User Manual
HDMI EXTENDER
KVM Point to Point Extender
14.99.3042
Important Safety Notice
1. Please distinguish the transmitter and receiver before installation.
2. Do not disassemble the machine to repair the product during the working process to avoid
electric shock.
3. Please cut off the power before installation. Live installation may damage the equipment.
4. Do not expose the devices to rain, moisture and liquid.
5. Use a 5V/1A DC adapter only. Make sure the specification matched if using 3rd party DC
adapters.
Advertisement
Table of Contents
Summary of Contents for SECOMP 14.99.3042
- Page 1 User Manual HDMI EXTENDER KVM Point to Point Extender 14.99.3042 Important Safety Notice 1. Please distinguish the transmitter and receiver before installation. 2. Do not disassemble the machine to repair the product during the working process to avoid electric shock.
- Page 2 Introduction This HDMI Extender includes a transmitter unit and a receiver unit, allows the HDMI signal to be transmitted up to 70 meters at 1080p resolution using a Cat6/6A/7 network cable. It adopts a point-to-point connection configuration, supports KVM remote control and management and 3.5 mm stereo audio output.
- Page 3 III. Installation Requirements 1. HDMI source device (compute graphics card, DVD, PS4, HD monitoring equipment etc.) 2. HDMI display device like SDTV, HDTV, projector with HDMI port. 3.UTP/STP Cat6/6A/7 cable, follow standard IEEE-568B, It is recommended to select a network cable with less loss and crosstalk.
- Page 4 2. Receiver (RX) DC5V input Connect to the 5V1A DC power adapter. 3.5mm L/R out Connect headphones or power amplifiers to output stereo audio. HDMI output Connect to a HDMI display device. Reset button Press the button to restart the device. Rj45 signal input Input modulated HDMI signal.
- Page 5 V. Installation Procedures 1. Connection Note: When using the 3.5mm stereo audio jack, please switch the audio output format of the signal source to PCM format. The network cable should follow the standard of IEEE-568B. It is recommended to select a network cable with less loss and crosstalk.
- Page 6 VI. FAQ Q: There is no output on screen when all connections are correct? A: 1) Please make sure the HDMI cables support the resolution of the output signal from the source device. 2) Please check and make sure the network cable inserts to the RJ45 port well. 3) Restart the transmitter or receiver by pressing the reset button.
- Page 7 Output cable length ≤8m(AWG24) Transmission Cat6/6A/7 ≤70m Distance Implementation of the standard: IEC61000-4-2 Electrostatic protection of the Protection Level 1a Contact discharge level 4 (8KV) whole machine 1b Air discharge level 4 (15KV) Working temperature -20~60℃ Operating Storage temperature -30~70℃ Environment Humidity (no condensation) 0～90%RH...
