Parts & Operations Manual
Manuel de pièces et d'opérations
DOODLE SCRUB/DOODLE MOP
Surface Preparation Machines / Machines de préparation de surface
EBG-9 & EBG-9-BAT-PLUS / EBG-16 & EBG-16-BAT-PLUS
Serial Number / Numéro de série :
Date of Purchase / Date d'achat :
Distributor Name / Nom du distributeur :
Date of Issue / Date d'émission : 2024-02
Advertisement
Related Manuals for Square Scrub EBG-9
Summary of Contents for Square Scrub EBG-9
- Page 1 Manuel de pièces et d’opérations DOODLE SCRUB/DOODLE MOP Surface Preparation Machines / Machines de préparation de surface EBG-9 & EBG-9-BAT-PLUS / EBG-16 & EBG-16-BAT-PLUS Serial Number / Numéro de série : Date of Purchase / Date d’achat : Distributor Name / Nom du distributeur :...
- Page 2 Save these instructions. Please read all installation, operation, & safety instructions before using this machine. You are now the proud owner of an EBG-Series machine. This machine is a product of Square Scrub. It is made of fine materials and will give you many years of satisfactory service if maintained and used according to the guidelines in this owner’s manual.
- Page 3 When the floor scrubber is provided with a rechargeable battery pack, it is intended to be used with Charger marked with Square scrub model number 051145. Placed on the front of the charger. The charger employs double insulation in lieu of grounding.
-
Page 4: Weekly Preventative Maintenance
Maintenance Schedule Prior to using (daily) • Check AC power cord. Do NOT operate equipment if AC power cord is cut, frayed, or if ground is missing. • Check grip face and driver pad. Inspect for wear/debris. After use (daily) •... -
Page 5: Liability Statement
Liability Statement This Square Scrub machine has been built to the highest industry standards. Please not and heed the WARNING and CAUTION labels that have been placed on the machine and in this manual for your safety. PLEASE DO NOT ATTEMPT TO OPERATE OR REPAIR THIS EQUIPMENT WITHOUT ADEQUATE TRAINING. - Page 6 Warning: This appliance is not suitable for picking up hazardous dust. Transport To transport this machine, the following procedure is advised: • Unplug machine from power source. • Always leave a pad on the machine to protect the grip face from damage in transport and storage. •...
- Page 7 Plugging in the Charger Parts & Operations Manual Doodle Scrub / Doodle Mop...
- Page 8 The grip face has a very tough life! The Industrial Velcro one-piece grip face material on this Square Scrub machine is the very best we have ever tested! With proper care and attention, it will do a great deal of work for you. Our machine drives a huge amount of energy into the grip face and then the driver pad and then to the floor: Some pads are more durable and long lasting than others.
- Page 9 Test out different pads: Test several different pads for yourself in your buildings with your floors and your chemicals. We have tested lots of pads from everyone we know of that makes pads. Some pads are better than others. Please try some options if you are unhappy with how well the pads you are using hold up.
-
Page 10: Warranty
General This Square Scrub EBG-9 Doodle Scrub Floor Preparation Machine is warranted to be free from defects in materials and workmanship under normal use and service for a period of one year on machine handle and base when operated and maintained in accordance with Square Scrub Maintenance and Operating Instructions. - Page 11 Labor to repair the unit is also included for the first 90 days from date of original purchase. Unit must be returned to Square Scrub for all repairs other than the handle switch. End user must ship the unit to Square Scrub at their expense. Unit will be repaired or replaced and returned to the end user or the authorized Square Scrub dealer by normal ground shipping method at Square Scrub’s expense.
- Page 12 BASE PLATE SS 051603V GRIP FACE � � � ® SS 051180 TRIGGER � LJ SS 051104 EBG-9 SWITCH � LJ � SS 0101Z HANDLE GRIP � INCLUDED IN KIT POWER CORD � €) : � • INCLUDED IN KIT...
- Page 13 INCLUDED IN KIT BOTTOM ISOLATOR BOLT (4) SS 051634 BASE PLATE SS 051603V GRIP FACE SS 051180 TRIGGER SS 051104 EBG-9 SWITCH SS 0101Z HANDLE GRIP INCLUDED IN KIT POWER CORD INCLUDED IN KIT HANDLE INCLUDED IN KIT CRUSH WASHER...
- Page 14 SS 051145 CHARGER SS 051152 BASE CLIP Item N. Part N. Description 1, 2, 3, 4, 5, BATTERY POWERED EBG-9 SS 05166BAT 6, 7 COVER REPLACEMENT KIT 8, 9, 12 SS 051106BAT MOTOR REPLACEMENT KIT 7, 10, 11, 12, 13, 14, 15, 16,...
- Page 15 CRUSH WASHER SS 051634 BASE PLATE SS 051603V GRIP FACE SS 051145 CHARGER SS 051180 TRIGGER SS 051104 EBG-9 SWITCH SS 0101Z HANDLE GRIP CHARGING PORT SS 051140 BATTERY PACK/HANDLE SS 051152 BASE CLIP HANDLE CORD SS 051153 3 WIRE CONNECTOR (2) Parts &...
- Page 16 Doodle Scrub Pad Information 28054 Parts / Pièces Blue Tile & Grout Pad I SS P0SllTGBV I Sold Individually Our Tile & Grout Pad is best used on grouted tile floors, but can be used very effectively on terrazo, poured non-slip, concrete and other uneven floors.
- Page 17 Doodle Mop Pad Information 28054 Parts / Pièces Disposable Microfiber Pad I SS 0516DMF I Sold - 240/case The Doodle Mop disposable microfiber pad helps increase soil removal and reduce cross contamination. Xtreme Sponge I SS P0516XTR I Sold - 5/case Use the Xtreme Sponge to remove scuff marks on VCT or bathroom tile.
- Page 18 Notes...
- Page 19 Notes...
- Page 21 Dustbane Customer Support Support à la clientèle Dustbane Mailing Address Adresse postale 1000 Last Mile Dr. 1000, promenade Last Mile Ottawa, ON K1G 6Y1 Ottawa, ON K1G 6Y1 Canada Canada Phone Téléphone 1-800-387-8226 1-800-387-8226 Email Courriel General Inquiries: info@dustbane.ca Demandes générales : info@dustbane.ca Technical Inquiries: techsupport@dustbane.ca Demandes techniques : techsupport@dustbane.ca Website...
