Summary of Contents for OSD NETWORKS OSD2183P
-
Page 1: Index
Operator Manual OSD2183P / PW Micro 10/100/1000Base-T to 100/1000Base-X Media Converter with IEEE802.3af/at/bt & PoH PoE Source... -
Page 3: Table Of Contents
FIGURE 10: DUAL SIGNATURE PD ..................16 TABLE 1: TECHNICAL SPECIFICATIONS ................6 TABLE 2: POWER CONNECTION ..................11 TABLE 3: LED FUNCTION....................... 12 TABLE 4: 3-WAY DIP SWITCH SETTINGS ................13 TABLE 5: POE MODE ......................14 PAGE 3 10120801 OSD2183P / PW Operator Manual... -
Page 4: Technical Summary
IP cameras, Wireless Access Points, microwave links and VOIP phones to be easily connected to your network. With a compact design the OSD2183P can easily be mounted inside a network enclosure or a Smart Pole using the DIN rail or wall mounting brackets provided. Optionally, the OSD2183PW version can be powered from a 12VDC to 57VDC supply. -
Page 5: Typical System Design
1.2 TYPICAL SYSTEM DESIGN Figure 1 below indicates a possible set-up for an OSD2183P/PW system. FIGURE 1: TYPICAL SYSTEM DESIGN PAGE 5 10120801 OSD2183P / PW Operator Manual... -
Page 6: Technical Specifications
Relative Humidity 0 to 95% non-condensing Dimensions 90W x 88D x 49H mm Weight 380g Warranty Warranty Period 5 years MTBF (Ground Benign 472,000 hours for OSD2183P Environment, 30ºC) 424,000 hours for OSD2183PW PAGE 6 10120801 OSD2183P / PW Operator Manual... - Page 7 PAGE 7 10120801 OSD2183P / PW Operator Manual...
-
Page 8: Front / Rear Panel Layout
Front Panel: One fixed copper port for 10/100/1000Base-T, one SFP port and a 2-way terminal block power connector Rear Panel: 3-way DIP switch. Front Panel RJ45 Port Power Input SFP Port Rear Panel 3-Way DIP switch Earth Screw FIGURE 2: PANEL LAYOUT PAGE 8 10120801 OSD2183P / PW Operator Manual... -
Page 9: Installation And Operation
2 INSTALLATION AND OPERATION 2.1 INTRODUCTION This section outlines the methods required to install and operate the OSD2183P/PW successfully. It should be studied carefully if damage to the equipment or poor results are to be avoided. This equipment has been fully tested prior to dispatch and is ready for immediate operation. -
Page 10: Drawings And Dimensions
2.2.2 DRAWINGS AND DIMENSIONS The OSD2183P/PW is designed to be wall mounted onto a DIN-Rail (35mm top hat) fixture or by using 4 x M4 captivated screws (DIN Rail mount requires removal and flanges repositioned – see below). The unit dimensions (excluding connectors, SFPs, etc) is shown in below. -
Page 11: Location
2.2.3 LOCATION As with any electrical device, the OSD2183P/PW should be placed where the switch will not be subjected to extreme temperatures, humidity, or electromagnetic interference. Specifically, the site selected should meet the following requirements: • The ambient temperature should be between -40°C to 75°C. -
Page 12: Led Indicators
See Table 5 Notes: When PoE LED is on it indicates that the unit is supplying power to the PSE Invalid device – No PoE output Activity indicates traffic for copper port PAGE 12 10120801 OSD2183P / PW Operator Manual... -
Page 13: Controls
2.2.6 CONTROLS The OSD2183P/PW has a number of control functions: a 3-Way DIP Switch and a PoE Mode push button. 3-Way DIP Switch PoE Mode Push Button FIGURE 6: CONTROLS FIGURE 7: 3-WAY DIP SWITCH TABLE 4: 3-WAY DIP SWITCH SETTINGS... - Page 14 4 Pair power output, 90W Max, High Inrush PoH Mode Current Mode off 2 Pair power output, 30W Max, High Inrush BT Mode Current Mode off Custom There are no customized settings - this mode Mode will be skipped. PAGE 14 10120801 OSD2183P / PW Operator Manual...
-
Page 15: Fitting Sfp Connectors
Removing SFP – Remove fiber connector or RJ45 plug. Pull the SFP lever down to unlock SFP from housing. Using the lever, gently pull the SFP out. Fiber SFP Inserting Removing Copper SFP Inserting Removing FIGURE 8: FITTING/REMOVING SFP CONNECTORS PAGE 15 10120801 OSD2183P / PW Operator Manual... -
Page 16: Single/Dual Signature Pd Operation
2.3 SINGLE/DUAL SIGNATURE PD OPERATION The OSD2183P/PW supports single, dual or either single/dual signature PD by automatically detecting the user PD signature. 2.3.1 SINGLE SIGNATURE PD A “single signature PD” shares the same detection signature, classification signature, and maintains power signature between both pair sets. -
Page 17: Operation
2.4 OPERATION When using the OSD2183P/PW for the first time, check that the unit is in good condition with no visible damage. Upon power up check that the indicators illuminate accordingly on power up (see Table 3). 2.4.1 CONNECTIONS For RJ45 connection use Category 5 (CAT5) or higher. Length should be no more than 100 meters. -
Page 18: Maintenance
3 MAINTENANCE 3.1 INTRODUCTION The following section outlines the fault-finding procedure for the OSD2183P/PW modems. Please take note of the following: ▲ Personnel without appropriate training should not attempt any maintenance except that outlined below. ▲ If further maintenance is attempted you are warned that every care should be taken to... -
Page 19: Warranty
All modifications are to be carried out by OSD Technicians. Warranty is void if unauthorized removal and/or tampering with serial number and/or repair labels is evident. PAGE 19 10120801 OSD2183P / PW Operator Manual... - Page 20 Optical Systems Design Pty. Ltd. 7/1 Vuko Pl. Warriewood 2102 P.O. Box 891 Mona Vale N.S.W. Australia 2103 Telephone: +61 2 9913 8540 Facsimile: +61 2 9913 8735 Email: sales@osd.com.au Web Site: www.osd.com.au Printed in Australia...
