See Water Radar Pro RPRO-2000 Installation And Operation Manual

Radar Pro™ Level Sensor
See Water's Radar Pro™ Level Sensor is a high-precision ultra-low-power
millimeter-wave radar level sensor developed and designed for high
measurement accuracy, high sensitivity, easy integration, and superior
interaction performance.
The Radar Pro™ uses non-contact technology, eliminating the need for physical
contact with the measured substance, preventing contamination and minimizing
maintenance requirements. This sensor can be used in various industries and
applications, including liquids, distance, and harsh environments—such as
chemical, oil and gas, wastewater treatment, and food processing.
Model Range: ft(m)
RPRO-2000
Features:
• High precision ±2mm
• No-contact measurement
• Resistant to condensation, rain, and corrosion
• Operation is unaffected by temperature, pressure or vacuum; provides
accurate readings under all environmental conditions
• High sensitivity, lightweight, easy integration
• Two-year limited warranty
Dimensions:
Cable Length: ft(m)
32ft (10m)
∅76
G1
G1-1/2
Radar Pro™ Level Sensor
Installation and Operation Manual
Electrical Properties:
•
•
•
•
•
Mechanical Properties:
•
•
•
•
Operating Condition:
•
50ft (15m)
22220 Opportunity Way, Suite 101 • Riverside, CA 92518
Page 1-2
RPRO-2000
Power Requirement: 12-30 VDC
Output Signal: 4-20 mA DC, two wire
Scanning Frequency: 76-81 GHz
Electrical Connection: Wire pigtail
Accuracy: ±2 mm
Working Pressure: -1~3 bar
Material: Polycarbonate & Fiberglass
Wetted Materials: PVDF
Protection Class: IP67
Operating Temperature: -40 - 85°C
(-104 - 185°F)
www.seewaterinc.com
951.487.8073 • 888.733.9283 • info@seewaterinc.com
IM 5311 REV. 12/23
