- Page 1 Operating Manual Neptun SCS1 dry Sole Cleaning System...
-
Page 2: Important - Read First
Intended use Please observe without fail that whilst the roller brushes HEUTE® Neptun SCS1 dry sole cleaning systems are used for the are used, no shoelaces, tongues and straps on the sides external cleaning of closed shoes and boots by means of electrically of the shoes/boots will touch the ground. -
Page 3: Table Of Contents
Declaration of conformity Installation and commissioning General information The manufacturer herewith confirms the following machine of type Transport and installation Neptun SCS1 dry complies with the directives listed below: Electrical connection - Machinery directive (2006/42/EG) Precaution while commissioning Authorized representative Steffen Moersch, Operation same address as manufacturer. -
Page 4: Overview
Overview Control Cabinet: Dim.: 430 x 330 x 200 mm Power supply 400 V, 3-phase + grounding 50Hz P=0,75 kW PVC hose to protect electrical supply line (length = 2m) Reflection sensor barrier Reflector Reflection sensor barrier Reflector Step grid Adjustable feet Inspection flap, Reflective sensor barrier... - Page 5 1437 mm 1411 mm 1400 mm...
-
Page 6: Installation And Commissioning
Installation and commissioning Operation General information Cleaning principle Please follow below mentioned advices to protect the stainless steel - Cleaning of shoes and boots with horizontal roller brushes (Fig. 1).. housing of the sole cleaning machine during storing, before installa- tion, commissioning and use. -
Page 7: Service And Maintenance
With decreasing dirt, extend the cleaning intervals accordingly. Fig. 4 Maintenance The Neptun SCS1 dry is considered to be very low-maintenance and reliable. However, there are some components, which will wear out after a long period of service and will reduce the cleaning quality - e.g. -
Page 8: Cleaning Of Surfaces
Cleaning of surfaces Disassembly of brush axle The micro-blast stainless steel surface is made of stainless steel Remove roller brush (see chapter Service and maintenance > type 304. Change of roller brushes) Remove Allen screw on the front longitudinal side of the brush During the cleaning work, the following has to be noted, and body with suitable tool (Fig. -
Page 9: Access To Gear Motors
Troble shooting Access to gear motors only by qualified personell Remove the side cover by opening both clamping brackets – no tools Machine does not work required (Fig. 9). Power supply interrupted or malfunction of Fig. 9 components Please consult qualified specialists The motor is blocked or runs rough Foreign objects are inside running parts Immediately disconnect the machine from the... -
Page 10: Wiring Diagrams
Wiring diagrams Neptun SCS1 dry Wiring diagram I 3 * 400 Volt Clamping strips and connections Disconnect switch 03-2 03-2 03-20 Adjustment Adjustment to A1 to A1 0.37 Kw 0.37 Kw Brush 1 Brush 2 Power Wiring diagram II... - Page 11 Configuration clamping strips Configuration control cabinet POWER ON F1 F2 internal clamping strips clamping strips 1-3...
-
Page 12: Part Drawings
Part drawings Neptun SCS1 dry Item Article No. 06800501 Coupling – stainless steel 06800502 Axle of the roller brush, diam. 180x180 mm, stainless steel 304 06800503 Roller brush nylon, diam. 180 mm, length 1000 mm, fibre 1 mm 06800504 Axial bearing... - Page 13 Höhscheider Weg 37 · 42699 Solingen · Germany Phone: +49(0)212-380 310 · Fax: +49(0)212-380 31-49 E-mail: info@heute-gmbh.de · Internet: www.heute-gmbh.de...
