SLPU-2P2U1S-WL-BK
ELECTRICAL
With 2 × USB-A charger ports (Rated 5Vdc, 3.1A)
USB charger built-in open circuit, short circuit, over load protection
2 × TR AC Receptacles, rated 15A，125Vac
Wireless 3-way switching, controls the rear receptacle
for LED light fixtures
10' 14 AWG x 3C power cord with 5-15P plug
8" rear/side exiting cord with receptacle
MECHANICAL
Recessed mounting
CERTIFICATION
FCC compliant and UL Listed
WARRANTY
5 Years
SELF Electronics USA Corporation
3264 Saturn Ct,Peachtree Corners,GA 30092
Dimmension(inches/mm)
7-12/16"(197)
Installation
Cut hole size:
7.40"×2.09"(188mm×53mm)
*Thickness of the board:8~35mm
Tel: +1-770-248-9023
POWER UNIT
2-1/8"(54)
salesus@self-electronics.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the SLPU-2P2U1S-WL-BK and is the answer not in the manual?

Questions and answers

Related Manuals for SELF SLPU-2P2U1S-WL-BK

Summary of Contents for SELF SLPU-2P2U1S-WL-BK

  • Page 1 10' 14 AWG x 3C power cord with 5-15P plug 8" rear/side exiting cord with receptacle MECHANICAL Recessed mounting Installation CERTIFICATION Cut hole size: 7.40"×2.09"(188mm×53mm) FCC compliant and UL Listed WARRANTY 5 Years *Thickness of the board:8~35mm SELF Electronics USA Corporation 3264 Saturn Ct,Peachtree Corners,GA 30092 Tel: +1-770-248-9023 salesus@self-electronics.com...
  • Page 2 Unpair for 3-way version power units Power on Press power unit’s start button more than 6 seconds, until the blue indicator button starts flashing then stays ON, means the unpairing is successful. flashing SELF Electronics USA Corporation 3264 Saturn Ct,Peachtree Corners,GA 30092 Tel: +1-770-248-9023 salesus@self-electronics.com...
  • Page 3 10' 14 AWG x 3C power cord with 5-15P plug 8" rear/side exiting cord with receptacle MECHANICAL Recessed mounting Installation CERTIFICATION Cut hole size: 7.40"×2.09"(188mm×53mm) FCC compliant and UL Listed WARRANTY 5 Years *Thickness of the board:8~35mm SELF Electronics USA Corporation 3264 Saturn Ct,Peachtree Corners,GA 30092 Tel: +1-770-248-9023 salesus@self-electronics.com...
  • Page 4 Unpair for 3-way version power units Power on Press power unit’s start button more than 6 seconds, until the blue indicator button starts flashing then stays ON, means the unpairing is successful. flashing SELF Electronics USA Corporation 3264 Saturn Ct,Peachtree Corners,GA 30092 Tel: +1-770-248-9023 salesus@self-electronics.com...
  • Page 5 10' 14 AWG x 3C power cord with 5-15P plug 8" rear/side exiting cord with receptacle MECHANICAL Recessed mounting Installation CERTIFICATION Cut hole size: 7.40"×2.09"(188mm×53mm) FCC compliant and UL Listed WARRANTY 5 Years *Thickness of the board:8~35mm SELF Electronics USA Corporation 3264 Saturn Ct,Peachtree Corners,GA 30092 Tel: +1-770-248-9023 salesus@self-electronics.com...
  • Page 6 Unpair for 3-way version power units Power on Press power unit’s start button more than 6 seconds, until the blue indicator button starts flashing then stays ON, means the unpairing is successful. flashing SELF Electronics USA Corporation 3264 Saturn Ct,Peachtree Corners,GA 30092 Tel: +1-770-248-9023 salesus@self-electronics.com...
