PS1215 User’s Manual Table Of Contents INTRODUCTION ....................8 PS1215 P ................8 OWER UPPLY PS1215 ................9 AT A LANCE ..................10 ECHNICAL SAFETY ......................11 ................... 11 NJURY RECAUTIONS ....................... 11 AUTION ..................... 12 NPUT ATINGS ....................12 IRCUITS ..........
Page 4
PS1215 User’s Manual Document Revisions Document Revision Date Comment October 24 2014 First Release October 29 2014 Manual graphics changed December 2 2014 Updated the pin-out of the Output DC connector to match the names used in the datasheet January 18...
Page 5
PS1215 User’s Manual Safety information - Warnings CAEN ELS will repair or replace any product within the guarantee period if the Guarantor declares that the product is defective due to workmanship or materials and has not been caused by mishandling, negligence on behalf of the User, accident or any abnormal conditions or operations.
Page 6
PS1215 User’s Manual Read over the instruction manual carefully before using the instrument. The following precautions should be strictly observed before using the PS1215: • Do not use this product in any manner not WARNING specified by the manufacturer. The protective features of this product may be impaired if it is used in a manner not specified in this manual.
Page 7
PS1215 User’s Manual The following table shows the general environmental requirements for a correct operation of the instrument: Environmental Conditions Requirements Operating Temperature 0°C to 50°C Operating Humidity 30% to 85% RH (non-condensing) Storage Temperature -10°C to 60°C Storage Humidity...
CAEN ELS DC Current Transducers (DCCT): • CT-100-C, CT-100V-C • CT-150-C, CT-150V-C • CT-200, CT-200V • CT-300, CT-300V • CT-400, CT-400V • CT-600, CT-600V • CT-1000, CT-1000V All the above cited devices, combined with a PS1215 low-noise voltage power supply, guarantee their rated specifications.
LEDs monitor Figure 1: overall view of a PS1215 power supply The PS1215 is an isolated bipolar power supply, with a 3-pole output connector, specifically designed to supply DC Current Transducers (DCCT). The AC Power Line input is placed on the left side of the box while the output connectors on the right side;...
PS1215 User’s Manual 1.3 Technical Data The PS1215 power supply has an output voltage accuracy of ±3% on both its positive and negative outputs. Maximum peak-to-peak voltage noise measured at the device output terminals is rated at 4 mV. This value is measured over a 1 MHz bandwidth using a LeCroy MSO 44MXs-B, 400MHz, 5GS/s with AC Coupling at full load.
PS1215 User’s Manual 2. Safety 2.1 Injury Precautions Prior to shipment this system was inspected and found free of mechanical or electrical defects. Upon unpacking of the system, inspect for any damage, which may have occurred in transit. The inspection should confirm that there is no exterior damage to the system such as broken connectors.
For input voltage and frequency rating of the module see . For safety reasons, the Table 4: PS1215 power supply main specifications mains supply voltage fluctuations should not exceed above voltage range. 2.4 Live Circuits No internal adjustment or component replacement is allowed to non-CAEN ELS s.r.l.
The AC Line Input connector is in a standard IEC Male Socket as shown in Figure 3 The PS1215 power supply is designed for universal AC input voltage range since it can operate with voltage from 90V to 260V and input frequency from 47 to 63 Hz.
(CT-xx00V). The other side is terminated with one connector that fits in the output DC connector of the PS1215 and one BNC connector for the reading of the output voltage that is fed from the DCCT Voltage Output. The SUB-D pin-...
PS1215 User’s Manual Y Cable CT-I (Red: I , Black: I return, Yellow: shield) Figure 7: 3.3 Status LED On a lateral side of the power supply, two LEDs turn off whenever the +15V or -15V voltages are not correctly regulated on the output cable.
PS1215 User’s Manual 3.4 Fixing On the bottom side of the PS1215 four threaded M3×4mm holes can be used for fixing the power supply. These are indicated in the following Figure 9 Figure 9: Threaded holes position on the PS1215 bottom 3.5 Mounting position...
Page 18
PS1215 User’s Manual Figure 10: Ceiling mounting NOT allowed Figure 11: Lateral mounting (ten ventilation holes faced to the top) NOT allowed...
PS1215 User’s Manual 4. Technical Specifications Technical Specifications for the PS1215 linear power supplies are presented in the following Table 4. Technical Specifications PS1215 Output Positive Voltage (±3%) +15 V Output Negative Voltage (±3%) -15 V Maximum Output Power 27 W...
PS1215 User’s Manual 6. Output Current Derating Current [%] Input Voltage [V] Figure 13: Output current versus input voltage at 60 Hz Current [%] Ambient T. [°C] Figure 14: Output current versus ambient temperature...
PS1215 User’s Manual 7. Ordering Codes The PS1215 power supply can be ordered in three different codes, differing by the output cabling. Two versions are dedicated to operation together with the CAEN ELS current transducer series. Model Ordering Code Description...
