=crc_result>>1; return （ crc_result= （（ crc_result&0xff ） <<8 ） | （ crc_result>>8 ）） ; 10. Application example To start No.5 drive and make it rotate forward with a speed of 50.00Hz (expressed as 5000 internally), the command is as follows: Register content Data Addre...
Page 254 Number of registers or Data Register Register Address Command code Check code frame address content number of bytes read Request 0x05 0x03 0x6501 0x0001 None 0xCA82 Response 0x05 0x03 None 0x02 0x1388 0x44D2 Read the running frequency of No.5 drive and the response running frequency is 50.00Hz (32 bits mode): Number of registers or Data Register...
Page 255: Scaling Of Drive Parameters
Read the deceleration time 1 (i.e. P02.14 ） ) of No.5 drive and the response deceleration time is 6.0s (16 bits mode): Number of registers or Data Register Register Address Command code Check code frame address content number of bytes read Request 0x05 0x03...
Page 256: Appendix 2 Braking Components
Appendix 2 Braking Components 1. Definition of external braking unit model Attached Fig. 2-1 Definition of brake unit model Note : ED10% in the above figure means the brake utilization rate is 10%. 2. External brake module configuration (configuration for working conditions of 10% braking utilization rate and 760V braking action voltage) Attached Table 2-1 External brake module configuration Motor rated...
Page 257 520W/100Ω 780W/75Ω 1040W/50Ω 1560W/40Ω 18.5 4800W/32Ω 4800W/27.2Ω 6000W/20Ω 9600W/16Ω 9600W/13.6Ω 6000W/20Ω*2 9600W/13.6Ω*2 Note 1. For the drive with internal brake units, the user only needs to configure external braking resistor when the dynamic braking is required. The recommended resistor specification for 22kW drive is 3kW, 20Ω. 2.
Page 258 Brake Resistor Brake Resistor Brake Resistor 380VAC Input Drive Attached Fig.2-3 Connection diagram of the drive and braking component 4) Functions of brake unit · Brake unit action voltage adjustment; · Heatsink overheat protection; · Fault display and fault relay output indication; ·...
Page 259: Appendix 3 Warranty And Service
(such as unsatisfactory performance and function), please contact your product agent or Shenzhen Megmeet Drive Technology Co., Ltd.. 2. In case of any abnormality, please timely contact your product provider or Shenzhen Megmeet Drive Technology Co., Ltd. for help.
Page 260 Shenzhen Megmeet Drive Technology Co., Ltd. Shenzhen Megmeet Drive Technology Co., Ltd. Drive Warranty Bill Drive Warranty Bill Customer company: Customer company: Detailed address: Detailed address: Postal Code: Contact: Postal Code: Contact : Tel: Fax: Tel: Fax: Machine model: Machine model: Power: Machine No.:...
Page 261: Parameter Record Table
Parameter record table...
Page 262: Wring Diagram
Wring diagram 20mA 20mA...

Megmeet MV300 Series User Manual

Chapter 1 Introduction of MV300 Series Drive

Chapter 2 Drive Installation

Chapter 3 Wiring of Drive

Chapter 4 Quick Operation Guide for Drive

Chapter 5 Parameter List

Chapter 6 Parameter Description

Chapter 7 Troubleshooting

Chapter 8 Maintenance

Appendix 1 Modbus Communication Protocol

Appendix 2 Braking Components

Appendix 3 Warranty and Service

Quick Links

Need help?

Questions and answers

Related Manuals for Megmeet MV300 Series

Summary of Contents for Megmeet MV300 Series

This manual is also suitable for:

Table of Contents
