Summary of Contents for Direct Wicker PA-3256B
- Page 1 PA-3256B INSTRUCTION MANUAL...
- Page 3 Assembly Instructions Caution:You must read this before proceed Back panel Bottom nameplate Front panel Left side panel Right side panel Bottom panel Top panel...
- Page 4 Assembly Instructions Caution:You must read this before proceed Gas Lift cylinder 2pcs 20pcs M6*35mm 6pcs M6*15mm 26pcs Washers 6pcs Isolation column 2pcs Allen wrench Spanner 6pcs Clamping knob Liner...
- Page 5 Assembly Instructions ① Note: Please do not tighten all the screws before the products is fully installed, for it may cause assembling issues. Velcro on top Back screw hole Side screw hole Screw holes J H M 1. Use Allen wrenches (M), screws (H) and washers (J) to connect the four side panels (A) (B) (C) (D) 2.
- Page 6 Assembly Instructions ② 1. Turn the products upside down 2. Place the back panel (E) above the side panels 3. Use Allen wrench (M), screws (H) and washers (J) to connect the side panels and the bottom panel 4. Install the clamping knob (P) on the support foot...
- Page 7 Assembly Instructions ③ 1. Turn the product upside down again so that the top is facing up 2. Use Allen wrench (M), screws (I) and washers (J) to connect the top panel (F) and the back panel (A). The Isolation column (K) needs to be placed between the connecting pieces of the back panel and the top panel (F) to avoid friction.
- Page 8 Assembly Instructions ④ Zip up Velcro 1. Open the liner (Q) and stick the Velcro near the zipper to the Velcro on all side panels. 2. Zip up the storage box to make it waterproof 3. When you need to take items, liner top can be stick to the Velcro on the top panel for easy putting in and out.
- Page 10 Your Home Our Passion For more information,please visit our website: www.directwicker.com...
